Laporan Analisis Struktur Billboard 4.5m x 6m (Revisi)

ANALISIS & DESAIN STRUKTUR

BILLBOARD 4.5m x 6.00m
KONSTRUKSI BAJA

TAHUN 2014

ANALISIS STRUKTUR BILLBOARD 4.5m x 6.00m

ANALISIS STRUKTUR
KONSTRUKSI BAJA

KONSTRUKSI BILLBOARD RANGKA BAJA

Ukuran 4.50 m x 6.00 m (Satu Sisi)

1. STANDARD dan REFERENSI

- Peraturan Pembebanan Indonesia untuk Gedung, 1987;
- Peraturan Perencanaan Bangunan Baja Indonesia, 2000;
- AISC - LRFD, 1993;
- Konstruksi Baja II, Delta Teknik Group, 2007;
- Code / Standard Nasional dan Internasional lain yang relevan.

2. GAMBAR DESAIN RENCANA BILLBOARD 4.5m x 6.0m

Siku L 40 x 40 x 4

4.50 m

4.50 m Pipa 4" tebal 2.90mm
Pipa 16" tebal 9.35mm

3.50 m Kolom 1.50m x 1.50m

● Model Struktur Billboard dengan Rangka Baja

Spec. Finishing : 3. Board panel
1. Rangka Konstruksi Alumunium Plate 0,70 mm
dengan ruang Backligt selebar 80cm
Siku L 40 x 40 x 4 mm
Pipa 16" tebal 9.35mm
Pipa 4" tebal 2.90mm

2. Penerangan 4. Konstruksi bawah
Lampu sorot 150 watt Slast Pedestal 1.50m x 1.50m
Rencana 24 buah. Footplate 2.50m x 2.50m x 0,50m

3. PERHITUNGAN PEMBEBANAN

A. Beban Mati

a. Berat sendiri struktur tiang baja dan rangka baja :

Berat jenis baja = 7.85 ton/m3

( Berat sendiri struktur baja dihitung secara otomatis oleh program komputer SAP 2000 )

Faktor Pengali beban = 1.20

b. Berat Lampu Slast 150w = 6.00 kg

= 0.006 ton

Jumlah = 24 buah (Asumsi)

Faktor Pengali beban = 1.20

c. Berat Papan Billboard

( Terdiri atas board panel alumunium plate 0,70mm )

Tebal total = 0.70 mm

= 0.0007 m

Berat Jenis = 7.35 ton/m3

Regangan = 13.00 %

fy maksimum = 550.00 MPa

fu maksimum = 550.00 MPa

E ( Modulus Elastisitas ) = 2E+07 ton/m2

µ = 0.30

α = 1E-06 /oC

( Papan billboard dimodelkan sebagai elemen shell/pelat membran )

Faktor Pengali beban = 1.20 (Asumsi beban mati)

B. Beban Hidup

Beban hidup diasumsikan bekerja pada puncak tiang dan tengah tiang

dengan nilai = 60 kg

Faktor Pengali beban = 1.00

C. Beban Angin

Dari sumber Peraturan Pembebanan Indonesia Untuk Rumah dan Gedung 1987

Pasal 2.1.3.2

Besar tekanan angin = 25.00 kg/m2

= 0.025 ton/m2

Pemodelan Angin bisa dengan 2 macam cara:

a. Tiang struktur billboard ( lattice structure ) b. Rangka papan billboard yang tertutup
stallbuis dan alumunium :
Faktor pengali (awal) = 1.60 (PPIUG 1983) Dimodelkan sebagai shell load
Faktor pengali beban = 1.00
Faktor pengali (akhir) = 1.20 (PPIUG 1983)
Model shell dimensi terbesar :
Dianggap angin hanya menerpa

satu sisi rangka frame baja :

Beban angin diproyeksikan
jadi beban uniform

Q = 0.04 x 0.025
= 0.001 ton/m

1,125 m

angin diameter = 16 " 1,00 m
= 0.4064 m Beban angin tetap sebagai tekanan :
Q = 0.025 ton/m2
1/2 Keliling = 0.638 m
Q = 0.016 ton/m

40mm = 0,04 m

4. GAMBAR PERSPEKTIF FRAME SECTION Properti Siku L 40 x 40 x 4 Properti Pipa diameter 4"

Properti Tiang diameter 16" Properti Pipa diameter 2"

Properti Kolom 1.50m x 1.50m

Gambar Perspektif 3D

5. GAMBAR DISTRIBUSI PEMBEBANAN
a. Beban Angin

b. Beban Hidup
c. Beban Lampu

6. HASIL ANALISIS (dengan software SAP2000)
1. Pola Deformasi Struktur akibat input Beban Mati, Hidup, Angin, dan Lampu

2. Diagram tegangan - regangan (stress ratio ) untuk mengetahui kekuatan struktur

Dari Gambar di atas didapatkan bahwa besarnya nilai stress ratio < 1
(perbandingan antara tegangan ijin dan tegangan yang terjadi < 1)
sehingga Konstruksi Billboard : CUKUP AMAN

ANALISIS STRUKTUR BILLBOARD 4.5m x 6.00m

GAMBAR STRUKTURAL





















ANALISIS STRUKTUR BILLBOARD 4.5m x 6.00m

OUTPUT SAP2000

SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 1 134 COMB1 2.251E-06 3.430E-03 -1.071E-03 0.0000 0.0000 0.0000
2/25/14 21:43:00 135 COMB1 4.019E-06 3.422E-03 -1.071E-03 0.0000 0.0000 0.0000
136 COMB1 -1.821E-06 3.412E-03 -1.072E-03 0.0000 0.0000 0.0000
LOAD COMBINATION MULTIPLIERS 137 COMB1 -2.173E-06 3.409E-03 -1.055E-03 0.0000 0.0000 0.0000
138 COMB1 2.173E-06 3.409E-03 -1.055E-03 0.0000 0.0000 0.0000
COMBO TYPE CASE FACTOR TYPE TITLE 139 COMB1 1.821E-06 3.412E-03 -1.072E-03 0.0000 0.0000 0.0000
140 COMB1 -4.019E-06 3.422E-03 -1.071E-03 0.0000 0.0000 0.0000
COMB1 ADD COMB1 141 COMB1 -2.983E-06 3.537E-03 -1.067E-03 0.0000 0.0000 0.0000
142 COMB1 -2.650E-06 3.528E-03 -1.065E-03 0.0000 0.0000 0.0000
MATI 1.2000 STATIC(DEAD) 143 COMB1 -2.625E-06 3.565E-03 -1.058E-03 0.0000 0.0000 0.0000
144 COMB1 2.625E-06 3.565E-03 -1.058E-03 0.0000 0.0000 0.0000
HDP 1.0000 STATIC(LIVE) 145 COMB1 2.983E-06 3.537E-03 -1.067E-03 0.0000 0.0000 0.0000
146 COMB1 2.650E-06 3.528E-03 -1.065E-03 0.0000 0.0000 0.0000
ANGDPN 1.0000 STATIC(WIND) 147 COMB1
150 COMB1 0.0000 3.408E-03 -1.078E-03 0.0000 0.0000 0.0000
LAMPU 1.2000 STATIC(OTHER) 151 COMB1 0.0000 3.426E-03 -1.074E-03 0.0000 0.0000 0.0000
152 COMB1 0.0000 3.430E-03 -1.076E-03 0.0000 0.0000 0.0000
SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 2 153 COMB1 0.0000 3.542E-03 -1.077E-03 0.0000 0.0000 0.0000
2/25/14 21:43:00 154 COMB1 0.0000 3.432E-03 -1.078E-03 0.0000 0.0000 0.0000
155 COMB1 0.0000 3.532E-03 -1.078E-03 0.0000 0.0000 0.0000
JOINT DISPLACEMENTS 156 COMB1 -1.482E-06 3.411E-03 -1.077E-03 0.0000 0.0000 0.0000
157 COMB1 0.0000 3.430E-03 -1.078E-03 0.0000 0.0000 0.0000
JOINT LOAD U1 U2 U3 R1 R2 R3 158 COMB1 0.0000 3.542E-03 -1.077E-03 0.0000 0.0000 0.0000
159 COMB1 0.0000 3.555E-03 -1.076E-03 0.0000 0.0000 0.0000
1 COMB1 0.0000 3.430E-03 -2.331E-03 0.0000 0.0000 0.0000 160 COMB1 0.0000 3.417E-03 -1.075E-03 0.0000 0.0000 0.0000
161 COMB1 0.0000 3.430E-03 -1.076E-03 0.0000 0.0000 0.0000
2 COMB1 0.0000 3.408E-03 -2.287E-03 0.0000 0.0000 0.0000 162 COMB1 0.0000 3.426E-03 -1.074E-03 0.0000 0.0000 0.0000
163 COMB1 0.0000 3.555E-03 -1.076E-03 0.0000 0.0000 0.0000
5 COMB1 -1.791E-06 3.430E-03 -1.070E-03 0.0000 0.0000 0.0000 164 COMB1 0.0000 3.532E-03 -1.078E-03 0.0000 0.0000 0.0000
165 COMB1 0.0000 3.417E-03 -1.075E-03 0.0000 0.0000 0.0000
6 COMB1 1.791E-06 3.430E-03 -1.070E-03 0.0000 0.0000 0.0000 166 COMB1 1.482E-06 3.411E-03 -1.077E-03 0.0000 0.0000 0.0000
167 COMB1 0.0000 3.433E-03 -1.078E-03 0.0000 0.0000 0.0000
7 COMB1 0.0000 3.413E-03 -1.070E-03 0.0000 0.0000 0.0000 168 COMB1 0.0000 3.422E-03 -1.078E-03 0.0000 0.0000 0.0000
169 COMB1 -1.012E-06 3.431E-03 -1.074E-03 0.0000 0.0000 0.0000
8 COMB1 0.0000 3.413E-03 -1.070E-03 0.0000 0.0000 0.0000 170 COMB1 0.0000 3.430E-03 -1.077E-03 0.0000 0.0000 0.0000
171 COMB1 0.0000 3.430E-03 -1.077E-03 0.0000 0.0000 0.0000
9 COMB1 -1.646E-06 3.431E-03 -2.660E-03 0.0000 0.0000 0.0000 172 COMB1 1.012E-06 3.431E-03 -1.074E-03 0.0000 0.0000 0.0000
173 COMB1 0.0000 3.422E-03 -1.074E-03 0.0000 0.0000 0.0000
10 COMB1 0.0000 3.411E-03 -2.655E-03 0.0000 0.0000 0.0000 174 COMB1 -1.363E-06 3.412E-03 -1.075E-03 0.0000 0.0000 0.0000
175 COMB1 -1.285E-06 3.409E-03 -1.078E-03 0.0000 0.0000 0.0000
11 COMB1 0.0000 3.430E-03 -2.722E-03 0.0000 0.0000 0.0000 176 COMB1 1.285E-06 3.409E-03 -1.078E-03 0.0000 0.0000 0.0000
177 COMB1 1.363E-06 3.412E-03 -1.075E-03 0.0000 0.0000 0.0000
12 COMB1 0.0000 3.409E-03 -2.709E-03 0.0000 0.0000 0.0000 178 COMB1 0.0000 3.422E-03 -1.074E-03 0.0000 0.0000 0.0000
179 COMB1 0.0000 3.539E-03 -1.076E-03 0.0000 0.0000 0.0000
13 COMB1 0.0000 3.430E-03 -2.722E-03 0.0000 0.0000 0.0000 180 COMB1 0.0000 3.530E-03 -1.077E-03 0.0000 0.0000 0.0000
181 COMB1 0.0000 3.566E-03 -1.077E-03 0.0000 0.0000 0.0000
14 COMB1 0.0000 3.409E-03 -2.709E-03 0.0000 0.0000 0.0000 182 COMB1 0.0000 3.566E-03 -1.077E-03 0.0000 0.0000 0.0000
183 COMB1 0.0000 3.539E-03 -1.076E-03 0.0000 0.0000 0.0000
15 COMB1 1.646E-06 3.431E-03 -2.660E-03 0.0000 0.0000 0.0000 0.0000 3.530E-03 -1.077E-03 0.0000 0.0000 0.0000

