EV Charger | SPEV by CIRCONTROL

Leading EV
Charging Solutions

European Technology | Made in Spain

SPEV EV Charger

SPEV by CIRCONTROL comprises a set of products and solutions designed to facilitate Electric
Vehicle (EV) charging. We aim to provide user-friendly solutions for electric vehicle charging in
different scenarios, such as urban streets, intercity roads and public or private car parks, for
multiple or single users.

Our product portfolio offers a wide product range that covers slow charging (AC) and fast
charging (DC). Circontrol is a European Leader in EVSE with a presence in 60 countries and
more than 3,500 DC chargers and 80,000 charging points installed worldwide.

e-Home Charger

The best quality-price ratio for domestic charging

Designed to be installed (both indoors and outdoors) at
private homes, communal blocks, companies and other
places where user authentication is not a requirement.

AC power supply 1P + N + PE
Maximum current 32 A
Maximum power 7.4 kW
Connection Type 2 Cable

e-Next Charger

The perfect EV charger for your needs

eNext has been designed to simplify the charging process. We
developed Presence Recognition, a feature that allows the
user to start charging without any interaction with the device.
As soon as the approved user is detected by Bluetooth and
the cable is connected to the car, the charging process starts.

AC power supply 3P + N + PE
Maximum current 32 A
Maximum power 22 kW
Connection Type 2 Cable

Designed to be installed
(both indoors and outdoors)
at private homes, communal

blocks, workplaces and car
parks.

www.smartpower.biz

e-Volve Charger

The perfect combination of robustness, design and communications

Designed to be installed in both public access environments
(urban spaces, shopping centres, car parks, airports, petrol
stations...) and private areas (companies, community car park
sites...) where its intelligent capabilities offer a range of possibilities
which improve the user and/or operator experience.

AC power supply 3P + N + PE Nowadays, the concept
Maximum current 32 A & 64 A of smart cities
Maximum power 22 kW & 44 kW demands an innovative
Connection Type 1 & 2 Cable design for urban
equipment, especially
for EVSE (EV Supply
Equipment) due to its
innovative nature. With
its stylised shape and
modern lines, the
eVolve series meets this
demand.

Raption DC Charger

The best solution for eBuses and petrol stations

Designed to be installed in road-side rest areas
and petrol stations where vehicles with large
batteries require high charging power to be
ready to continue their journey in less than half
hour and minimise charging time.

AC power supply 3P + N + PE
Maximum current 237A / 160A*
Maximum power 250A
Connection Type 2 , CCS 1 & 2

For more details, please visit www.smartpower.biz

Designed to address the main
problems identified by charge
point owners/ operators when
fast charging (low uptime), the
Raption 150 series is based on
state-of-the-art modular power

technology.

Leading EV Charging Solutions

Services

We measure success through the number of satisfied clients. Every day in every
way, we strive for constant improvement. And that has made all the difference.
SPEV is here for you. For clients big and small, we offer:

• 24/7 technical support
• 2 to 4 hours technical response within major cities
• Installation and service by experienced technicians
• Regular check-ups

EV Charger Rentals

Single vehicle charger rentals for short-term use. Our EV Supply Equipment and
Charging Service is available for rent. Suitable for event that require EV charging.
Charging options available for Audi, BMW, Chevy, Fiat, Ford, Hyundai, Honda,
Jaguar, Kia, Mercedes-Benz, Mitsubishi, Nissan and VW.

Benefits • No additional or hidden costs
• Zero capital outlay • 24/7 service support
• Zero maintenance costs • Upgrade or downgrade according to need
• No spare parts replacement

Warranty

• All products come with standard 2-year warranty
• 1-for-1 exchange in the unlikely event of a malfunction during thewarranty period[1]

[1]Terms and Conditions apply

OEM Recognition TR25 certified EU certified

For more info please contact

016 9339 123 | [email protected]
www.smartpower.biz

Wallbox eHome

The best quality-price ratio for domestic charging

Application

Designed to be installed (both indoors and outdoors) at
private homes, communal blocks, companies and other
places where user authentication is not a requirement.

Concept Design

Taking into account that a domestic charger is often
considered an appliance, an attractive design and a small
size are key attributes to be addressed.
The Wallbox eHome series also offers other attributes
such as low-cost, robustness, and user-friendly operation.

Product highlights • Its well-designed shape allows the cable to
be rolled up, keeping it tidy and protecting
• Compatible with the Home BeOn sensor it from breaking while the charger is not in
(accessory), when combined with eHome, use.
it is able to dynamically adjust the electric
vehicle’s consumption according to the • Simple user operation thanks to its
available power of the installation. This Plug ‘n’ Charge mode that avoids user
avoids the risk of a power cut and/or having authentication by means of an RFID card,
to upgrade the existing installation (resulting phone of equivalent method.
in a lower initial investment).
• This series also includes a selector switch
• The LED bar at the front not only informs that facilitates the setup of the charger’s
the user about the charger’s status (e.g. maximum output current (reducing
operative, faulty...), but also the EV charging installation time and cost).
status: charging (dynamic blue light) vs
charged (static blue light). • Remote charging activation is also offered
by means of an ON/OFF external input
• The door at the front with key access and signal (e.g. timer).
electrical protections (optional) not only
provides easy access in the event of a • The Wallbox eHome series features a
power cut, but also protects the user from reserved space in case you want to include
electric shocks. It can also be used as your own branding on it.
a user authentication method (using the
protection as an ON/OFF switch). • Several security protections are available
as optional, including 6mA DC leakage
• The charger’s housing is made of ABS detector.
plastic, which is both robust and UV
resistant, providing protection against • Communication RS485 Modbus in order
mechanical stress and severe environmental to integrate with external HEMS (Home
conditions (increasing the charger’s Energy Management Systems) for smart
lifespan, meaning it does not need to be management and monitoring purpose.
replaced in just a few years).

