EcoAlly 2020 Catalogue

LIGHTING SOLUTIONS CATALOGUE 2020/21

www.ecoally.co.uk

PRODUCT INDEX
PANEL SERIES

SIRIUS SQUARE SIRIUS RECTANGULAR CAPELLA ALTAIR RIGEL TRITON
p.13 p.14 p.16 p.17 p.18 p.19

TITANIA RHEA CASSIOPEIA CASSIOPEIA
p.21 p.21 p.21 p.21

DOWNLIGHT SERIES

CALLISTO DRACO??? LYNX POLARIS VEGA ALYA
p.23 p.24 p.26 p.27 p.28 p.29

HYPERION CALLIPSO INDI INDI ACCESSORIES TAU CETI LUMI PLUGIN
p.31 p.33
p.34 p.34 p.35 p.36

NIMBUS NYX STRATUS I STRATUS II STRATUS III
p.38 p.39 p.40 p.41 p.42

TRACKLIGHT SERIES

JUPITER JUNO
p.44 p.45

2 www.ecoally.co.uk

CHANDELIER SERIES

HARMONIA LOTIS BELLATRIX II BELLATRIX III ELECTRA ATLANTA
p.47 p.47 p.48 p.48 p.49 p.49

DAPHNE CLIO SEMELE DANAE THALIA ARTEMIS
p.50 p.50 p.52 p.52 p.53 p.53

AGLAIA HEBE
p.54 p.54

BULKHEAD SERIES

LYRA ARCHE MAIA LUNA LUNA
p.56 p.57 p.58 p.60 p.60

VAPOUR PROOF SERIES

PERSEUS ORION AQUARIUS PHOENIX ROSALIND SOROS
p.62 p.63 p.65 p.66 p.67 p.68

ASTREA PORTIA
p.69 p.70

01628 876 076 3

PRODUCT INDEX
HIGHBAY SERIES

TYPHOON CYCLONE METEOR AIRGLOW ALPHA TAURI
p.73 p.73 p.76 p.77 p.79

ARCHITECTURAL SERIES

GALEXIA CIRCLE ARIEL HEXA OBERON PLEIADES CELESTE GALEXIA X
p.81 p.83 p.84 p.86 p.88 p.91

CLEAN ROOM SERIES

AQUILA AURORA NEBULA AURIGA ANDROMEDA
p.93 p.94 p.95 p.96 p.97

EXTERIOR LIGHTING SERIES

PEGASUS ARCTUR NEPTUN PLUTO SATURN POLLUX
p.99 p.100 p.100 p.101 p.102 p.103

ODIN ALDEBARAN VESTA BIANCA PERSEPHONA ARCAS
p.104 p.105 p.106 p.107 p.108 p.109

XENA ZETA ZETA ZETA CENTAURI PROXIMA
p.109 p.111 p.111 p.112 p.113 p.114

2 www.ecoally.co.uk

ALCOR CASTOR ASTEROPE ASTEROPE
p.115 p.116 p.116 p.111

STRIPLIGHT SERIES

SIGMA KAPPA OMEGA
p.117 p.118 p.119

SPECIALIST LED LAMPS

2G11 PUSH FIT LED

p.120 REPLACEMENT

EMERGENCY SERIES p.121

GAMMA CYGNI GAMMA DELTA
p.123 p.124 p.125 p.125

01628 876 076 3



INTRODUCTION

We are a family-run LED lighting consultancy, who were
established in 2012 in the Middle East through two exclusive
partner channels.

Since then our journey has expanded to operate in the UK for
the last three years, where Research and Development (R&D)
team are based, and are committed towards the innovation,
introduction and improvements of all our LED lighting solutions
for our clients across the globe.

We embrace emerging technologies and the benefits they
bring to the market, to provide products with low energy, low
maintenance, outstanding performance and return on investment.

Furthermore, our design experts are on hand to support our
clients through the planning of projects, by providing DIALux
design and calculations. We have found this to be key in the
successful understanding, planning and delivery of projects for
our clients.

Having access to advanced manufacturing facilities in China and
KSA, and additionally partners in the UK and Europe; Ecoally are
able to offer our prospective client’s a wide range of LED lighting
solutions, which can be tailored to the required specifications.

01628 876 076 5



OUR CORE VALUES

Our business comprises of three core areas; Research and and Development, Foundation and Education.

Around 20% of our workforce is dedicated to Research and Development. These are qualified electrical engineers
who understand not just lighting technology, but how it integrates with the other technologies in our lives.

At present, our teams in UK, Middle East and China are working on exciting new developments in:

• Automating Bluetooth controls • Organic LED (OLED) • and much more
• Daylight harvesting • Smart lighting/control

Education write-up

Our Foundation provides LED lighting solutions helping to enhance our daily environments by saving money
through energy efficiences which can be reinvested further into other projects. As part of our commitment to
corporate social responsibility we are dedicated to giving back to communities across the UK and beyond.

01628 876 076 5

PANEL SERIES

Our LED Panel range consists of a wide range of options that enables you to replace or retrofit existing fluorescent modular
ceiling lights and enjoy significant savings of electricity costs and reducing carbon footprint of the environment.
LED panels are a popular choice for office spaces, retail units, schools and hospitals as they can seamlessly integrate into their
respective environments.
The product range contains various dimensions and flexible solutions to fit various types of ceiling grids. LED panels can be
installed as a recessed, surface mounted or suspended option, however, must adhere to specific regulations, such as a TPa
rated product required where the LED panel forms as part of the ceiling.
We also have three-hour emergency lighting options available for areas such as escape routes, which are compulsory in the
event of a power failure.

