Thermogroup AU Product Guide 2018

Underfloor Heating

7mm cable diameter

Heavy duty
heating cable

Versatile In Slab heating cable

Thermoslab is a brilliantly versatile, robust 7mm thick underfloor heating cable designed for use
In Slab. Install the cable in the concrete slab of new builds to create an energy efficient thermal
mass under your floor.

Stock Code Length (m) Output (W) Resistance (Ω) RRP $ Excl. RRP $ Incl.

3140 29 850 62.24 344.55 379.00
3142 38 1100 48.09 380.91 419.00
3144 47 1400 37.79 432.73 476.00
3146 57 1700 31.12 508.18 559.00
3148 67 2000 26.45 544.55 599.00
3150 75 2250 23.51 590.00 649.00
3152 84 2500 21.16 644.55 709.00
3154 94 2800 18.89 726.36 799.00
3156 112 3350 15.79 817.27 899.00
3158 134 4000 14.21 926.36 1,019.00
3160 150 4500 11.76 1,135.45 1,249.00
3162 168 5000 10.58 1,318.18 1,450.00
3164 200 6000 1,480.91 1,629.00
8.82
Accessories Description
Size Unit RRP $ Excl. RRP $ Incl.
Stock Code Cable Ties
Manual Thermostat 140mm Pk 100 6.82 7.50
3257 H86 x W86 x D50m Ea 144.55 159.00
5250

Allow 3 cables ties for every 1m of cable.
Other Thermostat options are available on page 56-65 (demand power applications)

Call us on 1300 368 631 or visit www.thermogroup.com.au 51

Underfloor Heating

Underfloor Heating FAQs

We have put together a range of answers to the most
frequently asked questions about Underfloor Heating
systems.
If you have a question that isn’t answered here please
give us a calI.

What happens if it goes wrong Do I need a contactor/snubber? Is electric heating safe in
or breaks under my floor? bathrooms? What about the
Thermogroup thermostats have a water?
There are no moving parts to an max load of 16amps. If your system
electric underfloor heating system exceeds this total load you will It is perfectly safe to install a
and cable failures are extremely rare, require a suitably rated Thermonet system in a bathroom.
if installed correctly. A damaged cable contactor and snubber to ensure a Thermonet is protected to IP68
can usually be located and repaired safe and functional circuit. standards which means it can be
with minimal disruption. placed in zone 1 of a bathroom with
Can I extend or shorten the no issues. The thermostat, however,
Can I join two or more heating cold tail? should be installed away from water
cables or mats to fit a larger sources.
area? Yes! The low profile cold tail can be
shortened or extended up to 50m Do I need to use a special
No, the heating cables or mats with a standard 1.5mm twin core adhesive to fit tiles over
cannot be joined together however flex. We recommend that connections underfloor heating?
two or more can be connected in are accessible.
parallel to one Thermostat. You will need to use a cement based
When connecting multiple cables Can I install Underfloor Heating flexible tile adhesive, however there
or mats you need to ensure that the in the shower? is a wide variety available so ask
total load does not exceed the total your manufacturer or tile retailer for
load of your thermostat. If your shower floor is tiled you guidance.
can run the heating cables into
Can I cut the heating cable if I the shower area however it is How do I control my underfloor
have excess? recommended that you do not start heating system?
or end in the shower.
No - never. Cutting the heating cable Every system should be connected to
will alter the resistance and cause What should I do if I have left- a Thermostat. You can have a
the element to overheat. If you cut over heating cable? simple, manual on/off version,
the cable by accident, please call our but we recommend the use of a
technical helpline for assistance. You should always measure the room programmable heating thermostat
accurately and choose a system that with a heating schedule for better
How much does it cost to run covers the available heating area. If efficiency.
an electric underfloor heating you do have extra cable you can run
system? it around the edge of the room (Min. Do I need to include thermal
spacing 40 or 50mm), up the walls insulation as part of my floor?
Every system is different due to the or in the shower (if tiled).
insulation value of the property, We recommend the use of
type of flooring used and the level of Econoboard insulation as it can halve
insulation below the heating system. running costs. The underfloor heating
For an estimated running cost see systems will still be able to work
page 19. without the use of insulation however
it will increase the heat up times and
running costs.

52 Call us on 1300 368 631 or visit www.thermogroup.com.au

Underfloor Heating

Can underfloor heating be used Can you walk on the installed Can I use my floor heating on
as the primary heat source? heating cables before the tiles ‘Off-Peak’ electricity?
are laid?
Yes, if you cover at least 80% of the When using In Slab heating, you
floor area with the underfloor heating Whilst the cable is durable and will can take advantage of the Off-Peak
system, this can be used as the handle foot traffic we recommend electricity tariff as heating the slab
primary heat source in the room. reducing walking on unfinished creates a thermal mass beneath
floor surfaces to a minimum as a your floor that allows for a slow
How long will it take for the precaution. Avoid putting heavy continuous release of heat. Under tile
floor to heat up? objects with sharp edges down on the and In­Screed heating systems have
cable such as buckets of tile glue. a more rapid heat up and cool down
Every situation is different due to time, therefore are not suitable to be
the insulation value of the property, Can I turn the heating on to used with Off-Peak electricity.
type of flooring used and the level of make sure it heats up before
insulation below the heating system. the tiles are laid? Are there any special wiring
For an estimated heat up time see requirements?
page 18. No. The heating cable systems need
to be enclosed in a cement layer Your electrician will need to ensure
What floor covering can I have to help spread the heat. Turning that the amperage of the circuit
on top of underfloor heating? on the heating before the cement is suitable for the size of the floor
layer is applied will cause the cable heating system that is being installed.
When installed in the slab or screed to overheat and burn out. The The floor heating must also be
layer, underfloor heating is suitable heating cable needs to be tested installed on a RCD protected circuit.
for most floor finishes, subject by a qualified electrician to ensure
to manufacturers guidelines on no damage has occurred during Does the floor sensor have to
maximum floor temperatures. installation. be installed in the conduit?