Wallbox eHome Series

Enclosure rating IP54 / IK10* Optional devices
Meter*
Enclosure material ABS-PCV0 Active Energy
Low temperature kit* Class 1 (IEC 62053-21)
Operating temperature -5 °C to +45 ºC Safety protection* -30 ºC to +45 ºC
RCD Type A (30mA) + 6mA DC
Ambient temperature storage -40 ºC to +60 ºC Power limit control** RCD Type B (30mA)
Cable support Home BeON sensor
Operating humidity 5% to 95% Non-condensing Customisation
Communication** Metallic holder
Light beacon RGB colour indicator *Not available for socket models. Logo customisation
**Single-phase models only. RS485 Modbus
Current setup Onboard DIP switch

Dimensions (D x W x H) 115x180x315 mm

Weight 4 kg

External input Remote charging activation

*IK08 in some components appended to the body, i.e., beacon light.

Model T1C32 T2C32 T2S32 T2C16 TRI T2S16 TRI
AC power supply 1P + N + PE 1P + N + PE 1P + N + PE 3P + N + PE 3P + N + PE
AC voltage 230 VAC +/-10% 230 VAC +/-10% 230 VAC +/-10% 400 VAC +/-10% 400 VAC +/-10%
Maximum current 32 A 32 A 32 A 16 A 16 A
Maximum power 7.4 kW 7.4 kW 7.4 kW 11 kW 11 kW
Connection Type 1 Cable Type 2 Cable Type 2 Socket Type 2 Cable Type 2 Socket

Home BeON Compatible
Intelligent sensor for single-phase installations

Home BeON is a new step forward in domestic EV charging,
allowing you to charge your vehicle while using your appliances.
Its intelligent sensor, easily added to the standard domestic
fuse box, dynamically adjusts electric vehicle’s consumption if
the home’s system is about to be overloaded.

Contracted Power

h h h h h h hh h h

Wallbox eNext

The perfect EV charger for your needs

Application

Designed to be installed (both indoors and outdoors) at private homes,
communal blocks, workplaces and car parks.

Concept Design

eNext has been designed to simplify the charging process. We
developed Presence Recognition, a feature that allows the user
to start charging without any interaction with the device. As soon
as the approved user is detected by Bluetooth and the cable is
connected to the car, the charging process starts.
In terms of the exterior design, we kept black and white as the
core design colours while introducing curved lines and rounded
shapes. The appropriate proportions and the perfect size, along
with the piano black combined with matt white makes the eNext
series the best choice to match any wall.

Product highlights

• An app to control and configure the eNext: • DC leakage detection can be ordered as an
language configuration, user authentication, optional extra. Thus, in conjunction with the
wallbox diagnosis and firmware upgrades, latching contactor and RCD A, the highest
among others. safety protection is guaranteed.

• Presence recognition via smartphone • Compatible with the Home BeOn sensor
Bluetooth, so user authentication is confirmed (accessory), when combined with eNext, it is
simply by proximity. able to dynamically adjust the electric vehicle’s
consumption according to the available power
• Remote charging activation is also offered by of the installation.
means of an ON/OFF external input signal (e.g.
timer). • The LED bar at the front not only informs the
user about the charger’s status (e.g. operative,
• Timetable programming to adjust the charging faulty...), but also the EV charging status:
session to the hourly energy rates. charging (dynamic blue light) vs charged
(static blue light).
• Ready for internal integration of electrical
protections. • The charger’s housing is made of ABS plastic,
which is both robust and UV resistant, providing
• Includes latching contactor detection that protection against mechanical stress and
meets with IEC 61851-1 for safety protection. severe environmental conditions.

• The Wallbox eNext series features a reserved
space in case you want to include your own
branding on it.

Wallbox eNext Series

Enclosure rating IP54 / IK10* Optional devices
Low temperature kit
Enclosure material ABS / PC Protections -30 ºC to +45 ºC
Operating temperature -5 °C to +45 ºC MCB (Curve C)
Ambient temperature storage -40 ºC to +60 ºC Power limit control* DC 6mA leakage detection
Operating humidity 5% to 95% Non-condensing Type 2 socket protection RCBO (RCD Type A + MCB)
Light beacon RGB colour indicator Home BeOn sensor
Power limit control Mode 3 PWM control according Tethered cable Locking System
to Shutter
ISO/IEC 61851-1 Pedestal Type 1 straight + cable roller
Customisation Type 1 spring + connector holder
Dimensions (D x W x H) 200 x 335 x 315 mm *Single-phase models only. Type 2 straight + cable roller
Weight 4 kg Type 2 spring + connector holder
External input Remote charging activation
Wireless communication Bluetooth v4.2 + BLE Logo customisation

*IK08 in some components appended to the body, i.e., beacon light.

