MARINE ENVIRONMENTAL SOLUTIONS
MARKLEEN MARKLEEN SOLUTIONS PRODUCTS SERVICES CHOOSE MARKLEEN EXPERIENCE THE QUALITY REFERENCE CUSTOMERS MARKLEEN PRODUCTS DETAIL 1 2 2 9 10 10 11 11 12 CONTENTS
MARKLEEN products and services are designed to prevent and minimise marine pollution, and be effective when dealing with oil spills. There are containment booms available for every scenario, whether it be a spill in a marina, in a coastal area near a sensitive spot, or out at sea, and the design and size of the boom should take into account all circumstances. PRODUCTS MARKLEEN SOLUTIONS CONTAINMENT BOOMS 2
Type: Containment Booms Sectors: Oil spill clean-up Use: Ports & harbours ECOSPEED Self-inflatable containment boom Type: Containment Booms Sectors: Oil spill clean-up Use: Open sea ECOSAFE Strong inflatable booms Type: Containment Booms Sectors: Oil spill clean-up Use: Open sea ECOMARINE Single-point inflatable offshore boom Type: Containment Booms Sectors: Oil spill clean-up Use: Ports & harbours ECOFLEX Rapid response fence boom Type: Containment Booms Sectors: Industry Use: Ports & harbours ECOSOLID Containment booms with cylindrical foam floatation ECOPROTECT BEACH SEALING BOOM Type: Containment Booms Sectors: Construction Use: Ports & harbours Type: Containment Booms Sectors : Industry Use: Ports & harbours Type: Containment Booms Sectors: Oil spill clean-up Use: Ports, Beach & harbour SILT CURTAINS Permanent containment boom P Series Oil containment booms for use in intertidal areas Submerged screens to contain sediments in suspension 3
Type: High Speed Sweep Systems Sectors: Industry Use: Ports & harbours NOFI Current Buster 2 - Shallow Water Type: High Speed Sweep Systems Sectors: Industry Use: Ports & harbours NOFI Current Buster 4 Type: High Speed Sweep Systems Sectors: Industry Use: Ports & harbours The speed of the first response often determines whether the oil spill remains a minor incident, or if it develops into a more costly spill. The NOFI BoomBag is specially designed for fast response with minimal requirements for boats and personnel. NOFI BOOM BAG SYSTEM The NOFI Current Buster Technology represents a revolution in oil spill containment systems and holds an international patent. It has the unique ability to collect and concentrate spilled oil in current exposed waters or when being towed at high speed. What differentiates the NOFI Current Buster system from other high-speed oil booms is the built-in separator. 4 HIGH SPEED SWEEP SYSTEMS
Type: Skimmers Sectors: Oil spill clean-up Use: Open sea Capacity : 30 m3 / h Multiskimmers MS30 Type: Skimmers Sectors: Oil spill clean-up Use: Open sea Capacity : 60 m3 / h Multiskimmers MS60 Type: Skimmers Sectors: Oil spill clean-up Use: Ports & harbours Weir Skimmers Type: Skimmers Sectors: Industry Use: Ports & harbours Weir Skimmer For Shallow Water Type: Skimmers Sectors: Oil spill clean-up Use: Ports & harbours Capacity : 10 m3 / h Multiskimmers MS10 Type: Skimmers Sectors: Oil spill clean-up Use: Ports & harbours Capacity : 20 m3 / h Multiskimmers MS20 5 Skimmers are devices used for the mechanical recovery of oil on water. They can be oleophilic, meaning they distinguish between oil and water by way of their brush, disc or drum modules, or can be weir type skimmers, with a floating ring. SKIMMERS
Type: Storage tanks Sectors: Oil spill clean-up Use: Open sea ECOBAG Towable tank for temporary oil storage Type: Storage tanks Sectors: Industry Use: Ports & harbours ECOTANK Portable tanks for temporary oil storage Type: Storage tanks Sectors: Industry Use: Ports & harbours ECOPOOL Pop- Up Tanks For Instant Spill Containment When carrying out an oil spill clean-up operation it is important to have ready enough storage capacity for the recovered oil, in a way which is practical and easy to use. Markleen manufactures and supplies a number of solutions for the temporary storage of oil for use on docksides, beaches and ships 6 STORAGE TANK
Type: Ancillary equipment Sectors: Industry Use: Ports & harbours ECOREEL Hydraulic Reels For Handling Oil Booms Type: Ancillary equipment Sectors: Oil spill clean-up Use: Ports & harbours Containerised solutions Sea containers for optimum storage of oil spill response equipment packages Type: Ancillary equipment Sectors: Oil spill clean-up Use: Ports & harbours Hydraulic Boom Reels Type: Ancillary equipment Sectors: Oil spill clean-up Use: Ports & harbours Hydraulic Power Packs Markleen supplies complete oil spill packages, including all necessary equipment. Many products require ancillary equipment such as hydraulic reels for oil containment booms, power packs to operate hydraulic equipment, oil transfer pumps and storage containers and cages. Usually present in any oil spill containment and recovery operation at sea The best way of deploying and recovering inflatable or flat floatation oil containment booms 7 ANCILLARY EQUIPMENT