How long should the floor Does underfloor heating require We recommend the use of a conduit
heating be left on for? any maintenance? for the floor sensor so that in the
event of a floor sensor failing or the
The length of time depends on your No. An electric underfloor heating thermostat being upgraded, the
lifestyle, the system used and the system does not have any parts that floor sensor can be replaced without
desired temperature. require maintenance. The thermostat damaging the floor covering. If this is
will need to be programmed not possible we recommend installing
Does floor heating cause any according to your schedule and you a second floor sensor as a spare.
problems to the tiles or floor can adjust this when you wish to.
covering?
What is the difference between
No - if installed correctly the floor single and double conductor
heating does not affect the floor heating cables and mats?
covering.
A single conductor mat or cable has
Who installs underfloor only one cold tail which needs to
heating? be connected to the Thermostat as
opposed to a double conductor cable
Our underfloor heating systems or mat which has a cold tail at both
are designed to be simple to install ends of the heating cable that needs
and come with a comprehensive to be connected to the thermostat.
installation manual. Often the floor All of the Thermogroup underfloor
heating is installed by the electrician, heating cables have a single cold
tiler, builder or even the home owner. tail, making installation quicker and
The testing and wiring up of the floor easier.
heating needs to be by a qualified
electrician.

Call us on 1300 368 631 or visit www.thermogroup.com.au 53

Controls and Accessories

Did you know?

The scales of a pine cone move in response to
changes in humidity. When it is warm and dry,
the pine cone scales open up and when it is
damp or cold they close.
This is the job of your Underfloor Heating
Thermostat, controlling the temperature of your
room to keep it as comfortable as possible for
you, no matter what the weather is.

54 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories

Underfloor heating controls
and accessories

Call us on 1300 368 631 or visit www.thermogroup.com.au 55

Controls and Accessories

Efficient heating controls
help you save money

Our thermostats provide accurate floor and
ambient temperature control combined with a
heating schedule that only heats when you need
it and helps to cut your running costs.

• Create an on demand heating schedule to provide heat only when you need it
• WiFi connected thermostats allow you complete control from anywhere*
• Accurate ambient and floor sensors for total control over your heating system
• Easy installation into the mains electricity supply
• Conduit provided for floor sensor installation
• Range of models available to suit your home interior
• Dual relay Thermotouch 4.3dC designed to control floor heating and an additional

appliance

*Internet connection required

56 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories

DUAL CONTROL SYSTEM

Smart override function and
temperature boost mode

WiFi enabled models available
with free iOS & Android apps

Satin Black & Ice White
models available

Intelligent floor and ambient
temperature sensors

7 day, 6 event Dual relay for optional
heating schechule extra appliance control

Control your underfloor heating and towel rail from one thermostat

Control your electric underfloor heating and an additional appliance, such as an electric heated
towel rail or mirror demister. The WiFi enabled model allows you to control both relays remotely
from your smartphone or tablet.

Stock Code WiFi Colour Size (mm) IP Rating Max Combined RRP $ Excl. RRP $ Incl.
5245 No Ice White 129 x 88 x 48 (31mm in wall) IP30 Load
5245W 350.00 385.00
5246 20A
5246W
Yes Ice White 129 x 88 x 48 (31mm in wall) IP30 20A 409.09 450.00

No Satin Black 129 x 88 x 48 (31mm in wall) IP30 20A 350.00 385.00

Yes Satin Black 129 x 88 x 48 (31mm in wall) IP30 20A 409.09 450.00

Call us on 1300 368 631 or visit www.thermogroup.com.au 57

Controls and Accessories

DUAL CONTROL SYSTEM

Thermotouch 4.3dC is a unique thermostat that can control your
underfloor heating and electric towel rail or mirror demister.

Thermotouch has been redesigned to deliver an easy to use electric underfloor heating thermostat
that connects directly to your home WiFi network!

Dual relay controls

Thermotouch 4.3dC has an additional 5A relay which can control an extra
appliance such as an electric heated towel rail or mirror demister.

Economical heating schedule

Set up an energy efficient, on demand heating schedule for your underfloor
heating and an optional additional appliance.

Smart boost settings

Override your heating schedule for up to 4 hours with a simple touch of the
screen. Thermotouch will then revert back to your heating program.

Multiple sensor compatibility

Thermotouch 4.3dC is compatible with the most popular floor sensor probes
on the market, making it suitable to upgrade your current thermostat. For a
list of compatible sensor probes visit www.thermogroup.com.au.

Connect to your WiFi network and control from your smartphone

Connect Thermotouch 4.3dC to your wireless network and control from your
iOS or Android device. Control from anywhere with an internet connection.

58 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories

DUAL CONTROL SYSTEM

Dual relay control

Thermotouch 4.3dC has a 16A relay for an underfloor heating system and an additional 5A relay
that can be used to control another appliance such as a mirror demister or towel rail. The diagram
below shows a typical dual control setup. The maximum combined load is 20Amps.