Model S T
AC power supply 1P + N + PE 3P + N + PE

AC input voltage 230 VAC +/-10% 400 VAC +/- 10%
Maximum input current 32 A 32 A
Maximum input power 7.4 kW 22 kW
Number of plugs 1 1
Maximum output power per outlet 7.4 kW 22 kW

Maximum output current per outlet 32 A 32 A
AC output voltage 230 VAC (1P + N + PE) 400 VAC (3P + N + PE)
Socket Type 1 x Type 2 Socket 1 x Type 2 Socket

Pedestal Promotional Totem

A good choice A smart
when there is marketing tool
no wall. for car dealers,

showrooms,
exhibitions,

etc.
1500 mm
1550 mm

Material: Weight: Dimensions Material: Weight: Dimensions
Aluminium 5754 10 kg (H x W x D): Polystyrene 4 kg (H x W x D):
1500x373x150 mm (1.5 mm wide) 1550x400x250 mm

Wallbox eVolve Smart

The perfect combination of robustness, design and communications

Application

Designed to be installed in both public access environments (urban
spaces, shopping centres, car parks, airports, petrol stations...) and
private areas (companies, community car park sites...) where its
intelligent capabilities offer a range of possibilities which improve the
user and/or operator experience.

Concept Design

Nowadays, the concept of smart cities demands an innovative design
for urban equipment, especially for EVSE (EV Supply Equipment) due
to its innovative nature. With its stylised shape and modern lines, the
eVolve series meets this demand.

In addition, not only has the exterior design been taken into account,
but also the daily conditions (operational and environmental) that EVSE
has to withstand.

Product highlights
For Charge Point Operators / Owners For Charge Point Users

• The Integrated Load Management allows • Clear charging instructions and operating
for a lower TCO (Total Cost of Ownership) by status are shown using a backlit display,
charging two EVs simultaneously. increasing user satisfaction, especially useful
when the charger has been previously reserved
• The door at the front with key access provides by another user.
easy access to the interior of the charger which
results in a lower OPEX (operating expense) • eVolve series offers a ,
due to a quicker installation and service meaning that the user can authenticate either
(preventive/corrective). Moreover, it allows the before or after the cable to the EV. Additionally,
charger to be installed next to a wall, optimising the authentication process can also be
the available space. disabled for a Plug ‘n’ Charge mode.

• In terms of the charger’s housing, aluminium • Accessibility for disabled users has also
and ABS plastic have been combined in been considered, complying with international
a robust structural design that provides standards regarding the height of connectors/
protection against both mechanical stress and displays, facilitating their use.
severe environmental conditions, increasing the
charger’s lifespan, meaning it will not need to • The eVolve series includes the necessary
be replaces after just a few years. electrical protections (optional) not only to
minimise the human safety risk of electrical
• In terms of communication, either through shocks but also to ensure the maximum
the Ethernet port (by default) or 4G/3G/ uptime thanks to independent protections per
GPRS modem (optional), the charger can be connector.
connected to a back-office system (by means
of OCPP), obtaining benefits such as user
management, billing, remote error diagnostics,
etc.

• To comply with the most demanding
requirements regarding billing, the eVolve
series includes

• Available in two sizes, a small one with no
protections and a large one with protections.

Wallbox eVolve Smart Series

Network connection 10/100BaseTX (TCP-IP) Meter MID Class 1 - EN50470-3
Interface protocol Power output management Integrated Load Management
Enclosure rating OCPP 1.5 or OCPP 1.6J Type 2 socket protection Locking System
Enclosure material IP54 / IK10 Compatible with DLM
Enclosure door lock Aluminium & ABS
Enclosure access Key lock Optional devices
Operating temperature Frontal door
Ambient temperature storage -5 °C to + 45 ºC Low temperature kit -30 ºC to +45 ºC
Operating humidity -40 ºC to + 60 ºC Overcurrent protection* MCB (curve C)
Light beacon 5% to 95% Non-condensing Electrical protection* RCD Type A (30mA)
Display RGB colour indicator RCD Type A (30mA) + 6mA DC
Power limit control Multi-language LCD RCD Type B (30mA)
Mode 3 PWM control according to Autorecovery function optional**
Dimensions (D x W x H) ISO/IEC 61851-1
Small: 222x382x628 mm Type 2 socket protection Shutter
Weight (Model S & T without protections) Wireless Communication 4G / 3G / GPRS / GSM
Large: 222x382x928 mm Tethered Cable (spring) * Type 1 + Type 1
RFID Reader Small: 25 kg (Cable length: 4 m) Type 2 + Type 2
Large: 30 kg Type 2 + Type 2 Socket
ISO / IEC14443A / B
MIFARE Classic/DESFire EV1 RFID Extension Legic Advant / Legic Prime
ISO 18092 / ECMA-340 ISO 15693 / ISO 18092, Sony FeliCa
NFC 13.56MHz
Customisation Frontal Labelling

Anti-vandal key

*Not available in the TM4 model
**As per directive this function is not available for cable. It is also not
compatible with the “RCD Type A + 6mA DC” option.