6 www.ecoally.co.uk

SIRIUS SQUARE

FEATURES IP40 TP(a) 5
High efficient utilization of lighting
YEARS
Three ways of luminaire mounting: In suspended modular WTY
ceiling, directly on ceiling or on slings.
Power supply: Electronic (standard), DIM DALI (optional)
Available accessories: adaptive frame for ceiling mounting,
set of slings
TP(a) available

Type of optics: PLX (opalised diffuser PMMA), Micro-PRM
(micro prismatic diffuser)
Housing made of aluminium
Emergency option available
Standard UGR: ≤22, UGR: <19 available on request

TECHNICAL INFORMATION

Model number Power CCT Lumen Lumen Dimensions
per Watt Output (L*H)

EA-P20-WS3030N-WW 20W 3000K 89 1780lm 295*295mm

EA-P20-WS3030N-NW 20W 4000K 90 1800lm 295*295mm

EA-P20-WS3030N-CW 20W 6500K 92 1840lm 295*295mm

EA-P40-WS6060N-WW 40W 3000K 95 3200lm 595*595mm

EA-P40-WS6060N-NW 40W 4000K 100 3250lm 595*595mm

EA-P40-WS6060N-CW 40W 6500K 100 3280lm 595*595mm

SPECIFICATION 3000-65000K
80
CCT: 50,000hrs
CRI: 220-240V, 50/60Hz
Lifespan: 120o
Voltages: ≤0.96
Beam angle:
Power factor:

Surface mount Slings mount Installation in suspended modular ceiling
01628 876 076
7

SIRIUS RECTANGULAR

FEATURES IP40 TP(a) 5 CE
High efficient utilization of lighting
YEARS
Three ways of luminaire mounting: In suspended modular WTY
ceiling, directly on ceiling or on slings.
Power supply: Electronic (standard), DIM DALI (optional)
Available accessories: adaptive frame for ceiling mounting,
set of slings
TP(a) available
Opal diffuser
Housing made of aluminium
Emergency option available
Standard UGR: ≤22, UGR: <19 available on request

TECHNICAL INFORMATION

Model number Power CCT Lumen per Lumen Dimensions
(L*H)
Watt Output

EA-PL40W3012-WW 40W 3000K 95 3800lm 295*1195mm

EA-PL40W3012-NW 40W 4000K 100 4000lm 295*1195mm

EA-PL40W3012-CW 40W 6500K 100 4000lm 295*1195mm

EA-PL60W6012-WW 60W 3000K 95 5700lm 595*1195mm

EA-PL60W6012-NW 60W 4000K 100 6000lm 595*1195mm

EA-PL60W6012-CW 60W 6500K 100 6000lm 595*1195mm

SPECIFICATION 3000-65000K
80
CCT: 25,000hrs
CRI: 220-240V, 50/60Hz
Lifespan: 120o
Voltages: ≤0.96
Beam angle:
Power factor:

Surface mount Slings mount Installation in suspended modular ceiling
www.ecoally.co.uk
8

What are the Commercial Building Regulations for LED Panel Lights?

Building Regulations apply to new buildings, extensions to existing buildings and change of use which may affect
the compliance of the building. Building Regulations Part B – Fire Safety, require that where the luminaire forms
part of the internal ceiling lining of the building, it must restrict the spread of fire over their surfaces.

Panel Lights that comply with Building Regulation BS 5266, which specifically relates to Panel diffusers, LED
Panel Lights with TP(a) and TP(b) flammability-rated diffusers can be installed with confidence. A diffuser with no
flammability rating can melt in the event of a fire, causing combustion on surfaces and risking the safety of the
occupants in a building.

TP(a) flammability-rated diffusers

Panel Lights with TP(a) rated diffusers have a slower burn time as the diffuser material self-extinguishes, with any
flame or afterglow lasting five seconds or less once the flame is removed. There is no restriction to the extent of
use of Panel Lights with TP(a) rated diffusers, so they can be installed in areas that require minimal spacing be-
tween each Panel, such as fire exit routes.

TP(b) flammability-rated diffusers

Panels with TP(b) rated diffusers can be used in open areas. As the diffuser material combusts, the spread of the
flame will be no more than 50mm per minute. When the product is installed, there are limitations on total area
coverage and spacing between the Panel Lights.

01628 876 076 9

CAPELLA IP20 5 CE

FEATURES YEARS
Edgelit panel for direct recessed mount and surface or WTY
suspended mount with accessories
Two luminous flux range variants 2,800 or 3,800lm
For suspended ceiling grid measure of 600 and 625mm
LED system solution with outstanding system efficacy up to
101lm/W
Efficacy of the module up to 120lm/W
Small colour tolerance MacAdam 4
UGR: <19
Small luminous flux tolerances
Diffusor material standard article: PS,
diffusor material TPA article: PC
Light guide material: PMMA

TECHNICAL INFORMATION

Model number Power Lumen per Lumen per Lumen Lumen Min. forward Max. forward
consumption Watt at Watt at Output at Output at voltage at voltage at
tp=25o tp=45o tp=45oC tp=25oC
at tp=45o tp=25o tp=45o
112 33.0V 36.6V
EA-CPL-24-113 23.8W 113 2,700lm 2,660lm
118 33.0V 36.6V
EA-CPL-24-120 23.8W 120 2,860lm 2,800lm
108 35.7V 43.0V
EA-CPL-32-111 32.4W 111 3,620lm 3,550lm
EA-CPL-32-119 32.4W 119 117 35.7V 43.0V
3,870lm 3,800lm

*other versions available

SPECIFICATION 3000K, 4000K, 6500K
>80
CCT: 50,000hrs
CRI: 106o
Lifespan: 88o
Beam characteristic: ≤x
Beam characteristic TPA:
Power factor:

8 www.ecoally.co.uk

ALTAIR IP40 5 CE

FEATURES YEARS
Metal sheet body with electrostatic powder coated WTY
High efficiency satin PS opal diffuser
Uniform illumination
Operating temperature: -20oC - +45oC
Power supply: electronic (standard), DIM DALI (optional)
Comes in white, black or grey

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions (mm)
number per Watt Output A1 A2 L1 L2 H

EA-ALT-9 9W 116 1046lm 275 275 297 297 45
275 275 297 297 45
EA-ALT-13 13W 107 1399lm 575 575 595 595 65
575 575 595 595 65
EA-ALT-25 25W 120 2996lm 575 575 595 595 65
575 575 595 595 65
EA-ALT-32 32W 118 3765lm

EA-ALT-38 38W 115 4346lm

EA-ALT-52 52W 108 5616lm

SPECIFICATION 4000K
80
CCT: 50.000hrs
CRI: 220-240V, 50-60Hz
Lifespan: 120o
Voltages: >0.9
Beam angle:
Power factor:

01628 876 076 9

RIGEL IP20 5 CE

Lensed troffers are modern light fixtures used primarily in YEARS
office spaces, educational centres and hospitals, as well as other WTY
public buildings. They emit and diffuse, constant light, ideal for
workspaces. Due to the lensed louver technology, they provide a
non-reflexive relaxing light, with little to no reflection on computer
displays which may otherwise hinder work.

FEATURES
Luminaire mounting: recessed
Finish: grey and white
Housing made of aluminium alloy
Power supply: electronic (standard), DIM DALI (optional)
Operating temperature: -30 ~ +50°C

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions
number per Watt Output (L*W*H)

EA-RGT-21 21W 150 3165lm 600*600*120mm

SPECIFICATION 4000K
80
CCT: 50,000hrs
CRI: 100~240VAC/100~277VAC, 50~60Hz
Lifespan: 120o
Voltages: >0.94
Beam angle:
Power factor:

8 www.ecoally.co.uk

TRITON

FEATURES IP20 5 CE
Galvanized steel body, prepainted with polyester white resin
Diffusion lens 90° in PMMA YEARS
Dark light louver with double parabolic low luminance WTY
(60° 200 cd/mq cat2)

Incandescent wire resistance: 850°
Leaning recessed fixture for false ceilings panels with
visible structure 15/24mm.

Photobiological safety class: IEC 62471: Exempt group
Insulation class - class I
Ambient temperature (Ta): -25 / +45 °C
UGR: <19
IK08

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions
number per Watt Output A*B*C

EA-PL-24 24W 113 2708lm 595*90*595mm

EA-PL-37 37W 96 3568lm 595*90*595mm

* The flux may vary from -5/+5% compared to the real
* 3000K = -5,15% lm • 4000K = standard • 5000K = +1,46% lm

SPECIFICATION 4000K
>80
CCT: x
CRI: 230V, 50-60Hz
Lifespan: 120o
Voltages: x
Beam angle:
Power factor:

01628 876 076 9

RHEA IP40 5 CE
IP20
FEATURES YEARS
Protection against light gleaming WTY
Comfortable lighting for work station
Equipped with highly efficient LED light sources
Mounting in suspended modular ceilings with visible
type T24/A24 construction and in plasterboard ceilings
Adapting the luminaire to dofferent types of ceilings
upon request
Available accessories: adaptive frame or mounting
in suspended plasterboard ceiling
Operating temperature range: 5 ÷ 30oC
Type of optics: Micro-PRM (micro prismatic diffuser)
Power supply: electronic (standard) or DIM DALI (optional)

TECHNICAL INFORMATION

Model Power Lumen Lumen output Size
number per watt A*B*H
EA-RH-18 18W 144/150 2590/2708lm 596*596*55mm
EA-RH-27 27W 144/150 3885/4062lm 596*596*55mm
EA-RH-32 32W 138/144 4408/4608lm 596*596*55mm
EA-RH-47 47W 141/147 6612/6912lm 596*596*55mm
EA-RH-62 62W 142/149 8816/9216lm 1196*296*55mm

SPECIFICATION 3000/4000K
>80
CCT:
CRI: 60,000hrs L80/B10
Lifespan: x
Voltages: x
Beam angle: x
Power factor: 3
SDCM:

8 www.ecoally.co.uk

TITANIA

FEATURES IP20 5 CE

Dedicated to be mounted on suspended modular ceilings, cardboard YEARS
suspended ceilings (using adaptive frame), directly on the ceiling WTY
(using ceiling slab) or using slings

Equipped with highly efficient LED light sources
Light distribution available with modern lenses
Housing made of steel sheet
Standard colour of the luminary is white
Significant diversity of the value of luminous flux

Two variants of LED sources colour temperature are available: 3000K
(white warm) or 4000K (white neutral)

Thanks to its innovative optics, Titania perfectly fits to be used in
offices-especially to work with computers

TECHNICAL INFORMATION

Model Power Version Lumen Lumen output Size
number per watt
EA-TTN-1-R-27 27W 1R 142/148 3844/4000lm 1200*300mm
EA-TTN-1-S-27 27W 1R 142/148 3844/4000lm 600*600mm
EA-TTN-1-R-53 53W 1R 145/151 7687/8000lm 1200*300mm
EA-TTN-2-S-27 27W 2R 142/148 3844/4000lm 600*600mm
EA-TTN-2-R-53 53W 2R 145/151 7687/8000lm 600*300mm
EA-TTN-2-S-53 53W 2R 145/151 7687/8000lm 600*600mm
EA-TTN-3-S-51 51W 3R 113/118 5765/6000lm 600*600mm
EA-TTN-4-S-53 53W 4R 145/151 7687/8000lm 600*600mm

SPECIFICATION 3000/4000K
>80
CCT:
CRI: 60,000hrs L80/B10
Lifespan: x
Voltages x
Beam angle: x
Power factor: 3
SDCM:

01628 876 076 57



CASSIOPEIA IP20 CE

Our suspended remote panels are available in two shapes;
hexagonal and round. Both options are sleek and a unique
in design and primarily used to create a stunning design as
a suspended or surface mounted option. A remote control
is also included with each panel, which allows the user to
interchange between colour temperatures to suit its intended
environment. These range from warm white, natural white
and cool white. The remote control features an operating
distance of up to 15 metres.

