STANDARD TELECOM PDC UNITS

STANDARD DC POWER DISTRIBUTION
PRODUCTS FOR 54V DC TELECOMS SYSTEMS

2020

Edition 2.1

Design & Manufacture's of:

| AC Switchgear | DC Switchgear | Bespoke Control Panels | AC & DC PDC’s & PDU’s |
| Copper Junction Boxes | Marshalling Panels | Transition Boxes | Earth Bars |

1 Table of Contents

Page Introduction
2 Wall Mounted Single Feed 10 Way DC Distribution Board
3 Wall Mounted Dual Feed 10 Way DC Distribution Board
5 Wall Mounted Single Feed 15 Way DC Distribution Board
7 Wall Mounted Dual Feed 15 Way DC Distribution Board
9 40 Way Dual Floor Standing Front & Rear Access Power
11 Distribution Centres (PDC’s)
40 Way Dual Wall Mounting Front Access Power Distribution
13 Centres (PDC’s)
24 Way Dual Wall Mounting Front Access Power Distribution
15 Centres (PDC’s)
Battery LVD Units (Low Volt Disconnects)
17 Battery Fuse Boxes & Transition Boxes)
19

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

A M Joynes Standard DC Distribution Boards

Our Standard range of DC Distribution products cater for all aspects of the
Telecoms Power Distribution requirements.

From smaller 300A single input wall mounting 10 way distribution, to 1200A dual
Input floor standing 40 way distribution boards .

We also have a range of Battery fused transition boxes, along with a range of battery
low volt disconnects to protect your batteries from being damaged through deep
discharge.

All of our boards have a unique facility allowing all the outgoing circuits to be “hot
swappable”, without the need to power down.

Ample cable space , with suitable containment, always being provided to ensure a
neat and easy installation for the power engineers.

Various metering options are available throughout the range, from simple analogue
metering, to full digital multi-metering with comms output, for web browsing.

Having a large copper holding, with all ancillary materials in stock, we can offer a
bespoke service with quick turn arounds, if our Standard Range doesn't suit your
needs please get in touch to see how we can help your project as we have the
capability to build DC Distribution Boards upto 20,000A DC

tel: 01455 234996 / 01455 616686 email: [email protected] 2

email: [email protected]

3 Wall Mounted Single Feed 10 Way
DC Distribution Board

• Wall Mounting front access 600mm High x 500mm Wide x 260mm Deep Enclosure
Size in RAL 7035 (other colours available on request please add £215.00 to price)

• 300Amp, 400Amp , 500Amp or 600Amp 54V DC Range (please specify)
• To accept 10 off up to 125amp C120H MCB’s

• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with
RS 485 comms output

• Supplied with or with out C120H 100amp Type “C” MCB’s
• All MCB’s hot swappable without the need to isolate
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• Other colours available on request, please add £215.00 to prices - 7 Week lead time

Part Number Description MCB’s Lead Price
Time
***A/10/W/S/A/N ***A 10way single feed, with amp meter (ex VAT & Delivery)
***A/10/W/S/A/Y ***A 10way single feed, with amp meter
***A/10/W/S/V/N ***A 10way single feed, with volt meter NO 2-3 weeks £1,388.97
***A/10/W/S/V/Y ***A 10way single feed, with volt meter
***A/10/W/S/AV/N ***A 10way single feed, with amp & volt meter YES 2-3 weeks £1,825.21
***A/10/W/S/AV/Y
***A/10/W/S/RS/N NO 2-3 weeks £1,388.97

***A/10/W/S/RS/Y YES 2-3 weeks £1,825.21

NO 2-3 weeks £1,465.02

***A 10way single feed, with amp & volt meter YES 2-3 weeks £1,901.26

***A 10way single feed, with DC Multimeter & RS485 NO 2-3 weeks £1,910.52
comms module

***A 10way single feed, with DC Multimeter & RS485 YES 2-3 weeks £2,346.76
comms module

***PLEASE STATE EITHER 300A/400A/500A/600A—Eg: 400A/10/W/S/A/N (400amp 10 way single board with amp meter no mcb’s)

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]



5 Wall Mounted Dual Feed 10 Way
DC Distribution Board

• Wall Mounting front access 1200mm High x 500mm Wide x 260mm Deep Enclosure
Size in RAL 7035 (other colours available on request please add £300.00 to price)

• 300Amp, 400Amp , 500Amp or 600Amp 54V DC Range (please specify)
• To accept 10 off up to 125amp C120H MCB’s

• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with
RS 485 comms output

• Supplied with or with out C120H 100amp Type “C” MCB’s
• All MCB’s hot swappable without the need to isolate
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• Other colours available on request, please add £300.00 to prices - 7 Week lead time