16 COMB1 0.0000 3.411E-03 -2.655E-03 0.0000 0.0000 0.0000

17 COMB1 -2.839E-06 3.426E-03 -1.069E-03 0.0000 0.0000 0.0000

18 COMB1 2.839E-06 3.426E-03 -1.069E-03 0.0000 0.0000 0.0000

19 COMB1 -2.922E-06 3.422E-03 -1.069E-03 0.0000 0.0000 0.0000

20 COMB1 2.922E-06 3.422E-03 -1.069E-03 0.0000 0.0000 0.0000

21 COMB1 -1.487E-06 3.417E-03 -1.069E-03 0.0000 0.0000 0.0000

22 COMB1 1.487E-06 3.417E-03 -1.069E-03 0.0000 0.0000 0.0000

110 COMB1 0.0000 3.408E-03 -1.013E-03 0.0000 0.0000 0.0000

111 COMB1 0.0000 1.282E-05 -4.864E-05 0.0000 0.0000 0.0000

112 COMB1 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000

113 COMB1 -3.518E-06 3.426E-03 -1.071E-03 0.0000 0.0000 0.0000

114 COMB1 -2.034E-06 3.430E-03 -1.068E-03 0.0000 0.0000 0.0000

115 COMB1 -1.810E-06 3.540E-03 -1.063E-03 0.0000 0.0000 0.0000

116 COMB1 0.0000 3.429E-03 -1.055E-03 0.0000 0.0000 0.0000

117 COMB1 4.641E-06 3.531E-03 -1.052E-03 0.0000 0.0000 0.0000

118 COMB1 -1.978E-06 3.411E-03 -1.064E-03 0.0000 0.0000 0.0000

119 COMB1 0.0000 3.430E-03 -1.063E-03 0.0000 0.0000 0.0000

120 COMB1 1.810E-06 3.540E-03 -1.063E-03 0.0000 0.0000 0.0000

121 COMB1 4.181E-06 3.555E-03 -1.065E-03 0.0000 0.0000 0.0000

122 COMB1 2.169E-06 3.417E-03 -1.072E-03 0.0000 0.0000 0.0000

123 COMB1 2.034E-06 3.430E-03 -1.068E-03 0.0000 0.0000 0.0000

124 COMB1 3.518E-06 3.426E-03 -1.071E-03 0.0000 0.0000 0.0000

125 COMB1 -4.181E-06 3.555E-03 -1.065E-03 0.0000 0.0000 0.0000

126 COMB1 -4.641E-06 3.531E-03 -1.052E-03 0.0000 0.0000 0.0000

127 COMB1 -2.169E-06 3.417E-03 -1.072E-03 0.0000 0.0000 0.0000

128 COMB1 1.978E-06 3.411E-03 -1.064E-03 0.0000 0.0000 0.0000 SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 3
2/25/14 21:43:00

129 COMB1 0.0000 3.431E-03 -1.061E-03 0.0000 0.0000 0.0000

JOINT REACTIONS

130 COMB1 0.0000 3.420E-03 -1.044E-03 0.0000 0.0000 0.0000

JOINT LOAD F1 F2 F3 M1 M2 M3

131 COMB1 -2.251E-06 3.430E-03 -1.071E-03 0.0000 0.0000 0.0000

112 COMB1 0.0000 -19.4172 724.4412 33.9800 0.0000 0.0000

132 COMB1 -1.232E-06 3.430E-03 -1.064E-03 0.0000 0.0000 0.0000

133 COMB1 1.232E-06 3.430E-03 -1.064E-03 0.0000 0.0000 0.0000 SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 4

2/25/14 21:43:00 22 COMB1
0.00 -6.663E-03 -1.050E-01 3.142E-04
FRAME ELEMENT FORCES 0.00 1.571E-04 -4.736E-02
2.5E-01 -6.663E-03 -9.730E-02 3.142E-04 0.00 7.856E-05 -2.208E-02
FRAME LOAD LOC P V2 V3 T M2 M3 5.0E-01 -6.663E-03 -8.959E-02 3.142E-04 0.00 0.00 1.285E-03
7.5E-01 -6.663E-03 -8.188E-02 3.142E-04 0.00 -7.856E-05 2.272E-02

1.00 -6.663E-03 -7.417E-02 3.142E-04 0.00 -1.571E-04 4.222E-02

2 COMB1 -3.91 0.00 -1.917E-01 0.00 -1.078E-01 0.00 23 COMB1 0.00 2.051E-04 3.098E-03
0.00 -4.52 0.00 -1.917E-01 0.00 0.00 0.00 0.00 -4.973E-02 -4.085E-03 4.103E-04 0.00 1.026E-04 3.155E-03
0.00 0.00 0.00 1.285E-03
5.6E-01 -5.12 0.00 -1.917E-01 0.00 1.078E-01 2.5E-01 -4.973E-02 3.625E-03 4.103E-04 0.00 -1.026E-04 -2.512E-03
1.13 5.0E-01 -4.973E-02 1.133E-02 4.103E-04
7.5E-01 -4.973E-02 1.904E-02 4.103E-04 0.00 -2.051E-04 -8.237E-03
3 COMB1 0.00 4.050E-01 0.00 2.278E-01 0.00
0.00 -10.33 0.00 4.050E-01 0.00 0.00 0.00 1.00 -4.973E-02 2.675E-02 4.103E-04

5.6E-01 -10.93 0.00 4.050E-01 0.00 -2.278E-01 0.00 24 COMB1
1.13 -11.54 0.00 -5.202E-03 3.212E-01 3.261E-04

4 COMB1 0.00 1.85 0.00 1.04 0.00 2.5E-01 -5.202E-03 3.289E-01 3.261E-04 0.00 1.631E-04 1.657E-01
0.00 -22.62 0.00 1.85 0.00 0.00 0.00 5.0E-01 -5.202E-03 3.366E-01 3.261E-04 0.00 8.153E-05 8.448E-02
7.5E-01 -5.202E-03 3.443E-01 3.261E-04 0.00 0.00 1.285E-03
5.6E-01 -23.22 0.00 1.85 0.00 -1.04 0.00 0.00 -8.153E-05 -8.384E-02
1.13 -23.83 1.00 -5.202E-03 3.521E-01 3.261E-04
0.00 -1.631E-04 -1.709E-01

5 COMB1 0.00 2.45 0.00 1.38 0.00 25 COMB1 0.00 3.919E-04 -2.026E-04
0.00 -64.28 0.00 2.45 0.00 0.00 0.00 0.00 2.207E-03 -3.601E-04 6.968E-04 0.00 0.00 0.00

5.6E-01 -64.88 0.00 2.45 0.00 -1.38 0.00 5.6E-01 1.955E-02 -3.601E-04 6.968E-04 0.00 -3.919E-04 2.026E-04
1.13 -65.49 1.13 3.690E-02 -3.601E-04 6.968E-04

9 COMB1 0.00 -4.498E-05 -1.714E-01 26 COMB1 0.00 3.989E-04 -1.208E-04
0.00 9.677E-03 -3.530E-01 -8.997E-05 0.00 -2.249E-05 -8.407E-02 0.00 -1.042E-02 -2.147E-04 7.091E-04 0.00 0.00 0.00
0.00 0.00 1.285E-03
2.5E-01 9.677E-03 -3.453E-01 -8.997E-05 0.00 2.249E-05 8.471E-02 5.6E-01 6.925E-03 -2.147E-04 7.091E-04 0.00 -3.989E-04 1.208E-04
5.0E-01 9.677E-03 -3.376E-01 -8.997E-05 1.13 2.427E-02 -2.147E-04 7.091E-04
7.5E-01 9.677E-03 -3.299E-01 -8.997E-05 0.00 4.498E-05 1.662E-01
27 COMB1
1.00 9.677E-03 -3.221E-01 -8.997E-05 0.00 -2.185E-02 1.232E-05 6.608E-04

10 COMB1 0.00 4.442E-06 -9.246E-03 5.6E-01 -4.504E-03 1.232E-05 6.608E-04 0.00 3.717E-04 6.929E-06
0.00 4.525E-02 -2.877E-02 8.884E-06 0.00 2.221E-06 -3.017E-03 1.13 1.284E-02 1.232E-05 6.608E-04 0.00 0.00 0.00
0.00 0.00 1.285E-03
2.5E-01 4.525E-02 -2.106E-02 8.884E-06 0.00 -2.221E-06 3.659E-03 0.00 -3.717E-04 -6.929E-06
5.0E-01 4.525E-02 -1.335E-02 8.884E-06
7.5E-01 4.525E-02 -5.641E-03 8.884E-06 0.00 -4.442E-06 4.106E-03 28 COMB1 0.00 3.163E-04 8.824E-05
0.00 -3.697E-02 1.569E-04 5.622E-04 0.00 0.00 0.00
1.00 4.525E-02 2.069E-03 8.884E-06
5.6E-01 -1.963E-02 1.569E-04 5.622E-04 0.00 -3.163E-04 -8.824E-05
1.13 -2.278E-03 1.569E-04 5.622E-04

11 COMB1 0.00 -1.753E-06 3.903E-02 263 COMB1 0.00 19.42 0.00 43.69 0.00
0.00 6.487E-02 6.779E-02 -3.506E-06 0.00 0.00 2.112E-02 0.00 -497.19 0.00 19.42 0.00 0.00 0.00
0.00 0.00 1.285E-03 2.25 -499.61 0.00 19.42 0.00 -43.69 0.00
2.5E-01 6.487E-02 7.550E-02 -3.506E-06 0.00 0.00 -2.048E-02 4.50 -502.03
5.0E-01 6.487E-02 8.321E-02 -3.506E-06
7.5E-01 6.487E-02 9.092E-02 -3.506E-06 0.00 1.753E-06 -4.417E-02

1.00 6.487E-02 9.863E-02 -3.506E-06

12 COMB1 0.00 1.753E-06 -4.417E-02 264 COMB1 0.00 19.42 0.00 33.98 0.00
0.00 6.487E-02 -9.863E-02 3.506E-06 0.00 0.00 -2.048E-02 0.00 -502.03 0.00 19.42 0.00 0.00 0.00
0.00 0.00 1.285E-03 1.75 -613.23 0.00 19.42 0.00 -33.98 0.00
2.5E-01 6.487E-02 -9.092E-02 3.506E-06 0.00 0.00 2.112E-02 3.50 -724.44
5.0E-01 6.487E-02 -8.321E-02 3.506E-06 0.00 -1.753E-06 3.903E-02
7.5E-01 6.487E-02 -7.550E-02 3.506E-06 265 COMB1 0.00 -9.813E-05 -1.231E-02
1.0E+00 6.487E-02 -6.779E-02 3.506E-06 0.00 1.014E-01 -3.743E-02 -1.304E-04 0.00 0.00 1.058E-02

13 COMB1 7.5E-01 1.171E-01 -2.342E-02 -1.304E-04 0.00 9.813E-05 -1.237E-02
0.00 4.525E-02 -2.069E-03 -8.884E-06 1.51 1.857E-01 3.750E-02 -1.304E-04

