Innovate. Illuminate. Inspire. 2024 Altair & Capella DOWNLIGHTS Fo r m o r e i n f o r m a t i o n v i s i t e t i s s l . c o m
4 8 12 16 20 22 Commercial Canless Wafer Canless Gimbal Illuminate with Precision Capella & Altair Downlights Downlighting For Every Scenario Capella Commercial Altair Canless Downlights Altair Retrofit Downlights Altair Surface Downlights Installation methods Order Numbers 2
Enhanced Customization & Inventory Management: with Lumen Boost and Color Preference technology, users can tailor power outputs and color temperatures according to their needs, aiding distributors in efficient inventory management. Straightforward Installation: ETI downlights are designed for easy setup, working seamlessly with existing designs and providing simple connectivity, with available mounting accessories for added convenience. Energy-Efficient and Dependable: LED lighting delivers energy and cost savings while outlasting traditional lighting. With ETI, you can rely on durable lights with lifespans over 50,000 hours. Retrofit Retrofit Gimbal Surface Disk 3
120-277V Commercial Applications
CAPELLA Commercial Downlights Color Preference® Lumen Boost® Applications Field adjustable: 3000K | 3500K | 4000K | 5000K Field-selectable wattages: 7W up to 43W Ideal for new construction projects, and equally suitable for retrofits, in multifamily residences, retail spaces, restaurants, hospitality venues, offices, and more.
ETI Lighting’s Capella Commercial Downlights offer quality and flexibility for 120-277V commercial applications—with 4 Color Preference® and 3 Lumen Boost® . Commercial Applications 120-277V 4”: 600lm | 800lm | 1000lm 7W | 9W | 12W 6”: 1100lm | 1500lm | 2000lm 14W | 18W | 24W 8”: 2400lm | 2800lm | 3300lm 25W | 29W | 36W 10”: 3000lm | 3500lm | 4000lm 32W | 37W | 43W Adjustable wattage and color-selectable switches are easily accessible on back of integrated driver. Features Metal Conduit Length 19” CAPELLA Commercial Two low-profile spring retention clips provide a secure fit. 6
AVAILABLE SIZES Luminaires have a deep-recessed design that emits a gentle, diffused light, ensuring visual comfort while minimizing glare. These high-performing commercial downlights offer a timeless elegance and exceptional functionality with a stellar 90+ CRI and a durable wet-location rating. Goof Rings | Rough-In Mounting Plates Interchangeable Trims Black Satin Nickel 4” 6” 8” 10” 4-6”, 6-8”, 8-10” 3”, 4”, 6”, 8” Accessories Available 7
120V | 120-277V Commercial & Residential
ALTAIR Commercial & Residential Downlights Color Preference® Magnetic Trim System Applications Field adjustable: 2700K | 3000K | 3500K | 4000K | 5000K Optional magnetic color trims that are interchangeable and easily installed. Perfectly suited for new or retrofit construction projects for multifamily, homes, hospitality, offices, and more