Model S One T One S T TM4 16 A
AC power supply 1P + N + PE 3P + N + PE 1P + N + PE 3P + N + PE 3P + N + PE
AC input voltage 230 VAC +/-10% 400 VAC +/-10% 230 VAC +/-10% 400 VAC +/-10% 400 VAC +/-10%
Maximum input current 32 A 32 A 64 A 64 A 64 A
Maximum input power 7.4 kW 22 kW 14.7 kW 44 kW 44 kW
Number of plugs 1 1 2 2 4
32 A 32 A 32 A 32 A 32 A
Maximum 7.4 kW 22 kW
Outlet Aoutput current 230 VAC 400 VAC 7.4 kW 22 kW 22 kW 3.7 kW
Maximum (1P + N + PE) (3P + N + PE)
output power 230 VAC 400 VAC 400 VAC 230 VAC
AC output No No (1P + N + PE) (3P + N + PE) (3P + N + PE) (1P + N + PE)
voltage Yes Yes 32 A 32 A 32 A 16 A
Maximum Type 2 Socket Type 2 Socket
Outlet Boutput current (lock system) (lock system) 7.4 kW 22 kW 22 kW 3.7 kW
Maximum
output power 230 VAC 400 VAC 400 VAC 230 VAC
AC output (1P + N + PE) (3P + N + PE) (3P + N + PE) (1P + N + PE)
voltage No No
Protections Small Yes Yes Not Available
2x Type 2 Socket 2x Type 2 Socket
Large (lock system) (lock system) No
Connection
2x Type 2 Socket 2x CEE/7
(lock system)

A A AB AB A B

Post eVolve Smart

The most suitable charger for urban environments

Application

Designed to be installed in both public access environments (urban spaces,
shopping centres, car parks, airports, petrol stations...) and private areas
(companies, community car park sites...) where its intelligent capabilities offer
a range of possibilities which improve the user and/or operator experience.

Concept Design

Nowadays, the concept of smart cities demands an innovative design for
its urban equipment, especially for EVSE (EV Supply Equipment) due to its
innovative nature. With its stylised shape and modern lines, the eVolve series
meets this demand.

In addition, not only has the exterior design been taken into account, but
also the daily conditions (operational and environmental) that EVSE has to
withstand.

Product highlights
For Charge Point Operators / Owners For Charge Point Users

• The Integrated Load Management allows • Clear charging instructions and operating
for a lower TCO (Total Cost of Ownership) by status are shown using a backlit display,
charging two EVs simultaneously even when increasing user satisfaction, especially useful
the charger is not supplied with its maximum when the charger has been previously reserved
output power. by another user.

• The door at the front with key access provides • eVolve series offers a ,
an access to the interior of the charger which meaning that the user can authenticate either
results in a lower OPEX (operating expense) before or after the cable to the EV. Additionally,
due to a quicker installation and service the authentication process can also be
(preventive/corrective). Moreover, it allows the disabled for a Plug ‘n’ Charge mode.
charger to be installed next to a wall, optimising
the available space. • Accessibility for disabled users has also
been considered, complying with international
• In terms of the charger’s housing, aluminium standards regarding the height of connectors/
and ABS plastic have been combined in displays, facilitating their use.
a robust structural design that provides
protection against both mechanical stress and • The eVolve series includes the necessary
severe environmental conditions, increasing the electrical protections not only to minimise
charger’s lifespan, meaning it will not need to the human safety risk of electrical shock, but
be replaces after just a few years. also to ensure the maximum uptime thanks to
independent protections per connector.
• In terms of communication, either through
the Ethernet port (by default) or 4G/3G/
GPRS modem (optional), the charger can be
connected to a back-office system (by means
of OCPP), obtaining benefits such as user
management, billing, remote error diagnostics,
etc.

• To comply with the most demanding
requirements regarding billing, the eVolve
series includes

Post eVolve Smart Series

Network connection 10/100BaseTX (TCP-IP) Overcurrent protection MCB (curve C)
Interface protocol Safety protection RCD Type A (30mA)
Enclosure rating OCPP 1.5 or OCPP 1.6J Autorecovery function optional*
Enclosure material IP54 / IK10
Enclosure door lock Aluminium & ABS Type 2 socket protection Locking System
Enclosure access Key lock
Operating temperature Frontal door Compatible with DLM
Ambient temperature storage -5 °C to +45 ºC
Operating humidity -40 ºC to +60 ºC Optional devices
Light beacon 5% to 95% Non-condensing
Display RGB colour indicator Low temperature kit -30 ºC to +45 ºC
Power limit control Multi-language LCD Safety protection RCD Type A (30mA) + 6mA DC
Mode 3 PWM control according to RCD Type B (30mA) with
Dimensions (D x W x H) ISO/IEC 61851-1 autorecovery function optional*
Weight 290x450x1550 mm
RFID Reader 55 kg Surge protection Four pole transient surge protector
ISO / IEC14443A / B IEC 61643-1 (class II)
Meter MIFARE Classic/DESFire EV1
Power output management ISO 18092 / ECMA-340 Type 2 charging socket Shutter
NFC 13.56MHz Wireless Communication 4G / 3G / GPRS / GSM
MID Class 1 - EN50470-3
Integrated Load Management Anti-vandal key

Anti-vandal door Not available for TM4

Tethered Cable (spring) Type 1 + Type 1
(Cable length: 4 m) Type 2+ Type 2
Type 2 + Type 2 Socket

RFID Extension Legic Advant / Legic Prime
ISO 15693 / ISO 18092, Sony FeliCa

Customisation Frontal Labelling

*As per regulations this function is not available for cable. It is also not
compatible with the “RCD Type A + 6mA DC” option.