2.5E-01 4.525E-02 5.641E-03 -8.884E-06 0.00 -4.442E-06 4.106E-03 266 COMB1 0.00 -2.674E-03 -1.225E-02
5.0E-01 4.525E-02 1.335E-02 -8.884E-06 0.00 -2.221E-06 3.659E-03 0.00 -1.115E-01 -3.735E-02 -3.553E-03 0.00 0.00 1.058E-02
7.5E-01 4.525E-02 2.106E-02 -8.884E-06 0.00 0.00 1.285E-03
0.00 2.221E-06 -3.017E-03 7.5E-01 -1.272E-01 -2.334E-02 -3.553E-03 0.00 2.674E-03 -1.243E-02
1.00 4.525E-02 2.877E-02 -8.884E-06 1.51 -1.958E-01 3.759E-02 -3.553E-03
0.00 4.442E-06 -9.246E-03

14 COMB1 0.00 4.498E-05 1.662E-01 267 COMB1 0.00 6.586E-03 -1.395E-02
0.00 9.677E-03 3.221E-01 8.997E-05 0.00 2.249E-05 8.471E-02 0.00 -2.204E-01 -4.486E-02 8.751E-03 0.00 0.00 1.157E-02
0.00 0.00 1.285E-03
2.5E-01 9.677E-03 3.299E-01 8.997E-05 0.00 -2.249E-05 -8.407E-02 7.5E-01 -2.450E-01 -2.296E-02 8.751E-03 0.00 -6.586E-03 -1.469E-02
5.0E-01 9.677E-03 3.376E-01 8.997E-05 1.51 -3.224E-01 4.584E-02 8.751E-03
7.5E-01 9.677E-03 3.453E-01 8.997E-05 0.00 -4.498E-05 -1.714E-01
268 COMB1
1.00 9.677E-03 3.530E-01 8.997E-05 0.00 7.097E-02 -3.729E-02 -3.276E-03

15 COMB1 0.00 3.163E-04 8.824E-05 7.5E-01 5.521E-02 -2.327E-02 -3.276E-03 0.00 -2.465E-03 -1.221E-02
0.00 -2.278E-03 1.569E-04 5.622E-04 0.00 0.00 0.00 1.51 -1.333E-02 3.765E-02 -3.276E-03 0.00 0.00 1.058E-02

5.6E-01 -1.963E-02 1.569E-04 5.622E-04 0.00 -3.163E-04 -8.824E-05 0.00 2.465E-03 -1.248E-02
1.13 -3.697E-02 1.569E-04 5.622E-04
269 COMB1
16 COMB1 0.00 3.717E-04 6.929E-06 0.00 2.361E-01 -3.789E-02 3.861E-03 0.00 2.906E-03 -1.266E-02
0.00 1.284E-02 1.232E-05 6.608E-04 0.00 0.00 0.00 0.00 0.00 1.058E-02
7.5E-01 2.203E-01 -2.388E-02 3.861E-03
5.6E-01 -4.504E-03 1.232E-05 6.608E-04 0.00 -3.717E-04 -6.929E-06 1.51 1.518E-01 3.704E-02 3.861E-03 0.00 -2.906E-03 -1.202E-02
1.13 -2.185E-02 1.232E-05 6.608E-04
270 COMB1
17 COMB1 0.00 3.989E-04 -1.208E-04 0.00 8.798E-02 -3.742E-02 -3.558E-03 0.00 -2.678E-03 -1.231E-02
0.00 2.427E-02 -2.147E-04 7.091E-04 0.00 0.00 0.00 0.00 0.00 1.058E-02
7.5E-01 7.222E-02 -2.341E-02 -3.558E-03
5.6E-01 6.925E-03 -2.147E-04 7.091E-04 0.00 -3.989E-04 1.208E-04 1.51 3.680E-03 3.751E-02 -3.558E-03 0.00 2.678E-03 -1.238E-02
1.13 -1.042E-02 -2.147E-04 7.091E-04
271 COMB1
18 COMB1 0.00 3.919E-04 -2.026E-04 0.00 1.762E-01 -3.746E-02 -4.764E-04 0.00 -3.585E-04 -1.234E-02
0.00 3.690E-02 -3.601E-04 6.968E-04 0.00 0.00 0.00 0.00 0.00 1.058E-02
7.5E-01 1.604E-01 -2.345E-02 -4.764E-04
5.6E-01 1.955E-02 -3.601E-04 6.968E-04 0.00 -3.919E-04 2.026E-04 1.51 9.189E-02 3.747E-02 -4.764E-04 0.00 3.585E-04 -1.235E-02
1.13 2.207E-03 -3.601E-04 6.968E-04
272 COMB1
19 COMB1 0.00 -1.631E-04 -1.709E-01 0.00 1.960E-01 -3.766E-02 4.454E-03 0.00 3.352E-03 -1.249E-02
0.00 -5.202E-03 -3.521E-01 -3.261E-04 0.00 -8.153E-05 -8.384E-02 0.00 0.00 1.058E-02
0.00 0.00 1.285E-03 7.5E-01 1.802E-01 -2.365E-02 4.454E-03
2.5E-01 -5.202E-03 -3.443E-01 -3.261E-04 0.00 8.153E-05 8.448E-02 1.51 1.117E-01 3.727E-02 4.454E-03 0.00 -3.352E-03 -1.219E-02
5.0E-01 -5.202E-03 -3.366E-01 -3.261E-04
7.5E-01 -5.202E-03 -3.289E-01 -3.261E-04 0.00 1.631E-04 1.657E-01 273 COMB1 0.00 9.813E-05 -1.237E-02
0.00 1.857E-01 -3.750E-02 1.304E-04 0.00 0.00 1.058E-02
1.00 -5.202E-03 -3.212E-01 -3.261E-04
7.5E-01 1.699E-01 -2.349E-02 1.304E-04 0.00 -9.813E-05 -1.231E-02
1.51 1.014E-01 3.743E-02 1.304E-04

20 COMB1 0.00 -2.051E-04 -8.237E-03 274 COMB1 0.00 -3.130E-03 -1.225E-02
0.00 -4.973E-02 -2.675E-02 -4.103E-04 0.00 -1.026E-04 -2.512E-03 0.00 -1.685E-01 -3.735E-02 -4.160E-03 0.00 0.00 1.058E-02
0.00 0.00 1.285E-03
2.5E-01 -4.973E-02 -1.904E-02 -4.103E-04 0.00 1.026E-04 3.155E-03 7.5E-01 -1.843E-01 -2.333E-02 -4.160E-03 0.00 3.130E-03 -1.243E-02
5.0E-01 -4.973E-02 -1.133E-02 -4.103E-04 1.51 -2.528E-01 3.759E-02 -4.160E-03
7.5E-01 -4.973E-02 -3.625E-03 -4.103E-04 0.00 2.051E-04 3.098E-03

1.00 -4.973E-02 4.085E-03 -4.103E-04

21 COMB1 0.00 -1.571E-04 4.222E-02 275 COMB1 0.00 5.968E-04 -1.214E-02
0.00 -6.663E-03 7.417E-02 -3.142E-04 0.00 -7.856E-05 2.272E-02 0.00 -3.586E-01 -3.720E-02 7.929E-04 0.00 0.00 1.058E-02
0.00 0.00 1.285E-03
2.5E-01 -6.663E-03 8.188E-02 -3.142E-04 0.00 7.856E-05 -2.208E-02 7.5E-01 -3.743E-01 -2.319E-02 7.929E-04 0.00 -5.968E-04 -1.254E-02
5.0E-01 -6.663E-03 8.959E-02 -3.142E-04 0.00 1.571E-04 -4.736E-02 1.51 -4.429E-01 3.773E-02 7.929E-04
7.5E-01 -6.663E-03 9.730E-02 -3.142E-04
1.0E+00 -6.663E-03 1.050E-01 -3.142E-04 276 COMB1
0.00 -1.61 -4.302E-02 9.671E-03 0.00 7.278E-03 -1.257E-02

7.5E-01 -1.63 -2.113E-02 9.671E-03 0.00 0.00 1.157E-02

1.51 -1.71 4.768E-02 9.671E-03 0.00 -7.278E-03 -1.607E-02 300 COMB1
0.00 2.520E-02 3.857E-05 3.382E-04
277 COMB1 0.00 1.502E-04 -1.215E-02 0.00 1.902E-04 2.170E-05
0.00 -7.120E-02 -3.721E-02 1.996E-04 0.00 0.00 1.058E-02 5.6E-01 9.435E-03 3.857E-05 3.382E-04 0.00 0.00 0.00
1.13 -6.329E-03 3.857E-05 3.382E-04
7.5E-01 -8.697E-02 -2.319E-02 1.996E-04 0.00 -1.502E-04 -1.254E-02 0.00 -1.902E-04 -2.170E-05
1.51 -1.555E-01 3.773E-02 1.996E-04
301 COMB1
278 COMB1 0.00 -3.352E-03 -1.219E-02 0.00 3.304E-02 -1.426E-04 3.652E-04 0.00 2.054E-04 -8.020E-05
0.00 1.117E-01 -3.727E-02 -4.454E-03 0.00 0.00 1.058E-02 0.00 0.00 0.00
5.6E-01 1.728E-02 -1.426E-04 3.652E-04
7.5E-01 1.274E-01 -2.326E-02 -4.454E-03 0.00 3.352E-03 -1.249E-02 1.13 1.517E-03 -1.426E-04 3.652E-04 0.00 -2.054E-04 8.020E-05
1.51 1.960E-01 3.766E-02 -4.454E-03
302 COMB1
279 COMB1 0.00 3.585E-04 -1.235E-02 0.00 3.542E-02 -3.077E-04 3.829E-04 0.00 2.154E-04 -1.731E-04
0.00 9.189E-02 -3.747E-02 4.764E-04 0.00 0.00 1.058E-02 0.00 0.00 0.00
5.6E-01 1.966E-02 -3.077E-04 3.829E-04
7.5E-01 1.077E-01 -2.346E-02 4.764E-04 0.00 -3.585E-04 -1.234E-02 1.13 3.897E-03 -3.077E-04 3.829E-04 0.00 -2.154E-04 1.731E-04
1.51 1.762E-01 3.746E-02 4.764E-04
303 COMB1
280 COMB1 0.00 2.678E-03 -1.238E-02 0.00 2.774E-02 -2.251E-02 -2.838E-03 0.00 -1.419E-03 2.334E-03
0.00 3.680E-03 -3.751E-02 3.558E-03 0.00 0.00 1.058E-02 0.00 -7.096E-04 5.415E-03
2.5E-01 2.774E-02 -2.127E-03 -2.838E-03 0.00 0.00 3.398E-03
7.5E-01 1.944E-02 -2.350E-02 3.558E-03 0.00 -2.678E-03 -1.231E-02 5.0E-01 2.774E-02 1.826E-02 -2.838E-03 0.00 7.096E-04 -3.716E-03
1.51 8.798E-02 3.742E-02 3.558E-03 7.5E-01 2.774E-02 3.865E-02 -2.838E-03
0.00 1.419E-03 -1.593E-02
1.00 2.774E-02 5.904E-02 -2.838E-03

281 COMB1 0.00 -2.906E-03 -1.202E-02 304 COMB1 0.00 -1.877E-03 4.491E-03
0.00 1.518E-01 -3.704E-02 -3.861E-03 0.00 0.00 1.058E-02 0.00 3.457E-02 -1.820E-02 -3.754E-03 0.00 -9.384E-04 6.493E-03
0.00 0.00 3.398E-03
7.5E-01 1.676E-01 -2.303E-02 -3.861E-03 0.00 2.906E-03 -1.266E-02 2.5E-01 3.457E-02 2.187E-03 -3.754E-03 0.00 9.384E-04 -4.794E-03
1.51 2.361E-01 3.789E-02 -3.861E-03 5.0E-01 3.457E-02 2.257E-02 -3.754E-03
7.5E-01 3.457E-02 4.296E-02 -3.754E-03 0.00 1.877E-03 -1.808E-02
282 COMB1
0.00 -1.333E-02 -3.765E-02 3.276E-03 1.00 3.457E-02 6.335E-02 -3.754E-03