RCD TOWEL RAIL OR MIRROR DEMISTER
PROTECTED
SUPPLY 5A RELAY
16A RELAY
THERMOSTAT

FLOOR SENSOR

UNDERFLOOR HEATING

This diagram is for illustrative purposes only. Please ensure all installations are carried out in accordance with current local electrical
regulations and read the relevant installation information in full before attempting to install an underfloor heating system.

Call us on 1300 368 631 or visit www.thermogroup.com.au 59

Controls and Accessories

IDN UT EAL L I G CE NO TN HTE AR TOI NLG CS OYNST RT OEL MS

Download the MyThermotouch app from your app store today!

MyThermotouch is designed to give you full control over all of your wireless Thermogroup
thermostats from one central application. The app is compatible with the Thermotouch 4.3dC
WiFi models and the Themotouch 7.6cG Connected Glass range.

Search for “MyThermotouch” on the relevant
app store to download the free app

60 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories

IDN UT EAL L I G CE NO TN HTE AR TOI NLG CS OYNST RT OEL MS

Control all of your Thermogroup connected thermostats from one
application, wherever you have an internet connection

Our connected WiFi thermostats connect directly to your wireless network. It is easy to connect
multiple thermostats* to your network and control them from anywhere** via the MyThermotouch
app.

iOS and Android apps

Download the app for your tablet or smartphone from the app store of your
choice. The MyThermotouch app gives you full control and the ability to edit
your heating schedule remotely.

User friendly network connection

The simple connection process makes it easy to set up your new WiFi
thermostats and share connections with others quickly and easily.

Customise each room with a photo

Add your own photos to each thermostat on the app. Customise each room
with a picture of your choice.

Wireless dual relay control

When used with the 5245W or 5246W, the MyThermotouch app can control
your underfloor heating and an additional appliance remotely.

*The amount of thermostats that can be connected differs depending on the capabilities of the specific router and network capacity as well as the fabric of the building.
**Internet connection required for wireless app control.

Call us on 1300 368 631 or visit www.thermogroup.com.au 61

Controls and Accessories

IDN UT EAL L I G CE NO TN HTE AR TOI NLG CS OYNST RT OEL MS

Have full control over your electric underfloor heating system with
the Thermotouch fully programmable glass thermostat

Thermotouch 7.6iG, 7 day programmable thermostat is also available in a WiFi enabled model and
comes with an ice white or piano black glass fascia.

Fully programmable

The Thermotouch 7.6iG Programmable Thermostat features an improved
7 day, 6 event heating schedule with 6 heating events on the weekend.

Portrait or landscape mounting

Thermotouch 7.6iG is supplied with a portrait backing plate as standard.
However, if required you can purchase the landscape mounting plate.

Sensor mode

Thermotouch 7.6iG is supplied with a floor sensor probe and an option for
using an ambient sensor to ensure total control over your heating system.

Manual mode

Thermotouch 7.6iG also features a simple to use manual function that allows
you to manually control the temperature of your underfloor heating.

Connect to your WiFi network and control from your smartphone.

Connect Thermotouch 7.6cG to your wireless network and control from your
iOS or Android device. Control from anywhere with an internet connection.

62 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories Controls and Accessories

IDN UT EAL L I G CE NO TN HTE AR TOI NLG CS OYNST RT OEL MS

7 day, 6 event heating schedule
with 6 weekend events

Sleek glass fascia with
LED back light

WiFi models available with Built in ambient Easy to program with the
free iOS and Android apps. temperature sensor touch panel display

Thermotouch 7.6iG Glass Programmable Thermostat

The 7.6iG Glass Programmable Thermostat features an improved 7 day 6 event heating schedule
including 6 heating events on each day of the weekend. The piano black and ice white glass
fascias and clean lines are a perfect match for any modern interior.

Stock Code WiFi Colour Size (mm) (W x H x D) IP Rating Max Load RRP $ Excl. RRP $ Incl.
5220A* No Ice White
5220AW Yes Ice White 85 x 115 x 46 (26mm in wall) IP30 16A 259.09 285.00
5226A No Piano Black 85 x 115 x 46 (26mm in wall) IP30 16A 318.18 350.00
5226AW Yes Piano Black 85 x 115 x 46 (26mm in wall) IP30 16A 259.09 285.00
85 x 115 x 46 (26mm in wall) IP30 16A 318.18 350.00

Stock Code Accesories Size (mm) (W x H x D) RRP $ Excl. RRP $ Incl.
20.00 22.00
5221 White Landscape Mounting Plate 115 x 86 x 5 20.00 22.00
5223 Black Landscape Mounting Plate 115 x 86 x 5

*5220A Thermostat included as standard in all Thermonet 150W/m². T kits - See page 25.

Call us on 1300 368 631 or visit www.thermogroup.com.au 63

Controls and Accessories

Electrical accessories

6025 6026 5266
UFH Cable Monitor Spray Adhesive Floor Sensor Probe

For installation monitoring Useful for matting and loose wire installations Supplied with every Thermostat and is
*Supplied with every kit purchased designed to provide accurate floor temperature
control.

5279 / 5280 / 5286 5250 5270
25A / 40A / 63A Contactor Manual Thermostat Slimline Repair Kit
and Snubber
Designed for use with off-peak electricity To extend cold tail or repair underfloor heating
Used to switch loads greater than 16 amps cables (Professional use only)

Stock Code Description Unit RRP $ Excl. RRP $ Incl.

