Product Size Item No. Weight(kgs/pc) 48.3x3.2x500mm 10050 3.20 48.3x3.2x1000mm 10100 5.70 48.3x3.2x1500mm 10150 8.20 48.3x3.2x2000mm 10200 10.50 48.3x3.2x2500mm 10250 13.20 48.3x3.2x3000mm 10300 15.40 48.3x3.2x4000mm 10400 20.30 Product Size Item No. Weight(kgs/pc) Start Collar 250mm 10025 1.74 Product Size Item No. Weight(kgs/pc) 48.3x3.2x730mm 11073 3.45 48.3x3.2x1090mm 11109 4.78 48.3x3.2x1400mm 11140 5.96 48.3x3.2x1570mm 11157 6.62 48.3x3.2x2070mm 11207 8.50 48.3x3.2x2570mm 11257 10.39 48.3x3.2x3070mm 11307 12.28 Product Size Item No. Weight(kgs/pc) U type Ledger 730mm 12073 2.80 - U Type Ledgers are used as horizontal support for ringlock U type hook steel decks RINGLOCK LEDGER U TYPE RINGLOCK LEDGER O TYPE Ringlock Ledger U Type Ringlock Ledger U Type is also called ringlck u ledger, ringlock u transom etc. - Steel, hot dip galvanized - With wedge head connections for attachment to the perforated discs - The discs provide vertical support when attaching horizontal ledgers and diagonal braces BASE COLLAR/STARTER COLLAR Ringlock Base collar Ringlock Base Collar is also called ringlock start collar, ringlock starter unit etc. - With perforated disc Ringlock Ledgers O Type are used as horizontal support for ringlock o type hook steel planks. - With wedge head connections for attachment to the perforated discs - Ringlock O Type Ledgers can also be used as midrails and guardrails. Vertical Standard with Spigot O type Ledger - Vertical standards is placed in the base collar for furthur assembly - Forms the scaffold base together with base jacks Ringlock Ledger O Type VERTICAL STANDARD WITH SPIGOT EN12811 CERTIFIED Ringlock Standards Ringlock Standard are made of steel tube 48.33.2mm, hot dipped galvanized, fixed with pressed spigot. - Perforated discs at the distance of 0.5m for up to eight connections 1 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 1090mm 12109 5.90 1400mm 12140 7.70 Product Size Item No. Weight(kgs/pc) 2000x730mm 13073 8.03 2000x1090mm 13109 8.41 2000x1400mm 13140 8.85 2000x1570mm 13157 9.42 2000x2070mm 13207 10.10 2000x2570mm 13257 11.20 2000x3070mm 13307 12.38 Product Size Item No. Weight(kgs/pc) 1570mm 22157 9.40 2070mm 22207 12.50 2570mm 22257 17.90 3070mm 22307 19.20 Product Size Item No. Weight(kgs/pc) 1570mm 22157 9.80 2070mm 22207 12.80 2570mm 22257 18.50 3070mm 22307 19.40 Ringlock Truss Ledger U Type is also called ringlock u type bridging Ledger. Steel, hot dip galvanzied - Provide support U type hook steel decks with high loads or larger spans RINGLOCK TRUSS LEDGER U TYPE Diagnal Brace Steel, hot dip galvanzied - Provide support O type hook steel decks with high loads or larger spans Truss Ledger O Type Ringlock Truss Ledger U Type Ringlock Diagonal Brace is made of steel tube 48.3 x 2.5 mm, hot dip galvanized With swiveling wedge heads - For bracing the vertical scaffold structure RINGLOCK DIAGONAL BRACE Truss Ledger O Type Ringlock Truss Ledger O Type Ringlock Truss Ledger O Tupe is also called ringlock bridging ledger. RINGLOCK TRUSS LEDGER O TYPE U Transom Reinforced Ringlock U Transom Reinforced Ringlock U Transom Reinforced is also called ringlock U ledger reinforced. Ringlock Diagonal Brace - With wedge head connections for attachment to the perforated discs - U Type transom reinforced are used as horizontal support for ringlock U type hook steel decks. RINGLOCK U Transom Reinforced 2 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 320x76x1.5x730mm 29073 6.70 320x76x1.5x1090mm 29109 9.27 320x76x1.5x1400mm 29140 11.34 320x76x1.5x1570mm 29157 13.15 320x76x1.5x2070mm 29207 14.47 320x76x1.5x2570mm 29257 19.74 320x76x1.5x3070mm 29307 23.04 Product Size Item No. Weight(kgs/pc) 320x76x1.5x730mm 19073 6.16 320x76x1.5x1090mm 19109 8.82 320x76x1.5x1400mm 19140 10.55 320x76x1.5x1570mm 19157 12.17 320x76x1.5x2070mm 19207 15.45 320x76x1.5x2570mm 19257 19.55 320x76x1.5x3070mm 19307 23.87 Product Size Item No. Weight(kgs/pc) 390mm 24039 4.00 730mm 24073 6.00 Product Size Item No. Weight(kgs/pc) 390mm 24039 4.70 730mm 24073 6.50 - To extend scaffold the working platform closer to the buidling structure RINGLOCK BOARD BRACKET U TYPE Board Bracket U Type RINGLOCK STEEL DECKS U TYPE Extremely robust, for the toughest operations Reducing the wall thickness and optimized hole profiling leads to weight savings Complies with the requirements of DIN EN 12811 Can be used in guard and roofguard scaffolds as per DIN 4420 Ringlock Board Bracket U Type - To extend scaffold the working platform closer to the buidling structure RINGLOCK STEEL DECK O TYPE Ringlock Steel Deck U Type Ringlock Steel Deck O Type, width 320mm, with hook connecting ringlock horizontal ledger. Ringlock Board Bracket O Type Ringlock Board Bracket O Type is also called ringlock console bracket or ringlock side bracket. O Hook Steel Deck U HOOK Steel Deck Steel, hot dip galvanzied - Non-slip surface through pronounced hole profiling Steel, hot dip galvanzied - Non-slip surface through pronounced hole profiling Ringlock Steel Deck O Type Ringlock Steel Deck O Type, width 320mm, with hook connecting ringlock horizontal ledger. RINGLOCK BOARD BRACKET O TYPE Board Bracket O Type Ringlock Board Bracket U Type is also called ringlock u console bracket or ringlock u profile side bracket. Steel, hot dip galvanzied Steel, hot dip galvanzied 3 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 730mm 60073 3.50 1090mm 60109 4.60 1400mm 60140 6.70 1570mm 60157 7.40 2070mm 60207 10.30 2570mm 60257 12.50 3070mm 60307 15.00 Product Size Item No. Weight(kgs/pc) 2070mm 50207 25.20 2570mm 50257 30.20 3070mm 50307 35.30 4140mm 50414 46.00 5140mm 50514 50.00 6140mm 50614 62.50 7710mm 50771 77.10 Product Size Item No. Weight(kgs/pc) 730mm 21073 1.50 1090mm 21109 2.20 1400mm 21140 2.50 1570mm 21157 3.00 2070mm 21207 5.10 2570mm 21257 6.50 3070mm 21307 8.20 Product Size Item No. Weight(kgs/pc) 300mm 70030 2.10 500mm 70050 2.80 800mm 70080 3.60 1200mm 70120 4.50 Ringlock Wall Tie Tube Wall Tie Tube is also called wall tie anchor, they are made of Steel tube 48.3 mm Steel tube 48.3 mm, hot dip galvanized - Installation as long scaffold tie with two right angle couplers RINGLOCK WALLTIE TUBE Wall Tie Tube - Installation as short scaffold tie with one right angle coupler Ringlock U Lift Off Preventer is also called ringlock deck locker. Steel, hot dip galvanzied - It serves to prevent scaffolding decks from being lifted off RINGLOCK U LIFT OFF PREVENTER Ringlock U Lift Off Preventer Steel, hot dip galvanzied - Working as strong horizontal braces that allow for larger spans or gaps over walkways, roads, ditches, etc. RINGLOCK LATTICE GIRDER Lattice Girder Ringlock U Lift Off Preventer Ringlock Lattice Girder Ringlock Lattice Girder is also called ringlock lattic girder beam. Ringlock Intermediate Transom Ringlock Intermediate Transoms are also called board bearer. Ringlock Intermediate Transoms are used as support for steel planks Steel, hot dip galvanzied - Working as support for steel decks RINGLOCK INTERMEDIATE TRANSOM Intermediate Transom 4 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) Rosette Clamp 1.00 Product Size Item No. Weight(kgs/pc) 2000x2070mm 18207 26.00 2000x2570mm 18257 30.00 2000x3070mm 18307 36.00 Product Size Item No. Weight(kgs/pc) 730mm 94073 7.30 1090mm 94109 10.10 1570mm 94157 13.30 2070mm 94207 17.60 2570mm 94257 20.60 3070mm 94307 25.00 Product Size Item No. Weight(kgs/pc) 610x2570mm 945257 24.50 610x3070mm 945307 28.00 Steel, hot dip galvanized ALUMINIUM ACCESS DECK WITH LADDER AlumInium Access Deck With Ladder Aluminium Staircase is stairway for the planned construction with facade scaffolding Bay height 2.00 m ALUMINIUM STAIRCASE -The steps are designed in a non-slip manner and allow comfortable outside access for extensive use of scaffold and when transporting bulky material, without reducing the work surface in the main walkway Single load distributed on 0.2 x 0.2 m2 F = 1.5 kN Evenly distributed area load p = 2.5 kN/m2 Meets the requirements according to DIN EN 12811-1 Ringlock Rosette Clamp Ringlock Rosette Clamps are kind of adjustable Clamps. Ensures the possibility of mounting at the desired position along a standards or tubes 48.3 mm RINGLOCK ROSETTE CLAMP Aluminium Combi Deck Aluminium Combi Deck Aluminium Combi Decks are also called aluminium access decks. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate Aluminium Staircase -Lightweight, non-slip working surface U hook aluminum platform ALUMINIUM COMBI DECK Aluminium Access Deck With ladder Aluminium Access Deck With Ladder is made of aluminium profile frame. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate -With integrated access ladder U hook or O hook Aluminium Staircase 5 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 300mm 90030 2.10 500mm 90050 2.80 600mm 90060 3.60 780mm 90078 4.50 1000mm 90100 5.20 ADJUSTABLE BASE JACK Adjustable Base Jack For adjusting level with differences in height of the underground Adjustbale Base Jacks are also called base jacks, screw base jacks, scaffold jack base etct. Steel, hot dip galvanized or Electro-galvanized. Hollow type with tube spindle - Base plate 150 x 150 mm 6 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. Adjustable Base Jack HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type Right Angle Couplers hot dip galvanized 48.3 x 48.3 1.20 Product Surface Size Weight(kgs/pc) German Type Swivel Coupler hot dip galvanized 48.3 x 48.3 1.35 Product Surface 9O`K Weight(kgs/pc) 38.1 x 38.1mm 48.3 x 42mm 42m x 42mm 48.3 x 60mm 48.3 x 76mm Product Surface 9O`K Weight(kgs/pc) 38.1 x 38.1mm 48.3 x 42mm 42m x 42mm 48.3 x 60mm 48.3 x 76mm German Type Reducing Standard Couplers hot dip galvanized German Tyep Reducing Swivel Couplers are hot dip galvanized, made of drop-forged steel. - Different size to meet different tube size - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm German Type Reducing Swivel Couplers GERMAN TYEP REDUCING SWIVEL COUPLERS German Type Reducing Swivel Coupler hot dip galvanized German Tyep Reducing Standard Couplers are hot dip galvanized, made of drop-forged steel. -Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm -Comply with EN74-1 B German Type Right Angle Couplers German Type Right Angle Coupler utilised for attaching a horizontal tube to a vertical tube to create a 90 degree angle - Steel, hot dip galvanized, made of drop-forged steel - Comply with EN 74-1 BB - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYEP RIGHT ANGLE COUPLERS GERMAN TYPE SWIVEL COUPELRS German Type Swivel Couplers German Type Swivel Coupler connects two Scaffold tubes at any angle. --Steel, hot dip galvanized, made of drop-forged steel German Type 8KJ[IOTM9ZGTJGXJ Couplers - Different size to meet different tube size - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYEP REDUCING STANDARD COUPLERS Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type Half Swivel Couplers hot dip galvanized self colour 48.3 0.70 Product Surface Size Weight(kgs/pc) M14 Bolt and Collar Nut Electri-galvanized M14 Product Surface Size Weight(kgs/pc) M14 High Speed Bolt and Collar Nut Hot dip galvanized M14 Product Surface Size Weight(kgs/pc) German Type Half Coupler Loose hot dip galvanized self colour 0.68 Product Surface Size Weight(kgs/pc) German Type Tension Coupler hot dip galvanized 48.3 1.80 GERMAN TYPE HALF COUPELR 2559+ M14 High Speed Bolt and Collar Nut -Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm -hot dip galvanized M14 HIGH SPEED BOLT AND )522'8 4;: German Type HGRL Coupler2UUYK German Type HGRL Swivel Couplers German Type Half Swivel Coupler is also called half coupler. It is always welded with other compoments . --Steel, hot dip galvanized or self colour, made of drop-forged steel -Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE HALF SWIVEL COUPELRS M14 Bolt and Collar Nut -Steel, Cover hot dip galvanized and base self colour, made of drop-forged steel German type half coupler Loose is not assemblied. German Type Tension Coupler -Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm -Electri-galvanized M14 BOLT AND COLLAR NUT - Comply with EN74-1 B -Seperately packing German Type Tension Coupler is also called german type sleeve couplers, They are made in drop forged Steel and connect two steel or aluminum tubes 48.3 mm in one axis - Steel, hot dip galvanized, made of drop-forged steel M14 Bolts and Collar Nuts are the components of German type couplers. M14 High Speed Bolts and Collar Nuts are the components of German type couplers. - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE TENSION COUPLER Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type Tube Connecting Spigot hot dip galvanized 48.3 1.00 Product Surface Size Weight(kgs/pc) German Type Joint Pin hot dip galvanized 48.3 1.10 Product Surface Size Weight(kgs/pc) German Type Bolt On Coupler hot dip galvanized 48.3 0.80 Product Surface Size Weight(kgs/pc) German Type Claw Coupler hot dip galvanized 48.3 1.00 Product Surface Size Weight(kgs/pc) German Type Combination Coupler hot dip galvanized 48.3 0.90 German Type 0UOTZ6OT German Type Joint Pin can also connect two steel or aluminum tubes 48.3 mm in one axis. - Steel, hot dip galvanized GERMAN TYPE 05/4: 6/4 - Steel, hot dip galvanized German Type Bolt On Coupler - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm German Type Combination Coupler German Type Tube Connecting Spigot German Type Tube Connecting Spigot is also called german type internals. They connect two steel or aluminum tubes 48.3 mm in one axis. German Type Claw Coupler - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE CLAW COUPLER GERMAN TYPE TUBE CONNECTING SPIGOT GERMAN TYPE BOLT ON COUPLER - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE COMBINATION COUPLER - Made of drop-forged steel - Made of drop-forged steel German Type Bolt On Coupler, half coupler welded bolt with nut German Type Claw Coupler, half coupler welded L plate. German Type Combination Coupler, half coupler welded screw bolt Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type Gravity Pin Coupler hot dip galvanized 48.3 0.90 Product Surface Size Weight(kgs/pc) German Type Guardrail Coupler hot dip galvanized 48.3 1.05 Product Surface Size Weight(kgs/pc) German Type Hook Coupler hot dip galvanized 48.3 1.00 Product Surface Size Weight(kgs/pc) German Type Toe Board coupler hot dip galvanized 48.3 0.80 Product Surface Size Weight(kgs/pc) German Type Timber Coupler hot dip galvanized 48.3 1.80 German Type Timber Coupler - Steel, hot dip galvanized, made of drop-forged steel GERMAN TYPE TIMBER COUPLER German Type Gravity Pin Coupler - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE GRAVITY PIN COUPLER GERMAN TYPE GUARDRAIL COUPLER German Type Guardrail Coupler - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE TOE BOARD COUPLER German Type Toe Board coupler - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm GERMAN TYPE GUARDRAIL COUPLER German Type Hook Coupler - Steel, hot dip galvanized, made of drop-forged steel - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm German Type Gravity Pin Coupler, half coupler welded gravity pin. German Type Guardrail Coupler, half coupler welded assembly frame guardrail accessories. German Type Hook Coupler, half coupler welded short steel bar. German Type Toe Board Coupler, half coupler welded long L steel bar. German Type Timber Coupler, half coupler welded 90 degree steel plate. Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type Welded Plate Twin Coupler hot dip galvanized 48.3 1.80 Product Surface Size Weight(kgs/pc) German Type Wedge Standard Coupler hot dip galvanized 48.3 x 48.3 1.35 Product Surface Size Weight(kgs/pc) German Type Wedge Swivel Coupler hot dip galvanized 48.3 x 48.3 1.45 Product Surface Size Weight(kgs/pc) German Type Wedge Half Coupler hot dip galvanized 48.3 0.70 Product Surface Size Weight(kgs/pc) German Type Spigot Half Coupler hot dip galvanized 48.3 1.80 GERMAN TYPE SPIGOT HALF COUPLER - Steel, hot dip galvanized - Made of drop-forged steel GERMAN TYPE WEDGE STANDARD COUPLER German Type Wedge Swivel Coupler - Steel, hot dip galvanized - Made of drop-forged steel GERMAN TYPE WEDGE SWIVEL COUPLER German Type Spigot Half Coupler - Made of drop-forged steel German Type Welded Plate Twin Coupler German Type Welded Plate Twin Coupler, two Half coupler weled on plate Steel. - Grade 8.8 bolt and flang nuts, Nuts size 19mm/22mm - Steel , hot dip galvanized GERMAN TYPE WELDED PLATE TWIN COUPLER German Type Wedge Half Coupler - Steel, hot dip galvanized German Type Wedge 9ZGTJGXJ Coupler - Steel, hot dip galvanized - Made of drop-forged steel German Type Wedge Swivel Coupler, swivel coupler assemblied with wedge. German Type Spigot Half Coupler, Half coupler welded with spigot. German Type Wedge Half Coupler, half coupler assemblied with wedge. GERMAN TYPE WEDGE HALF COUPLER German Type Wedge Standard Coupler, standard coupler assemblied with wedge. Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Size Weight(kgs/pc) German Type SK Coupler hot dip galvanized 48.3 1.15 Product Surface Size Weight(kgs/pc) German Type Distance Coupler hot dip galvanized 48.3 2.00 Product Surface Size Weight(kgs/pc) Ledger Head Standard Coupler hot dip galvanized 48.3 1.00 Product Surface Size Weight(kgs/pc) Ledger Head Swivel Coupler hot dip galvanized 48.3 1.10 Ledger Head Standard Coupler - Half Couplers are made of drop-forged steel GERMAN TYPE DISTANCE COUPLER German Type Distance Coupler - Steel, hot dip galvanized, made of drop-forged steel GERMAN TYPE SK COUPLER - Made of drop-forged steel - Steel, hot dip galvanized, made of drop-forged steel - One Half coupler assemblied with ledger head LEDGER HEAD SWIVEL )5;62+8 - Steel, hot dip galvanized, made of drop-forged steel - One Half coupler welded with ledger head LEDGER HEAD ST'4*'8* )5;62+8 Ledger Head Swivel Coupler,the ledger head can connect ringlock standard rosette, the half coupler can connect one scaffold tube at any angle. Ledger Head Standard Coupler,the ledger head can connect ringlock standard rosette, the half coupler can connect one scaffold tube at 90 degree angle. German Type Distance Coupler, two half couplers are seperately welded at the end of tube . German Type SK Coupler is also called U plate coupler, half coupler assemblied with U plate. Ledger Head Swivel Coupler German Type SK Coupler - Steel, hot dip galvanized Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) British Type Double Couplers Electro-galvanized 1.05 Product Surface Item No. Weight(kgs/pc) British Type Swivel Couplers Electro-galvanized 1.15 Product Surface Item No. Weight(kgs/pc) British Type Putlog Couplers Electro-galvanized 0.65 Product Surface Item No. Weight(kgs/pc) British Type Board Retaining Couplers Electro-galvanized 0.65 -Grade 8.8 bolt and nuts -Comply with EN74-1 B British Type Putlog Couplers British Type Putlog Coupler is also called putlogs or single coupler, Putlog Coupler is another form of securing a tube to your structure. British Type Double Couplers British Type Double Coupler is also called doubles or right angle coupler, utilised for attaching a horizontal tube to a vertical tube to create a 90 degree angle - Electro-galvanized - Comply with EN74-1 B -Comply with BS1139 -Grade 8.8 bolt and nuts BRITISH TYPE PUTLOG COUPELRS - Grade 8.8 bolt and nuts BRITISH TYPE DOUBLE COUPELRS British Type Board Retaining Couplers BRITISH TYPE SWIVEL COUPELRS British Type Swivel Couplers British Type Swivel Coupler is also called swivels, connects two Scaffold tubes at any angle. --Electro-galvanized --Electro-galvanized British Type Board Retaining Coupler is also called BRC coupler or board retaining clamp, board retaining couplers are required to secure your timber boards in place providing a secure lock so no boards move under load. - Electro-galvanized - Comply with BS1139 - Grade 8.8 bolt and nuts BRITISH TYPE BOARD RETAINING COUPELRS Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) British Type External Joiner Electro-galvanized 1.10 Product Surface Item No. Weight(kgs/pc) British Type Internal Joint Pin Electro-galvanized 1.10 Product Surface Item No. Weight(kgs/pc) British Type Pressed Joint Pin Electro-galvanized 0.75 Product Surface Item No. Weight(kgs/pc) British Type Girder Couplers Electro-galvanized 1.50 Product Surface Item No. Weight(kgs/pc) British Type Girder Swivel Coupler Electro-galvanized 1.70 British Type External Joiner British Type External Joiner is also called sleeve couplers and externals. They are made in Pressed Steel, they are used for joining two Scaffold tubes - Electro-galvanized - Made of pressed steel BRITISH TYPE EXTERNAL JOINER British Type Internal Joint Pin British Type Internal Joint Pin is also called joint pin and internals. They are made in Drop Forged Steel, they are used for joining two Scaffold tubes - Made of pressed steel - Electro-galvanized - Made of drop forged steel BRITISH TYPE INTERNAL JOINT PIN British Type Girder Swivel Coupler British Type Girder Swivel Coupler is also called swivel gravlock girder coupler, they allows tube to be used through 360 degrees. - Electro-galvanized British Type Pressed Joint Pin British Type Pressed Joint Pin is also called joint pin and internals. They are made in Pressed Steel, they are also used for joining two Scaffold tubes - Electro-galvanized - Electro-galvanized - Always used in pairs BRITISH TYPE GIRDER SWIVEL COUPLER BRITISH TYPE PRESSED JOINT PIN - Always used in pairs BRITISH TYPE GIRDER COUPLERS British Type Girder Couplers British Type Girder Couplers also called gravlock couplers, girder clamps. Solid one piece drop forged steel fitting providing quick and secure fixing to beams. Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) British Type Pressed Double Coupler Electro-galvanized 0.92 Product Surface Item No. Weight(kgs/pc) British Type Pressed Swivel Coupler Electro-galvanized 0.92 Product Surface Item No. Weight(kgs/pc) Pressed Band and Plate Fitting Electro-galvanized 1.98 Pressed Band and Plate Fitting is also called Band and Plate coupler - Electro-galvanized - Made of pressed steel Pressed Band and Plate Fitting Pressed Band and Plate Fitting British Type Pressed Swivel Coupler connects two Scaffold tubes at any angle. - Electro-galvanized - Made of pressed steel BRITISH TYPE PRESSED SWIVEL COUPLER British Type Pressed Double Coupler British Type Pressed Double Coupler utilised for attaching a horizontal tube to a vertical tube to create a 90 degree angle. - Electro-galvanized - Made of pressed steel BRITISH TYPE PRESSED DOUBLE COUPLER British Type Pressed Swivel Coupler Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) Italian Type Drop Forged Right Angle Coupler Electri-galvanized 1.40 Product Surface Item No. Weight(kgs/pc) Italian Type Drop Forged Swivel Coupler Electri-galvanized 1.70 Product Surface Item No. Weight(kgs/pc) Italian Type Malleable Right Angle Coupler Electri-galvanized 1.50 Product Surface Item No. Weight(kgs/pc) Italian Type Malleable Swivel Coupler Electri-galvanized 1.90 Italian Type Malleable Swivel Couplers consist of drop forged steel Cover, malleable casting base, 2 hammer bolt with 2 T-bolt. - Electri-galvanized ITALIAN TYPE MALLEABLE SWIVEL COUPLER - Assembly with 2 hammer bolts and 2 T-bolts Italian Type Malleable Right Angle Coupler Italian Type Malleable Right Angle Couplers consist of drop forged steel Cover, malleable casting base, 2 hammer bolt with 2 T-bolt. Italian Type Drop Forged Right Angle Coupler Italian Type Drop Forged Right Angle Couplers are made of drop forged steel,assembly with 2 hammer bolts and 2 T-bolts Italian Type Drop Forged Swivel Couplers are made of drop forged steel,assembly with 2 hammer bolts and 2 T-bolts - Electri-galvanized - Assembly with 2 hammer bolts and 2 T-bolts - Electri-galvanized - Electri-galvanized - Assembly with 2 hammer bolts and 2 T-bolts ITALIAN TYPE DROP FORGED RIGHT ANGLE COUPLER Italian Type Malleable Swivel Coupler ITALIAN TYPE DORP FORGED SWIVEL COUPLER Italian Type Drop Forged Swivel Coupler - Assembly with 2 hammer bolts and 2 T-bolts ITALIAN TYPE MALLEABLE RIGHT ANGLE COUPLER Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) Italian Type Pressed Double Coupler Electri-galvanized 1.35 Product Surface Item No. Weight(kgs/pc) Italian Type Pressed Swivel Coupler Electri-galvanized 1.75 Product Surface Item No. Weight(kgs/pc) Italian Type Simple Coupler Electri-galvanized 0.75 Product Surface Item No. Weight(kgs/pc) Italian Type Head Swivel Coupler Electri-galvanized 0.85 - Made of drop forged steel ITALIAN TYPE HEAD SWIVEL COUPLER Italian Type Simple Coupler Italian Type Simple Couplers are made of drop forged steel and assembly with 1 hammer bolt and 1 T-Bolt - Electri-galvanized - Made of drop forged steel Italian Type Head Swivel Coupler Italian Type Head Swivel Couplers are made of drop forged steel. - Electri-galvanized Italian Type Pressed Double Couplers are made of pressed steel and assembly with 4 T-Bolts. - Electri-galvanized - Made of pressed steel ITALIAN TYPE PRESSED DOUBLE COUPLER Italian Type Pressed Swivel Coupler Italian Type Pressed Double Couplers are made of pressed steel and assembly with 4 T-Bolts. ITALIAN TYPE SIMPLE COUPLER - Made of pressed steel Italian Type Pressed Double Coupler ITALIAN TYPE PRESSED SWIVEL COUPLER - Electri-galvanized Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) American Type Right Angle Coupler Electri-galvanized Hot dip galvanized 1.70 Product Surface Item No. Weight(kgs/pc) American Type Swivel Couplers Electri-galvanized Hot dip galvanized 1.80 Product Surface Item No. Weight(kgs/pc) American Type Half Coupler Electri-galvanized Hot dip galvanized 0.88 Product Surface Item No. Weight(kgs/pc) American Type Single Coupler Electri-galvanized Hot dip galvanized 0.88 American Type Single Couplers Use for fixed 2pcs of 1.9 pipe together in horizontal direction. Couplers can be Hot dipped galv. or Electro galv. With eye bolt and 22mm flange nut - Electri-galvanized or hot dip galvanized - Made of drop forged steel AMERICAN TYPE SINGLE COUPLER - Made of drop forged steel AMERICAN TYPE HALF COUPLER AMERICAN TYPE RIGHT ANGLE COUPLER American Type Single Coupler BRITISH TYPE SWIVEL COUPELRS American Type Swivel Couplers American Type Swivel Couplers are Suitable for scaffold tubes 48.3 mm. Couplers can be Hot dipped galv. or Electro galv. With eye bolt and 22mm flange nut - Electri-galvanized or hot dip galvanized - Made of drop forged steel American Type Half Coupler American Type Half Couplers can weld any parts below the half clamp to fix all requirements in your project. With eye bolt and 22mm flange nut - Electri-galvanized or hot dip galvanized American Type Right Angle Coupler American Type Right Angle Couplers are Suitable for scaffold tubes 48.3 mm. Couplers can be Hot dipped galv. or Electro galv. With eye bolt and 22mm flange nut - Electri-galvanized or hot dip galvanized - Made of drop forged steel Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) American Type Right Angle Clamp Heavy Duty Electri-galvanized Hot dip galvanized 2.05 Product Surface Item No. Weight(kgs/pc) American Type Swivel Clamp Heavy Duty Electri-galvanized Hot dip galvanized 2.20 Product Surface Item No. Weight(kgs/pc) American Type Girder Clamp Heavy Duty Electri-galvanized Hot dip galvanized 1.50 Product Surface Item No. Weight(kgs/pc) American Type Girder Swivel Clamp Heavy Duty Electri-galvanized Hot dip galvanized 1.90 American Type Girder Swivel Clamp Heavy Duty designed to connect scaffold tube to beam or girder flange at any angle. - Electri-galvanized or hot dip galvanized - Always used in pairs AMERICAN TYPE GIRDER SWIVEL CLAMP HEAVY DUTY - Always used in pairs AMERICAN TYPE GIRDER CLAMP HEAVY DUTY - Made of drop forged steel - Electri-galvanized or hot dip galvanized - Made of drop forged steel AMERICAN TYPE RIGHT ANGLE CLAMP HEAVY DUTY AMERICAN TYPE SWIVEL CLAMP HEAVY DUTY American Type Girder Swivel Clamp Heavy Duty American Type Girder Clamp Heavy Duty American Type Girder Clamp Heavy Duty designed to connect scaffold tube to beam or girder flange.always use in pairs. American Type Swivel Clamp Heavy Duty - Electri-galvanized or hot dip galvanized American Type Right Angle Clamp Heavy Duty American Type Right Angle Clamps Heavy Duty can be Hot dipped galv. or Electro galv. With eye bolt and 22mm flange nut American Type Swivel Clamps Heavy Duty can be Hot dipped galv. or Electro galv. With eye bolt and 22mm flange nut - Electri-galvanized or hot dip galvanized Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Surface Item No. Weight(kgs/pc) Van Thiel Right Angle Wedge Clamps Electro-galvanzied Hot dip galvanized Product Surface Item No. Weight(kgs/pc) Van Thiel Swivel Wedge Clamps Electro-galvanzied Hot dip galvanized Product Surface Item No. Weight(kgs/pc) Brazil Type Fix Clamps Self-colour or Painted 1.20 Product Surface Item No. Weight(kgs/pc) Brazil Type Swivel Clamps Self-colour or Painted 1.20 Van Thiel Right Angle Wedge Clamps Van Thiel Right Angle Wedge Clamp is a kind of steel welding clamp. It can be eletro-galvanized or hot dip galvanized. - Electro-galvanzied or hot dip galvanized - Steel welding clamp Van Thiel Right Angle Wedge Clamps Van Thiel Swivel Wedge Clamps Van Thiel Swivel Wedge Clamp is a kind of steel welding clamp. It can be eletro-galvanized or hot dip galvanized. - Electro-galvanzied or hot dip galvanized - Steel welding clamp Van Thiel Swivel Wedge Clamps Brazil Type Fix Clamps Brazil Type Fix Clamps utilised for attaching a horizontal tube to a vertical tube to create a 90 degree angle. The clamps are widely used in Brazil. - Steel clamp Brazil Type Swivel Clamps - Self-colour or Painted - Steel clamp Brazil Type Fix Clamps Brazil Type Swivel Clamps Brazil Type Swivel Clamps are designed for connecting two Scaffold tubes at any angle. the clamps are widely used in Brazil. - Self-colour or Painted Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) Product Size Item No. Weight(kgs/pc) Product Size Item No. Weight(pc) flffifflfffi ! "fflfffi !