7.5E-01 2.433E-03 -2.363E-02 3.276E-03 0.00 2.465E-03 -1.248E-02 305 COMB1 0.00 -2.082E-03 4.232E-02
1.51 7.097E-02 3.729E-02 3.276E-03 0.00 0.00 1.058E-02 0.00 -3.844E-01 5.745E-02 -4.164E-03 0.00 -1.041E-03 2.541E-02
0.00 0.00 3.398E-03
0.00 -2.465E-03 -1.221E-02 2.5E-01 -3.844E-01 7.784E-02 -4.164E-03 0.00 1.041E-03 -2.371E-02
5.0E-01 -3.844E-01 9.823E-02 -4.164E-03 0.00 2.082E-03 -5.591E-02
283 COMB1 0.00 -6.586E-03 -1.469E-02 7.5E-01 -3.844E-01 1.186E-01 -4.164E-03
0.00 -3.224E-01 -4.584E-02 -8.751E-03 0.00 0.00 1.157E-02 1.0E+00 -3.844E-01 1.390E-01 -4.164E-03

7.5E-01 -2.978E-01 -2.395E-02 -8.751E-03 0.00 6.586E-03 -1.395E-02
1.51 -2.204E-01 4.486E-02 -8.751E-03

284 COMB1 0.00 2.674E-03 -1.243E-02 306 COMB1 0.00 2.082E-03 -5.591E-02
0.00 -1.958E-01 -3.759E-02 3.553E-03 0.00 0.00 1.058E-02 0.00 -3.844E-01 -1.390E-01 4.164E-03 0.00 1.041E-03 -2.371E-02
0.00 0.00 3.398E-03
7.5E-01 -1.800E-01 -2.357E-02 3.553E-03 0.00 -2.674E-03 -1.225E-02 2.5E-01 -3.844E-01 -1.186E-01 4.164E-03 0.00 -1.041E-03 2.541E-02
1.51 -1.115E-01 3.735E-02 3.553E-03 5.0E-01 -3.844E-01 -9.823E-02 4.164E-03
7.5E-01 -3.844E-01 -7.784E-02 4.164E-03 0.00 -2.082E-03 4.232E-02

1.00 -3.844E-01 -5.745E-02 4.164E-03

285 COMB1 -1.71 -4.768E-02 -9.671E-03 0.00 -7.278E-03 -1.607E-02 307 COMB1 0.00 1.877E-03 -1.808E-02
0.00 -1.69 -2.578E-02 -9.671E-03 0.00 0.00 1.157E-02 0.00 3.457E-02 -6.335E-02 3.754E-03 0.00 9.384E-04 -4.794E-03
0.00 0.00 3.398E-03
7.5E-01 -1.61 4.302E-02 -9.671E-03 0.00 7.278E-03 -1.257E-02 2.5E-01 3.457E-02 -4.296E-02 3.754E-03 0.00 -9.384E-04 6.493E-03
1.51 5.0E-01 3.457E-02 -2.257E-02 3.754E-03
7.5E-01 3.457E-02 -2.187E-03 3.754E-03 0.00 -1.877E-03 4.491E-03
286 COMB1 0.00 -5.968E-04 -1.254E-02
0.00 -4.429E-01 -3.773E-02 -7.929E-04 0.00 0.00 1.058E-02 1.00 3.457E-02 1.820E-02 3.754E-03

7.5E-01 -4.271E-01 -2.372E-02 -7.929E-04 0.00 5.968E-04 -1.214E-02 308 COMB1
1.51 -3.586E-01 3.720E-02 -7.929E-04 0.00 2.774E-02 -5.904E-02 2.838E-03

287 COMB1 0.00 3.130E-03 -1.243E-02 2.5E-01 2.774E-02 -3.865E-02 2.838E-03 0.00 1.419E-03 -1.593E-02
0.00 -2.528E-01 -3.759E-02 4.160E-03 0.00 0.00 1.058E-02 5.0E-01 2.774E-02 -1.826E-02 2.838E-03 0.00 7.096E-04 -3.716E-03
7.5E-01 2.774E-02 2.127E-03 2.838E-03 0.00 0.00 3.398E-03
7.5E-01 -2.370E-01 -2.358E-02 4.160E-03 0.00 -3.130E-03 -1.225E-02 0.00 -7.096E-04 5.415E-03
1.51 -1.685E-01 3.735E-02 4.160E-03 1.00 2.774E-02 2.251E-02 2.838E-03
0.00 -1.419E-03 2.334E-03

288 COMB1 0.00 -1.502E-04 -1.254E-02 309 COMB1 0.00 2.154E-04 -1.731E-04
0.00 -1.555E-01 -3.773E-02 -1.996E-04 0.00 0.00 1.058E-02 0.00 3.897E-03 -3.077E-04 3.829E-04 0.00 0.00 0.00

7.5E-01 -1.397E-01 -2.371E-02 -1.996E-04 0.00 1.502E-04 -1.215E-02 5.6E-01 1.966E-02 -3.077E-04 3.829E-04 0.00 -2.154E-04 1.731E-04
1.51 -7.120E-02 3.721E-02 -1.996E-04 1.13 3.542E-02 -3.077E-04 3.829E-04

293 COMB1 0.00 9.979E-06 -2.138E-03 310 COMB1 0.00 2.054E-04 -8.020E-05
0.00 1.321E-02 -1.362E-02 1.996E-05 0.00 4.989E-06 3.903E-04 0.00 1.517E-03 -1.426E-04 3.652E-04 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 1.321E-02 -6.612E-03 1.996E-05 0.00 -4.989E-06 1.935E-04 5.6E-01 1.728E-02 -1.426E-04 3.652E-04 0.00 -2.054E-04 8.020E-05
5.0E-01 1.321E-02 3.937E-04 1.996E-05 1.13 3.304E-02 -1.426E-04 3.652E-04
7.5E-01 1.321E-02 7.400E-03 1.996E-05 0.00 -9.979E-06 -2.532E-03
311 COMB1
1.00 1.321E-02 1.441E-02 1.996E-05 0.00 -6.329E-03 3.857E-05 3.382E-04

294 COMB1 0.00 5.191E-06 -2.140E-03 5.6E-01 9.435E-03 3.857E-05 3.382E-04 0.00 1.902E-04 2.170E-05
0.00 4.871E-02 -1.362E-02 1.038E-05 0.00 2.596E-06 3.896E-04 1.13 2.520E-02 3.857E-05 3.382E-04 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 4.871E-02 -6.615E-03 1.038E-05 0.00 -2.596E-06 1.942E-04 0.00 -1.902E-04 -2.170E-05
5.0E-01 4.871E-02 3.909E-04 1.038E-05
7.5E-01 4.871E-02 7.397E-03 1.038E-05 0.00 -5.191E-06 -2.531E-03 312 COMB1 0.00 1.830E-04 5.497E-05
0.00 -2.424E-02 9.772E-05 3.254E-04 0.00 0.00 0.00
1.00 4.871E-02 1.440E-02 1.038E-05
5.6E-01 -8.477E-03 9.772E-05 3.254E-04 0.00 -1.830E-04 -5.497E-05
1.13 7.286E-03 9.772E-05 3.254E-04

295 COMB1 0.00 3.651E-06 -2.246E-03 313 COMB1 0.00 -4.646E-03 -4.116E-05
0.00 7.490E-02 -1.383E-02 7.302E-06 0.00 1.825E-06 3.366E-04 0.00 -4.302E-02 -7.317E-05 -8.260E-03 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 7.490E-02 -6.827E-03 7.302E-06 0.00 -1.825E-06 2.473E-04 5.6E-01 -5.878E-02 -7.317E-05 -8.260E-03 0.00 4.646E-03 4.116E-05
5.0E-01 7.490E-02 1.786E-04 7.302E-06 1.13 -7.454E-02 -7.317E-05 -8.260E-03
7.5E-01 7.490E-02 7.185E-03 7.302E-06 0.00 -3.651E-06 -2.425E-03

1.00 7.490E-02 1.419E-02 7.302E-06

296 COMB1 0.00 -3.651E-06 -2.425E-03 314 COMB1 0.00 -7.650E-04 -5.199E-05
0.00 7.490E-02 -1.419E-02 -7.302E-06 0.00 -1.825E-06 2.473E-04 0.00 -8.509E-02 -9.243E-05 -1.360E-03 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 7.490E-02 -7.185E-03 -7.302E-06 0.00 1.825E-06 3.366E-04 5.6E-01 -1.009E-01 -9.243E-05 -1.360E-03 0.00 7.650E-04 5.199E-05
5.0E-01 7.490E-02 -1.786E-04 -7.302E-06 0.00 3.651E-06 -2.246E-03 1.13 -1.166E-01 -9.243E-05 -1.360E-03
7.5E-01 7.490E-02 6.827E-03 -7.302E-06
1.0E+00 7.490E-02 1.383E-02 -7.302E-06 315 COMB1 0.00 1.161E-03 6.642E-05
0.00 4.104E-03 1.181E-04 2.063E-03 0.00 0.00 0.00
297 COMB1
0.00 4.871E-02 -1.440E-02 -1.038E-05 5.6E-01 -1.166E-02 1.181E-04 2.063E-03 0.00 -1.161E-03 -6.642E-05
1.13 -2.742E-02 1.181E-04 2.063E-03
2.5E-01 4.871E-02 -7.397E-03 -1.038E-05
5.0E-01 4.871E-02 -3.909E-04 -1.038E-05 0.00 -5.191E-06 -2.531E-03 316 COMB1 0.00 5.090E-03 2.007E-04
7.5E-01 4.871E-02 6.615E-03 -1.038E-05 0.00 -2.596E-06 1.942E-04 0.00 -2.707E-03 3.568E-04 9.048E-03 0.00 0.00 0.00
0.00 0.00 1.168E-03
1.00 4.871E-02 1.362E-02 -1.038E-05 0.00 2.596E-06 3.896E-04 5.6E-01 -1.847E-02 3.568E-04 9.048E-03 0.00 -5.090E-03 -2.007E-04
1.13 -3.423E-02 3.568E-04 9.048E-03
0.00 5.191E-06 -2.140E-03

298 COMB1 0.00 -9.979E-06 -2.532E-03 317 COMB1 0.00 -4.776E-03 -2.507E-05
0.00 1.321E-02 -1.441E-02 -1.996E-05 0.00 -4.989E-06 1.935E-04 0.00 -7.721E-02 -4.457E-05 -8.490E-03 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 1.321E-02 -7.400E-03 -1.996E-05 0.00 4.989E-06 3.903E-04 5.6E-01 -9.297E-02 -4.457E-05 -8.490E-03 0.00 4.776E-03 2.507E-05
5.0E-01 1.321E-02 -3.937E-04 -1.996E-05 1.13 -1.087E-01 -4.457E-05 -8.490E-03
7.5E-01 1.321E-02 6.612E-03 -1.996E-05 0.00 9.979E-06 -2.138E-03
318 COMB1
1.00 1.321E-02 1.362E-02 -1.996E-05 0.00 -2.123E-01 -6.282E-05 -1.940E-03