6025 Mat Monitor ea 35.45 39.00
6026 Spray Adhesive 500ml (10m2) ea 35.45 39.00
5266 Floor Sensor Probe ( 10k Ω) ea 20.00 22.00
5279 25A Contactor/Snubber 5700W ea 133.64 147.00
5280 40A Contactor/Snubber 9000W ea 208.18 229.00
5286 63A Contactor/Snubber 14440W ea 235.45 259.00
5281 Snubber ea 26.36 29.00
5250 Manual Thermostat ea 144.55 159.00
5270 Slimline Repair Kit ea 20.00 22.00
5267 Flexible Conduit Kit 1.8 Lm 22.73 25.00
6994 Plastic Single Back Box ea 13.64 15.00
5274 Metal Back Box ea 13.64 15.00
5412 Cold Tail Extension Wire Lm 10.91 12.00

64 Call us on 1300 368 631 or visit www.thermogroup.com.au

Controls and Accessories

Thermostat FAQs

We have put together a range of answers to the most
frequently asked questions about Underfloor Heating
Controllers.
If you have a question that isn’t answered here please
give us a calI.

What is a floor sensor? What is an Eco Temperature? What is the difference between
an underfloor heating controller
A floor sensor is a small probe that is The Eco temperature is a lower and a towel rail controller?
installed beneath the floor, between temperature that is set for the ‘Off’
two runs of heating cable. This is period on the Thermostat. This An underfloor heating controller
connected to the Thermostat and is normally set at a temperature (Thermostat) allows you to have
gives an accurate reading of the floor between 15-18°C. This means that control over the temperature of your
temperature. the heating will still come on if the floor whereas a towel rail controller
temperature drops below this even is only a timing device (On/Off) and
What temperature should I set during an ‘Off’ period ensuring, the does not allow for any control over
my underfloor heating at? floor heating will not be trying to heat the temperature.
from freezing for each ‘On’ period.
Every situation is different however Can I control my underfloor
it is recommended to set your How much does it cost to run heating using C-Bus?
underfloor heating to 24°C to begin an electric underfloor heating
with. After testing for several days system? Yes, ensure that you purchase the
increase or decrease the temperature manual controller (5250 - see page
to find your comfort temperature. Every system is different because of 64) with your underfloor heating
Please note a decrease of 1°C may the insulation value of the property, and this can be connected to and
not affect the comfort or warmth of type of flooring used and the level of controlled by your C-Bus system.
the floor enough to make it noticeable insulation below the heating system.
but can help to reduce running costs. For an estimated running cost see Can I control my underfloor
page 19. heating and towel rail from one
What is a contactor/snubber? controller?
Do I need to purchase a floor
A contactor is designed to switch sensor? Yes, with our Thermotouch 4.3dC
loads greater than 16A on one dual control thermostat, you can
thermostat. The snubber must also No, every Thermostat is supplied individually control both your
be connected to absorb any electrical with a compatible floor sensor so underfloor heating and towel rail from
surges that could disrupt the memory this does not need to be purchased the single controller.
of the thermostat. separately.
What is the flexible conduit
Do I need a contactor/snubber? Can I control my underfloor for? Do I need to install it?
heating from my phone while
Thermogroup thermostats have a max I’m away? We recommend that the floor sensor
load of 16A. If your system exceeds is installed in the flexible conduit so
this total load you will require a Yes, choose a Thermotouch WiFi that if the floor sensor fails or if you
suitably rated contactor/snubber to thermostatic controller and you will choose to upgrade your thermostat
ensure a safe and functional circuit. be able to monitor and control your later the floor sensor can be removed
heating from anywhere with an and replaced without damaging the
Can I control multiple zones available internet connection. floor covering.
with one controller?

No, each zone that you want to have
individual control over needs to have
it’s own separate controller.
However, the WiFi enabled
Thermostats will allow control of
multiple Thermostats from your
phone.

Call us on 1300 368 631 or visit www.thermogroup.com.au 65

Insulation

Insulation & Adhesive Title Page
Did you know?

Trapped air which cannot move is the best
insulator. That’s why birds puff up their feathers
to enable them to trap air between their
feathers and keep them warm.
Insulation boards trap air creating an active
barrier against heat going down into your
substrate and therefore pushing it back up into
the room where you need to keep warm.

66 Call us on 1300 368 631 or visit www.thermogroup.com.au

Insulation

Insulation

Call us on 1300 368 631 or visit www.thermogroup.com.au 67

Insulation

Insulation Boards for Underfloor Heating

Using the correct Insulation Board is vital for an efficient electric underfloor heating system as it minimises downward
heat loss and reduces your running costs by up to 50%

Uncoated boards for concrete Coated tile backer boards for Econosoft Underlay for floating
substrates and under tile heating timber substrates and wetrooms floor build ups and timber flooring

For more details see page 72 - 73 For more details see page 70 - 71 For more details see page 74 - 75

Typical concrete floor build up Typical timber floor build up Typical floating floor build up

Tiled floor Tiled floor Timber floor
Flexible tile adhesive Flexible tile adhesive Econosoft overlay
Thermonet mat Thermonet mat (5422)
Econoboard Uncoated Econoboard Coated Thermofoil PRO
Flexible tile adhesive Timber substrate Econosoft underlay
Concrete substrate Econoboard Coated
Timber substrate

SAVING ZONE

Floor Temperature Insulated
(°C)
Un-insulated

More detail on heat up
times on page 18

Heat up time
(Hours)

68 Call us on 1300 368 631 or visit www.thermogroup.com.au

Insulation

Key benefits of Econoboard insulation

Econoboard insulation is essential for an energy efficient electric underfloor heating system. A layer
of Econoboard will help prevent heat loss into the substrate and ensure faster heat up times, as
well as providing a stable, flat substrate for underfloor heating.