Type: Sorbents Sectors: Industry Use: Ports & harbours Skirted Sorbent Booms Type: Sorbents Sectors: Oil spill clean-up Use: Beaches and coasts Sorbent spill kits : Marine Type: Sorbents Sectors: Industry Use: Ports & harbours Oil containment and absorption in a wide variety of marine applications Sorbent spill kits : Industrial Multi-format sorbent kits to cover any kind of spill in industry These handy clean-up kits provide a complete solution to accidental spills of oil or fuel on water. 8 SORBENTS Sorbents are a vital tool when dealing with all kinds of spills, whatever the application and whatever the liquid. There are two categories of sorbents: those which absorb oil only and repel water, and those which absorb all liquids, including chemicals and water
Take a look at some of the solutions provided by Markleen to its customer’s problems. We work hand in hand with our customers from day one to offer them an integral package which is tailored to their needs. Preventive maintenance and repair Product commissioning and training 9 SERVICES
10 CHOOSE MARKLEEN GROUP • More than 20 years of experience in the offshore sector • In-house engineering and development department • Adaptability to customer needs • Highly specialised personnel • Design and manufacturing under strict quality controls in our plants • Wide network of distributors worldwide • Global solutions • After-sales service with worldwide coverage MARKLEEN’s direct involvement in many oil spills has given us the experience and knowledge required to help customers prepare a sustainable response to oil spill emergencies. Private and public organisations worldwide have put themselves in our hands when dealing with oil spill response Quality in production processes, the application of new technology to our products and adaptability to customer needs form the basis of our company. All our products have been successfully tested by our professionals in the harshest of working environments. EXPERIENCE, The basis for our company
11 THE QUALITY Our company guarantees the quality and inspection of all its equipment, and manufactures all its products in Europe, at its manufacturing facilities in Spain and Sweden. Our company is endorsed by DNV (Det Norske Veritas) with ISO 9001, ISO 14001 and OHSAS 18001 certifications. REFERENCE CUSTOMERS
MARKLEEN PRODUCTS DETAIL 12
CONTAINMENT BOOMS
www.markleen.com The ECOSPEED booms are air-filled containment booms which expand instantly as they come off the reel during deployment, without the need of blowers, compressors, or other forms of external air-supply. Instead, air is sucked in through the flush-mounted breathers situated on the top of the boom, thereby filling the floats with atmospheric air. The self-inflating system and absence of check valves make the ECOSPEED an exceptionally fast launching boom, with minimum personnel requirements. ECOSPEED booms have excellent wave following characteristics because of their high buoyancy, flexibility, and stability. Internal solid flotation foam gives the booms plenty of reserve buoyancy making them virtually impossible to sink in the case of damage. – Solutions for the marine environment ECOSPEED Self-inflatable containment boom
Contact Technical Specifications increased visibility in the dark. The booms are bright yellow and have pockets for flashing, high-intensity LED marker lights every 25 metres in addition to generously sized welded-on reflectors on the entire circumference of the float every 5 metres. ECOSPEED Inflation system Type of floatation Section length [m] Freeboard height [mm] Draft (skirt) [mm] Total height [mm] Fabric type Fabric weight [g/m2] Ballast Handling straps Mooring points Buoy light pockets Reflex reflectors Sea state, Beaufort Deployment time 850 1150 Markleen Management S.L. Pol. Río Gállego, C/ E, 22, 50840 San Mateo de Gállego, Zaragoza, Spain • Email: [email protected] • Phone (+34) 976 68 30 00. ECOSPEED Self-inflatable containment boom 2-3 25 350 500 850 Self-inflatable Air-filled 25 500 650 1150 PU/PVC blend coated polyester 1200 High quality thermo- galvanised chain Yes Yes Yes Yes 4-5 Rapid The air breathers prevent water from entering the floatation chambers and eliminate the risk of damage associated with surface-mounted valves. Moreover, each 25-metre section has drainage valves at both ends. Water that might enter a damaged boom will automatically drain out when the boom is lifted out of the sea with the boom reel, without the need for opening valves or removing caps. ECOSPEEED booms are made from high-frequency welded PU/PVC blended fabric, which is resistant to oil, salt, and UV light. ECOSPEED booms are designed to provide
www.markleen.com – Solutions for the marine environment ECOSAFE booms are conventionally inflatable oil containment booms with easily replaceable internal buoyancy chambers. Cylindrical floats with short, independent buoyancy chambers give the boom excellent floating ability and particularly good wave following properties. ECOSAFE Strong inflatable booms