# !!$%&' () *+, *-*.&,$ (/#'.*$%! *-00#$$-%-*0*-.$#%#.$ SWIVEL BASE JACK ! 1'.*& 2/#'.*$%! *-00#$$-%-*0*-.$#%#.$ Adjustable Base Jack 1'.*&#&'3# &'300'&** 2*3-*,%!$4#5*#(%!$4 2) *+, *-*.&,$ (,* 6 ADJUSTABLE BASE JACK Solid Base Jack 1'.*&$&.#*!$%0*-00$%$.$!$%#.$$$0$*'.*$*$,$%%#.$ (*+,&' (781 9 35*#(%!$4#-*,,%!$4 SOLID BASE JACK Swivel Base Jack fi,+#%-*:)8fi1//;"7fi;3"<71#%-*##! HISCAFFOLD.COM
Product Size Item No. Material 0.73mx0.66m 1700.066 Steel 0.73mx1.00m 1700.100 Steel 0.73mx1.50m 1700.150 Steel 0.73mx2.00m 1700.200 Steel 1.09mx0.66m 1780.066 Steel 1.09mx1.00m 1780.100 Steel 1.09mx1.50m 1780.150 Steel 1.09mx2.00m 1780.200 Steel 0.73mx0.66m 1714.066 Aluminium 0.73mx1.00m 1714.100 Aluminium 0.73mx1.50m 1714.150 Aluminium 0.73mx2.00m 1714.200 Aluminium Product Size Item No. Material 0.73m 1724.073 Steel 1.09m 1724.109 Steel 1.57m 1725.157 Steel 2.07m 1725.207 Steel 2.57m 1725.257 Steel 3.07m 1725.307 Steel 0.73m Aluminium 1.09m Aluminium 1.57m Aluminium 2.07m Aluminium 2.57m Aluminium 3.07m Aluminium Product Size Item No. Material 1.57m 1728.157 Steel 2.07m 1728.207 Steel 2.57m 1728.257 Steel 3.07m 1728.307 Steel 1.57m 1732.157 Aluminium 2.07m 1732.207 Aluminium 2.57m 1732.257 Aluminium 3.07m 1732.307 Aluminium Euro Double Guardrail is the same as layher speedy frame or layher blitz frame design. -Made of steel, hot dip galvanized -Made of aluminium, light weight option EURO DOUBLE GUARDRAIL Euro Double Guardrail -Made of steel, hot dip galvanized -Made of aluminium, light weight option Euro Double Guardrail Euro Assembly Frame Euro Single Guardrail Euro Single Guardrail EURO ASSEMBLY FRAME Euro Assembly Frame Euro Assembly Frame is the same as layher speedy assembly frame or layher blitz frame design. -Made of aluminium, light weight option Euro Singel Guardrail is the same as layher speedy frame or layher blitz frame design. EURO SINGLE GUARDRAIL -Made of steel, hot dip galvanized Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material 0.36m 1744.360 Steel 0.73m 1744.730 Steel Product Size Item No. Material 1.57m 1736.157 Steel 2.07m 1736.207 Steel 2.57m 1736.257 Steel 3.07m 1736.307 Steel Product Size Item No. Material 1.00mx0.73m 1722.073 Steel 1.00mx1.09m 1722.109 Steel 1.00mx0.73m 1770.073 Aluminium Product Size Item No. Material 1.00mx0.73m 1719.073 Steel 1.00mx1.09m 1719.109 Steel 1.00mx0.73m 1769.073 Aluminium - 100% compatiable with layher blitz system Euro Console Bracket Euro Top Intermediate Frame Euro Top End Frame Euro Top End Frame EURO CONSOLE BRACKET Euro Diagonal Brace is the same as layher speedy frame or layher blitz frame design. -Made of steel, hot dip galvanized Euro Top Intermediate Frame is the same as layher speedy frame or layher blitz frame design. -Made of steel, hot dip galvanized -Made of aluminium, light weight option EURO TOP INTERMEDIATE FRAME EURO TOP END FRAME Euro Diagonal Brace EURO DIAGONAL BRACE Euro Diagonal Brace Euro Top End Frame is the same as layher speedy frame or layher blitz frame design. -Made of steel, hot dip galvanized -Made of aluminium, light weight option Euro Top Intermediate Frame Euro Console Bracket is the same as layher speedy frame or layher blitz frame design. - Made of steel, hot dip galvanized Euro Console Bracket Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material 0.73m 1728.073 Steel 1.09m 1728.109 Steel 0.73m Aluminium Product Size Item No. Weight(kgs/pc) 2000x2070mm 18207 26.00 2000x2570mm 18257 30.00 2000x3070mm 18307 36.00 Product Size Item No. Weight(kgs/pc) 730mm 94073 7.30 1090mm 94109 10.10 1570mm 94157 13.30 2070mm 94207 17.60 2570mm 94257 20.60 3070mm 94307 25.00 Aluminium Combi Deck Aluminium Combi Deck Aluminium Combi Decks are also called aluminium access decks. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate Aluminium Staircase Aluminium Staircase is stairway for the planned construction with facade scaffolding Bay height 2.00 m ALUMINIUM STAIRCASE -The steps are designed in a non-slip manner and allow comfortable outside access for extensive use of scaffold and when transporting bulky material, without reducing the work surface in the main walkway Single load distributed on 0.2 x 0.2 m2 F = 1.5 kN Evenly distributed area load p = 2.5 kN/m2 Meets the requirements according to DIN EN 12811-1 Aluminium Staircase -Lightweight, non-slip working surface U hook aluminum platform ALUMINIUM COMBI DECK Euro Double End Guardrail Euro Double End Guardrail is the same as layher speedy frame or layher blitz frame design. -Made of steel, hot dip galvanized -Made of aluminium, light weight option EURO DOUBLE END GUARDRAIL Euro Double End Guardrail Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 610x2570mm 945257 24.50 610x3070mm 945307 28.00 Product Size Item No. Weight(kgs/pc) 300mm 90030 2.10 500mm 90050 2.80 600mm 90060 3.60 780mm 90078 4.50 1000mm 90100 5.20 Adjustable Base Jack For adjusting level with differences in height of the underground Steel, hot dip galvanized or Electro-galvanized. Hollow type with tube spindle - Base plate 150 x 150 mm AlumInium Access Deck With Ladder ADJUSTABLE BASE JACK ALUMINIUM ACCESS DECK WITH LADDER Adjustable Base Jack Adjustbale Base Jacks are also called base jacks, screw base jacks, scaffold jack base etct. Aluminium Access Deck With Ladder is made of aluminium profile frame. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate -With integrated access ladder U hook or O hook Aluminium Access Deck With ladder Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 320x76x1.5x730mm 29073 6.70 320x76x1.5x1090mm 29109 9.27 320x76x1.5x1400mm 29140 11.34 320x76x1.5x1570mm 29157 13.15 320x76x1.5x2070mm 29207 14.47 320x76x1.5x2570mm 29257 19.74 320x76x1.5x3070mm 29307 23.04 Product Size Item No. Weight(kgs/pc) 320x76x1.5x730mm 19073 6.16 320x76x1.5x1090mm 19109 8.82 320x76x1.5x1400mm 19140 10.55 320x76x1.5x1570mm 19157 12.17 320x76x1.5x2070mm 19207 15.45 320x76x1.5x2570mm 19257 19.55 320x76x1.5x3070mm 19307 23.87 Product Size Item No. Weight(kgs/pc) 730mm 94073 7.30 1090mm 94109 10.10 1570mm 94157 13.30 2070mm 94207 17.60 2570mm 94257 20.60 3070mm 94307 25.00 Product Size Item No. Weight(kgs/pc) 610x2570mm 945257 24.50 610x3070mm 945307 28.00 Aluminium Access Deck With ladder Aluminium Access Deck With Ladder is made of aluminium profile frame. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate -With integrated access ladder U hook or O hook ALUMINIUM ACCESS DECK WITH LADDER U hook aluminum platform ALUMINIUM COMBI DECK Aluminium Combi Deck Ringlock Steel Deck O Type Ringlock Steel Deck O Type, width 320mm, with hook connecting ringlock horizontal ledger. AlumInium Access Deck With Ladder Steel, hot dip galvanzied - Non-slip surface through pronounced hole profiling Steel, hot dip galvanzied - Non-slip surface through pronounced hole profiling Aluminium Combi Deck Aluminium Combi Decks are also called aluminium access decks. -Aluminium profile frame,plywood plate or glass-fibre-reinforced plastic plate -Lightweight, non-slip working surface RINGLOCK STEEL DECK O TYPE Ringlock Steel Deck U Type Ringlock Steel Deck O Type, width 320mm, with hook connecting ringlock horizontal ledger. O Hook Steel Deck RINGLOCK STEEL DECKS U TYPE Extremely robust, for the toughest operations Reducing the wall thickness and optimized hole profiling leads to weight savings Complies with the requirements of DIN EN 12811 Can be used in guard and roofguard scaffolds as per DIN 4420 U HOOK Steel Deck 1 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Weight(kgs/pc) 2000x2070mm 18207 26.00 2000x2570mm 18257 30.00 2000x3070mm 18307 36.00 Product Description Item No. Weight(LBS/pc) 3' Steel Plank RSP30 14.70 4' Steel Plank RSP40 18.60 5' Steel Plank RSP50 22.60 6' Steel Plank RSP60 26.50 7' Steel Plank RSP70 31.20 8' Steel Plank RSP80 34.30 10' Steel Plank RSP100 42.00 Product Description Item No. Weight(LBS/pc) 3' Low Profile Steel Plank RLP30 15.80 4' Low Profile Steel Plank RLP40 20.00 5' Low Profile Steel Plank RLP50 23.80 6' Low Profile Steel Plank RLP60 27.40 7' Low Profile Steel Plank RLP70 31.50 8' Low Profile Steel Plank RLP80 35.10 10' Low Profile Steel Plank RLP100 43.00 Product Size HDG Item No. Weight(kgs/pc) 230mmx1.8mmx700mm KSP0700 5.00 230mmx1.8mmx1200mm KSP1200 8.00 230mmx1.8mmx1800mm KSP1800 11.60 230mmx1.8mmx2400mm KSP2400 14.60 Single load distributed on 0.2 x 0.2 m2 F = 1.5 kN Meets the requirements according to DIN EN 12811-1 ALUMINIUM STAIRCASE Aluminium Staircase Aluminium Staircase Aluminium Staircase is stairway for the planned construction with facade scaffolding Bay height 2.00 m -The steps are designed in a non-slip manner and allow comfortable outside access for extensive use of scaffold and when transporting bulky material, without reducing the work surface in the main walkway Evenly distributed area load p = 2.5 kN/m2 Made of pre-galvanzied steel sheet Sit on the section of 2 transoms Tested and approved as per Australian standards AS 1577-2013 KWIKSTAGE STEEL PLANK Kwikstage Steel Plank - Meets ANSI, CSA, and OSHA standards of safety RINGLOCK LOW PFOFILE STEEL P2'419 Ringlock Low Profile Steel Plank Kwikstage Steel Plank Kwikstage Steel Plank manufactured from Pre Galvanised steel sheet pressed to a hollow shape 60 mm High x 230mm wide. Steel Planks are strong, durable and light in weight. They fit neatly sit on the section of 2 transoms. giving a non slip surface and a working deck. Ringlock Steel Plank Ringlock Low Profile Steel Plank Ringlock Low Profile Steel Plank, width 9.5", made of galvanized steel sheet, with hook connecting ringlock horizontal ledger. Non-slip surface through pronounced hole profiling - Reducing the wall thickness and optimized hole profiling leads to weight savings Ringlock Steel Plank Ringlock Steel Deck, width 9", with hook connecting ringlock horizontal ledger. Steel, hot dip galvanized - Non-slip surface through pronounced hole profiling - Meets ANSI, CSA, and OSHA standards of safety RINGLOCK STEEL PLANK 2 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) Aluminium Stair 1500mm KAS1500 34.00 Product Size Item No. Material 1250mm AP1.25 Steel 1650mm AP1.65 Steel 2000mm AP2.0 Steel 2500mm AP2.5 Steel 3000mm AP3.0 Steel Product Size Item No. Material 1315x495mm AD1315 Aluminium 1308x595mm AD1308 Aluminium Product Size Item No. Material Nordic Steel Stair 3050x2000mm HSS Steel Nordic Steel Stair is placed in the scaffold for workers to walk upwards. Steel, hot dip galvanized - Non-slip surface for walking NORDIC STEEL STAIR Nordic Steel Stair NORDIC ALUMINIUM DECK UNIT Nordic Aluminium Deck Unit - Non-slip surface through pronounced hole profiling Nordic Aluminium Deck Unit Nordic Aluminium Deck Unit, connecting Nordic horizontal components Aluminium Nordic Aluminium Plank Nordic Aluminium Plank, width 295mm, with hook connecting Nordic horizontal components Aluminium - Non-slip surface through pronounced hole profiling NORDIC ALUMINIUM PLANK Nordic Aluminium Plank Kwikstage Aluminium Stair Kwikstage Aluminium Stairs are designed specifically for use with the steel quickstage modular scaffolding system. They are pre-fabricated and designed to fit in a 1.2m x 2.5m bay with a 1.5m rise (lift). The stairs are 564mm wide with a rise of 230mm. Bay height 1.5m - Made of aluminium, Pre-fabricated for use with a 1.2m x 2.5m bay providing 1.5m lift. Stairs are 564mm wide with a stair rise of 230mm ALUMINIUM STAIR 3 Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) 48.3x4.0x500mm KS0500G 3.78 48.3x4.0x1000mm KS1000G 6.83 48.3x4.0x1500mm KS1500G 9.24 48.3x4.0x2000mm KS2000G 12.29 48.3x4.0x2500mm KS2500G 15.23 48.3x4.0x3000mm KS3000G 18.38 Product Size HDG Item No. Weight(kgs/pc) Solid Base Jack 650mm 6.25 Product Size HDG Item No. Weight(kgs/pc) 48.3x3.0x500mm KL0500G 2.50 48.3x3.0x700mm KL0700G 3.40 48.3x3.0x800mm KL0800G 3.80 48.3x3.0x1200mm KL1200G 5.45 48.3x3.0x1800mm KL1800G 7.20 48.3x3.0x2400mm KL2400G 9.00 Product Size HDG Item No. Weight(kgs/pc) Kwikstage Toe Board Bracket 730mm KTBBG 0.78 -Steel, hot dip galvanized -Hold the batten toe board vertically in place KWIKSTAGE TOE BOARD BRACKET KWIKSTAGE LEDGER Kwikstage Toe Board Bracket Kwikstage Toe Board Bracket is also known as toe board clips are Clamped to the standard with a captive wedge to hold the batten toe board vertically in place. -The V pressings provide vertical support when attaching horizontal ledgers and diagonal braces. SOLID BASE JACK Solid Base Jack Adjustable Solid Base Jack enables accurate levelling of the scaffolding on uneven ground and infinite adjustment on sloping ground Kwikstage Ledgers can connect the upper V pressings on the kwikstage standards. -Steel tube 48.33.0mm, hot dip galvanized or painted -With banana end fit into upper V pressings on the standards Kwikstage Ledger KWIKS:'-+ 9:'4*'8* Kwikstage Standard Kwiktage Standards has v pressings and can provide support for ledgers, transoms, diagonal braces. Kwikstage standards can be with spigot or without spigot. -Steel tube 48.34.0mm, hot dip galvanized or painted Kwikstage Standard Kwikstage Ledger -DIA34*650mm, Electro-galvanized or hot dipped galvanized -Solid type base jack Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) Kwikstage End Toe Board Bracket 730mm KETBBG 1.30 Product Size HDG Item No. Weight(kgs/pc) 4200mm KLB4200G 54.50 6300mm KLB6300G 81.30 Product Size HDG Item No. Weight(kgs/pc) 48.3*3.0*1700mm KB1700G 8.20 48.3*3.0*2000mm KB2000G 8.90 48.3*3.0*2700mm KB2700G 11.70 48.3*3.0*3200mm KB3200G 13.60 48.3*3.0*3600mm KB3600G 15.10 Product Size HDG Item No. Weight(kgs/pc) 700mm KT0700G 5.50 1200mm KT1200G 9.50 1800mm KT1800G 16.70 2400mm KT2400G 23.70 Kwikstage Transom Kwikstage Transom Kwikstage Transom fit into the lower V pressings on the standards to carry steel boards and secure the standards together. The transoms are installed horizontally and at 90 degrees to the ledger. -Transoms