Features ALTAIR Canless Downlights 120V | 120-277V Commercial & Residential Field-selectable CCT switch easily accessible on remote driver. Two low-profile spring retention clips provide a secure fit. Smaller trim ring for enhanced optical performance. Cable Length 16” The Altair Canless Downlights provide quality and flexibility for residential and commercial use, featuring single and multi-volt options, with high-output variants available for 6-inch models, and gimbal versions. These low-profile downlights with 5 Color Preference® offer 90+ CRI and are wet-location rated. 4” SV/MV: 10W | 800lm 4” SV: 8W | 650lm 6” SV/MV: 10W | 800lm 8” SV: 19W | 1600lm MV: 17W | 1600lm 6” SV: 12W | 950lm 6” HO SV/MV: 14W | 1200lm Wafers Gimbals 10
AVAILABLE SIZES Interchangeable Magnetic Trims for ALCD wafers only Extension Cables | BBU Rough-In Mounting Plates Black Satin Nickel 4” 4” 6” 6” 8” 3”, 4”, 6”, 8” Wafers Gimbals 120V only 12’ & 20’ Multi-Volt 120-277V Single-Volt 120V Remote Drivers Accessories Available 355° Rotation 25° Tilt 11
120V Residential
ALTAIR Retrofit Downlights Color Preference® Easy Install Applications Field adjustable: 2700K | 3000K | 3500K | 4000K | 5000K Quick and effortless install with included detachable E26 base. Suitable for multifamily, homes, hospitality, small or home offices, and other residential applications. E INSTALLZ™
Efficient and versatile, suitable for various projects, featuring detachable E26 bases for easy installation in standard sockets or hard-wired setups, with a wet location rating for indoor use. Features ALTAIR Retrofit Downlights Field-selectable CCT switch easily accessible on back. Torsion springs (5/6”) and Friction clips (4”) provide a secure fit. Baffle design maximizes glare reduction. Cable length 13” 120V Residential 4”: 8W | 700lm 4”: 8W | 700lm 5/6”: 10.5W | 900lm 5/6”: 10W | 900lm Baffle Downlights Gimbals 14
AVAILABLE SIZES These downlights offer selectable CCTs—5 Color Preference® for flexibility—and high 90+ CRI, ensuring superior color rendering, along with a long projected life exceeding 65,000 hours, while featuring diffused lenses to minimize glare. 4” 4” 5/6” 5/6” Baffle Downlights Gimbals 2 7 0 0 K 3 0 0 0 K 3 5 0 0 K 4 0 0 0 K 5 0 0 0 K Quick connect E26 base included Direct light where it’s needed most with Gimbal option. 350° Rotation 30° Tilt Highlights 15
120V Residential
ALTAIR Surface Mount Downlights Color Preference® Motion Sensor Applications Choose between 3 or 5 color temperature options or opt for a single CCT. Add hands-free lighting with PIR motion sensor option. Ideal for new or retrofit construction projects for multifamily, homes, hospitality, offices, and more.
ALTAIR Surface Mount Downlights 120V Residential These flexible luminaires offer field-selectable CCT and single CCT options and soft, comfortable light quality. They are 90+CRI and JA8/Title 24 Compliant. Features Field-selectable CCT switch located under lens. (on select models) Convenient twist-off lens for easy access. High-impact PC diffuser lens offers zero pixelation and overall visual comfort. 4”: 10W | 850lm 6”: 15W | 1230lm 6”: 15W | 1230lm 6”: 15W | 1230lm 6”: 15W | 1230lm 5 CCT Selectable Single 3000K Single 4000K 3 CCT Selectable w/ PIR Motion Sensor 18
AVAILABLE SIZES 4” 6” 6” With integrated motion sensor Friction Clips with E26 Adapter Interchangeable Clip-n Trims Black Satin Nickel Accessories Available Low profile allows for installations in regular and pancake junction boxes. Integrated PIR Motion Sensor 120° at 11 feet sensing distance with a 30 second hold time (non-adjustable) 19