Contact Technical Specifications Should the boom suffer damage, it is easy to replace the affected buoyancy chamber on site. ECOSAFE booms are designed to be easy to deploy and give reliable operation with low personnel requirements. The proven design, low inflation pressure and high buoyancy to weight ratio make these booms an effective tool for oil containment, even in adverse weather conditions. The booms are designed to remain in the water for long periods of time. ECOSAFE booms are made from high frequency welded heavy PU/PVC blended fabric, being resistant to oil, salt, and UV light. ECOSAFE booms are designed to provide increased visibility in the dark. The booms are bright yellow and have pockets for flashing, high-intensity LED marker lights every 25 metres in addition to generously sized welded-on reflectors on the floats every 5 metres. ECOSAFE booms are also available in an extra heavy-duty version with double fabric thickness in the floats, being stronger than most booms made of rubber, Hypalon or neoprene. ECOSAFE Inflation system Type of floatation Chamber length, if applicable [m] Section length [m] Freeboard height [mm] Draft (skirt) [mm] Total height [mm] Fabric type Fabric weight [g/m2] Weight dry [m] Ballast Handling straps Mooring points Buoy light pockets Reflex reflectors Sea state, Beaufort Deployment time – per 100m [min] 1100 1400 1800 Markleen Management S.L. Pol. Río Gállego, C/ E, 22, 50840 San Mateo de Gállego, Zaragoza, Spain • Email: [email protected] • Phone (+34) 976 68 30 00. ECOSAFE Strong inflatable booms 4 5 3 25 400 700 1100 1250 6 Air/Manual Air inflated, separate chambers 3 3 25 25 600 800 800 1000 1400 1793 Yellow TPU-PVC blend coated PES 1250 1250 8 12 Thermo-galvanized high tensile chain Yes Yes Yes Yes 5 6 5 6
www.markleen.com – Solutions for the marine environment ECOMARINE® series Single-point inflatable offshore boom The ECOMARINE boom is the most advanced offshore boom systems available today. The boom expands instantly during deployment, due to coils of highpressure air hoses taking a spiral shape as soon as the boom comes off the reel. As the boom expands, atmospheric air is drawn in through dedicated breather hoses, filling the floats with air. The ECOMARINE boom’s inflation system reduces deployment and recovery times, as well as personnel requirements, to a minimum. The ECOMARINE boom series has two independent air circuits for redundancy and has bulkheads dividing the continuous float into 5-metre chambers, allowing for a fully operational boom even if one of the circuits should fail. The boom design also features a secondary high-flow back-up air system that is used to top up the boom’s chamber-air if necessary, enabling the boom to be deployed over long periods of time, even in rough conditions.
Contact Markleen Management S.L. Pol. Río Gállego, C. E, 22, 50840 San Mateo de Gállego, Zaragoza Email: [email protected] • Phone (+47) 00 00 00 00, ECOMARINE® Single-point inflatable offshore boom ECOMARINE boom fully operative when it reaches the water. The fabric used to manufacture the ECOMARINE booms is highly resistant to oil, chemicals, all weather conditions, and UV light. This fabric is both strong and lightweight, giving rise to high quality booms, highly flexible and with excellent wave-following characteristics. All seams and unions are high frequency welded, maintaining the excellent mechanical properties of the membrane. Deployment, recovery, and storage ECOMARINE booms are designed to be stored and operated with an ECOREEL with turntable and integrated air delivery system to inflate the boom automatically while being deployed. The spiral hoses are pressurized while the boom is still on the reel and during deployment the spiral hoses expand the float as the boom leaves the reel, making the boom fully operational when it reaches the water. The only operating and storage space required on deck is the ECOREEL’s own footprint. Remote control operation The ECOMARINE boom system is best operated using the remote control of the ECOREEL from any position on board the vessel. A single operator can control boom inflation, deployment, and recovery with a full view of all movements. A major advantage of this system is that it allows the boom to be deployed in rough conditions without the need for crew or other personnel being in direct contact with the equipment. ECOMARINE boom internal spiral system. ECOMARINE boom operating with cross-bridle. Specifications ECOMARINE® 1500 1900 2200 2700 Inflation system Self-inflatable Type of floatation Double spiral hose/back up system Chamber length, if applicable [m] 5 Section length [m] Up to 400 m Freeboard height [mm] 600 800 1000 1200 Draft (skirt) [mm] 900 1100 1200 1500 Total height [mm] 1500 1900 2200 2700 Fabric type Yellow TPU/PVC blend coated polyester Fabric weight [g/m2] 1250 1250 1250 1250 Weight dry [kg/m] 15 21 23 25 Ballast High strength thermogalvanized chain Tension members Central and bottom Top, central and bottom Top, central and bottom Top, central and bottom Buoy light pockets Yes Reflex Yes, every 5 m Sea state, Beaufort 5 6 6 - 7 7 Deployment time Fast deployment, typically 15 min 300 m.
www.markleen.com – Solutions for the marine environment ECOFLEX Rapid response fence booms ECOFLEX Series booms are easy to handle high quality fence booms for use in harbours and coastal applications.