299 COMB1 0.00 1.830E-04 5.497E-05 5.6E-01 -2.281E-01 -6.282E-05 -1.940E-03 0.00 -1.091E-03 -3.534E-05
0.00 7.286E-03 9.772E-05 3.254E-04 0.00 0.00 0.00 1.13 -2.439E-01 -6.282E-05 -1.940E-03 0.00 0.00 0.00

5.6E-01 -8.477E-03 9.772E-05 3.254E-04 0.00 -1.830E-04 -5.497E-05 0.00 1.091E-03 3.534E-05
1.13 -2.424E-02 9.772E-05 3.254E-04
319 COMB1
0.00 -3.253E-01 -1.555E-04 2.695E-03 0.00 1.516E-03 -8.745E-05

5.6E-01 -3.410E-01 -1.555E-04 2.695E-03 0.00 0.00 0.00 1.00 4.643E-01 4.812E-02 3.191E-01 0.00 -1.595E-01 -1.047E-02
1.13 -3.568E-01 -1.555E-04 2.695E-03 0.00 -1.516E-03 8.745E-05

320 COMB1 0.00 5.255E-03 2.956E-04 338 COMB1 0.00 -1.595E-01 -1.047E-02
0.00 1.595E-01 5.255E-04 9.342E-03 0.00 0.00 0.00 0.00 4.643E-01 -4.812E-02 -3.191E-01 0.00 -7.977E-02 -9.877E-04
0.00 0.00 3.398E-03
5.6E-01 1.437E-01 5.255E-04 9.342E-03 0.00 -5.255E-03 -2.956E-04 2.5E-01 4.643E-01 -2.774E-02 -3.191E-01 0.00 7.977E-02 2.687E-03
1.13 1.279E-01 5.255E-04 9.342E-03 5.0E-01 4.643E-01 -7.349E-03 -3.191E-01 0.00 1.595E-01 -3.121E-03
7.5E-01 4.643E-01 1.304E-02 -3.191E-01
1.0E+00 4.643E-01 3.343E-02 -3.191E-01

321 COMB1 0.00 -4.776E-03 2.507E-05 339 COMB1 0.00 1.217E-02 -1.446E-02
0.00 -7.721E-02 4.457E-05 -8.490E-03 0.00 0.00 0.00 0.00 2.753E-01 -5.611E-02 2.433E-02 0.00 6.084E-03 -2.984E-03
0.00 0.00 3.398E-03
5.6E-01 -9.297E-02 4.457E-05 -8.490E-03 0.00 4.776E-03 -2.507E-05 2.5E-01 2.753E-01 -3.572E-02 2.433E-02 0.00 -6.084E-03 4.683E-03
1.13 -1.087E-01 4.457E-05 -8.490E-03 5.0E-01 2.753E-01 -1.533E-02 2.433E-02
7.5E-01 2.753E-01 5.053E-03 2.433E-02 0.00 -1.217E-02 8.714E-04
322 COMB1 0.00 -1.091E-03 3.534E-05
0.00 -2.123E-01 6.282E-05 -1.940E-03 0.00 0.00 0.00 1.00 2.753E-01 2.544E-02 2.433E-02

5.6E-01 -2.281E-01 6.282E-05 -1.940E-03 0.00 1.091E-03 -3.534E-05 340 COMB1
1.13 -2.439E-01 6.282E-05 -1.940E-03 0.00 -2.879E-02 -5.613E-02 3.116E-01

323 COMB1 0.00 1.516E-03 8.745E-05 2.5E-01 -2.879E-02 -3.574E-02 3.116E-01 0.00 1.558E-01 -1.447E-02
0.00 -3.253E-01 1.555E-04 2.695E-03 0.00 0.00 0.00 5.0E-01 -2.879E-02 -1.536E-02 3.116E-01 0.00 7.789E-02 -2.990E-03
7.5E-01 -2.879E-02 5.031E-03 3.116E-01 0.00 0.00 3.398E-03
5.6E-01 -3.410E-01 1.555E-04 2.695E-03 0.00 -1.516E-03 -8.745E-05 0.00 -7.789E-02 4.689E-03
1.13 -3.568E-01 1.555E-04 2.695E-03 1.00 -2.879E-02 2.542E-02 3.116E-01
0.00 -1.558E-01 8.826E-04

324 COMB1 0.00 5.255E-03 -2.956E-04 341 COMB1 0.00 -6.091E-03 -1.946E-03
0.00 1.595E-01 -5.255E-04 9.342E-03 0.00 0.00 0.00 0.00 -2.921E-02 -1.323E-02 -1.218E-02 0.00 -3.045E-03 4.864E-04
0.00 0.00 1.168E-03
5.6E-01 1.437E-01 -5.255E-04 9.342E-03 0.00 -5.255E-03 2.956E-04 2.5E-01 -2.921E-02 -6.228E-03 -1.218E-02 0.00 3.045E-03 9.740E-05
1.13 1.279E-01 -5.255E-04 9.342E-03 5.0E-01 -2.921E-02 7.781E-04 -1.218E-02
7.5E-01 -2.921E-02 7.784E-03 -1.218E-02 0.00 6.091E-03 -2.724E-03
325 COMB1
0.00 -4.302E-02 7.317E-05 -8.260E-03 1.00 -2.921E-02 1.479E-02 -1.218E-02

5.6E-01 -5.878E-02 7.317E-05 -8.260E-03 0.00 -4.646E-03 4.116E-05 342 COMB1 0.00 -1.208E-04 -1.642E-03
1.13 -7.454E-02 7.317E-05 -8.260E-03 0.00 0.00 0.00 0.00 -1.210E-01 -1.263E-02 -2.416E-04 0.00 -6.041E-05 6.385E-04
0.00 0.00 1.168E-03
0.00 4.646E-03 -4.116E-05 2.5E-01 -1.210E-01 -5.620E-03 -2.416E-04 0.00 6.041E-05 -5.468E-05
5.0E-01 -1.210E-01 1.386E-03 -2.416E-04
326 COMB1 0.00 -7.650E-04 5.199E-05 7.5E-01 -1.210E-01 8.392E-03 -2.416E-04 0.00 1.208E-04 -3.029E-03
0.00 -8.509E-02 9.243E-05 -1.360E-03 0.00 0.00 0.00
1.00 -1.210E-01 1.540E-02 -2.416E-04
5.6E-01 -1.009E-01 9.243E-05 -1.360E-03 0.00 7.650E-04 -5.199E-05
1.13 -1.166E-01 9.243E-05 -1.360E-03

327 COMB1 0.00 1.161E-03 -6.642E-05 343 COMB1 0.00 6.064E-03 -1.895E-03
0.00 4.104E-03 -1.181E-04 2.063E-03 0.00 0.00 0.00 0.00 2.821E-01 -1.313E-02 1.213E-02 0.00 3.032E-03 5.120E-04
0.00 0.00 1.168E-03
5.6E-01 -1.166E-02 -1.181E-04 2.063E-03 0.00 -1.161E-03 6.642E-05 2.5E-01 2.821E-01 -6.126E-03 1.213E-02 0.00 -3.032E-03 7.188E-05
1.13 -2.742E-02 -1.181E-04 2.063E-03 5.0E-01 2.821E-01 8.802E-04 1.213E-02
7.5E-01 2.821E-01 7.886E-03 1.213E-02 0.00 -6.064E-03 -2.775E-03

1.00 2.821E-01 1.489E-02 1.213E-02

328 COMB1 0.00 5.090E-03 -2.007E-04 344 COMB1 0.00 -6.064E-03 -2.775E-03
0.00 -2.707E-03 -3.568E-04 9.048E-03 0.00 0.00 0.00 0.00 2.821E-01 -1.489E-02 -1.213E-02 0.00 -3.032E-03 7.188E-05
0.00 0.00 1.168E-03
5.6E-01 -1.847E-02 -3.568E-04 9.048E-03 0.00 -5.090E-03 2.007E-04 2.5E-01 2.821E-01 -7.886E-03 -1.213E-02 0.00 3.032E-03 5.120E-04
1.13 -3.423E-02 -3.568E-04 9.048E-03 5.0E-01 2.821E-01 -8.802E-04 -1.213E-02 0.00 6.064E-03 -1.895E-03
7.5E-01 2.821E-01 6.126E-03 -1.213E-02
329 COMB1 0.00 -6.091E-03 -2.087E-03 1.0E+00 2.821E-01 1.313E-02 -1.213E-02
0.00 3.256E-02 -1.352E-02 -1.218E-02 0.00 -3.045E-03 4.158E-04
0.00 0.00 1.168E-03 345 COMB1 0.00 1.208E-04 -3.029E-03
2.5E-01 3.256E-02 -6.510E-03 -1.218E-02 0.00 3.045E-03 1.680E-04 0.00 -1.210E-01 -1.540E-02 2.416E-04 0.00 6.041E-05 -5.468E-05
5.0E-01 3.256E-02 4.957E-04 -1.218E-02 0.00 0.00 1.168E-03
7.5E-01 3.256E-02 7.502E-03 -1.218E-02 0.00 6.091E-03 -2.583E-03 2.5E-01 -1.210E-01 -8.392E-03 2.416E-04 0.00 -6.041E-05 6.385E-04
5.0E-01 -1.210E-01 -1.386E-03 2.416E-04
1.00 3.256E-02 1.451E-02 -1.218E-02 7.5E-01 -1.210E-01 5.620E-03 2.416E-04 0.00 -1.208E-04 -1.642E-03

330 COMB1 0.00 -1.580E-04 -2.105E-03 1.00 -1.210E-01 1.263E-02 2.416E-04
0.00 7.126E-02 -1.355E-02 -3.161E-04 0.00 -7.902E-05 4.070E-04
0.00 0.00 1.168E-03 346 COMB1 0.00 6.091E-03 -2.724E-03
2.5E-01 7.126E-02 -6.546E-03 -3.161E-04 0.00 7.902E-05 1.769E-04 0.00 -2.921E-02 -1.479E-02 1.218E-02 0.00 3.045E-03 9.740E-05
5.0E-01 7.126E-02 4.602E-04 -3.161E-04 0.00 0.00 1.168E-03
7.5E-01 7.126E-02 7.466E-03 -3.161E-04 0.00 1.580E-04 -2.565E-03 2.5E-01 -2.921E-02 -7.784E-03 1.218E-02 0.00 -3.045E-03 4.864E-04
5.0E-01 -2.921E-02 -7.781E-04 1.218E-02
1.00 7.126E-02 1.447E-02 -3.161E-04 7.5E-01 -2.921E-02 6.228E-03 1.218E-02 0.00 -6.091E-03 -1.946E-03

331 COMB1 0.00 5.984E-03 -2.221E-03 1.00 -2.921E-02 1.323E-02 1.218E-02
0.00 1.100E-01 -1.378E-02 1.197E-02 0.00 2.992E-03 3.491E-04
0.00 0.00 1.168E-03 349 COMB1 0.00 -9.726E-05 -3.539E-03
2.5E-01 1.100E-01 -6.777E-03 1.197E-02 0.00 -2.992E-03 2.347E-04 0.00 -9.878E-02 -1.404E-02 -1.292E-04 0.00 0.00 1.758E-03
5.0E-01 1.100E-01 2.288E-04 1.197E-02
7.5E-01 1.100E-01 7.235E-03 1.197E-02 0.00 -5.984E-03 -2.450E-03 7.5E-01 -8.302E-02 -3.234E-05 -1.292E-04 0.00 9.726E-05 -3.491E-03
1.51 -6.725E-02 1.398E-02 -1.292E-04
1.00 1.100E-01 1.424E-02 1.197E-02