FEATURES
Remote control function, changeable CCT, warm
white, natural white and cool white

Operating distance up to 15 metres

Luminaire mounting: suspended or recessed
2.4 GHz remote controller

Housing made of aluminium alloy
Finish: white spray painted

Power supply: dimmable electronic (standard)

TECHNICAL INFORMATION

Model number Power Lumen Lumen Dimensions 53mm
per Watt Output Ø*H*W

EA-RPL26W 26W 80 2080lm 400*400*53mm ΦxH ΦxH
EA-RPL35W 36W 80 2800lm 500*500*53mm
EA-RPL45W 45W 80 3600lm 600*600*53mm
EA-PPL26 26W 80 1600lm 400*400*53mm
EA-PPL35 35W 80 2800lm 500*500*53mm
EA-PPL45 45W 80 3600lm 600*600*53mm

*other versions available

SPECIFICATION 3000-65000K
>80
CCT: 50,000hrs
CRI: 220-240V, 50/60Hz
Lifespan: 120o
Voltages <0.9
Beam angle <6
Power factor
SDCM:

01628 876 076 10

DOWNLIGHT SERIES

Our range of LED Downlights offers high-quality, proven lighting solutions with instant energy savings for applications from
general lighting to high-end luxury.
The product range offers various IP ratings ensuring you can always find the most suitable product for your application
including kitchens and bathrooms.

11 www.ecoally.co.uk

CALLISTO

FEATURES IP20 5 CE
Emergency option available
YEARS
Housing made of aluminium WTY

Type of diffuser: opal

Finish:
Operating temperature:
Power supply: electronic (standard) or DIM DALI (optional)

Mounting on suspended plasterboard ceiling or on modular
ceilings

Light construction not weighting down the ceiling

TECHNICAL INFORMATION

Model Power CCT Lumen Lumen Dimensions
number per Watt Output Ø*H

EA-DL-8-WW 8W 3000K 80 640lm Ø100*52mm

EA-DL-8-NW 8W 4000K 85 680lm Ø100*52mm
730lm Ø100*52mm
EA-DL-8-CW 8W 5000K 91 810lm Ø100*52mm
870lm Ø100*52mm
EA-DL-10-WW 10W 3000K 81 920lm Ø100*52mm
1050lm Ø175*13mm
EA-DL-10-NW 10W 4000K 87 1080lm Ø175*13mm
1095lm Ø175*13mm
EA-DL-10-CW 10W 5000K 92

EA-DL-15-WW 15W 3000K 70

EA-DL-15-NW 15W 4000K 72

EA-DL-15-CW 15W 5000K 73

SPECIFICATION 3000-6000K
>80
CCT: 50,000hrs
CRI: 200-240V
Lifespan: 92o or 120o
Voltages: >0.9
Beam angle:
Power factor:

01628 876 076 12

DRACO IP44 5 CE

FEATURES YEARS
Housing made of aluminium WTY
Type of diffuser: opal
Power supply: electronic (standard) or DIM DALI (optional)
Finish:
Mounting on suspended plasterboard ceiling or on modular
ceilings
Emergency option available
UGR: <19

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions
number per Watt Output Ø*H

EA-D20WCFWD 20W 100 2000lm Ø145*69mm

SPECIFICATION 3000K,4000K, 6000K
>80
CCT: 50,000hrs
CRI: 220-240V, 50/60Hz
Lifespan: 120o
Voltages: ≤0.9
Beam angle:
Power factor:

13 www.ecoally.co.uk



LYNX 5CEIP20

FEATURES YEARSIP44
UGR: <19 WTY
Finish: inner ring gold/rose gold
Outer body: painted grey
Mounting on suspended plasterboard ceiling or modular ceilings
Power supply: electronic (standard) or DIM DALI (optional)
Emergency option available

TECHNICAL INFORMATION

Model number Power Lumen Lumen Dimensions
per Watt Output
Ø50xH47mm
EA-RDL3W 3W 70 210lm Ø75xH70mm
Ø85xH80mm
EA-RDL7W 7W 80 560lm
EA-RDL12W 12W 95 960lm

SPECIFICATION 3000/4000/6000K
>90
CCT: 50,000hrs
CRI: 220-240V
Lifespan: 15o/24o/38o/60o
Voltages: >0.5
Beam angle: <6
Power factor:
SDCM:

14 *beam angle for 7W
www.ecoally.co.uk

POLARIS IP40 CE

FEATURES
Dimensions: Φ115/140/160/200/230mm
UGR: <19
Power supply: electronic (standard) or DIM DALI
(optional)
Emergency option available
Finish: black and white
Mounting on suspended plasterboard ceiling or on
modular ceiling
Type of diffuser: opal

TECHNICAL INFORMATION

Model number Power Lumen Lumen
per Watt Output

EA-POLDL-10 10W >90 >900lm

EA-POLDL-15 15W >100 >1500lm
EA-POLDL-20 20W >100 >2000lm
EA-POLDL-25 25W >100 >2500lm
EA-POLDL-30 30W >100 >3000lm
EA-POLDL-40 40W >100 >4000lm
EA-POLDL-50 50W >100 >5000lm