Part Number Description MCB’s Lead Price
Time
***A/10/W/D/A/N ***A 10way dual feed, with amp meter (ex VAT & Delivery)
***A/10/W/D/A/Y ***A 10way dual feed, with amp meter
***A/10/W/D/V/N ***A 10way dual feed, with volt meter NO 2-3 weeks £2,777.94
***A/10/W/D/V/Y ***A 10way dual feed, with volt meter
***A/10/W/D/AV/N ***A 10way dual feed, with amp & volt meter YES 2-3 weeks £3,650.42
***A/10/W/D/AV/Y
***A/10/W/D/RS/N NO 2-3 weeks £2,777.94

***A/10/W/D/RS/Y YES 2-3 weeks £3,650.42

NO 2-3 weeks £2,930.03

***A 10way dual feed, with amp & volt meter YES 2-3 weeks £3,802.51

***A 10way dual feed, with DC Multimeter & RS485 NO 2-3 weeks £3,821.05
comms module

***A 10way dual feed, with DC Multimeter & RS485 YES 2-3 weeks £4,693.53
comms module

***PLEASE STATE EITHER 300A/400A/500A/600A—Eg: 400A/10/W/D/A/N (400amp 10 way dual board with amp meter no mcb’s)

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

26

7 Wall Mounted Single Feed 15 Way
DC Distribution Board

• Wall Mounting front access 800mm High x 600mm Wide x 260mm Deep Enclosure
Size in RAL 7035 (other colours available on request please add £215.00 to price)

• 300Amp, 400Amp , 500Amp or 600Amp 54V DC Range (please specify)
• To accept 15 off up to 125amp C120H MCB’s

• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with
RS 485 comms output

• Supplied with or with out C120H 100amp Type “C” MCB’s
• All MCB’s hot swappable without the need to isolate
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• Other colours available on request, please add £215.00 to prices - 7 Week lead time

Part Number Description MCB’s Lead Price
Time
***A/15/W/S/A/N ***A 15way single feed, with amp meter (ex VAT & Delivery)
***A/15/W/S/A/Y ***A 15way single feed, with amp meter
***A/15/W/S/V/N ***A 15way single feed, with volt meter NO 2-3 weeks £1,560.69
***A/15/W/S/V/Y ***A 15way single feed, with volt meter
***A/15/W/S/AV/N ***A 15way single feed, with amp & volt meter YES 2-3 weeks £1,996.93
***A/15/W/S/AV/Y
***A/15/W/S/RS/N NO 2-3 weeks £1,560.69

***A/15/W/S/RS/Y YES 2-3 weeks £1,996.93

NO 2-3 weeks £1,636.73

***A 15way single feed, with amp & volt meter YES 2-3 weeks £2,072.97

***A 15way single feed, with DC Multimeter & RS485 NO 2-3 weeks £2,082.23
comms module

***A 15way single feed, with DC Multimeter & RS485 YES 2-3 weeks £2,518.47
comms module

***PLEASE STATE EITHER 300A/400A/500A/600A—Eg: 400A/15/W/S/A/N (400amp 15 way single board with amp meter no mcb’s)

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

8

9 Wall Mounted Dual Feed 15 Way
DC Distribution Board

• Wall Mounting front access 800mm High x 600mm Wide x 260mm Deep Enclosure
Size in RAL 7035 (other colours available on request please add £300.00 to price)

• 300Amp, 400Amp , 500Amp or 600Amp 54V DC Range (please specify)
• To accept 15 off up to 125amp C120H MCB’s

• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with
RS 485 comms output

• Supplied with or with out C120H 100amp Type “C” MCB’s
• All MCB’s hot swappable without the need to isolate
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• Other colours available on request, please add £300.00 to prices - 7 Week lead time

Part Number Description MCB’s Lead Price
Time
***A/15/W/D/A/N ***A 15way dual feed, with amp meter (ex VAT & Delivery)
***A/15/W/D/A/Y ***A 15way dual feed, with amp meter
***A/15/W/D/V/N ***A 15way dual feed, with volt meter NO 2-3 weeks £3,121.38
***A/15/W/D/V/Y ***A 15way dual feed, with volt meter
***A/15/W/D/AV/N ***A 15way dual feed, with amp & volt meter YES 2-3 weeks £3,993.86
***A/15/W/D/AV/Y
***A/15/W/D/RS/N NO 2-3 weeks £3,121.38