Remote Driver Wafer Remote Driver Gimbal Integrated Driver Integrated Driver & BBU RECESSED Diverse Installations Two low-profile spring retention clips for a secure fit—no need for a separate recessed housing or junction box. Minimum 2” plenum space required to install the remote driver box. The internal driver and built-in whip facilitate swift installation into either new or existing junction boxes. Additionally, a separate emergency backup unit is available for purchase. 20
SURFACE Retrofit with Spring Clips/Friction Clips Surface Mount Retrofit Kit with E26 Adapter Two spring retention clips or friction clips for a secure fit. Easy to install. Includes detachable E26 base. Suitable for surface mounting with a wide range of standard and pancake junction boxes, or into existing recessed housing with available retrofit kit. 21
CATALOG PART NUMBER ORDER NUMBER SIZE CRI CCT SELECTABLE WATTAGE LUMEN PKG VOLTAGE DIM SELECTABLE WATTAGE AND CCT CCDL-4-LB3-9CP4-MV-LVD 63314101 4” 90+ 3000K|3500K|4000K|5000K 7|9|12 600|800|1000 120-277V 0-10V CCDL-6-LB3-9CP4-MV-LVD 63315101 6” 90+ 3000K|3500K|4000K|5000K 14|18|24 1100|1500|2000 120-277V 0-10V CCDL-8-LB3-9CP4-MV-LVD 63316101 8” 90+ 3000K|3500K|4000K|5000K 25|29|35 2400|2800|3300 120-277V 0-10V CCDL-10-LB3-9CP4-MV-LVD 63317101 10” 90+ 3000K|3500K|4000K|5000K 32|37|43 3000|3500|4000 120-277V 0-10V CATALOG PART NUMBER ORDER NUMBER SIZE CRI CCT SELECTABLE WATTAGE LUMEN PKG VOLTAGE DIM SINGLE VOLT (120V), TRIAC DIM ARDL-4-9CP5-SV-TD 63318101 4” 90+ 2700K|3000K|3500K|4000K|5000K 8 700 120V TRIAC ARDL-6-9CP5-SV-TD 63319101 5/6” 90+ 2700K|3000K|3500K|4000K|5000K 10.5 900 120V TRIAC SINGLE VOLT (120V), TRIAC DIM - GIMBAL ARDG-4-9CP5-SV-TD 63320101 4” 90+ 2700K|3000K|3500K|4000K|5000K 8 700 120V TRIAC ARDG-6-9CP5-SV-TD 63321101 5/6” 90+ 2700K|3000K|3500K|4000K|5000K 10 900 120V TRIAC CAPELLA Commercial Downlights Altair Retrofit Downlights Capella Commercial Downlight Accessories CATALOG PART NUMBER ORDER NUMBER DESCRIPTION CCDL-4-TRIM-BL 70545101 CCDL 4" Clip-On Black Trim CCDL-4-TRIM-SN 70547101 CCDL 4” Clip-On Satin Nickel Trim CCDL-6-TRIM-BL 70548101 CCDL 6" Clip-On Black Trim CCDL-6-TRIM-SN 70550101 CCDL 6” Clip-On Satin Nickel Trim CCDL-8-TRIM-BL 70551101 CCDL 8" Clip-On Black Trim CCDL-8-TRIM-SN 70553101 CCDL 8” Clip-On Satin Nickel Trim CCDL-10-TRIM-BL 70554101 CCDL 10" Clip-On Black Trim CCDL-10-TRIM-SN 70556101 CCDL 10” Clip-On Satin Nickel Trim DL-46GR 70557101 4”– 6” Goof Ring DL-68GR 70558101 6” – 8” Goof Ring DL-810GR 70559101 8 – 10” Goof Ring DLGP-U 70566101 3"/4"/6"/8" Universal Rough-In Mounting Plate DLGPB-U 70565101 3"/4"/6"/8" Universal Rough-In Mounting Plate with Bar Hangers EMA25FY-170 70112202-2 Square Emergency LED Driver BBU 25W, IP rated, 90 min Trim Rings Goof Rings Battery Backup Rough-In Mounting Plates 22