SPECIFICATION 3000K *beam angle for 30o *beam angle for
>80/90
CCT: 50,000hrs
CRI: AC220-240V
Lifespan: 30o/45o
Voltages: >0.90
Beam angle:
Power factor:

01628 876 076 15

VEGA IP65 5 CE

FEATURES YEARS
Finish: gold/silver or black WTY
Dimensions: Φ 100/140/185/230mm
UGR: <19
Mounting on suspended plasterboard ceiling or on
modular ceiling
Emergency option available
Power supply: electronic (standard) or DIM DALI
(optional)

TECHNICAL INFORMATION

Model number Power CCT Lumen Lumen
per Watt Output

EA-VDL-10 10W 3000K >90 >900lm

EA-VDL-20 20W 3000K >100 >2000lm
EA-VDL-30 30W 3000K >100 >3000lm
EA-VDL-40 40W 3000K >100 >4000lm
EA-VDL-10 10W 4000K >90 >900lm
EA-VDL-20 20W 4000K >100 2000lm
EA-VDL-30 30W 4000K >100 3000lm
EA-VDL-40 40W 4000K >100 4000lm

SPECIFICATION 3000/4000K
>80/90
CCT: 50,000hrs
CRI: AC220-240V
Lifespan: 30o/45o
Voltages: >0.65/>0.90
Beam angle:
Power factor:

*beam angle for 30o *beam angle for 45o

14 www.ecoally.co.uk

ALYA IP40 5 CE

FEATURES YEARS
Finish: white WTY
Mounting on suspended plasterboard ceiling
or on modular ceilings
UGR: <19
Emergency option available
Power supply: electronic (standard) or DIM DALI
(optional)

TECHNICAL INFORMATION

Model number Power CCT Lumen Lumen
per Watt Output

EA-ALDL-10 10W 3000K >90 >900lm

EA-ALDL-20 20W 3000K >100 >2000lm
>3000lm
EA-ALDL-30 30W 3000K >100 >4000lm
>5000lm
EA-ALDL-40 40W 3000K >100
EA-ALDL-50 50W 3000K >100

SPECIFICATION 3000K
>80/90
CCT: 50,000hrs
CRI: AC220-240V
Lifespan: 30o/45o
Voltages: >0.90
Beam angle:
Power factor:

01628 876 076 *beam angle for 50W

15

TUNABLE DOWNLIGHTS

Today, modern lighting offers more than just optimum visibility. With innovative concepts for tunable downlights
and Human Centric Lighting, Ecoally uses the many positive effects of light in order to create more pleasant
working environments.

Dynamic adjustment over the day
Daylight with a higher blue content has the most influence on our internal clock as blue light has an
activating impact.
Therefore, a great amount of light with at least 5300K and a higher blue content is used to increase
performance during the day, whereas warm light with color temperatures below 3000K is suitable for
the evening.
Improve the quality of life with light quality – profit from innovative HCL concepts!

More alert, active and productive
While the color and intensity of the light is manually controlled in applications for tunable downlights, HCL
solutions dynamically adjust the brightness and color temperature of the lighting to the natural course of daylight
– from activating cold white to relaxing warm white. In order to make use of the biological impact of light, suitable
luminaires have to be chosen for the HCL concept.
In addition, parameters such as daylight level, room structure and user profile have to be considered. Studies have
shown that dynamic lighting solutions simulating the natural course of daylight significantly improve concentration
and productivity as well as alertness and quality of sleep.

14 www.ecoally.co.uk

HYPERION TUNABLE DOWNLIGHT

IP44 LED 5 CE

YEARS
WTY

FEATURES

Diffuser made of material with very good light transmittance
factor
Mounting in suspended plasterboad ceilings or on modular
ceilings

Perfect to create interesting effects in premises
Wide range of applications
Luminaire equipped with high efficient LED light source

3000/4000/5000K NON-DIMMABLE DIMMABLE >50K

HOURS

TECHNICAL INFORMATION

Model Power Lumen Lumen Product color Dimensions CRI Beam Operation
number 7W per Watt output Ø*H angle temperature
White face/black face Ra>80 -20oC - +50oC
EA-HTDL-7 100 700lm White face/black face Ø110*53mm Ra>80 60o
White face/black face Ra>80 -20oC - +50oC
EA-HTDL-11 11W 100 1100lm White face/black face Ø110*53mm Ra>80 60o
White face/black face Ra>80 -20oC - +50oC
EA-HTDL-20 20W 100 2000lm Ø145*69mm 60o -20oC - +50oC
EA-HTDL-30 30W 100 3000lm Ø190*86mm 60o -20oC - +50oC
Ø230*99mm 60o
EA-HTDL-40 40W 100 4000lm

01628 876 076 15



CALLYPSO IP20 5 CE

FEATURES YEARS
Emergency option available WTY
Finish: white
Material made of aluminium
Sleek design
Mounting on suspended plasterboard ceiling
or on modular ceilings
Power supply: electronic (standard)

TECHNICAL INFORMATION

Model Power CCT Lumen Lumen Output Dimensions
number per Watt H*W
EA-DL-3 3W 3000/4000/6500K 70/73/75 210/220/225lm
EA-DL-6 6W 3000/4000/6500K 70/72/74 420/430/440lm 13*85mm
EA-DL-9 9W 3000/4000/6500K 77/80/82 700/725/740lm 13*105mm
EA-DL-12 12W 3000/4000/6500K 80/82/83 960/985/995lm 13*120mm
EA-DL-15 15W 3000/4000/6500K 70/72/73 1050/1080/1095lm 13*175mm
EA-DL-18 18W 3000/4000/6500K 80/82/82 1440/1476/1476lm 13*175mm
EA-DL-24 24W 3000/4000/6500K 80/82/82 1920/1968/1968lm 13*225mm
13*225mm