Contact Specifications Construction ECOFLEX booms are made from highfrequency welded PVC-coated fabric, which is resistant to oil, salt, and UV light. The floats are made of flat, closed-cell foam and the booms feature vertical fibreglass stiffeners. The booms are fitted with handles, pockets for marker lights every 25 metres, generously sized welded-on reflectors, and a galvanised ballast chain, making them extremely robust while being of low weight. ECOFLEX booms are equipped with DRC connectors as standard. Deployment The ECOFLEX boom’s compact design means that it can be stored and deployed from a boom reel or manually from a customised container, requiring only 2 operators. There are handles placed every metre along the top of the boom for ease of handling. Retrieval is equally straightforward, and the boom’s flat surfaces make it easy to clean. ECOFLEX Type of floatation Section length [m] Freeboard height [mm] Draft (skirt) [mm] Total height [mm] Fabric type Fabric weight [g/m2] Weight dry [kg/m] Ballast Handling straps Mooring points Buoy light pockets Reflex reflectors Sea state, Beaufort Deployment time 500 750 900 Markleen Management S.L. Pol. Río Gállego, C/ E, 22, 50840 San Mateo de Gállego, Zaragoza, Spain • Email: [email protected] • Phone (+34) 976 68 30 00. ECOFLEX Rapid response fence booms Solid foam 25 200 300 500 Yellow PVC coated PES 950 3 Galvanised chain Yes Yes Yes Yes 2 Rapid Solid foam 25 250 500 750 Yellow PVC coated PES 950 4 Galvanised chain Yes Yes Yes Yes 2-3 Rapid Solid foam 25 300 600 900 Yellow PVC coated PES 950 5 Galvanised chain Yes Yes Yes Yes 3 Rapid
ECOSOLID Containment booms with cylindrical foam floatation ECOSOLID containment booms are solid floatation booms for harbours and inshore waters. The booms are equipped with flexible, closed cell foam floats, giving the boom excellent wave following characteristics and a particularly robust construction, allowing for a long service-life in adverse conditions. www.markleen.com – Solutions for the marine environment
Contact Technical Specifications The fabric used, top quality, highfrequency-welded oil-resistant coated fabrics, make this boom robust and highly resistant to hydrocarbons, chemical agents, and adverse weather conditions. A high visibility yellow colour and large reflective strips vertically positioned on the floats make the boom easy to see in the dark. Folding points are marked in black every 2 m. Each 25-metre section has drainage valves at both ends. Water that might enter a damaged boom will automatically drain out when the boom is lifted out of the sea, without the need for opening valves or removing caps. Each section is also fitted with the flexible Dynamic Response end connectors, mooring points, handles and a holder for high-intensity LED marker lights. ECOSOLID is exclusively developed and designed for packing in the NOFI BoomBag system, but may also be stored on pallets, in packing crates, hung from ceiling-mounted rails in containers and spooled onto most boom reels. ECOSPEED Type of floatation Section length [m] Freeboard height [mm] Draft (skirt) [mm] Total height [mm] Fabric type Fabric weight [g/m2] Weight dry [kg/m] Ballast Handling straps Mooring points LED marker lights pockets Reflex reflectors Sea state, Beaufort Deployment time 250 350 Markleen Management S.L. Pol. Río Gállego, C/ E, 22, 50840 San Mateo de Gállego, Zaragoza, Spain • Email: [email protected] • Phone (+34) 976 68 30 00. ECOSOLID Containment booms with cylindrical foam floatation Solid 25 25 250 350 350 450 600 800 PU/PVC blend coated polyester 950 950 3,2 5,2 Galvanized chain Yes Yes Yes Yes 2-3 2-3 Rapid Data shown is to be used as a guideline only. In keeping with its policy of continuous improvement MARKLEEN reserves the right to modify its specifications without prior notice. Base fabric length (±2%). Other materials or other end connectors are available on request.