Model S One T One C63 One S T TM4
AC power supply 1P + N + PE 3P + N + PE 3P + N + PE 1P + N + PE 3P + N + PE 3P + N + PE
AC input voltage 230 VAC +/-10% 400 VAC +/-10% 400 VAC +/-10% 230 VAC +/-10% 400 VAC +/-10% 400 VAC +/-10%
Maximum input 32 A 32 A 63 A 64 A 64 A 64 A
current
Maximum input 7.4 kW 22 kW 43 kW 14.7 kW 44 kW 44 kW
power
Number of plugs 1 1 1 2 2 4* 16 A
32 A 32 A 63 A 32 A 32 A 32 A
Maximum
Outlet Aoutput current 7.4 kW 22 kW 43 kW 7.4 kW 22 kW 22 kW 3.7 kW
Maximum
output power 230 VAC 400 VAC 400 VAC 230 VAC 400 VAC 400 VAC 230 VAC
AC output (1P + N + PE) (3P + N + PE) (3P + N + PE) (1P + N + PE) (3P + N + PE) (3P + N + PE) (1P + N + PE)
voltage 32 A 32 A 32 A 16 A

Maximum
output current

Outlet B Maximum 7.4 kW 22 kW 22 kW 3.7 kW
output power

AC output Type 2 Socket Type 2 Socket Type 2 Cable 230 VAC 400 VAC 400 VAC 230 VAC
voltage (lock system) (lock system) (4m) (1P + N + PE) (3P + N + PE) (3P + N + PE) (1P + N + PE)
Connection 2x Type 2 Socket 2x Type 2 Socket 2x Type 2 2x CEE/7
(lock system) (lock system) Socket (lock
system)

AA A AB AB AB
* Exclusive use type 2 or
Customisation Examples
CEE/7 per outlet
The eVolve series features a
broad frontal panel that can be
easily customised.

Raption 50

The perfect combination of power, design and reliability

Application

Designed to be installed in both public access environments (urban
spaces, shopping centres, airports, road-side rest areas...) and private
areas (companies with EV fleets, taxi ranks...) where vehicles need to
be ready to continue their journey in less than half an hour.

Concept Design

Designed to address the main problem identified by charge point
owners/ operators when fast charging (low uptime), the Raption 50
series is bases on state-of-the-art modular power technology.
Another key attribute considered was its exterior design. Sophisticated,
slim and robust are just some adjectives that can be used to describe
this series and features that make it ideal for any type of site (from the
most stylish urban area to industrial sites).

Product highlights For Charge Point Users
For Charge Point Operators / Owners

• Its modular power technology ensures a very high • Its 8” anti-vandal daylight readable
uptime (reducing the non-operation expenditure), colour touchscreen not only provides
because in the event of a power module failure, the clear charging instructions (e.g. incorrect
rest of the modules continue charging. EV shift position to start the charge) and
operating status (e.g. reserved charge
• Lower energy consumption (and therefore OPEX) is point), but it also allows the user to select
achieved due to a from several languages.
resulting from disconnecting power modules when
lower charging power is requested by the EV. • User satisfaction is also increased due
to its built-in courtesy light which both
• The modular architecture allows power scalability facilitates locating the charge point in dark
from 25 kW to 50 kW to meet present and future EV areas and reading the messages included
battery demands. on operator instruction labels.

• It offers a unique connector care concept by means • Accessibility for disabled users has
of the connector locking feature (optional) and also been considered, complying with
floating cable design, which reduces the risk of the international standards regarding the
cable breaking. height of connectors/ displays, facilitating
their use.
• The double door at the front with key access
provides an easy access to the charger for quicker • Integrated contactless payment system:
installation and service. Moreover, it allows the Offers an easy, intuitive and contactless
charger to be installed next to a wall, optimising the card payment experience.
available space.

• Possible to configure as a Master for the Master-
Slave solution (p. 22).

• 480 V model available for Mexico and other
countries in Latin America.

Raption 50 Series

AC Power Supply 3P + N + PE DC cable length CCS 3 metres
AC Voltage 400V AC +/- 10% DC cable length CHAdeMO 3 metres
Power Factor >0.98 AC cable length 3 metres
95% at nominal output power Lights for status indication RGB colour indicator
Frequency 50 / 60 Hz Dimensions (D x W x H) 355x940x1800 mm (without cable engaged)
Electrical input protection Main breaker disconnection Weight 235 kg
Overcurrent protection MCB Cooling system Air cooling fans
Safety protection RCD Type B Operational noise level < 55 dBA
Network connection Ethernet 10/100BaseTX AC Meter Compliant with the EN 50470-1
Interface protocol OCPP 1.5 or OCPP 1.6J and EN 50470-3 (MID European
Compliance CE / Combo-2 Wireless Communication EU standards) or IEC 62052-11
(DIN 70121; ISO15118) Optional devices 4G LTE/WiFi Hotspot/GPRS/GSM
Enclosure rating IEC 61851-1; IEC 61851-23; Wireless Communication
Enclosure material IEC 61851-21-2 Surge protection LATAM/APAC/4G LTE/GPRS/GSM
Operating temperature CHAdeMO compatible Four pole transient surge protector
Ambient temperature sto- IP54 / IK10 Cable Length IEC 61643-1 (class II)
rage Stainless steel Anti-vandal connector 5.5 metres (all cables)
Operating humidity -30 ºC to +50 ºC protection CHAdeMO, CCS
Socket protection -40 ºC to +60 ºC Type 2 charging socket (mechanical connector locking)
RFID system 25 kW DC version Shutter
5% to 95% Non-condensing Network hub Power output DC of 25 kW
Display HMI Locking System Switch TCP ethernet 8 ports
Power limit control ISO / IEC14443-1/2/3 RFID Extension Switch TCP ethernet 12 ports
MIFARE Classic Legic Advant / Legic Prime
8” anti-vandal colour touchscreen Contactless payment* ISO 15693/ISO 18092. Sony FeliCa
DC & AC by software * Ask for availability. Integrated credit card payment terminal