fit into the lower V pressings on the standard to carry steel boards KWIKSTAGE TRAMNSOM Kwikstage Ladder Beam -Steel, hot dip galvanized or painted Kwikstage Diagonal Brace Steel tube 48.3 x3.0mm, hot dip galvanized or painted Kwikstage Diagonal Braces can provide strength and stability to the scaffold. They can be used for handrail to strecther stairs. With swiveling wedge heads -For bracing the vertical scaffold structure and used for handrail to strecther stairs. KWIKSTAGE DIAGONAL BRACE Diagnal Brace Kwikstage Ladder Beam Kwikstage Ladder Beams are made of steel, hot dip galvanized or painted -Steel tube 48.34.0mm, hot dip galvanized or painted -Span over difficult access locations KWIKSTAGE LADDER BEAM -Steel, hot dip galvanized or painted -Secure to the outside of a standard to allow for the installation of toe boards. KWIKSTAGE END TOE BOARD BRACKET Kwikstage End Toe Board Bracket Kwikstage End Toe Board brackets also called toe board Clips are fabricated brackets placed on the outside of a scaffold standard to allow toe boards to be installed Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) 700mm KTB0700G 1.90 1200mm KTB1200G 3.10 1800mm KTB1800G 4.60 2400mm KTB2400G 5.90 Product Size HDG Item No. Weight(kgs/pc) 230mmx1.8mmx700mm KSP0700 5.00 230mmx1.8mmx1200mm KSP1200 8.00 230mmx1.8mmx1800mm KSP1800 11.60 230mmx1.8mmx2400mm KSP2400 14.60 Product Size HDG Item No. Weight(kgs/pc) 1200mm KIB1200 5.00 1800mm KIB1800 7.50 2400mm KIB2400 10.00 Product Size HDG Item No. Weight(kgs/pc) Kwikstage Steel Stillage KSSG 39.00 Sit on the section of 2 transoms Kwikstage Steel Stillages is also called kwikstage steel pallet, it built to hold kwikstage materials in a stable fashion while being lifted by a forklift to stock, stack-up and transport Kwikstage Steel Plank Kwikstage Infill Board KWISKTAGE INFILL BOARD Tested and approved as per Australian standards AS 1577-2013 KWIKSTAGE STEEL PLANK Kwikstage Infill Board Kwikstage Infill Board is designed to fill up the gaps between transom and plank to make a non slip surface Kwikstage Steel Stillage KWIKSTAGE TIE BAR Made of pre-galvanzied steel sheet Kwikstage Steel Plank Kwikstage Steel Plank manufactured from Pre Galvanised steel sheet pressed to a hollow shape 60 mm High x 230mm wide. Steel Planks are strong, durable and light in weight. They fit neatly sit on the section of 2 transoms. giving a non slip surface and a working deck. Made of pre-galvanzied steel sheet Steel, hot dip galvanized or painted Kwikstage Tie Bar - Used whenever 2 or 3 board stage brackets are fitted and ensure positive location of the boards. Kwikstage Tie Bar have pins at each ends which fit in holes of 2 and 3 board hop up brackets to prevent the brackets from spreading and the planks from becoming dislodged Kwikstage Tie Bar Steel, hot dip galvanized or painted - Storage and transport KWIKSTAGE STEEL STILLAGE - Anti-slip surface Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) Kwikstage Mesh Stillage KMSG 70.00 Product Size HDG Item No. Weight(kgs/pc) 1200mm KTT1200G 22.00 1800mm KTT1800G 32.50 2400mm KTT2400G 41.00 Product Size HDG Item No. Weight(kgs/pc) 1/4 KCP14 6.30 2/2 KCP22 12.00 1/2 KCP12 4.30 3/2 KCP32 15.00 Product Size HDG Item No. Weight(kgs/pc) 700mm KLAT0700G 6.80 1200mm KLAT1200G 11.50 1800mm KLAT1800G 17.20 2400mm KLAT2400G 22.50 Product Size HDG Item No. Weight(kgs/pc) 1 Board K1BG 2.30 2 Board K2BG 6.40 3 Board K3BG 11.30 KWIKSTAGE HOP UP BRACKET Kwikstage Hop Up Bracket - Provide an extra work platform. located on the inside face of the scaffold these come in 1, 2 and 3 board sizes. KWIKSTAGE LADDER ACCESS TRANSOM Kwikstage Ladder Access Transom Kwikstage Hop Up Bracket Kwikstage Hop Up Brackets are also called kwikstage Stage Brackets, They fit into the V pressing of the standard which is nearest to the wall. The 2 board brackets and 3 board brackets have holes into which tie bar pins are attached. They are used to provide cantilevered platform on the inside of the scaffold nearest the wall. Steel, hot dip galvanized or painted Kwikstage Corner Panel Kwikstage Ladder Access Transom Kwikstage Ladder Access Transom component used for insertion into scaffold bay. Allows installation of a ladder opening within the scaffold deck. Steel, hot dip galvanized or painted - To render access to the scaffold platform through ladders Kwikstage Truss Transom heavy duty back to back angle transoms for location of scaffold boards. These are used to where greater loads are required for pedestrain access. Steel, hot dip galvanzied or painted - Utilised to construct secure walkways in pedestrian areas. Steel, hot dip galvanized or painted - Used as a gap filler between hop up brackets KWIKSTAGE CORNER PANEL Steel, hot dip galvanized or painted - Storage and transport RINGLOCK BOARD BRACKET U TYPE RINGLOCK TRUSS TRANSOM Kwikstage Truss Transom Kwikstage Corner Panel Kwikstage Corner Panel is also called kwikstage corner filler, used as a gap filler between hop up brackets Kwikstage Truss Transom Kwikstage Mesh Stillage Kwikstage Mesh Stillages is also called kwikstage mesh pallet, it built to hold kwikstage materials in a stable fashion while being lifted by a forklift to stock, stack-up and transport Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) Kwikstage Doube C Clip KDCCG 1.20 Product Size HDG Item No. Weight(kgs/pc) Aluminium Stair 1500mm KAS1500 34.00 Product Size HDG Item No. Weight(kgs/pc) Kwikstage Stair Intermediate Handrail KSIH 11.50 Product Size HDG Item No. Weight(kgs/pc) Kwikstage Stair Top Handrail KSTH 21.00 Used for join 2 standards together KWIKSTAGE DOUBLE C CLIPS ALUMINIUM STAIR - Made of aluminium, Pre-fabricated for use with a 1.2m x 2.5m bay providing 1.5m lift. Stairs are 564mm wide with a stair rise of 230mm - Provided a hand rail assistance Kwikstage Aluminium Stair Kwikstage Aluminium Stairs are designed specifically for use with the steel quickstage modular scaffolding system. They are pre-fabricated and designed to fit in a 1.2m x 2.5m bay with a 1.5m rise (lift). The stairs are 564mm wide with a rise of 230mm. Bay height 1.5m KWIKSTAGE STAIR INTERMEDIATE HANDRAIL Kwikstage Stair Top Handrail Kwikstage Doube C Clip Kwikstage Double C Clips used to Join Kwikstage scaffolding Standards Back to Back for more stability and steenght to the scaffold structure Steel, hot dip galvanized Kwikstage Stair Intermediate Handrails are made of steel and hot dipped galvanized, provided a hand rail assistance when walking up the stair access bay. - Steel, hot dip galvanized or painted Kwikstage Stair Intermediate Handrail Kwikstage Stair Top Handrails are made of steel and hot dipped galvanized, provides a top rail at the end of your stair access. Steel, hot dip galvanized - Provides a top rail at the end of your stair access. KWIKSTAGE STAIR TOP HANDRAIL Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size HDG Item No. Weight(kgs/pc) 730mm KMG0700 4.50 1270mm KMG1200 9.10 1830mm KMG1800 12.10 2440mm KMG2400 15.30 Product Size HDG Item No. Weight(kgs/pc) 500mm KLP500 9.70 700mm KLP700 12.30 Product Size HDG Item No. Weight(kgs/pc) 300mm KLTB1 2.20 500mm KLTB2 4.20 KWIKSTAGE LAP PANEL Steel, hot dip galvanized With one half coupler or with two half couplers Kwikstage Lap Panel Kwikstage Mesh Guard Kwikstage Mesh Guard KWIKSTAGE WALL TIE BRACKET