www.markleen.com – Solutions for the marine environment Permanent containment booms with rigid external floats for protected waters. ECOPROTECT 700 booms are heavy duty booms which are built to give a particularly long service life in installations where they are used frequently or permanently. ECOPROTECT 700 Permanent Booms
Contact Technical Specifications ECOPROTECT booms are made using a strong PU-PVC blend coated polyester barrier fabric with high-density polyethylene floats filledwith polyurethane foam. The floats are bolted in pairs,trapping the boom fabric in between, this gives rise to a heavy-duty build which is alsoeasy to maintain and repair on site. The boom’s visibility is enhanced by reflective strips on the ends of each section. ECOPROTECT Type of floatation Section length ±2% [m] Floats distance ±2% [mm] Total height [mm] Freeboard height [mm] Draft [mm] Fabric type Fabric weight [g/m2] Weight dry [kg/m] Ballast [mm] Handling straps Mooring points Buoy light pockets Reflex reflectors Sea state, Beaufort Deployment time – per 100m [min] 700 Markleen Management S.L. Pol. Río Gállego, C/ E, 22, 50840 San Mateo de Gállego, Zaragoza, Spain • Email: [email protected] • Phone (+34) 976 68 30 00. ECOPROTECT 700 Permanent Booms 863 700 300 400 7.7 Polyurethane foam filled polyethylene floats 25 Yellow TPU-PVC blend coated PE 1700 13x81 mm long link Approximately every 6.25m Approximately every 6.25m Located at the end of each section Approximately every 6.25m 3 15
HIGH SPEED SWEEP SYSTEMS
www.allmaritim.com – Supplier of environmental products that make a difference NOFI Current Buster 2 / shallow water The NOFI Current Buster® technology is one of the world’s most efficient and advanced oil containment and recovery systems, capable of containing and controlling oil in up to 5 knots towing speed* without losing any of the contained oil.
AllMaritim AS, Hillerenveien 82, 5174 Mathopen, Norway Email: [email protected] • Phone: (+47) 55 33 61 60 Contact NOFI Current Buster 2 / Shallow water Technical Specifications Model NCB2 / SW Max speed through water (STW) 3 knots Max. Front opening 15 m Max. Front opening separator 6 m Storage tank 11 m3 Dimensions Freeboard maximum length Ø 600 Total length 27 m Total width 3.2 m Weight Total system dry weight 580 kg Total weight Separator 350 kg Total weight front sweep 230 kg Storage / Transport Boom reel size (m3 ) 3 m3 Container size (inch) 10’ Boom Vane type Shallow water 0.5 m The NOFI Current Buster® 2 / SW is based on the same proven Current Buster® technology designed specifically to meet the demands of operating in fast moving shallow waters. The draft of the Current Buster 2 / SW has been reduced to approximately one meter and the system can be separated into two parts to aid in overland and air transport to remote locations. Recent trials on the Columbia, Flathead, Middlefork and Yukon River using the NOFI Current Buster® systems together with a BoomVane confirm the ease of operation and efficiency in challenging fast water environments in remote locations. Other features: • System divided into two parts. Functional only using the separator part with a sweep opening of 6m (System opening 15m). • Bottom tension member, chain replaced by leaded Dynema. • Floating sweep netting. • Draft reduced to 1 m.
www.allmaritim.com – Supplier of environmental products that make a difference NEW NOFI Current Buster 4 The NOFI Current Buster Technology, holding an international patent, represents a revolution within the oil spill containment systems available. Over the years, it has proven a unique ability to collect and concentrate spilled oil, even in current exposed waters and at high towing speeds. The enhanced features have resulted in the highest recorded recovery efficiency by any available oil spill containment systems. The system is suitable for fjords, bays, coastal and offshore areas with currents up to 4 knots. At towing speeds between 4 and 4,4 knots (STW*), the NCB4 offers excellent area coverage and high maneuverability. The compact system can be easily turned and towed quickly between oil slicks. It may be operated by one single vessel in combination with the paravane BoomVane. It is a plugand-play system that requires no vessel modification and a minimum of space on deck. *speed through water
AllMaritim AS, Hillerenveien 82, 5174 Mathopen, Norway Email: [email protected] • Phone: (+47) 55 33 61 60 Contact New NOFI Current Buster 4 The New NOFI Current Buster 4 reflects years of continuous development and improvements of the globally recognized technology. Many advancements came after the Deepwater Horizon where 48 systems were used continuosly for over 100 days. This experience led to the development of the NOFI Current Buster 6. The new NOFI Current Buster 4 is currently the most up to date and efficient HighSpeed oil recovery system available worldwide. What differentiates the NOFI Current Buster technology from other highspeed sweep systems, is the built-in separator. The system is designed to separate contained oil from water, and to retain the oil inside the closed separator. The process results in a thicker layer of oil, which in turn offers great advantages when pumping the collected oil onboard vessels or into storage tanks. As a result, the vessels storage tanks are filled with oil and not water increasing the overall oil recovery efficiency significantly. Some of the new features: • Improved hydrodynamic shape. • Increased operational speed up to 4,4 knots. • Larger oil-water separator and storage tank. • Greater stability and improved performance in high wave conditions. • Larger area coverage. • Debris and wave dampeners incorporated. • Dedicated pump area. • Prepared for NorMar 3 IPS (Integrated Pump System) • Double air valve configuration for deployment and recovery both ways. • Quick drain system for recovery. Despite the improvements, the system remains compact and requires little deck space. There was no change in the required storage space. This allows for the re-use of existing reels and other accessories.