Models CCS CCS T2C32 CCS T2S32
Maximum AC input current 76 A (38 A*) 108 A (70 A*) 108 A (70 A*)
Required power supply capacity 53 kVA (26 kVA*) 75 kVA (48 kVA*) 75 kVA (48 kVA*)
Maximum output power 50 kW (25 kW*) DC: 50 kW (25 kW*) DC: 50 kW (25 kW*)
(@400 VDC) (@400 VDC) (@400 VDC)
AC: 22 kW AC: 22 kW
Output voltage range DC: 50 - 500 V DC: 50 - 500 V DC: 50 - 500 V
Maximum output current DC: 125 A (63 A*) AC: 400 V AC: 400 V
Connection CCS 2 DC: 125A (63 A*) DC: 125A (63 A*)
AC: 32 A AC: 32 A
CCS 2 CCS 2
Type 2 Tethered cable Type 2 Socket (Lock system)

Models CCS CHA CCS CHA T2S32 CCS CHA T2C32 CCS CHA T2C63
Maximum AC input current 76 A (38 A*) 108 A (70 A*) 108 A (70 A*) 138 A (101 A*)
Required power supply capacity 53 kVA (26 kVA*) 75 kVA (48 kVA*) 75 kVA (48 kVA*) 96 kVA (70 kVA*)
50 kW (25 kW*) DC: 50 kW (25 kW*) DC: 50 kW (25 kW*) DC: 50 kW (25 kW*)
Maximum output power (@400 VDC) (@400 VDC) (@400 VDC) (@400 VDC)
AC: 22 kW AC: 22 kW AC: 43 kW
Output voltage range DC: 50 - 500 V DC: 50 - 500 V DC: 50 - 500 V DC: 50 - 500 V
AC: 400 V AC: 400 V AC: 400 V
Maximum output current DC: 125 A (63 A*) DC: 125 A (63 A*) DC: 125 A (63 A*) DC: 125 A (63 A*)
AC: 32 A AC: 32 A AC: 63 A
Connection CCS 2 - JEVS G105 CCS 2 - JEVS G105 CCS 2 - JEVS G105 CCS 2 - JEVS G105
Type 2 Socket (Lock system) Type 2 Tethered cable Type 2 Tethered cable

* 25 kW DC version

Raption 100

Ideal to satisfy the rapid charging needs of new EVs

Application

Designed to be installed in both public access spaces (urban and
inter-urban spaces, service areas...) and private ones (EV fleets,
taxi ranks...) where EVs need to minimise their charge times as
much as possible.

Concept Design

Designed to satisfy the rapid charging needs of new EV models
with larger batteries capable of offering greater autonomy, but
without sacrificing the design nor most of the features that defined
its predecessor, the Raption 50: modular power technology, elegant
yet robust design, user-friendliness and reliability.

Product highlights For Charge Point Users
For Charge Point Operators / Owners

• Greater charging power: Its 25 kW charging • 8-inch colour touch screen: The user
modules allow it to offer up to 100 kW, doubling the receives clear charging instructions as well
charging power of the Raption 50. as the connector status on the touch screen.
It also allows the user to select from several
• Its modular architecture languages.
allows for power scalability of 50 kW or 100 kW
depending on the contracted power, and for this • Built-in courtesy light: Facilitates locating
power to be adapted to the growing battery sizes the charge point in dark areas and reading
of new EV models. Furthermore, the modular the operator instructions.
power guarantees very high uptime, as if one of
the modules fails, the others will keep working. • Accessibility: The height of the connectors
Likewise, when an EV needs less charging and the screen have been adapted to
power, modules can be disconnected and energy comply with standards in order to improve
consumption reduced thanks to its sustained accessibility for disabled people.
efficiency.
• Integrated contactless payment system:
• Compact and 100% customisable design: It Offers an easy, intuitive and contactless card
maintains the elegant, high-quality and robust payment experience.
enclosure of the Raption 50, one of the most highly
rated charge points on the market.

• Reduced OPEX: It maintains features such as the
connector locking and the floating cable design,
which result in increased durability. Furthermore,
the door at the front with key access reduces
repair and maintenance times and allows the
charger to be installed next to a wall, optimising
the available space.

• Can be configured as
a Master for multi-point solutions.