332 COMB1 0.00 -5.984E-03 -2.450E-03 350 COMB1 0.00 -2.715E-03 -3.522E-03
0.00 1.100E-01 -1.424E-02 -1.197E-02 0.00 -2.992E-03 2.347E-04 0.00 7.377E-02 -1.402E-02 -3.607E-03 0.00 0.00 1.758E-03
0.00 0.00 1.168E-03
2.5E-01 1.100E-01 -7.235E-03 -1.197E-02 0.00 2.992E-03 3.491E-04 7.5E-01 5.800E-02 -8.622E-06 -3.607E-03 0.00 2.715E-03 -3.509E-03
5.0E-01 1.100E-01 -2.288E-04 -1.197E-02 0.00 5.984E-03 -2.221E-03 1.51 4.224E-02 1.400E-02 -3.607E-03
7.5E-01 1.100E-01 6.777E-03 -1.197E-02
1.0E+00 1.100E-01 1.378E-02 -1.197E-02

333 COMB1 0.00 1.580E-04 -2.565E-03 351 COMB1 0.00 2.663E-03 -3.517E-03
0.00 7.126E-02 -1.447E-02 3.161E-04 0.00 7.902E-05 1.769E-04 0.00 3.120E-02 -1.401E-02 3.538E-03 0.00 0.00 1.758E-03
0.00 0.00 1.168E-03
2.5E-01 7.126E-02 -7.466E-03 3.161E-04 0.00 -7.902E-05 4.070E-04 7.5E-01 1.544E-02 -2.754E-06 3.538E-03 0.00 -2.663E-03 -3.513E-03
5.0E-01 7.126E-02 -4.602E-04 3.161E-04 1.51 -3.257E-04 1.401E-02 3.538E-03
7.5E-01 7.126E-02 6.546E-03 3.161E-04 0.00 -1.580E-04 -2.105E-03
352 COMB1 0.00 -2.424E-03 -3.516E-03
1.00 7.126E-02 1.355E-02 3.161E-04 0.00 4.169E-03 -1.401E-02 -3.221E-03 0.00 0.00 1.758E-03

334 COMB1 7.5E-01 -1.159E-02 -1.220E-06 -3.221E-03 0.00 2.424E-03 -3.514E-03
0.00 3.256E-02 -1.451E-02 1.218E-02 1.51 -2.736E-02 1.401E-02 -3.221E-03

2.5E-01 3.256E-02 -7.502E-03 1.218E-02 0.00 6.091E-03 -2.583E-03 353 COMB1 0.00 2.945E-03 -3.526E-03
5.0E-01 3.256E-02 -4.957E-04 1.218E-02 0.00 3.045E-03 1.680E-04 0.00 -4.024E-02 -1.403E-02 3.913E-03 0.00 0.00 1.758E-03
7.5E-01 3.256E-02 6.510E-03 1.218E-02 0.00 0.00 1.168E-03
0.00 -3.045E-03 4.158E-04 7.5E-01 -5.600E-02 -1.475E-05 3.913E-03 0.00 -2.945E-03 -3.504E-03
1.00 3.256E-02 1.352E-02 1.218E-02 1.51 -7.177E-02 1.400E-02 3.913E-03
0.00 -6.091E-03 -2.087E-03

335 COMB1 0.00 -1.558E-01 8.826E-04 354 COMB1 0.00 -2.721E-03 -3.503E-03
0.00 -2.879E-02 -2.542E-02 -3.116E-01 0.00 -7.789E-02 4.689E-03 0.00 4.127E-03 -1.400E-02 -3.615E-03 0.00 0.00 1.758E-03
0.00 0.00 3.398E-03
2.5E-01 -2.879E-02 -5.031E-03 -3.116E-01 0.00 7.789E-02 -2.990E-03 7.5E-01 -1.164E-02 1.649E-05 -3.615E-03 0.00 2.721E-03 -3.528E-03
5.0E-01 -2.879E-02 1.536E-02 -3.116E-01 1.51 -2.740E-02 1.403E-02 -3.615E-03
7.5E-01 -2.879E-02 3.574E-02 -3.116E-01 0.00 1.558E-01 -1.447E-02
355 COMB1
1.00 -2.879E-02 5.613E-02 -3.116E-01 0.00 -2.391E-02 -1.399E-02 -4.293E-04

336 COMB1 0.00 -1.217E-02 8.714E-04 7.5E-01 -3.967E-02 1.821E-05 -4.293E-04 0.00 -3.231E-04 -3.501E-03
0.00 2.753E-01 -2.544E-02 -2.433E-02 0.00 -6.084E-03 4.683E-03 1.51 -5.543E-02 1.403E-02 -4.293E-04 0.00 0.00 1.758E-03
0.00 0.00 3.398E-03
2.5E-01 2.753E-01 -5.053E-03 -2.433E-02 0.00 6.084E-03 -2.984E-03 0.00 3.231E-04 -3.529E-03
5.0E-01 2.753E-01 1.533E-02 -2.433E-02
7.5E-01 2.753E-01 3.572E-02 -2.433E-02 0.00 1.217E-02 -1.446E-02 356 COMB1 0.00 3.356E-03 -3.498E-03
0.00 -5.673E-02 -1.399E-02 4.460E-03 0.00 0.00 1.758E-03
1.00 2.753E-01 5.611E-02 -2.433E-02
7.5E-01 -7.250E-02 2.299E-05 4.460E-03 0.00 -3.356E-03 -3.532E-03
1.51 -8.826E-02 1.403E-02 4.460E-03

337 COMB1 0.00 1.595E-01 -3.121E-03 357 COMB1 0.00 9.726E-05 -3.491E-03
0.00 4.643E-01 -3.343E-02 3.191E-01 0.00 7.977E-02 2.687E-03 0.00 -6.725E-02 -1.398E-02 1.292E-04 0.00 0.00 1.758E-03
0.00 0.00 3.398E-03
2.5E-01 4.643E-01 -1.304E-02 3.191E-01 0.00 -7.977E-02 -9.877E-04 7.5E-01 -8.302E-02 3.234E-05 1.292E-04 0.00 -9.726E-05 -3.539E-03
5.0E-01 4.643E-01 7.349E-03 3.191E-01 1.51 -9.878E-02 1.404E-02 1.292E-04
7.5E-01 4.643E-01 2.774E-02 3.191E-01

358 COMB1 0.00 -3.135E-03 -3.546E-03 379 COMB1 0.00 7.306E-06 -2.365E-03
0.00 9.640E-02 -1.405E-02 -4.166E-03 0.00 0.00 1.758E-03 0.00 3.654E-02 -1.407E-02 1.461E-05 0.00 3.653E-06 2.770E-04
0.00 0.00 1.168E-03
7.5E-01 8.064E-02 -4.139E-05 -4.166E-03 0.00 3.135E-03 -3.484E-03 2.5E-01 3.654E-02 -7.066E-03 1.461E-05 0.00 -3.653E-06 3.068E-04
1.51 6.487E-02 1.397E-02 -4.166E-03 5.0E-01 3.654E-02 -5.966E-05 1.461E-05
7.5E-01 3.654E-02 6.946E-03 1.461E-05 0.00 -7.306E-06 -2.305E-03
359 COMB1
0.00 5.862E-02 -1.403E-02 7.459E-04 1.00 3.654E-02 1.395E-02 1.461E-05

7.5E-01 4.286E-02 -2.277E-05 7.459E-04 0.00 5.613E-04 -3.532E-03 380 COMB1 0.00 -7.306E-06 -2.305E-03
1.51 2.710E-02 1.399E-02 7.459E-04 0.00 0.00 1.758E-03 0.00 3.654E-02 -1.395E-02 -1.461E-05 0.00 -3.653E-06 3.068E-04
0.00 0.00 1.168E-03
0.00 -5.613E-04 -3.498E-03 2.5E-01 3.654E-02 -6.946E-03 -1.461E-05 0.00 3.653E-06 2.770E-04
5.0E-01 3.654E-02 5.966E-05 -1.461E-05 0.00 7.306E-06 -2.365E-03
360 COMB1 0.00 3.015E-03 -3.526E-03 7.5E-01 3.654E-02 7.066E-03 -1.461E-05
0.00 2.245E-02 -1.403E-02 4.006E-03 0.00 0.00 1.758E-03 1.0E+00 3.654E-02 1.407E-02 -1.461E-05

7.5E-01 6.688E-03 -1.422E-05 4.006E-03 0.00 -3.015E-03 -3.504E-03
1.51 -9.075E-03 1.400E-02 4.006E-03

361 COMB1 0.00 1.500E-04 -3.539E-03 381 COMB1 0.00 -5.899E-06 -2.266E-03
0.00 1.074E-01 -1.404E-02 1.994E-04 0.00 0.00 1.758E-03 0.00 2.090E-02 -1.387E-02 -1.180E-05 0.00 -2.950E-06 3.265E-04
0.00 0.00 1.168E-03
7.5E-01 9.166E-02 -3.145E-05 1.994E-04 0.00 -1.500E-04 -3.491E-03 2.5E-01 2.090E-02 -6.868E-03 -1.180E-05 0.00 2.950E-06 2.574E-04
1.51 7.590E-02 1.398E-02 1.994E-04 5.0E-01 2.090E-02 1.382E-04 -1.180E-05
7.5E-01 2.090E-02 7.144E-03 -1.180E-05 0.00 5.899E-06 -2.404E-03

1.00 2.090E-02 1.415E-02 -1.180E-05

362 COMB1 0.00 -3.356E-03 -3.532E-03 382 COMB1 0.00 -2.469E-05 -2.219E-03
0.00 -8.826E-02 -1.403E-02 -4.460E-03 0.00 0.00 1.758E-03 0.00 4.095E-03 -1.378E-02 -4.938E-05 0.00 -1.235E-05 3.501E-04
0.00 0.00 1.168E-03
7.5E-01 -7.250E-02 -2.299E-05 -4.460E-03 0.00 3.356E-03 -3.498E-03 2.5E-01 4.095E-03 -6.773E-03 -4.938E-05 0.00 1.235E-05 2.338E-04
1.51 -5.673E-02 1.399E-02 -4.460E-03 5.0E-01 4.095E-03 2.326E-04 -4.938E-05
7.5E-01 4.095E-03 7.239E-03 -4.938E-05 0.00 2.469E-05 -2.452E-03
363 COMB1 0.00 3.231E-04 -3.529E-03
0.00 -5.543E-02 -1.403E-02 4.293E-04 0.00 0.00 1.758E-03 1.00 4.095E-03 1.424E-02 -4.938E-05

7.5E-01 -3.967E-02 -1.821E-05 4.293E-04 0.00 -3.231E-04 -3.501E-03 383 COMB1
1.51 -2.391E-02 1.399E-02 4.293E-04 0.00 1.149E-02 -5.278E-05 3.433E-04

364 COMB1 0.00 2.721E-03 -3.528E-03 5.6E-01 -4.269E-03 -5.278E-05 3.433E-04 0.00 1.931E-04 -2.969E-05
0.00 -2.740E-02 -1.403E-02 3.615E-03 0.00 0.00 1.758E-03 1.13 -2.003E-02 -5.278E-05 3.433E-04 0.00 0.00 0.00