www.allmaritim.com – Supplier of environmental products that make a difference NOFI BoomBag The NOFI Current Buster® technology is one of the world’s most efficient and advanced oil containment and recovery systems, capable of containing and controlling oil in up to 5 knots towing speed* without losing any of the contained oil.
AllMaritim AS, Hillerenveien 82, 5174 Mathopen, Norway Email: [email protected] • Phone: (+47) 55 33 61 60 Contact NOFI BoomBag Technical Specifications Model 250 EP / 150 m 250 EP / 200 m 250 EP / 300 m 350 EP / 150 m 350 EP / 200 M Freeboard size 250 mm 250 mm 250 mm 350 mm 350 mm Skirt depth 350 mm 350 mm 350 mm 500 mm 500 mm Standard section length 25 m 25 m 25 m 25 m 25 m Fabric freeboard PU/PVC, 680g/m² PU/PVC, 680g/m² PU/PVC, 680g/m² PU/PVC, 680g/m² PU/PVC, 680g/m² Towing speed (STW) 15 knots 15 knots 15 knots 15 knots 15 knots Wave height 1.5 m 1.5 m 1.5 m 2 m 2 m Inflation system Expanded polystyrene Expanded polystyrene Expanded polystyrene Expanded polystyrene Expanded polystyrene The NOFI BoomBag is specially designed for fast response with minimal requirements for boats and personnel. The boom is packed in a zigzag pattern inside the NOFI BoomBag. It is a standard NOFI EP series solid flotation boom, renowned in the market for reliability, ease of handling and ability to contain the oil. The NOFI BoomBag may be stored on the quayside for immediate deployment. It may also be stored on a trailer for transportation on land or in a warehouse using forklift for transportation to the quay. In both cases the time required to mobilize the boom for towing is extremely short. Mobilization and towing out requires two people, and any available boat can be used. Stored on wooden pallet with lifting slings Lenght / EP 250 EP / 150 m 250 EP / 200 m 250 EP / 300 m 350 EP / 150 m 350 EP / 200 M L x W x H (m) 2,6 x 2,2 x 1,7 3,6 x 2,2 x 1,7 5 x 2,2 x 1,7 3,6 x 2,2 x 2,2 5 x 2,2 x 1,9 Total weight 720 kg 930 kg 1310 kg 1100 kg 1350kg Stored on steel pallet without lifting slings. Lenght / EP 250 EP / 150 m 250 EP / 200 m 250 EP / 300 m 350 EP / 150 m 350 EP / 200 M L x W x H (m) 3,6 x 2,25 x 1,7 3,6 x 2,25 x 1,7 5 x 2,25 x 1,7 3,6 x 2,25 x 2,2 5 x 2,25 x 1,9 Total weight 870 kg 1110 kg 1610 kg 1320 kg 1650 kg
The NOFI Current Buster Technology represents a revolution in oil spill containment systems and holds an interational patent. It has the unique ability to collect and concentrate spilled oil in current exposed waters or when being towed at high speed. What differentiates the NOFI Current Buster system from other high speed oil booms is the built-in separator. The system is designed to separate contained oil from water, and to retain the oil inside the separator. The process results in thicker layer of oil which in turn offers great advantages when pumping the collected oil on board vessels or into storage tanks. The NOFI Current Buster has demonstrated in real life conditions that is capable of sweeping, containing and separating oil from seawater at towing speeds up to 5 knots. As many as 48 systems were in operation during the Deepwater Horizon blowout in the Gulf of Mexico in 2010. The NOFI Current Buster can be used together with a BoomVane which allows the user to operate as a single-vessel sweep system. This towing configuration gives the operator many advantages such as reduced response time, increased efficiency due to stable configuration, better operating and safety conditions for the user and reduced costs due to the use of one vessel only. NOFI CURRENT BUSTER SERIES Supplier of environmental products that make a difference www.allmaritim.com
Supplier of environmental products that make a difference AllMaritim AS, Hillerenveien 82, 5174 Mathopen, Bergen Norway Phone (+47) 55 33 61 60, Fax (+47) 55 33 61 61, Email: [email protected] www.allmaritim.com Contact MODEL NCB2 NCB4 NCB6 NCB8 Freeboard size Ø600 mm Ø800 mm Ø1000 mm Ø1400 mm Fabric freeboard (NOFI X-15) PU/PVC, 1150 g/m² PU/PVC, 1150 g/m² PU/PVC, 1150 g/m² PU/PVC, 1150 g/m² Towing speed (STW) 3 knots 4 knots 5 knots 5 knots Inflation system High capacity air blower High capacity air blower High capacity air blower High capacity air blower Total length 27 m 35.2 m 62.9 m 64.8 m Total width m (front opening) 15 m 22 m 34 m 50 m Weight kg (dry) 560 kg 910 kg 2017 kg 2830 kg Separator 15 m3 35 m3 70 m3 70 m3 Beaufort scale 3 to 6 * 4 to 6* 5 to 7* 5 to 7* Deployment time 10 min 10-20 min 25 min 25 min Boom reel size 3 m3 5 m3 10 m3 12 m3 Container size 10' 10' 20' 20' Total weight w/reel & container 3800 kg 4000 kg 8140 kg 9000 kg Boom Vane type BV Shallow water BV standard BV standard/BV1.5 BV 1.5/BV2.0 *Depending on area of use. TECHNICAL SPECIFICATIONS | NOFI CURRENT BUSTER SERIES NOFI Current Buster Series Supplier of environmental products that make a difference