***A/15/W/D/RS/Y YES 2-3 weeks £3,993.86

NO 2-3 weeks £3,273.45

***A 15way dual feed, with amp & volt meter YES 2-3 weeks £4,145.93

***A 15way dual feed, with DC Multimeter & RS485 NO 2-3 weeks £4,164.47
comms module

***A 15way dual feed, with DC Multimeter & RS485 YES 2-3 weeks £5,036.95
comms module

***PLEASE STATE EITHER 300A/400A/500A/600A—Eg: 400A/15/W/D/A/N (400amp 15 way dual board with amp meter no mcb’s)

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

10

11 40 Way Dual Floor Standing Front & Rear
Access Power Distribution Centres (PDC’s)

• Floor Standing 2100mm High x 600mm Wide x 600mm Deep, arranged for front and
rear access (Fits standard Telecoms floor tile)

• Enclosure supplied in RAL 7035 or RAL 9011 (other colours available on request)
• To accept 40 off up to 125amp hot swappable C120H MCB’s per A and B Board
• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with

RS 485 comms output
• Supplied with or with out C120H 100amp Type “C” MCB’s
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• All MCB’s prewired to rear access “Live Line” cable chamber

Part Number Description MCB’s Lead Price
Time
630/40/FL/D/AV/N 630A 40 Way Dual Supply Floor Standing PDC NO (ex VAT & Delivery)
with Standard Amp & Volt Meters 6-8 Weeks £7,002.55

630/40/FL/D/AV/Y 630A 40 Way Dual Supply Floor Standing PDC YES 6-8 Weeks £8,594.21
with Standard Amp & Volt Meters NO 6-8 Weeks £7,941.39
YES 6-8 Weeks £9,553.04
630/40/FL/D/RS/N 630A 40 Way Dual Supply Floor Standing PDC NO 6-8 Weeks £7,980.67
with DC Multi Meter & RS 485 Comms Meter YES 6-8 Weeks £9,572.33
NO 6-8 Weeks £8,919.51
630/40/FL/D/RS/Y 630A 40 Way Dual Supply Floor Standing PDC YES 6-8 Weeks £10,511.16
with DC Multi Meter & RS 485 Comms Meter

1250/40/FL/D/AV/N 1250A 40 Way Dual Supply Floor Standing PDC
with Standard Amp & Volt Meters

1250/40/FL/D/AV/Y 1250A 40 Way Dual Supply Floor Standing PDC
with Standard Amp & Volt Meters

1250/40/FL/D/RS/N 1250A 40 Way Dual Supply Floor Standing PDC
with DC Multi Meter & RS 485 Comms Meter

1250/40/FL/D/RS/Y 1250A 40 Way Dual Supply Floor Standing PDC
with DC Multi Meter & RS 485 Comms Meter

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

12

13 40 Way Dual “Wall Mounted” Front Access
Power Distribution Centres (PDC’s)

• Floor / Wall mounted 2000mm High x 1400mm Wide x 400mm Deep, arranged for
front access

• Enclosure supplied in RAL 7035 or RAL 9011 (other colours available on request)
• To accept 40 off up to 125amp hot swappable C120H MCB’s per A and B Board
• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with

RS 485 comms output
• Supplied with or with out C120H 100amp Type “C” MCB’s
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• All MCB’s prewired to side access “Live Line” cable chambers

Part Number Description MCB’s Lead Price
Time (ex VAT & Delivery)
630/40/W/D/AV/N 630A 40 Way Dual Supply Floor Standing PDC NO
6-8 Weeks £7,557.36

630/40/W/D/AV/Y 630A 40 Way Dual Supply Floor Standing PDC YES 6-8 Weeks £8,510.45
with Standard Amp & Volt Meters NO 6-8 Weeks £8,496.20
YES 6-8 Weeks £9,449.28
630/40/W/D/RS/N 630A 40 Way Dual Supply Floor Standing PDC NO 6-8 Weeks £8,357.10
with DC Multi Meter & RS 485 Comms Meter YES 6-8 Weeks £10,345.96
NO 6-8 Weeks £9,295.95
630/40/W/D/RS/Y 630A 40 Way Dual Supply Floor Standing PDC YES 6-8 Weeks £11,284.79
with DC Multi Meter & RS 485 Comms Meter

1250/40/W/D/AV/N 1250A 40 Way Dual Supply Floor Standing PDC
with Standard Amp & Volt Meters

125040/W/D/AV/Y 1250A 40 Way Dual Supply Floor Standing PDC
with Standard Amp & Volt Meters

1250/40/W/D/RS/N 1250A 40 Way Dual Supply Floor Standing PDC
with DC Multi Meter & RS 485 Comms Meter

1250/40/W/D/RS/Y 1250A 40 Way Dual Supply Floor Standing PDC
with DC Multi Meter & RS 485 Comms Meter

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

14

15 24 Way Dual “Wall Mounted” Front Access
Power Distribution Centres (PDC’s)