SPECIFICATION 3000/4000/6500K
80
CCT: 25,0000hrs
CRI: AC 220-240V, 50/60Hz
Lifespan: 120o
Voltages: ≤0.95
Beam angle:
Power factor:

01628 876 076 *beam angle for 24W

17

INDI SPOTLIGHT

FEATURES IP20 5 CE
Perfect solution for MR16 / GU10 replacement project
Module with integrated electronic, heatsink and optics YEARS
Dimming range 0.1 to 100% (depends on dimmer) WTY
Eye-catching lens optic with mirrors halogen facettes
High colour consistency (MacAdam 3)
Powered by Tridonics components

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions
number output
per Watt Ø*H

EA-IN-9.5-710 9.5W 710lm 75 49.9*75.5mm

EA-IN-9.5-810 9.5W 810lm 85 49.9*75.5mm

EA-IN-9.5-760 9.5W 810lm 80 49.9*75.5mm

*other versions available

SPECIFICATION 2700K-4000K * Light distribution for 24o
CCT: >90
CRI: >50.000hrs *Light distribution for 36o
Lifespan: 220-240V, 50-60 Hz
Voltages: 24o/36o FEATURES
Beam angle:
- Up to 30° swivel mounting rings
LED ACCESSORY for ceiling cutouts 68mm and
75mm
32 - Matt white / matt black brushed
nickel finishing
- Version 75mm with optional
anti-glare guard
- Spring clip pre-assembled

www.ecoally.co.uk

TAU CETI DOWNLIGHT IP20 5 CE

FEATURES YEARS
LED replacement for downlights with compact WTY
fluorescent lamp

Ripple current 5% and UGR 19 (specific model only)
makes office installation possible
Accessories and an assembly concept with integrated
mounting springs offer extra convenience for
installations

Powered by Tridonics components

Approved emergency solution with EM converter LED
Small colour tolerance: MacAdam 4
The module and the driver are available as individual
components, making logistics arrangements more
cost-effective

TECHNICAL INFORMATION

Model Power Lumen Lumen Dimensions
number 10.2W per Watt output Ø*H
20.2W
EA-TC-10 96 980lm Ø114*57mm

EA-TC-20 101 1,020lm Ø163*86mm

EA-TC-30 29.9W 99 4170lm Ø218*106mm

*other versions available

SPECIFICATION 3000-4000K
80
CCT: 50.0000hrs
CRI: 220-240V, 50-60 Hz
Lifespan: 60o/90o/100o
Voltages:
Beam angle:

*Light distribution for 100mm lamp without reflector

01628 876 076 33

IP65 LED CE

FEATURES

• Available colours: white or chrome
• Dimmable
• Lifespan: 50,000hrs
• Material: mixed (metal and plastic)
• The luminaire is fire rated 30/60/90

minutes under EN1365-2014 fire test.

• The luminaire is IP65 rated (Zone 1) so
is suitable to be installed in bathrooms

• Aesthetically pleasing: the compact and
simplistic design of Lumi-Plugin allows
it to seamlessly blend in with its
surroundings without disrupting the
home or property.

Lumi-Plugin’s modular and versatile design features, combined with its world-class durability and reliability,
means it brings real benefits wherever it’s used. It is designed to save lives and properties in the event of fire.
With its combination of various plugins, you are able to tailor your needs to meet your fire safety requirements.
Traditionally, conventional fire sprinkler systems, fire detection and emergency lights all compete with room
lighting for the same place on the ceiling. Now they no longer have to.
Lumi-Plugin is a great product that incorporates low voltage lighting with either fire suppression, fire detection
and/or 3 hours emergency lighting in a stylish luminaire that will help streamline ceiling spaces. These luminaires
can also host PIR sensors.
Coming Soon - Lumi-Plugin will soon enable you to control the lights using your voice! This will work with all major
Virtual Assistants including Amazon Alexa, Google Home and HomePod.

13 www.ecoally.co.uk

Standard downlight
Emergency light
Sprinkler
Smoke alarm
Heat alarm
CO CO alarm
PIR sensor
Air vent

TECHNICAL INFORMATION

Model number Power CCT Lumen Luminosity Input Voltage Input Voltage Dimensions Beam
per Watt flux to Luminaire to Driver D*H angle
9.5W 2700/4000K
44 700lm 16V 240V Ø120*70mm 60o

01628 876 076 77

COMMERCIAL LIGHTS

Commercial lighting is lighting used for commercial spaces such as offices, stores, institutions, hospitals and government
buildings. These are essentially those spaces that are not residential, industrial or for manufacturing. When compared to other
types of lighting, commercial lighting tends to have a higher initial cost, longer lifespan, better durability, higher maintenance
and service costs and better energy saving options.
The main objective when using a commercial building is to accomplish a task or conduct an activity, which is why illuminance
or the focus and amount of light is important.
While under lighting impedes several types of activities, over lighting also poses a problem in accomplishing tasks.
To understand lux or illumination level requirements for commercial spaces, it is important to understand the units of
measurement of light and the efficacy of their relationship.

22 www.ecoally.co.uk

JUPITER

LED Track lights are commonly used in illuminating Paintings, Pictures, Certificates, and other decorations attached to the
walls. They are used in shops to illuminate the variety of goods and displays being sold.

This stylish and compact LED track light can be used in a various number of settings and can be easily attached to the wall.
They come complete with the mounting brackets and are easy to install wall mounted, ceiling mounted or mounted on
railings so that it can be adjusted depending on the area is being used.