SKIMMERS
MultiSkimmer MS 10 Multiskimmer MS 10 Multiskimmer MS 10 Modular skimmers with interchangeable cartridges MARKLEEN MULTISKIMMERS are compact, lightweight units used for recovering all types of oil. Diesel oil, grease and emulsions are quickly and efficiently recovered with a minimum of water content. All components used in MARKLEEN MULTISKIMMERS MultiSkimmers are robust and water and oil resistant. Depending on the viscosity of the substance to be recovered, standard rotating brush MARKLEEN MULTISKIMMERS may be converted to drum or disc skimmers in just a few minutes and without the use of tools. Thus MARKLEEN MULTISKIMMERS offer the advantages of having three skimmers in one. Multiskimmer MS 10
E-mail: [email protected] Multiskimmer MS 10 Operating principle Multi Skimmers operate based on the well proven oleophilic (oil attracting) properties of some materials and recover light oils through to heavy crude. The rotating module powered by a hydraulic or pneumatic motor creates a current which draws the substance to be recovered towards the skimmer. The oil sticks firmly to the chosen module which is made of oil attracting and water repelling material. It then reaches the comb or scraper where it is separated and poured into an intermediate tank in the skimmer head. Due to the hydrophobic (water repelling) effect of the module, the water drains down before reaching the scraper. A transfer pump, totally integrated into the MultiSkimmer, except on the MS 10, then transfers the oil to an external tank. Drum Discs Brushes MS 10 with brush module MS 10 coupled to pneumatic pump with floats
E-mail: [email protected] Multiskimmer MS 10 Specifications MODEL MS 10 AIR OPERATED MS 10 HYDRAULIC Service type Brush, drum or disc Operating environment Industrial, protected waters Measurements (l x w x h) [mm] 860 x 730 x 420 Measurements (l x w x h) [mm] with air-operated pump coupled to skimmer 860 x 1130 x 420 Max. draft [mm] 120 Weight (approx.) [kg] 29 Oil recovered Light to heavy Max. recovery capacity [m³/h] 10 Cartridge speed [rpm] 40 Cartridge beds 1 Frame Marine grade aluminium Brushes / Drum Thermoplastic Discs Marine grade aluminium SKIMMER MOTOR Pneumatic Hydraulic Air consumption [l/min] 498 @ 6 bar Pneumatic couplings 3/8” Máx. hydraulic power required [l/min] 1.8 @ 100 bar Hydraulic couplings Pressure: 3/8” Return: 3/8” PUMP Air-operated diaphragm See hydraulic pump Tech. Description Air consumption [l/min] 15 @ 6 bar Max. capacity [m³/h] 13 Máx. discharge pressure [bar] 6 Viscosity range [cSt] 1 - 100,000 Debris handling - Solids in inlet dia. [mm] Diameter 5 Pump weight [kg] 14 Pump location External or coupled to skimmer External Discharge connection 2” (50 mm) with Camlock coupling Operators required 1 Equipment required Air control panel Discharge hose Air hoses Power pack Hydraulic pump Discharge hose Hydraulic hoses
E-mail: [email protected] Multiskimmer MS 10 Properties • Three skimmers in one: Different modules (brush, disc or drum) can be changed in minutes - no tools needed. • Versatile: Covers wide range of viscosities. • Highly efficient: Recovered oil contains only 2 to 8% water. • Transportable: The MS 10 can be easily carried by one person. All models feature handles and lifting points. • Modular: All components can be easily dismantled for transport or maintenance. • Long working life: Rugged corrosion resistant build. Made of marine grade aluminium and stainless steel. Shallow draft: May be used in shallow water