Raption 100 Series

AC Power Supply 3P + N + PE DC cable length CHAdeMO 3 metres
AC Voltage 400V AC +/- 10%
Power Factor >0.98 AC cable length 3 metres
95% at nominal output power
Frequency 50 / 60 Hz Lights for status indication RGB colour indicator
Electrical input protection Main breaker disconnection
Overcurrent protection MCB Dimensions (D x W x H) 355x940x1800 mm (without cable engaged)
Safety protection RCD Type B
Network connection Ethernet 10/100BaseTX Weight 255 kg
Interface protocol OCPP 1.5 or OCPP 1.6J
Compliance CE / Combo-2 Cooling system Air cooling fans
(DIN 70121; ISO15118)
Enclosure rating IEC 61851-1; IEC 61851-23; Operational noise level < 55 dBA
Enclosure material IEC 61851-21-2
Operating temperature CHAdeMO compatible AC Meter Compliant with the EN 50470-1
Ambient temperature sto- IP54 / IK10 and EN 50470-3 (MID European
rage Stainless steel standards) or IEC 62052-11
Operating humidity -30 ºC to +50 ºC
Socket protection -40 ºC to +60 ºC Wireless Communication EU 4G LTE/WiFi Hotspot/GPRS/GSM
RFID system
5% to 95% Non-condensing Optional devices
Display HMI Locking System
Power limit control ISO / IEC14443-1/2/3 Wireless Communication LATAM/APAC/4G LTE/GPRS/GSM
DC cable length CCS MIFARE Classic
8” anti-vandal colour touchscreen Surge protection Four pole transient surge protector
DC & AC by software IEC 61643-1 (class II)
3 metres
Cable Length 5.5 metres (all cables)

CHAdeMo cable upgrade 200 A (100 kW)*

Anti-vandal connector CHAdeMO, CCS
protection (mechanical connector locking)

Type 2 charging socket Shutter

50 kW DC version Power output DC of 50 kW

Network hub Switch TCP ethernet 8 ports

Switch TCP ethernet 12 ports

RFID Extension Legic Advant / Legic Prime
ISO 15693/ISO 18092. Sony FeliCa

Contactless payment** Integrated credit card payment terminal

* HW ready SW available within 2021.
** Ask for availability.

Models CCS CCS T2C32 CCS T2S32
Maximum AC input current 160 A 192 A 192 A
Required power supply capacity 110 kVA 132 kVA 132 kVA
Maximum output power 100 kW DC: 100 kW DC: 100 kW
AC: 22 kW AC: 22 kW
Output voltage range DC: 150 - 920 V
Maximum output current DC: 250 A DC: 150 - 920 V DC: 150 - 920 V
Connection CCS 2 AC: 400 V AC: 400 V
DC: 250 A DC: 250 A
AC: 32 A AC: 32 A
CCS 2 CCS 2
Type 2 Tethered cable Type 2 Socket (Lock system)

Models CCS CHA CCS CHA T2C32 CCS CHA T2S32
Maximum AC input current 160 A 192 A 192 A
Required power supply capacity 110 kVA 132 kVA 132 kVA
CCS 100 kW DC: CSS 100 kW / CHA 50 kW DC: CSS 100 kW / CHA 50 kW
Maximum output power CHA 50 kW AC: 22 kW AC: 22 kW

Output voltage range DC: 150 - 920 V DC: 150 - 920 V DC: 150 - 920 V
AC: 400 V AC: 400 V
Maximum output current DC: CSS 250 A / CHA 125 A DC: CSS 250 A / CHA 125 A DC: CSS 250 A / CHA 125 A
AC: 32 A AC: 32 A
Connection CCS 2 - JEVS G105 CCS 2 - JEVS G105 CCS 2 - JEVS G105
Type 2 Tethered cable Type 2 Socket (Lock system)

Raption 150

The best solution for eBuses and petrol stations

Application

Designed to be installed in road-side rest areas and petrol
stations where vehicles with large batteries require high
charging power to be ready to continue their journey in less
than half hour and minimise charging time.

Concept Design

Designed to address the main problems identified by charge
point owners/ operators when fast charging (low uptime),
the Raption 150 series is based on state-of-the-art modular
power technology.

Another key attribute considered was the exterior design.
Sophisticated, slim and robust are just some adjectives that
can be used to describe this series features that make it
ideal for any type of site (from the most stylish urban areas to
industrial ones). The Raption 150’s modular architecture allows
power scalability from 100 kW to 150 kW.

Product highlights For Charge Point Users
For Charge Point Operators / Owners

• SatimthueltsaanmeeoutismDe Cbycshpalritgtiengabthlee to charge 2 EVs • cIdthsaay8rl”gigianhngttrii-envasatdrnuadcbatlileocnnosolto(eou.ngrl.ytoinpucrcoohvrrisdeccertseEecVnlear
available power position to start the charge) and operating
(e.g. 75 kW + 75 kW). status (e.g. reserved charge point), but
also allows the user to select from several
• Ihtsigmh oupdtuimlaersp(orewdeurctiencghtnhoelnoogny-oepnesuraretison languages.
expenditure), because in the event of a power
module failure, the rest of the modules continue • User satisfaction is also increased due to its
charging. lboucialtt-iningcthoeurctheasrygleigphotinwthinichdabroktharfeaacsiliatantdes
reading the messages included on operating
• Lower energy consumption (and therefore OPEX) instruction labels.
is achieved due to a
wlehveenl resulting from disconnecting power modules
EV. lower charging power is requested by the • aAlcscoebseseibnilcitoynsfoidredreisda,bcloemd pulsyeinrgs has
with
• The modular architecture allows power international standards regarding the height
scalability, so two models are possible; of connectors/ displays, facilitating their use.
Raption 150 Lite (max output 100 kW) and
Raption 150 (max output 150 kW). • The Raption series can be optionally
cteeaqrrumdipianpnaedldteownfihtahacnailcintaeitnethtepegaurysameterednetxpspabeyyrmiecnerecndet i.t Our
• It offers a tuhneiqcuoennceocntnoer clotockricnagrfeeactounrece(oppt tbioynal) payment terminal allows payment without a
means of membership model and can operate with or
and floating cable design, which reduces the without a back-office platform.
risk of the cable breaking (i.e., lower OPEX and
higher uptime).