FEATURES IP20 5 CE

High Ra ﹥90, low SDCM ﹤3 YEARS
High efficacy, high illuminance WTY
Glare-free design, perfect light spot and
accurate beam angle, make surroundings of
comfortable illumination

Finish: black or white

Body made of aluminium

Rotatable horizontal 355° and vertical 180°
Perfect combination of spherical heat sink and
cambered driver box, smooth and concise
appearance, fit for different occasions

TECHNICAL INFORMATION

Model Power CCT Luminosity
number flux

EA-JUP-30-WW 30W 3000K 2722lm (12o) / 2679lm (24o) / 2668lm (40°)

EA-JUP-30-NW 30W 4000K 2980lm (12o) / 2961lm (24o) / 2940lm (40°)

EA-JUP-35-WW 35W 3000K 2967lm (12o) / 3020lm (24o) / 2952lm (40°)

EA-JUP-35-NW 35W 4000K 3370lm (12o) / 3365lm (24o) / 3279lm (40°)

EA-JUP-45-WW 45W 3000K 4128lm (12o) / 4065lm (24o) / 3990lm (40°)

EA-JUP-45-NW 45W 4000K 4473lm (12o) / 4478lm (24o) / 4329lm (40°)

EA-JUP-56-WW 56W 3000K 5566lm (12o) / 5482lm (24o) / 5318lm (40°)

EA-JUP-56-NW 56W 4000K 6011lm (12o) / 5919lm (24o) / 5743lm (40°)

SPECIFICATION 3000/4000K *beam angle for 30W, 24o *beam angle=35W, 24o
>90
CCT: 50.000hrs *beam angle for 45W, 24o *beam angle=56W, 40o
CRI: AC100-240/220-240V, 50-60Hz
Lifespan: 12o/24o/40o/60o 23
Voltages: ≤0.95
Beam angle: <3
Power factor:
SDCM:

01628 876 076

JUNO IP20 5 CE

FEATURES YEARS
Die-cast aluminium heatsink WTY
Lens & Reflector for options
Anti-glare accessories available
The light shape can be square, oval and linear
Dimable type: standard/DALI, WiFi dimmable
CCT dimmable available: 2500-3000K/2700-5000K
Finish: black or white

TECHNICAL INFORMATION

Model Power CCT Luminosity flux
number

EA-JUN-15 15W 3000K 1268lm (15o) / 1263lm (24o) / 1320lm (36°)

EA-JUP-20 20W 3000K 1949lm (15o) / 1902lm (24o) / 1897lm (36°)

EA-JUP-25 25W 3000K 2195lm (15o) / 2129lm (24o) / 2143lm (36°)

EA-JUP-35 35W 3000K 3031lm (15o) / 3068lm (24o) / 3055lm (36°)

Reflector size Lens size

SPECIFICATION 2500-3000K/2700-5000K *beam angle for 15W, 24o *beam angle for 24W,
>90
CCT: >50,000hrs
CRI: AC100-240/220-240V, 50-60 Hz
Lifespan: 15o/24o/36o (lens), 18o/24o/38o/45o/60o (reflector)
Voltages: ≤0.96
Beam angle:
Power factor:

*beam angle for 25W, 24o *beam angle=35W, 24o

14 www.ecoally.co.uk

ACCESSORIES

OPTICAL ACCESSORIES
Different diffuser make different light spot shape

Optics lens in round Optics lens in elliptic Optics lens in rectangle Optics lens in line
shape shape shape shape

ANTI-GLARE ACCESSORIES

The hidden position of the light source and the optical accessories provided prevent glare, provide a comfortable light
evironment and protect your eyes. Can be used alone or with a variety of dimmers

Lens Honeycomb ring

15o/24o/36o 1. Honeycomb ring only
2. Honeycomb ring with filter glass
Reflector
Slant anti-glare hat
15o/24o/38o/35o/60o
1. Slant anti-glare hat only
Anti-glare cross ring 2. Slant anti-glare hat with filter glass

1. Cross ring only Anti-glare fan
2. Cross ring with filter glass
1. Anti-glare fan only
01628 876 076 2. Anti-glare fan with filter glass

23

HARMONIA

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output D*H
EA-HMC-30 5W 425lm
EA-HMC-40 5W 85 425lm 3*30cm
EA-HMC-50 5W 85 425lm 3*40cm
EA-HMC-60 5W 85 425lm 3*50cm
EA-HMC-70 5W 85 425lm 3*60cm
EA-HMC-80 5W 85 425lm 3*70cm
EA-HMC-90 5W 85 425lm 3*80cm
EA-HMC-100 5W 85 425lm 3*90cm
85 3*100cm

SPECIFICATION 4000K
CCT: >80
CRI: 16V
Voltages: 80o
Beam angle: Iron
Material: Black/matt white + gold
Color:

LOTIS

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Light Lumen Lumen Dimensions
number source per Watt Output H*W
EA-LTC 1*E14
n/a n/a 5*40cm

SPECIFICATION Aluminium + iron
Material: Gold
Color:

24 www.ecoally.co.uk

BELLATRIX II

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output (D+D)*H
EA-BT2C-28 1837lm
EA-BT2C-38 28W 66 2449lm (40+20)*80cm
EA-BT2C-47 3062lm (50+30)*80cm
EA-BT2C-57 38W 64 3674lm (60+40)*80cm
EA-BT2C-66 4286lm (70+50)*80cm
EA-BT2C-85 47W 65 5511lm (80+60)*80cm
(100+80)*80cm
57W 64

66W 65

85W 65

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o
Beam angle: Iron + aluminium + PC
Material: White
Color:

BELLATRIX III

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output (D+D+D)*H
EA-BT3C-57 57W 3674lm (20+40+60)*150cm
EA-BT3C-71 71W 64
EA-BT3C-85 85W 4592lm (30+50+70)*150cm
EA-BT3C-113 113W 65 5511lm (40+60+80)*150cm
65
7348lm (60+80+100)*150cm
65

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o
Beam angle: Iron + aluminium + PC
Material: White
Color:

01628 876 076 25

ELECTRA

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output D*H
EA-ELTC-9 9W 550lm
EA-ELTC-13 13.5W 61 870lm 20*120cm
EA-ELTC-18 18W 64 1150lm 30*120cm
EA-ELTC-24 24W 64 1560lm 40*120cm
EA-ELTC-27 27W 65 1800lm 50*120cm
EA-ELTC-30 30W 67 1950lm 60*120cm
EA-ELTC-33 33W 65 2140lm 70*120cm
65 80*120cm

SPECIFICATION 4000K
CCT: >80
CRI: 16V
Voltages: 80o
Beam angle: Iron + steel + crystal
Material: Chrome + clear
Color:

ATLANTA

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Dimensions
number 6W+14W+24W Output D*H
EA-ATC
+36W+36W 7450lm (20+40+60+80+80)
*250cm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 180o
Beam angle: Iron + steel + crystal
Material: Chrome + clear
Color:

26 www.ecoally.co.uk

DAPHNE

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output D*H
EA-DPHC-9 9W 612lm
EA-DPHC-14 14W 68 918lm 20*120cm
EA-DPHC-19 19W 66 1225lm 30*120cm
EA-DPHC-24 24W 64 1531lm 40*120cm
EA-DPHC-28 28W 64 1837lm 50*120cm
EA-DPHC-33 33W 66 2143lm 60*120cm
EA-DPHC-38 38W 65 2449lm 70*120cm
EA-DPHC-47 47W 64 3062lm 80*120cm
65 100*120cm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o
Beam angle: Iron + aluminium + PC
Material: White
Color:

CLIO

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output L*W*H
EA-CLCH-40 40W
EA-CLCH-55 55W 61 2450lm 57*55*14cm

61 3350lm 66*65*14cm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o ~ 140o
Beam angle: iron + aluminium + PC
Material: black/white/gold
Color:

01628 876 076 27



SEMELE

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output
EA-SMLC-22 22W 1400lm Ø40cm
EA-SMLC-28 28W 65 1680lm Ø50cm
EA-SMLC-34 34W 60 2050lm Ø60cm
EA-SMLC-40 40W 60 2450lm Ø70cm
EA-SMLC-45 45W 61 2750lm Ø80cm
EA-SMLC-56 56W 61 3380lm Ø100cm
60

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 80o
Beam angle: Iron + acryl
Material: Gold + white
Color:

DANAE

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output
EA-DNC-26 26W Ø60cm
EA-DNC-38 38W 60 1560lm Ø80cm

60 2280lm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o
Beam angle: Iron + aluminium + PC
Material: Black/white/coffee
Color:

01628 876 076 29

THALIA

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output H*W
EA-THLC-8 8W 480lm
EA-THLC-12 12W 60 Ø20cm
EA-THLC-15 15W 720lm
60 Ø25cm
900lm
60 Ø30cm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 140o
Beam angle: Iron
Material: White/gray/black
Color:

ARTEMIS

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number per Watt Output L*W*H
EA-ADC-5 5W
EA-ADC-7 7W 64 320lm 16*16*6cm

64 450lm 20*20*6cm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 140o
Beam angle: Iron
Material: White/black
Color:

30 www.ecoally.co.uk

AGLAIA

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Power Lumen Lumen Dimensions
number 84W per Watt Output 80*40*60cm
EA-AGC-84
65 5450lm

SPECIFICATION 4000K
CCT: >80
CRI: 24V
Voltages: 120o
Beam angle: Iron + aluminium + PC
Material: Black/white/coffee
Color:

HEBE

TECHNICAL INFORMATION IP20 5 CE

YEARS
WTY

Model Light Lumen Lumen Dimensions
number source per Watt Output L*H
EA-HBC 2*E27
n/a n/a 13*30cm

SPECIFICATION Iron
Material: Black/white
Color:

01628 876 076 31

NIMBUS

FEATURES IP20 5 CE

Electrostatic powder coated aluminium housing YEARS
Tempered glass cover WTY
Uniform illlumination
99,9% pure aluminium reflector
Operating temperature: -20o/+45o
DALI, SwitchDIM and Emergency options
Colour tolerance MacAdam 3
Comes in white, black or gray

TECHNICAL INFORMATION

Model Power CCT Lumen Lumen Dimensions
number output per Watt L*A1*A1

EA-NB-11-WW 11W 3000K 1158lm 105 100*80*80mm

EA-NB-11-NW 11W 4000K 1231lm 112 100*80*80mm

EA-NB-11-CW 11W 5000K 1251lm 113 100*80*80mm

EA-NB-13-WW 13W 3000K 1368lm 105 120*100*100mm

EA-NB-13-NW 13W 4000K 1454lm 112 120*100*100mm

EA-NB-13-CW 13W 5000K 1478lm 113 120*100*100mm

EA-NB-19-WW 19W 3000K 2000lm 105 140*120*120mm

EA-NB-19-NW 19W 4000K 2126lm 112 140*120*120mm

EA-NB-19-CW 19W 5000K 2126lm 113 140*120*120mm

SPECIFICATION 3000/4000/5000K
80+, 90+
CCT: 50,000hrs
CRI: 220-240V, 50-60 Hz
Lifespan: 150o
Voltages: 0.95
Beam angle:
Power factor:

32 www.ecoally.co.uk