• Floor / Wall mounted 1600mm High x 1200mm Wide x 400mm Deep, arranged for
front access

• Enclosure supplied in RAL 7035 or RAL 9011 (other colours available on request)
• To accept 24 off up to 125amp hot swappable C120H MCB’s per A and B Board
• Varity of metering options—Standard Amp, Volt Amp & Volt or DC Multi meter with

RS 485 comms output
• Supplied with or with out C120H 100amp Type “C” MCB’s
• When supplied without MCB’s, hot swappable “dummy” MCB’s are fitted
• All busbar fully insulated, with secondary Perspex shrouding
• Cable entry from above or below as standard
• All MCB’s prewired to side access “Live Line” cable chambers

Part Number Description MCB’s Lead Price
Time (ex VAT & Delivery)
630/24/W/D/AV/N 630A 24 Way Dual Supply Floor Standing PDC with NO
Standard Amp & Volt Meters YES 6-8 Weeks £7,276.24
NO
630/24/W/D/AV/Y 630A 24 Way Dual Supply Floor Standing PDC with YES 6-8 Weeks £8,400.91
Standard Amp & Volt Meters NO 6-8 Weeks £8,215.08
YES 6-8 Weeks £9,339.75
630/24/W/D/RS/N 630A 24 Way Dual Supply Floor Standing PDC with DC NO 6-8 Weeks £8,403.71
Multi Meter & RS 485 Comms Meter YES 6-8 Weeks £9,356.79
6-8 Weeks £9,342.54
630/24/W/D/RS/Y 630A 24 Way Dual Supply Floor Standing PDC with DC 6-8 Weeks £10,295.64
Multi Meter & RS 485 Comms Meter

1250/24/W/D/AV/N 1250A 24 Way Dual Supply Floor Standing PDC with
Standard Amp & Volt Meters

1250/24/W/D/AV/Y 1250A 24 Way Dual Supply Floor Standing PDC with
Standard Amp & Volt Meters

1250/24/W/D/RS/N 1250A 24 Way Dual Supply Floor Standing PDC with
DC Multi Meter & RS 485 Comms Meter

1250/24/W/D/RS/Y 1250A 24 Way Dual Supply Floor Standing PDC with
DC Multi Meter & RS 485 Comms Meter

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]



17 Battery LVD Units

• Wall mounting Battery low volt disconnector 630A through to 1600A
• Protects battery from deep discharge (disconnects at 41.6V)
• Accepts 2 off up to 400mm2 cables to and from battery
• In built time delay to prevent reclosure of LVD upon disconnect

(battery may rejuvenate temporarily on disconnect)
• Adjustable pick up and drop off settings (factory set 41.6V drop, 51.5V pick up)
• Off / Auto key switch to test / Isolate battery.
• Fully insulted IP67 enclosure with viewing window
• Volt free alarm contacts, N/O and N/C prewired to terminals
• Battery fuse being a fuse switch type for ease and safety of removal

Part Number Description Lead Price
Time (ex VAT & Delivery)
AMJ/LVD/630A 630A Battery LVD with Efen Fuse Base & 630A Efen
Fuse Links 3-4 Weeks £1,450.00

AMJ/LVD/1200A 1200A Battery LVD with Efen Fuse Base & 1200A Efen 3-4 Weeks £2,160.00

AMJ/LVD/1600A 1600A Battery LVD with Efen Fuse Base & 1600A Efen 3-4 Weeks P.O.A
Fuse Links

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

18

19 Battery Fuse Boxes & Junction Boxes
(Transition Boxes)

• Wall mounting Battery Transition Boxes & Junction Boxes
• For Connection of single or multiple battery Strings & Joining Existing Cables
• Custom Built to Customers needs, please send us a Spec of what you require, just in-

form us of Size/Amps/No Ways/Fuses/Incoming & Outgoing Cables/any other info.
• IP66 Enclosures in either Mild Steel Paint RAL7035 or GRP Plastic RAL 7035 Enclosures
• With our vast stock of copper, and quick delivery of Enclosures we have a 2-3day turn

around on all sizes
• All Busbar fully insulated
• Secondary shrouding fitted as standard
• Battery fuses being an Efen Fuse Switch type for ease and safety of removal, Other

Fuses available on request
• Full Layout Drawing Supplied

tel: 01455 234996 / 01455 616686 email: [email protected] email: [email protected]

20

Head Office: Workshop:
34 Forest Road Unit 56a Sparkenhoe Business Centre
Hinckley Southfield Road
Leicestershire Hinckley
LE10 1HB Leicestershire
Tel: 01455 234996 LE10 1UB
Email: [email protected] Tel: 01455 616686
Email: [email protected]