• aTchceedsosotroatthteheintferorniotrwoifththkeecyhaacrgceesr swhpircohvirdeessults
in a lower OPEX due to quicker installation and
servicing (preventive/corrective). Moreover, it
allows the charger to be installed next to a wall,
optimising the available space.

• Possible to configure as a Master for the Master-
Slave solution.

Raption 150 Series

Compliance CE / Combo-2 Power Unit
(DIN 70121; ISO15118)
IEC 61851-1; IEC 61851-23; AC power supply 3P + N + PE
IEC 61851-21-2
CHAdeMO compatible AC Voltage 400V AC +/- 10%

Maximum AC input current 237A / 160A*

Enclosure rating IP54 / IK10 Required power supply 163kVA / 110kVA*
capacity
Enclosure material Stainless steel Power Factor (pu) >0.98
94% at nominal output power
Operating temperature -10 ºC to + 50 ºC

Ambient temperature storage - 20 ºC to + 60 ºC Frequency (pu) 50 / 60 Hz
Cooling system Forced air
Operating humidity 5% to 95% Non-condensing Operational noise level < 55 dBA
Electrical input protection Main circuit disconnection
Network connection Dispenser Overcurrent protection MCB
Interface protocol Safety protection (pu) RCD Type B
RFID system Ethernet 10/100BaseTX Dimensions (D x W x H) 800x1000x2100 mm
Weight 420 kg
OCPP 1.5 or OCPP 1.6J Optional devices
Wireless Communication LATAM/APAC/4G LTE /GPRS/GSM
ISO / IEC14443-1/2/3 Surge protection Four pole transient surge protector
MIFARE Classic IEC 61643-1 (class II)
Cable Length 5.3 metres (all cables)
Display HMI 8" anti-vandal colour touchscreen Anti-vandal connector CHAdeMO, CCS
protection (mechanical connector locking)
Power limit control DC by software RFID Extension Legic Advant / Legic Prime
ISO 15693/ISO 18092. Sony FeliCa
DC cable length CCS 3.4 metres Low Temperature Kit -30ºC to +50ºC
Contactless payment** Integrated credit card payment terminal
DC cable length CHAdeMO 3.4 metres *Raption 150 Lite Models
Lights for status indication RGB colours indicator **Ask for availability.

Dimensions (D x W x H) 378x420x2067mm

Weight 115 kg
Operational noise level Not perceptible
AC Meter Compliant with the EN 50470-1
and EN 50470-3 (MID European
standards) or IEC 62052-11

Wireless Communication EU 4G LTE /WiFi Hotspot/GPRS/GSM

Raption 150 Models CCS250 (1) CCS200 CHA125 CCS250 CHA200 CCS250 CCS250 (1)
Maximum output power CCS: 150 kW (2) CCS: 150 kW (3) CCS: 150 kW (2) CCS: 150 kW (2)
CHA: 50 kW CHA: 50 kW (4) CCS: 150 kW (2)
Output voltage range CCS: 100-920V CCS: 100-920V
Maximum output current CCS: 100-920V CCS: 100-920V CCS: 100-920V
Connection CCS: 250A CHA: 100-500V CHA: 100-500V CCS: 250A
CCS: 200A CCS: 250A CCS: 250A
CHA: 125A CHA: 200A
CCS250 CCS250 (1)
(1) Also available with cable of 200 A (max output power: 150 kW @920 V or 80 kW @400 V) CCS: 100 kW
(2) 150 kW @720-920V or 100 kW @400V CCS: 100 kW
(3) 150 kW @750-920V or 80 kW @400V CCS: 100-920V
(4) HW suitable for up to 100 kW following FW update CCS: 100-920V
CCS: 250A
Raption 150 Lite Models CCS250 (1) CCS200 CHA125 CCS250 CHA200 CCS: 250A
Maximum output power CCS: 100 kW (2) CCS: 100 kW (2) CCS: 100 kW
CHA: 50 kW CHA: 50 kW (3)

Output voltage range CCS: 100-920V CCS: 100-920V CCS: 100-920V
Maximum output current CCS: 250A CHA: 100-500V CHA: 100-500V
CCS: 200A CCS: 250A
CHA: 125A CHA: 200A

Connection

(1) Also available with cable of 200 A (max output power: 100 kW @920 V or 80 kW @400 V)
(2) 80 kW @400V
(3) HW suitable for up to 100 kW following FW update

Fast, safe & eco-friend ly HIGH-QUALITY UV GERMICIDAL LIGHTS

ULTRAVIOLET-C
DISINFECTION

KILL 99.9% OF COVID 19 VIRUSES & BATERIA

For more info please contact

Tafri: 012 660 3207 | [email protected]

SMART POWER INNOVATION

Intergrated Flexible Medical
UPS & IPS system

For more info please contact

Nizam: 016 416 7628 | [email protected]

SUPERCAPACITOR

For more info please contact

Jepp: 012 969 7628 | [email protected]

LiFePO4 Battery

Smart Bluetooth inside, Pioneer Tech In The World

For more info please contact

Khairul : 016 512 9951 | [email protected]

DATA CENTER
SOLUTION

For more info please contact

Khairul : 016 512 9951 | [email protected]