• Improve the efficiency of electric underfloor heating by up to 50%

• 100% moisture resistant and rot proof

• Minimal heat loss into the substrate and faster heat up times

• Helps prevent mould staining from moisture in bathrooms

• Easy to install - cuts with regular hand tools

• Can be installed on floors and walls

• Coated boards improve lateral and flexural stability of timber floors

Without insulation With insulation

Heat loss into the substrate Improved efficiency and comfort

Without an insulation layer, heat travels in all Adding a layer of thermal insulation creates
directions equally until it reaches a thermal thermal resistance which drives the heat up to
break, or layer of thermal resistance. the surface of your floor and into your room.

Call us on 1300 368 631 or visit www.thermogroup.com.au 69

Insulation

Easy to cut with normal
hand tools

100% rot proof, ideal for
use in bathrooms

Improves the efficiency of underfloor
heating by up to 50%

Fibre reinforced for improved
lateral stability

Econoboard Coated Insulation Boards

Manufactured using a high-density extruded polystyrene core with a polymer modified,
fibre reinforced cement coating on both sides. Adds rigidity, strength and thermal
insulation to timber substrates.

DUCTIVITY STRENGTH RPTION ENSITY
Manufactured to
0.3W/MK 0.30N/mm² 0.6% by vol. 36 Kg/m³
DIN EN 13164 DIN EN 1606 DIN EN 1606
MAL CON
PRESSIVE
TER ABSO
M CORE D
THER FOA WA
COM

70 Call us on 1300 368 631 or visit www.thermogroup.com.au

Insulation

Installation overview

Using Econoboard Coated and the range of fixing accessories quickly creates an ideal, stable
substrate for tile adhesive and underfloor heating. It can be used on floors and walls and is 100%
rot proof which makes it ideal for use in bathrooms and wetrooms.

1. Ensure the timber substrate is secure and free
from dust and any debris.

2. Cut boards to size with a sharp blade and
position over the floor area in an offset brick
pattern.

3. Fix in position using fixing screws (6017)
and washers (6016) at 300mm centres (10
washers per board).

Stock Code Thickness (mm) Board Size (m) Board Area (m²) Pack Quantity Pack Area (m²) R value RRP $ Excl. RRP $ Incl.
6106 8 5.76 m²k/w 326.36 359.00
6110 6 1.2 x 0.6 0.72 6 4.32 271.82 299.00
1.5
10 1.2 x 0.6 0.72
2.7

Accessories

6016 Zinc Fixing Washers

Stock Code Description Unit RRP $ Excl. RRP $ Incl.
6015 100mm Reinforcing Tape 25m roll ea
6016 Zinc Fixing Washers (35mm) pk 100 44.55 49.00
6017 Fixing Screws (32mm) pk 500 44.55 49.00
35.45 39.00

6015 Reinforcing Tape

Call us on 1300 368 631 or visit www.thermogroup.com.au 71

Insulation

Easy to cut with normal hand
tools

Water resistant & 100% rot
proof, ideal for use in bathrooms

Improves the efficiency of underfloor
heating by up to 50%

Econoboard Thermal Insulation

Cost effective thermal insulation board for concrete and screed substrates. Improves
insulation and reduces heat loss into the substrate. Available in 6mm or 10mm
boards, Econoboard gives you maximum insulation with a minimal height build up - ideal
for refurbishment applications.

DUCTIVITY STRENGTH RPTION NTRE

0.3W/MK 0.25N/mm² 0.3% by vol. Manufactured to
DIN EN 13164 DIN EN 1606 DIN EN 1606 DIN EN 13164
MAL CON
PRESSIVE XPS
TER ABSO
FOAM CE
WA COM THER

72 Call us on 1300 368 631 or visit www.thermogroup.com.au

Insulation

Installation overview

Solid concrete floors and screeds absorb the cold and damp from below. Econoboard should
be used before tiling to inhibit moisture and prevent heat loss into the substrate. Econoboard is
100% rot proof and ideal for use in bathrooms and wetrooms.

1. Ensure the concrete substrate is free from
dust and any debris.

2. Mix tile adhesive according to manufacturer
guidelines and spread on substrate with a
notched trowel.

3. Fix in position by pressing the boards firmly
into the adhesive.

Stock Code Thickness (mm) Board Size (m) Board Area (m²) Pack Quantity Pack Area (m²) R value m²k/w RRP $ Excl. RRP $ Incl.
6012 6 20 14.4 3.0 435.45 479.00
6014 10 1.2 x 0.6 0.72 10 7.2 4.0 271.82 299.00

1.2 x 0.6 0.72

Econoboard Uncoated Acoustic Properties

Econoboard Uncoated Insulation boards will help to absorb
impact sound resulting in decreased noise pollution,
reducing impact by up to 20 db!

Call us on 1300 368 631 or visit www.thermogroup.com.au 73

Insulation
74 Call us on 1300 368 631 or visit www.thermogroup.com.au

Insulation

Overlay and underlay solutions

Every Thermofoil PRO system requires a layer of Econosoft Underlay (5400) and Econosoft Overlay
(5422). Econosoft overlay reduces sound by 21dB.