CATALOG PART NUMBER ORDER NUMBER SIZE CRI CCT SELECTABLE WATTAGE LUMEN PKG VOLTAGE DIM MULTI-VOLT (120-277V), 0-10V DIM ALCD-4-9CP5-MV-D 63322201 4” 90+ 2700K|3000K|3500K|4000K|5000K 10 800 120-277V 0-10V ALCD-6-9CP5-MV-D 63323201 6” 90+ 2700K|3000K|3500K|4000K|5000K 10 800 120-277V 0-10V ALCD-6HO-9CP5-MV-D 63323401 6” - High Output 90+ 2700K|3000K|3500K|4000K|5000K 14 1200 120-277V 0-10V ALCD-8-9CP5-MV-D 63324201 8” 90+ 2700K|3000K|3500K|4000K|5000K 17 1600 120-277V 0-10V SINGLE VOLT (120V), TRIAC DIM ALCD-4-9CP5-SV-TD 63322101 4” 90+ 2700K|3000K|3500K|4000K|5000K 10 800 120V TRIAC ALCD-6-9CP5-SV-TD 63323101 6” 90+ 2700K|3000K|3500K|4000K|5000K 10 800 120V TRIAC ALCD-6HO-9CP5-SV-TD 63323301 6” - High Output 90+ 2700K|3000K|3500K|4000K|5000K 14 1200 120V TRIAC ALCD-8-9CP5-SV-TD 63324101 8” 90+ 2700K|3000K|3500K|4000K|5000K 19 1600 120V TRIAC SINGLE VOLT (120V), TRIAC DIM - GIMBAL ALCG-4-9CP5-SV-TD 63325101 4” Gimbal 90+ 2700K|3000K|3500K|4000K|5000K 8 650 120V TRIAC ALCG-6-9CP5-SV-TD 63326101 6” Gimbal 90+ 2700K|3000K|3500K|4000K|5000K 12 950 120V TRIAC CATALOG PART NUMBER ORDER NUMBER SIZE CRI CCT WATTAGE LUMEN PKG VOLTAGE DIM SELECTABLE CCT ALSD-4-9CP5-SV-TD 63327101 4” 90+ 2700K|3000K|3500K|4000K|5000K 10 850 120V TRIAC ALSD-6-9CP5-SV-TD 63328101 6” 90+ 2700K|3000K|3500K|4000K|5000K 15 1230 120V TRIAC ALSD-6-9CP3-SV-TD-OS 63328102 6” 90+ 3000K|4000K|5000K 15 900 120V TRIAC SELECTABLE CCT 6 PACK ALSD-6-9CP5-SV-TD-6PK 63328101-6pk 6” 90+ 2700K|3000K|3500K|4000K|5000K 15 1230 120V TRIAC SINGLE CCT 6 PACK ALSD-6-930K-SV-TD-6PK 63328111 6” 90+ 3000K 15 1230 120V TRIAC ALSD-6-940K-SV-TD-6PK 63328141 6” 90+ 4000K 15 1230 120V TRIAC ALTAIR Canless Downlights ALTAIR Suface Mount Downlights ALTAIR Canless Downlight Accessories CATALOG PART NUMBER ORDER NUMBER DESCRIPTION ALCD-4IN-TRIM-B 70567101 ALCD 4in Magnetic Black Trim ALCD-4IN-TRIM-BN 70568101 ALCD 4in Magnetic Satin Nickel Trim ALCD-6IN-TRIM-B 70569101 ALCD 6in Magnetic Black Trim ALCD-6IN-TRIM-BN 70570101 ALCD 6in Magnetic Satin Nickel Trim ALCD-8IN-TRIM-B 70571101 ALCD 8in Magnetic Black Trim ALCD-8IN-TRIM-BN 70572101 ALCD 8in Magnetic Satin Nickel Trim DLGP-U 70566101 3"/4"/6"/8" Universal Rough-In Mounting Plate DLGPB-U 70565101 3"/4"/6"/8" Universal Rough-In Mounting Plate with Bar Hangers FRCDL-12FT-EXTENCORD 70232101 12-ft Extension Cable FRCDL-20FT-EXTENCORD 70233101 20-ft Extension Cable EMA25FY-170 70112202-2 Square Emergency LED Driver BBU 25W, IP rated, 90 min Trim Rings Extension Cables Battery Backup Rough-In Mounting Plates CATALOG PART NUMBER ORDER NUMBER DESCRIPTION ALSD-4-RETROFIT KIT 70604101 ALSD 4" Friction Clips with E26 adapter ALSD-6-RETROFIT KIT 70605101 ALSD 6" Friction Clips with E26 adapter ALSD-4-TRIM-BL 70573101 ALSD 4" Surface Mount Downlight Black Trim ALSD-4-TRIM-SN 70575101 ALSD 4" Surface Mount Downlight Satin Nickel Trim ALSD-6-TRIM-BL 70576101 ALSD 6" Surface Mount Downlight Black Trim ALSD-6-TRIM-SN 70578101 ALSD 6" Surface Mount Downlight Satin Nickel Trim ALTAIR Surface Mount Downlight Accessories Trim Rings Friction Clips with E26 Adapter 23
Contact ETI etissl.com/contact-us ETI Customer Service 1-855-ETI-SSLI (1-855-384-7754) 720 Northgate Parkway Wheeling, IL 60090 www.etissl.com View our Full Catalog online Innovate. Illuminate. Inspire. ©2024 ETI Solid State Lighting