Kwikstage Wall Tie Bracket Kwikstage Wall Tie Bracket Kwikstage Wall Tie Bracket one half coupler and two half couplers suitable to hold 48.30 OD tube are used to secure the scaffold to a structure. Kwikstage Mesh Guard is also called kwikstage brick guard or kwikstage mesh panel. It designed to be suspended from a guard rail ledger enclosing the space between the ledger and the working platform for safety. -Steel, hot dip galvanized -Steel, hot dip galvanized -Fill the gaps minimising trip hazard and deck weight variances. Kwikstage Lap Panels are an alternative for the LVL Scaffold planks. Steel panels have a folded returned to lock in between steel boards. Lap panels fill the gaps minimising trip hazard and deck weight variances. -Placed between the ledger and the steel plank KWIKSTAGE MESH GUARD Kwikstage Lap Panel Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material 500mm FSB0.5 Steel 1000mm FSB1.0 Steel 1500mm FSB1.5 Steel 2000mm FSB2.0 Steel 3000mm FSB3.0 Steel Product Size Item No. Material 500mm FSS0.5 Steel 1000mm FSS1.0 Steel 1500mm FSS1.5 Steel 2000mm FSS2.0 Steel 3000mm FSS3.0 Steel Product Size Item No. Material 500mm AS0.5 Aluminium 1000mm AS1.0 Aluminium 1500mm AS1.5 Aluminium 2000mm AS2.0 Aluminium 3000mm AS3.0 Aluminium Product Size Item No. Material 750mm ERB0.5 Steel 650mm ERB0.65 Steel 720mm ERB0.72 Steel 1000mm ERB1.0 Steel 1200mm ERB1.2 Steel 1600mm ERB1.6 Steel 1900mm ERB1.9 Steel 2450mm ERB2.45 Steel 3000mm ERB3.0 Steel Nordic Standards Nordic Single Tube Beam Nordic Single Tube Beam NORDIC STANDARDS Nordic Standards Nordic Standards have U lugs to provide support for ledger beams, diagonal braces. -Steel tube 48.3mm, hot dip galvanized or painted -U lugs provide support when attaching ledger beams, diagonal braces. Nordic Single Tube Beams have pins to insert the U lugs to provide horizontal support. -Steel, hot dip galvanized or painted -Nordic horizontal component Nordic Standards Nordic Standards have U lugs to provide support for ledger beams, diagonal braces. -Steel tube 48.3mm, hot dip galvanized or painted -U lugs provide support when attaching ledger beams, diagonal braces. NORDIC SINGLE TUBE BEAM NORDIC STANDARDS Nordic Standards -U lugs on the same level Nordic Aluminium Standards Nordic Aluminium Standards have U lugs to provide support for ledger beams, diagonal braces. -Aluminium tube 48.3mm -U lugs on the same level -U lugs provide support when attaching ledger beams, diagonal braces. NORDIC ALUMINIUM STANDARDS Nordic Aluminium Standards Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material 1200mm AERB1.2 Aluminium 1600mm AERB1.6 Aluminium Product Size Item No. Material 1600mm LB1.6 Steel 1900mm LB1.9 Steel 2450mm LB2.45 Steel 3000mm LB3.0 Steel Product Size Item No. Material 1600mm ALB1.6 Aluminium 1900mm ALB1.9 Aluminium 2450mm ALB2.45 Aluminium 3000mm ALB3.0 Aluminium Product Size Item No. Material 720mm TB0.72 Steel 1000mm TB1.0 Steel 1200mm TB1.2 Steel 1600mm TB1.6 Steel Product Size Item No. Material 720mm SKRV0.72 Steel 1600mm SKRV1.6 Steel 1900mm SKRV1.9 Steel 2450mm SKRV2.45 Steel 3000mm SKRV3.0 Steel Nordic Transom Beam NORDIC TRANSOM BEAM NordicTransom Beam Nordic Transom Beams as horizontal members provide horizontal support for Nordic system scaffolding -Steel, hot dip galvanized or painted -Nordic horizontal component Nordic Guardrail Frame Nordic Guardrail Frames provide horizontal support and protection for Nordic system scaffolding -Steel, hot dip galvanized or painted -Nordic horizontal component Nordic Aluminium Single Tube Beam Nordic Aluminium Single Tube Beams have pins to insert the U lugs to provide horizontal support. -Aluminium -Nordic horizontal component NORDIC ALUMINIUM SINGLE TUBE BEAM Nordic Aluminium Single Tube Beam Nordic Ledger Beam Nordic Ledger Beams as horizontal members provide horizontal support for Nordic system scaffolding -Steel, hot dip galvanized or painted -Nordic horizontal component NORDIC LEDGER BEAM Nordic Ledger Beam Nordic Aluminium Ledger Beam Nordic Aluminium Ledger Beams as horizontal members provide horizontal support for Nordic system scaffolding -Aluminium -Nordic horizontal component NORDIC ALUMINIUM LEDGER BEAM Nordic Aluminium Ledger Beam NORDIC GUARDRAIL FRAME Nordic Guardrail Frame Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material 1050mm SGN1050 Steel 1250mm SGN1250 Steel 1655mm SGN1655 Steel 1964mm SGN1964 Steel 2500mm SGN2500 Steel 3000mm SGN3000 Steel Product Size Item No. Material 2000x1200mm DSWP1.2 Steel 2000x1600mm DSWP1.6 Steel 2000x3000mm DSWP3.0 Steel 1200x3000mm DS1.2 Steel 1600x3000mm DS1.6 Steel Product Size Item No. Material 300mm SK0.3 Steel 500mm SK0.5 Steel 700mm SK0.7 Steel Product Size Item No. Material 1250mm AP1.25 Steel 1650mm AP1.65 Steel 2000mm AP2.0 Steel 2500mm AP2.5 Steel 3000mm AP3.0 Steel Product Size Item No. Material 1315x495mm AD1315 Aluminium 1308x595mm AD1308 Aluminium NordicBracket Nordic Bracket Nordic Brackets provide additional space to attach decks for Nordic system scaffolding Nordic Diagonal Brace NORDIC BRACKET Nordic Diagonal Brace Nordic Diagonal Braces provide support and protection for Nordic system scaffolding With swiveling wedge - With swiveling wedge on plate NORDIC DIAGONAL BRACE Steel, hot dip galvanzied - To extend scaffold the working platform closer to the buidling structure Nordic Aluminium Plank Nordic Aluminium Plank, width 295mm, with hook connecting Nordic horizontal components - Non-slip surface through pronounced hole profiling NORDIC ALUMINIUM PLANK Nordic Aluminium Deck Unit Nordic Aluminium Deck Unit, connecting Nordic horizontal components Nordic Aluminium Plank Nordic Aluminium Deck Unit Aluminium - Non-slip surface through pronounced hole profiling NORDIC ALUMINIUM DECK UNIT Nordic Safety Gate Net Nordic Safety Gate Net provide protection for Nordic system scaffolding -Steel, hot dip galvanized -Protection for Nordic system scaffolding NORDIC SAFETY GATE NET Nordic Safety Gate Net Aluminium Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
Product Size Item No. Material Nordic Steel Stair 3050x2000mm HSS Steel Product Size Item No. Material Nordic Aluminium Stair Handrail 3050x2000mm HSH Aluminium Product Size Item No. Material BVF Steel 600mm SVF0.6 Steel 800mm SVF0.8 Steel Product Size Item No. Weight(kgs/pc) 300mm 90030 2.10 500mm 90050 2.80 600mm 90060 3.60 780mm 90078 4.50 1000mm 90100 5.20 Nordic Aluminium Stair Handrail Nordic Aluminium Stair Handrail is placed in the scaffold for workers to step upwards. Aluminium NORDIC ALUMINIUM STAIR HANDRAIL Nordic Tie Rod Clamp - Protection NORDIC TIE ROD CLAMP - Non-slip surface for walking Nordic Steel Stair Nordic Steel Stair is placed in the scaffold for workers to walk upwards. Steel, hot dip galvanized ADJUSTABLE BASE JACK Adjustable Base Jack For adjusting level with differences in height of the underground Adjustable Base Jack Adjustbale Base Jacks are also called base jacks, screw base jacks, scaffold jack base etct. Steel, hot dip galvanized or electri-galvanized. Hollow type with tube spindle - Base plate 150 x 150 mm Steel, hot dip galvanized - Use with tie rod together NORDIC STEEL STAIR Nordic Tie Rod Clamp Nordic Tie Rod Clamp is made of steel and always use with tie rod Copyright 2021 HISCAFFOLD CO.,LTD. All rights reserved. HISCAFFOLD.COM