5400 5422
Econosoft Cushioning Underlay 5mm Econosoft Overlay 1.5mm

An essential 5mm cushioning underlay that should be An essential 1.5mm cushioning overlay that also acts
included under Thermofoil PRO in every installation as a moisture and acoustic barrier and should be
included above Thermofoil PRO in every installation

Stock Code Description Thickness (mm) Size (m) Pack Quantity Pack Area (m²) RRP $ Excl. RRP $ Incl.
5 1.2 x 0.5 6 10 90.00 99.00
5400 Econosoft Underlay 1.5 15 x 1.0 15 1 326.36 359.00
5422 Econosoft Overlay 21dB

Engineered timber or laminate floor finish
Econosoft overlay
Thermofoil PRO heating foil
Econosoft cushioning underlay
Sub floor

Call us on 1300 368 631 or visit www.thermogroup.com.au 75

Did you know?

Fire is the oldest form of Heating
used by man. Every 52 years,
when the Aztecs calendar
completed a cycle they would
extinguish every flame in the
empire. The high priest would
start a new fire and fires fed from
this flame would be distributed
throughout the land. Today you can
have heat anywhere in your home
whenever you like with the simple
flick of a switch.

Space heating

Model Shown: TF1000

Space Heating

Thermofan fan heaters are designed to quickly and effectively add
warmth to your home.

Easy installation

The Thermofan bathroom fan heaters are designed to be easy to install and
come with a 3-pin plug to provide a retrofit heating solution.

Rapid heat up time

Thermofan fan heaters deliver an evenly distributed air flow to quickly warm
and maintain a consistent, comfortable temperature throughout the room.

Low noise level

With a low noise level, Thermofans have minimal disruption to your home.

IP Safe for use in bathrooms

All the Thermofan fan heaters can be safely installed in bathrooms. Refer to
your electrician for the correct zone placement based on the IP rating.

Variety of programming options

The Thermofan fan heater range includes a variety of methods of operation,
from a simple pull cord on/off unit to a fully programmable unit.

Call us on 1300 368 631 or visit www.thermogroup.com.au 79

Space Heating

Unit Size Most Popular TF1800 New Model
Output - Watts
Room Size TF1000 H450 x W270 x D110mm TF2400S/TF2400W
IP Rating
Wiring Method H410 x W285 x D115mm 1800W H300 x W200 x D140mm
Ease of Operation
Programming 1000-1800W Up to 15m² 2200W - 2400W
Option
Warranty Up to 15m² IP24 Up to 16m²
Standard as Plugin
Finish Colour IP24 Hardwired optional IPX1
Standard as Plugin Standard as Plugin
Hardwired optional Complex Hardwired optional

Medium Fully Programmable with Simple
Touchscreen controls
Temperature and Boost Pull Cord On/Off Switch
Timer Knobs 2yrs
2yrs
2yrs White & Grey Stainless Steel (TF2400S)

White White (TF2400W)

60 minute Boost Timer

Removable and Washable Filter
Pilot Light

Comes with a 1m cord
and 3-Pin plug

Optional Towel Rail
(TF1000R)

The TF1000 Bathroom Fan Heater is an attractive, wall mounted fan heater with the controls
concealed on the side of the unit. It features extremely low noise level, a 60 minute boost timer and
has a removable and washable filter.

Stock Code Size (mm) Output (W) Room Size (m²) IP Rating RRP $ Excl. RRP $ Incl.
TF1000 H410 x W285 x D115 1000 – 1800 Up to 15 259.00
TF1000R IP24 235.45
Optional Towel Rail 29.00
26.36

80 Call us on 1300 368 631 or visit www.thermogroup.com.au

Space Heating

Presence Sensor

Touchscreen Controls
on front of unit

Removable Washable Filter
Concealed behind unit

Comes with a 1m cord
and 3-Pin-plug

Towel Rail and Hooks

The Thermofan TF1800 boasts the latest in intelligent energy saving controls, and its slimline
design and touchscreen controls make it a perfect addition to any modern home.
The TF1800 Thermofan is fully programmable, allowing you to set when you want it on every day
of the week and your desired temperature.

Stock Code Size (mm) Output (W) Room Size (m²) IP Rating RRP $ Excl. RRP $ Incl.
TF1800 H450 x W270 x D110 1800 Up to 15 IP24 271.82 299.00

Blue Led ‘On’ Indicator

Comes with a 1m cord
and 3-Pin-plug

80cm Pull Switch
on right

Stock Code Colour Size (mm) Output (W) Room Size (m²) IP Rating RRP $ Excl. RRP $ Incl.
2200 - 2400
TF2400S Stainless Steel H300 x W200 x D140 2200 - 2400 16 IPX1 144.55 159.00

TF2400W White H300 x W200 x D140 16 IPX1 144.55 159.00

Call us on 1300 368 631 or visit www.thermogroup.com.au 81

Space Heating

Thermoplinth is a space saving heater
designed to be fitted into your kick plate

Thermoplinth is a small compact unit that is
designed to fit into your kitchen kick plate,
saving you space and it will warm your room
very quickly and more efficiently than an
equivalent radiator.

Stock Code Size Output (W) Finish RRP $ Excl. RRP $ Incl.
562.73 619.00
3624 H100 x W500 x D240* 1000 – 2000 Grey**

* 20mm needs to be left free in the kick space above the heater for ventilation purposes
** Supplied with an optional white faceplate

Tubular Heaters are designed to provide
low background heat and are especially
useful in airing cupboards.

The low temperature convection heating helps
to combat winter chills and dampness.