MULTISKIMMER MS 20 Multiskimmer MS 20 Modular skimmers with interchangeable cartridges Markleen Multiskimmers are lightweight skimmers used for recovering all types of oil that may be operated with 3 different types of cartridges. Light oils through to heavy crude are efficiently recovered with a minimum of water content. Depending on the viscosity of the substance to be recovered, standard brush Markleen Multiskimmers may be converted to drum or disc skimmers by changing the cartridge in just a few minutes and without the use of tools. Thus they offer the advantages of having three skimmers in one. Markleen Multiskimmers are mainly made of marine aluminum, and stainless steel, therefore they are corrosion resistant. The rotating cartridge, powered by a hydraulic or pneumatic motor, creates a current which draws the substance to be recovered towards the skimmer. The oil sticks firmly to the chosen cartridge which is made of oil attracting and water repelling material. The oil then reaches the scraper where it is separated and poured into an intermediate tank in the skimmer head. Due to the hydrophobic effect of the cartridge, the water drains down before reaching the scraper. Markleen Multiskimmers are designed to be connected to an external pump to transfer the recovered oil to an external tank. MULTISKIMMER MS 20
MULTISKIMMER MS 20 E-mail: [email protected] Specifications MARKLEEN reserves the right to change such data without prior notice in accordance with its process of continuous improvement. * Recovery capacity depends on the selected pump. **ISO B-series quick hydraulic couplings are supplied as standard. Other hydraulic couplings may be supplied on request. MODEL MS 20 AIR OPERATED MS 20 HYDRAULIC Operating environment Industrial, protected waters Measurements (l x w x h) [mm] 1125 x 730 x 455 Max. draft [mm] 120 Weight (depending of the cartridge, approx.) [kg] 40 Max. recovery capacity [m³/h] 20 Frame Marine grade aluminium Brushes / Drum Thermoplastic Discs Marine grade aluminium SKIMMER MOTOR Pneumatic Hydraulic Air consumption [l/min] 498 @ 6 bar _ Máx. hydraulic power required [l/min] _ 1.8 @ 100 bar Couplings 3/8” Pneumatic couplings 3/8” quick hydraulic couplings PUMP Air-operated diaphragm External or coupled to the skimmer External hydraulic pump Air consumption [l/min] 33 @ 6 bar _ Max. capacity [m³/h] 30 _ Máx. discharge pressure [bar] 8 _ Viscosity range [cSt] 1 - 100,000 _ Solids in inlet dia. [mm] Diameter 5 _ Pump weight [kg] 28 _ Discharge connection 2” (50 mm) with Camlock coupling Operators required 1 Equipment required Air control panel Discharge hose Air hoses Power pack/ Hyd. supply Hydraulic pump Discharge hose Hydraulic hoses
MULTISKIMMER MS 20 E-mail: [email protected] Pneumatic MS20 with air-operated diaphragm pump coupled to the skimmer Properties • Recovers light oils through to heavy crude. • Three skimmers in one: brush, disc or drum cartridges • Highly efficient: Recovered oil contains only 2 to 8% water • Lightweight and shallow draft • Long working life: Rugged corrosion resistant build • Made of marine grade aluminium and stainless steel • Modular: All components easily dismantled for transport or maintenance
MultiSkimmer MS 30 MultiSkimmer MS 30 Modular skimmer with interchangeable cartridges. The MARKLEEN MULTISKIMMER MS 30 is a compact, lightweight unit used for recovering all types of oil. Diesel oil, grease and emulsions are quickly and efficiently recovered with a minimum of water content. All components used in the MARKLEEN MULTISKIMMER MS 30 are robust and water and oil resistant. Depending on the viscosity of the substance to be recovered, the standard rotating brush MARKLEEN MULTISKIMMER MS 30 may be converted to a drum or disc skimmer in just a few minutes and without the use of tools. MultiSkimmer MS 30
E-mail: [email protected] Multiskimmer MS 30 Operating priniciple: MultiSkimmers operate based on the well proven oleophilic (oil attracting) properties of some materials and recover light oils through to heavy crude. The rotating module powered by a hydraulic or pneumatic motor creates a current which draws the substance to be recovered towards the skimmer. The oil sticks firmly to the chosen module which is made of oil attracting and water repelling material. It then reaches the comb or scraper where it is separated and poured into an intermediate tank in the skimmer head. Due to the hydrophobic (water repelling) effect of the module, the water drains down before reaching the scraper. A transfer pump, totally integrated into the MultiSkimmer, then transfers the oil to an external tank. Discs Drum Brushes MS 30 on dense emulsion MS 30 on oil