7.5E-01 -1.164E-02 -1.649E-05 3.615E-03 0.00 -2.721E-03 -3.503E-03 0.00 -1.931E-04 2.969E-05
1.51 4.127E-03 1.400E-02 3.615E-03
384 COMB1
365 COMB1 0.00 -2.945E-03 -3.504E-03 0.00 2.453E-02 -3.356E-05 3.379E-04 0.00 1.901E-04 -1.888E-05
0.00 -7.177E-02 -1.400E-02 -3.913E-03 0.00 0.00 1.758E-03 0.00 0.00 0.00
5.6E-01 8.765E-03 -3.356E-05 3.379E-04
7.5E-01 -5.600E-02 1.475E-05 -3.913E-03 0.00 2.945E-03 -3.526E-03 1.13 -6.999E-03 -3.356E-05 3.379E-04 0.00 -1.901E-04 1.888E-05
1.51 -4.024E-02 1.403E-02 -3.913E-03
385 COMB1
366 COMB1 0.00 2.424E-03 -3.514E-03 0.00 3.559E-02 -4.580E-05 3.631E-04 0.00 2.043E-04 -2.576E-05
0.00 -2.736E-02 -1.401E-02 3.221E-03 0.00 0.00 1.758E-03 0.00 0.00 0.00
5.6E-01 1.982E-02 -4.580E-05 3.631E-04
7.5E-01 -1.159E-02 1.220E-06 3.221E-03 0.00 -2.424E-03 -3.516E-03 1.13 4.058E-03 -4.580E-05 3.631E-04 0.00 -2.043E-04 2.576E-05
1.51 4.169E-03 1.401E-02 3.221E-03
386 COMB1
367 COMB1 0.00 -2.663E-03 -3.513E-03 0.00 2.764E-02 -5.101E-05 3.953E-04 0.00 2.224E-04 -2.869E-05
0.00 -3.257E-04 -1.401E-02 -3.538E-03 0.00 0.00 1.758E-03 0.00 0.00 0.00
5.6E-01 1.188E-02 -5.101E-05 3.953E-04
7.5E-01 1.544E-02 2.754E-06 -3.538E-03 0.00 2.663E-03 -3.517E-03 1.13 -3.887E-03 -5.101E-05 3.953E-04 0.00 -2.224E-04 2.869E-05
1.51 3.120E-02 1.401E-02 -3.538E-03
387 COMB1
368 COMB1 0.00 2.715E-03 -3.509E-03 0.00 7.214E-03 -1.424E-02 -1.146E-04 0.00 -5.732E-05 -2.452E-03
0.00 4.224E-02 -1.400E-02 3.607E-03 0.00 0.00 1.758E-03 0.00 -2.866E-05 2.337E-04
2.5E-01 7.214E-03 -7.239E-03 -1.146E-04 0.00 0.00 1.168E-03
7.5E-01 5.800E-02 8.622E-06 3.607E-03 0.00 -2.715E-03 -3.522E-03 5.0E-01 7.214E-03 -2.327E-04 -1.146E-04 0.00 2.866E-05 3.501E-04
1.51 7.377E-02 1.402E-02 3.607E-03 7.5E-01 7.214E-03 6.773E-03 -1.146E-04
0.00 5.732E-05 -2.219E-03
1.00 7.214E-03 1.378E-02 -1.146E-04

369 COMB1 0.00 -3.015E-03 -3.504E-03 388 COMB1 0.00 -8.395E-05 -2.392E-03
0.00 -9.075E-03 -1.400E-02 -4.006E-03 0.00 0.00 1.758E-03 0.00 -1.195E-02 -1.413E-02 -1.679E-04 0.00 -4.198E-05 2.635E-04
0.00 0.00 1.168E-03
7.5E-01 6.688E-03 1.422E-05 -4.006E-03 0.00 3.015E-03 -3.526E-03 2.5E-01 -1.195E-02 -7.120E-03 -1.679E-04 0.00 4.198E-05 3.204E-04
1.51 2.245E-02 1.403E-02 -4.006E-03 5.0E-01 -1.195E-02 -1.138E-04 -1.679E-04
7.5E-01 -1.195E-02 6.892E-03 -1.679E-04 0.00 8.395E-05 -2.278E-03
370 COMB1
0.00 2.710E-02 -1.399E-02 -7.459E-04 1.00 -1.195E-02 1.390E-02 -1.679E-04

7.5E-01 4.286E-02 2.277E-05 -7.459E-04 0.00 -5.613E-04 -3.498E-03 389 COMB1 0.00 -7.416E-05 -2.341E-03
1.51 5.862E-02 1.403E-02 -7.459E-04 0.00 0.00 1.758E-03 0.00 -7.811E-02 -1.402E-02 -1.483E-04 0.00 -3.708E-05 2.889E-04
0.00 0.00 1.168E-03
0.00 5.613E-04 -3.532E-03 2.5E-01 -7.811E-02 -7.018E-03 -1.483E-04 0.00 3.708E-05 2.950E-04
5.0E-01 -7.811E-02 -1.218E-05 -1.483E-04 0.00 7.416E-05 -2.329E-03
371 COMB1 0.00 3.135E-03 -3.484E-03 7.5E-01 -7.811E-02 6.994E-03 -1.483E-04
0.00 6.487E-02 -1.397E-02 4.166E-03 0.00 0.00 1.758E-03 1.0E+00 -7.811E-02 1.400E-02 -1.483E-04

7.5E-01 8.064E-02 4.139E-05 4.166E-03 0.00 -3.135E-03 -3.546E-03
1.51 9.640E-02 1.405E-02 4.166E-03

372 COMB1 0.00 -1.500E-04 -3.491E-03 390 COMB1 0.00 7.416E-05 -2.329E-03
0.00 7.590E-02 -1.398E-02 -1.994E-04 0.00 0.00 1.758E-03 0.00 -7.811E-02 -1.400E-02 1.483E-04 0.00 3.708E-05 2.950E-04
0.00 0.00 1.168E-03
7.5E-01 9.166E-02 3.145E-05 -1.994E-04 0.00 1.500E-04 -3.539E-03 2.5E-01 -7.811E-02 -6.994E-03 1.483E-04 0.00 -3.708E-05 2.889E-04
1.51 1.074E-01 1.404E-02 -1.994E-04 5.0E-01 -7.811E-02 1.218E-05 1.483E-04
7.5E-01 -7.811E-02 7.018E-03 1.483E-04 0.00 -7.416E-05 -2.341E-03

1.00 -7.811E-02 1.402E-02 1.483E-04

373 COMB1 0.00 -2.376E-04 0.00 -1.337E-04 0.00 391 COMB1 0.00 8.395E-05 -2.278E-03
0.00 6.253E-03 0.00 -2.376E-04 0.00 0.00 0.00 0.00 -1.195E-02 -1.390E-02 1.679E-04 0.00 4.198E-05 3.204E-04
0.00 0.00 1.168E-03
5.6E-01 -9.510E-03 0.00 -2.376E-04 0.00 1.337E-04 0.00 2.5E-01 -1.195E-02 -6.892E-03 1.679E-04 0.00 -4.198E-05 2.635E-04
1.13 -2.527E-02 5.0E-01 -1.195E-02 1.138E-04 1.679E-04
7.5E-01 -1.195E-02 7.120E-03 1.679E-04 0.00 -8.395E-05 -2.392E-03
374 COMB1 0.00 5.306E-05 0.00 2.985E-05 0.00
0.00 1.380E-02 0.00 5.306E-05 0.00 0.00 0.00 1.00 -1.195E-02 1.413E-02 1.679E-04

5.6E-01 -1.959E-03 0.00 5.306E-05 0.00 -2.985E-05 0.00 392 COMB1
1.13 -1.772E-02 0.00 7.214E-03 -1.378E-02 1.146E-04

375 COMB1 0.00 8.145E-04 0.00 4.581E-04 0.00 2.5E-01 7.214E-03 -6.773E-03 1.146E-04 0.00 5.732E-05 -2.219E-03
0.00 1.790E-02 0.00 8.145E-04 0.00 0.00 0.00 5.0E-01 7.214E-03 2.327E-04 1.146E-04 0.00 2.866E-05 3.501E-04
7.5E-01 7.214E-03 7.239E-03 1.146E-04 0.00 0.00 1.168E-03
5.6E-01 2.140E-03 0.00 8.145E-04 0.00 -4.581E-04 0.00 0.00 -2.866E-05 2.337E-04
1.13 -1.362E-02 1.00 7.214E-03 1.424E-02 1.146E-04
0.00 -5.732E-05 -2.452E-03

376 COMB1 0.00 1.060E-03 0.00 5.960E-04 0.00 393 COMB1 0.00 2.224E-04 -2.869E-05
0.00 2.587E-02 0.00 1.060E-03 0.00 0.00 0.00 0.00 -3.887E-03 -5.101E-05 3.953E-04 0.00 0.00 0.00

5.6E-01 1.011E-02 0.00 1.060E-03 0.00 -5.960E-04 0.00 5.6E-01 1.188E-02 -5.101E-05 3.953E-04 0.00 -2.224E-04 2.869E-05
1.13 -5.652E-03 1.13 2.764E-02 -5.101E-05 3.953E-04

377 COMB1 0.00 2.469E-05 -2.452E-03 394 COMB1 0.00 2.043E-04 -2.576E-05
0.00 4.095E-03 -1.424E-02 4.938E-05 0.00 1.235E-05 2.338E-04 0.00 4.058E-03 -4.580E-05 3.631E-04 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 4.095E-03 -7.239E-03 4.938E-05 0.00 -1.235E-05 3.501E-04 5.6E-01 1.982E-02 -4.580E-05 3.631E-04 0.00 -2.043E-04 2.576E-05
5.0E-01 4.095E-03 -2.326E-04 4.938E-05 1.13 3.559E-02 -4.580E-05 3.631E-04
7.5E-01 4.095E-03 6.773E-03 4.938E-05 0.00 -2.469E-05 -2.219E-03
395 COMB1
1.00 4.095E-03 1.378E-02 4.938E-05 0.00 -6.999E-03 -3.356E-05 3.379E-04

378 COMB1 0.00 5.899E-06 -2.404E-03 5.6E-01 8.765E-03 -3.356E-05 3.379E-04 0.00 1.901E-04 -1.888E-05
0.00 2.090E-02 -1.415E-02 1.180E-05 0.00 2.950E-06 2.574E-04 1.13 2.453E-02 -3.356E-05 3.379E-04 0.00 0.00 0.00
0.00 0.00 1.168E-03
2.5E-01 2.090E-02 -7.144E-03 1.180E-05 0.00 -2.950E-06 3.265E-04 0.00 -1.901E-04 1.888E-05
5.0E-01 2.090E-02 -1.382E-04 1.180E-05
7.5E-01 2.090E-02 6.868E-03 1.180E-05 0.00 -5.899E-06 -2.266E-03 396 COMB1
0.00 -2.003E-02 -5.278E-05 3.433E-04 0.00 1.931E-04 -2.969E-05
1.00 2.090E-02 1.387E-02 1.180E-05
5.6E-01 -4.269E-03 -5.278E-05 3.433E-04 0.00 0.00 0.00

1.13 1.149E-02 -5.278E-05 3.433E-04 0.00 -1.931E-04 2.969E-05

397 COMB1 0.00 -4.723E-03 2.837E-05 417 COMB1 0.00 1.544E-04 -2.270E-03
0.00 1.855E-02 5.043E-05 -8.396E-03 0.00 0.00 0.00 0.00 6.119E-03 -1.388E-02 3.088E-04 0.00 7.720E-05 3.248E-04
0.00 0.00 1.168E-03
5.6E-01 2.788E-03 5.043E-05 -8.396E-03 0.00 4.723E-03 -2.837E-05 2.5E-01 6.119E-03 -6.875E-03 3.088E-04 0.00 -7.720E-05 2.591E-04
1.13 -1.298E-02 5.043E-05 -8.396E-03 5.0E-01 6.119E-03 1.314E-04 3.088E-04
7.5E-01 6.119E-03 7.137E-03 3.088E-04 0.00 -1.544E-04 -2.401E-03