Stock Size Output RRP $ Excl. RRP $ Incl.
Code (mm) (W)

TH60 L628 x W85 x D115 68 299.09 329.00

TH90 L928 x W85 x D115 104 362.73 399.00

TH120 L1228 x W85 x D115 145 417.27 459.00

82 Call us on 1300 368 631 or visit www.thermogroup.com.au

Space Heating

Thermodetect uses an intelligent, sensitive leak detection cable to alert you to leaks
faster than a regular spot leak detector.

A Thermodetect Leak Detection cable can cover a much larger area than a simple spot detector, and can be run along
lengths of pipe to detect any potential leaks early. The larger detection surface area gives you an early warning for a
quick reaction.

Stock Code Description Length (m) RRP $ Excl. RRP $ Incl.
5690 Thermodetect leak detector with sensing cable 1.2 271.82 299.00
5692 Thermodetect leak detection extension cable 2.4 135.45 149.00

Add the warm feeling of underfloor heating to your home
or office without having to replace your floor.
Thermomat heated carpet mats are a simple plug-in heat
mat ideal for use under your desk.

Stock Code Size Output (W) Colour RRP $ Excl. RRP $ Incl.
6050 W600 x H400 75 Anthracite 171.82 189.00

Call us on 1300 368 631 or visit www.thermogroup.com.au 83

How many times have you seen
a lizard sunning itself on a warm
wall?
That’s the same as placing a towel
over a Heated Towel Rail to keep it
warm and dry for when you need it.

Heated Towel Rails Heated Towel Rails

Heated towel
rails

85 Call us on 1300 368 631 or visit www.thermogroup.comC.alul us on 1300 368 631 or visit www.thermogroup.com.au 85

Heated Towel Rails Heated Towel Rails

Model Pictured: CR23M 86
86 Call us on 1300 368 631 or visit www.thermogroup.comC.alul us on 1300 368 631 or visit www.thermogroup.com.au

Heated Towel Rails

Every bathroom needs a
Heated Towel Rail

Something as simple as an electric heated towel rail
can transform the feeling of your bathroom.
There’s nothing like a warm, dry towel!

Energy efficient electric element

The Thermorail range is designed to run on the lowest wattage possible without
compromising comfort, and the fast response heating means you only have your
rail on when you really need it.

Easy installation

The Thermorail range is designed to be easy to install and come with all of the
fixings you’ll need to install the towel rail in your bathroom.

Range of practical designs

Choose from ladder style rails fixed to the wall or a space saving swivel design.
We even have free-standing rails that simply plug into a powerpoint.

On demand towel warming

An independently controlled electric towel rail is ideal for drying and warming
towels when the central heating is off.

Call us on 1300 368 631 or visit www.thermogroup.com.au 87

Heated Towel Rails

Model Picturede: DSS6 x 3
88 Call us on 1300 368 631 or visit www.thermogroup.com.au

Heated Towel Rails

Stylish single ended design can be
easily installed in multiples

Concealed right hand side
wiring

12V - Safe for installation
in wet areas

High quality polished stainless
steel body

Thermorail 12V Heated Towel Rails

Available as a single bar or single ended design in a range of shapes and sizes.
Thermorail 12V single bar towel rails are perfect for smaller bathrooms and can
be installed in multiples to create a design statement in your bathroom.

Use the second relay on the Thermotouch 4.3dC to control your electric heated
towel rail. Set up a heating schedule to match your underfloor heating.
More information on page 119

Call us on 1300 368 631 or visit www.thermogroup.com.au 89

Heated Towel Rails

12V Single Bar Range

40mm 40mm

100mm 450mm 632mm

100mm

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl.
DSS4 Polished 17 DSS6B Matt Black 23 153.64 169.00
131.82 145.00

40mm 40mm

100mm 632mm 100mm 632mm

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl.
DSS6 Polished 23 135.45 149.00
DSS6BR Brushed 23 180.91 199.00

40mm
40mm

100mm 832mm 632mm

100mm

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl.
DSS8 Polished 30 192.73 212.00 DSS6W White 23 180.91 199.00

ANSFORMER INCLU POLISHED STAINLES RY ELECTRIC ELEME HAND CONCEALED URED STAINLESS S

12V 240V 12V
TEEL

WIRING
NT
S STEEL
DED
TR
QUALITY

D
RIGHT
COLO

90 Call us on 1300 368 631 or visit www.thermogroup.com.au

Heated Towel Rails

12V Single Bar Range

32mm
32mm

100mm 632mm 632mm

100mm

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl.
DSR6 Polished 18 135.45 149.00 DSR6B Matt Black 18 150.00 165.00

100mm 32mm
40mm

100mm
700mm 700mm

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl.
DCF7 Polished 21 135.45 149.00 15 135.45 149.00
DCR7 Polished

40mm DTRAN
100mm
640mm

7089

Stock Code Finish Output (W) RRP $ Excl. RRP $ Incl. Stock Code Output (W) RRP Incl $
DSC6 Polished 23 180.91 199.00 7089
DTRAN 10-60 Supplied at no charge with 12V rails

HAND CONCEALED 35-105 Supplied at no charge with 12V rails

ANSFORMER INCLU POLISHED STAINLES RY ELECTRIC ELEME URED STAINLESS S

12V 240V 12V
WIRING
NT
S STEEL
DED
TR TEEL
QUALITY

D
RIGHT
COLO

Call us on 1300 368 631 or visit www.thermogroup.com.au 91

Heated Towel Rails
92 Call us on 1300 368 631 or visit www.thermogroup.com.au

Heated Towel Rails

Thermorail Mounting Rail

The mounting system allows for easy installation of multiple single bar rails by ensuring perfect rail
spacing and allows for supply cable to be installed before the wall is sheeted. Mounting spigots are
supplied with the single bar towel rails.

Stock Code Description Size (mm) RRP $ Excl. RRP $ Incl.
7060 Thermorail Mounting System H1000 x W110 x D10 180.91 199.00

Not suitable for use with DSS6BR, VS900H, VS900HB or Ladder Rails.
The 7060 mounting kit needs to be installed on the right hand side for double ended rails.

Call us on 1300 368 631 or visit www.thermogroup.com.au 93

Heated Towel Rails

Model Pictured: SES6 x 4
94 Call us on 1300 368 631 or visit www.thermogroup.com.au

Heated Towel Rails

12V Single Ended Range

32mm

100mm
32mm

100mm
400mm 600mm

Stock Code Output (W) RRP $ Excl. RRP $ Incl. Stock Code Output (W) RRP $ Excl. RRP $ Incl.
SER4 12 SER6 17
213.64 235.00 226.36 249.00

100mm 30mm
30mm
100mm 400mm 600mm

Stock Code Output (W) RRP $ Excl. RRP $ Incl. Stock Code Output (W) RRP $ Excl. RRP $ Incl.
SES4 SES6 16
12 222.73 245.00 235.45 259.00
RY ELECTRIC ELEME NCEALED WIRING O
ANSFORMER INCLU
12V
NLY
NT

DED
TR
D
CO

12V 240V

Mounting your single ended rail If you need to retrofit the single ended towel rail you
can simply mount the spigot to the wall surface and
The single ended rails feature a mounting spigot use the retrofit dress ring to conceal the mounting
designed to be mounted on the wall before tiling. If spigot.
you mount this spigot in the wall you can use either
the sleek dress ring (supplied with the rails) or have a
clean finish with the rail directly against the wall.

Sleek dress ring install No dress ring install 7064 round dress ring 7066 square dress ring
RRP $ Excl. RRP $ Incl.
Stock Code Description Size 26.36 29.00
70Ø 26.36 29.00
7064 Round Retrofit Dress Ring 70 x 70

7066 Square Retrofit Dress Ring

Call us on 1300 368 631 or visit www.thermogroup.com.au 95

Heated Towel Rails

Thermorail 12Volt Heated Towel Rails

Low Voltage

This range all have low voltage enabling them to be safely located anywhere
in your bathroom or wet areas allowing you to have full flexibility with your
bathroom design.

12V 240V Transformer Included

All of the Thermorail 12Volt range come with a 12Volt transformer meaning
the only additional item you will require is a switch or timer to control the
unit, everything else comes as one package and there are no additional costs
involved.

Energy Efficient Element

The Thermorail range is designed to run on the lowest wattage possible
without comprising comfort and the fast response heating means you only
have the rail on when you really need it.

Concealed Dry Electric Element

All of the 12Volt ladder rails have a dry electric element that can be concealed
wired on either the left or right-hand side while the vertical bars can be
concealed wired at the top or bottom of the rail.

96 Call us on 1300 368 631 or visit www.thermogroup.com.au

12V Range Heated Towel Rails

122mm 122mm

800mm
800mm

600mm 600mm

Stock Code No.Bars Output (W) RRP $ Excl. RRP $ Incl. Stock Code No.Bars Output (W) RRP $ Excl. RRP $ Incl.
90 453.64 499.00 90 499.09 549.00
SR4412 7 SR4412B 7

120mm 142mm 142mm

900mm
900mm

800mm

100mm 100mm

600mm Hooks are removable
VS900H have a 10yr warranty & VS900HB have a 7yr warranty

Stock Code No.Bars Output (W) RRP $ Excl. RRP $ Incl. Stock Code Finish Output RRP $ Excl. RRP $ Incl.
90 508.18 559.00 (W)
SS4412 7 VS900H Stainless Steel 271.82 299.00
30 329.00
299.09
VS900HB Matt Black 30
CEALED WIRING ALL
ANSFORMER INCLU RY ELECTRIC ELEME TIRFYLEEXLEWCIRTRINICG AELLEM4 E NTNALCEAAN3LD2EmVDEmRWTøIICRAILNBGA O

12V 240V 240V 12V
LEGS
RNSLYIZES
NLETGS
NT
DED
TR
D
MUDL
HORIZCOO
CON

19mmø

Call us on 1300 368 631 or visit www.thermogroup.com.au 97

Heated Towel Rails

Model Pictured: SS44M

98 Call us on 1300 368 631 or visit www.thermogroup.com.au

Call us on or visit

Heated Towel Rails

Efficient dry electric heating
element for fast heat up time

Easy installation with
the included fixings

Multiflex wiring for ease of installation
(Unless otherwise specified)

Thermorail Electric Heated Towel Rails

Electric heated towel rails have a quick response time, are a lot more energy efficient and are more
suited to the Australian climate than traditional liquid filled models. The dry electric element heats
up quickly and in turn heats the air in the tubes. When a towel is hung on the rails the heat is
concentrated under the towel allowing it to dry more quickly.

Consider using a timer to control your electric heated towel rail ensuring you have a
warm towel when you need it. See page 118 - 119

Call us on 1300 368 631 or visit www.thermogroup.com.au 99

Heated Towel Rails

Model Shown: SR44M
100 Call us on 1300 368 631 or visit www.thermogroup.com.au