1.00 6.119E-03 1.414E-02 3.088E-04

398 COMB1 0.00 -6.988E-04 1.439E-05 418 COMB1 0.00 6.185E-03 -2.212E-03
0.00 2.065E-02 2.559E-05 -1.242E-03 0.00 0.00 0.00 0.00 2.239E-03 -1.376E-02 1.237E-02 0.00 3.093E-03 3.536E-04
0.00 0.00 1.168E-03
5.6E-01 4.887E-03 2.559E-05 -1.242E-03 0.00 6.988E-04 -1.439E-05 2.5E-01 2.239E-03 -6.759E-03 1.237E-02 0.00 -3.093E-03 2.302E-04
1.13 -1.088E-02 2.559E-05 -1.242E-03 5.0E-01 2.239E-03 2.469E-04 1.237E-02
7.5E-01 2.239E-03 7.253E-03 1.237E-02 0.00 -6.185E-03 -2.459E-03
399 COMB1 0.00 1.094E-03 2.076E-05
0.00 2.975E-02 3.691E-05 1.946E-03 0.00 0.00 0.00 1.00 2.239E-03 1.426E-02 1.237E-02

5.6E-01 1.399E-02 3.691E-05 1.946E-03 0.00 -1.094E-03 -2.076E-05 419 COMB1
1.13 -1.772E-03 3.691E-05 1.946E-03 0.00 -4.046E-03 -1.425E-02 -1.462E-02

400 COMB1 0.00 5.163E-03 4.173E-05 2.5E-01 -4.046E-03 -7.245E-03 -1.462E-02 0.00 -7.308E-03 -2.455E-03
0.00 3.034E-02 7.418E-05 9.178E-03 0.00 0.00 0.00 5.0E-01 -4.046E-03 -2.391E-04 -1.462E-02 0.00 -3.654E-03 2.321E-04
7.5E-01 -4.046E-03 6.767E-03 -1.462E-02 0.00 0.00 1.168E-03
5.6E-01 1.458E-02 7.418E-05 9.178E-03 0.00 -5.163E-03 -4.173E-05 0.00 3.654E-03 3.517E-04
1.13 -1.188E-03 7.418E-05 9.178E-03 1.00 -4.046E-03 1.377E-02 -1.462E-02
0.00 7.308E-03 -2.216E-03

401 COMB1 0.00 -4.850E-03 1.782E-05 420 COMB1 0.00 -5.871E-04 -2.396E-03
0.00 1.521E-02 3.169E-05 -8.622E-03 0.00 0.00 0.00 0.00 -1.596E-03 -1.413E-02 -1.174E-03 0.00 -2.936E-04 2.614E-04
0.00 0.00 1.168E-03
5.6E-01 -5.513E-04 3.169E-05 -8.622E-03 0.00 4.850E-03 -1.782E-05 2.5E-01 -1.596E-03 -7.128E-03 -1.174E-03 0.00 2.936E-04 3.225E-04
1.13 -1.631E-02 3.169E-05 -8.622E-03 5.0E-01 -1.596E-03 -1.222E-04 -1.174E-03
7.5E-01 -1.596E-03 6.884E-03 -1.174E-03 0.00 5.871E-04 -2.274E-03
402 COMB1
0.00 1.609E-02 1.580E-05 -1.851E-03 1.00 -1.596E-03 1.389E-02 -1.174E-03

5.6E-01 3.295E-04 1.580E-05 -1.851E-03 0.00 -1.041E-03 8.888E-06 421 COMB1 0.00 7.318E-03 -2.354E-03
1.13 -1.543E-02 1.580E-05 -1.851E-03 0.00 0.00 0.00 0.00 -8.925E-04 -1.405E-02 1.464E-02 0.00 3.659E-03 2.827E-04
0.00 0.00 1.168E-03
0.00 1.041E-03 -8.888E-06 2.5E-01 -8.925E-04 -7.043E-03 1.464E-02 0.00 -3.659E-03 3.011E-04
5.0E-01 -8.925E-04 -3.685E-05 1.464E-02
403 COMB1 0.00 1.466E-03 8.861E-06 7.5E-01 -8.925E-04 6.969E-03 1.464E-02 0.00 -7.318E-03 -2.317E-03
0.00 2.369E-02 1.575E-05 2.607E-03 0.00 0.00 0.00
1.00 -8.925E-04 1.398E-02 1.464E-02
5.6E-01 7.930E-03 1.575E-05 2.607E-03 0.00 -1.466E-03 -8.861E-06
1.13 -7.833E-03 1.575E-05 2.607E-03

404 COMB1 0.00 5.322E-03 4.624E-05 422 COMB1 0.00 -7.318E-03 -2.317E-03
0.00 3.225E-02 8.220E-05 9.461E-03 0.00 0.00 0.00 0.00 -8.925E-04 -1.398E-02 -1.464E-02 0.00 -3.659E-03 3.011E-04
0.00 0.00 1.168E-03
5.6E-01 1.648E-02 8.220E-05 9.461E-03 0.00 -5.322E-03 -4.624E-05 2.5E-01 -8.925E-04 -6.969E-03 -1.464E-02 0.00 3.659E-03 2.827E-04
1.13 7.199E-04 8.220E-05 9.461E-03 5.0E-01 -8.925E-04 3.685E-05 -1.464E-02 0.00 7.318E-03 -2.354E-03
7.5E-01 -8.925E-04 7.043E-03 -1.464E-02
1.0E+00 -8.925E-04 1.405E-02 -1.464E-02

405 COMB1 0.00 -4.850E-03 -1.782E-05 423 COMB1 0.00 5.871E-04 -2.274E-03
0.00 1.521E-02 -3.169E-05 -8.622E-03 0.00 0.00 0.00 0.00 -1.596E-03 -1.389E-02 1.174E-03 0.00 2.936E-04 3.225E-04
0.00 0.00 1.168E-03
5.6E-01 -5.513E-04 -3.169E-05 -8.622E-03 0.00 4.850E-03 1.782E-05 2.5E-01 -1.596E-03 -6.884E-03 1.174E-03 0.00 -2.936E-04 2.614E-04
1.13 -1.631E-02 -3.169E-05 -8.622E-03 5.0E-01 -1.596E-03 1.222E-04 1.174E-03
7.5E-01 -1.596E-03 7.128E-03 1.174E-03 0.00 -5.871E-04 -2.396E-03
406 COMB1 0.00 -1.041E-03 -8.888E-06
0.00 1.609E-02 -1.580E-05 -1.851E-03 0.00 0.00 0.00 1.00 -1.596E-03 1.413E-02 1.174E-03

5.6E-01 3.295E-04 -1.580E-05 -1.851E-03 0.00 1.041E-03 8.888E-06 424 COMB1
1.13 -1.543E-02 -1.580E-05 -1.851E-03 0.00 -4.046E-03 -1.377E-02 1.462E-02

407 COMB1 0.00 1.466E-03 -8.861E-06 2.5E-01 -4.046E-03 -6.767E-03 1.462E-02 0.00 7.308E-03 -2.216E-03
0.00 2.369E-02 -1.575E-05 2.607E-03 0.00 0.00 0.00 5.0E-01 -4.046E-03 2.391E-04 1.462E-02 0.00 3.654E-03 3.517E-04
7.5E-01 -4.046E-03 7.245E-03 1.462E-02 0.00 0.00 1.168E-03
5.6E-01 7.930E-03 -1.575E-05 2.607E-03 0.00 -1.466E-03 8.861E-06 0.00 -3.654E-03 2.321E-04
1.13 -7.833E-03 -1.575E-05 2.607E-03 1.00 -4.046E-03 1.425E-02 1.462E-02
0.00 -7.308E-03 -2.455E-03

408 COMB1 0.00 5.322E-03 -4.624E-05 425 COMB1 0.00 -6.184E-03 -2.449E-03
0.00 3.225E-02 -8.220E-05 9.461E-03 0.00 0.00 0.00 0.00 -1.106E-02 -1.424E-02 -1.237E-02 0.00 -3.092E-03 2.351E-04
0.00 0.00 1.168E-03
5.6E-01 1.648E-02 -8.220E-05 9.461E-03 0.00 -5.322E-03 4.624E-05 2.5E-01 -1.106E-02 -7.233E-03 -1.237E-02 0.00 3.092E-03 3.487E-04
1.13 7.199E-04 -8.220E-05 9.461E-03 5.0E-01 -1.106E-02 -2.272E-04 -1.237E-02
7.5E-01 -1.106E-02 6.779E-03 -1.237E-02 0.00 6.184E-03 -2.222E-03
409 COMB1
0.00 1.855E-02 -5.043E-05 -8.396E-03 1.00 -1.106E-02 1.378E-02 -1.237E-02

5.6E-01 2.788E-03 -5.043E-05 -8.396E-03 0.00 -4.723E-03 -2.837E-05 426 COMB1 0.00 -1.171E-04 -2.390E-03
1.13 -1.298E-02 -5.043E-05 -8.396E-03 0.00 0.00 0.00 0.00 -1.827E-02 -1.412E-02 -2.343E-04 0.00 -5.857E-05 2.644E-04
0.00 0.00 1.168E-03
0.00 4.723E-03 2.837E-05 2.5E-01 -1.827E-02 -7.116E-03 -2.343E-04 0.00 5.857E-05 3.194E-04
5.0E-01 -1.827E-02 -1.099E-04 -2.343E-04
410 COMB1 0.00 -6.988E-04 -1.439E-05 7.5E-01 -1.827E-02 6.896E-03 -2.343E-04 0.00 1.171E-04 -2.280E-03
0.00 2.065E-02 -2.559E-05 -1.242E-03 0.00 0.00 0.00
1.00 -1.827E-02 1.390E-02 -2.343E-04
5.6E-01 4.887E-03 -2.559E-05 -1.242E-03 0.00 6.988E-04 1.439E-05
1.13 -1.088E-02 -2.559E-05 -1.242E-03

411 COMB1 0.00 1.094E-03 -2.076E-05 427 COMB1 0.00 6.044E-03 -2.348E-03
0.00 2.975E-02 -3.691E-05 1.946E-03 0.00 0.00 0.00 0.00 -1.331E-02 -1.404E-02 1.209E-02 0.00 3.022E-03 2.856E-04
0.00 0.00 1.168E-03
5.6E-01 1.399E-02 -3.691E-05 1.946E-03 0.00 -1.094E-03 2.076E-05 2.5E-01 -1.331E-02 -7.031E-03 1.209E-02 0.00 -3.022E-03 2.982E-04
1.13 -1.772E-03 -3.691E-05 1.946E-03 5.0E-01 -1.331E-02 -2.511E-05 1.209E-02
7.5E-01 -1.331E-02 6.981E-03 1.209E-02 0.00 -6.044E-03 -2.323E-03

1.00 -1.331E-02 1.399E-02 1.209E-02

412 COMB1 0.00 5.163E-03 -4.173E-05 428 COMB1 0.00 -6.044E-03 -2.323E-03
0.00 3.034E-02 -7.418E-05 9.178E-03 0.00 0.00 0.00 0.00 -1.331E-02 -1.399E-02 -1.209E-02 0.00 -3.022E-03 2.982E-04
0.00 0.00 1.168E-03
5.6E-01 1.458E-02 -7.418E-05 9.178E-03 0.00 -5.163E-03 4.173E-05 2.5E-01 -1.331E-02 -6.981E-03 -1.209E-02 0.00 3.022E-03 2.856E-04
1.13 -1.188E-03 -7.418E-05 9.178E-03 5.0E-01 -1.331E-02 2.511E-05 -1.209E-02 0.00 6.044E-03 -2.348E-03
7.5E-01 -1.331E-02 7.031E-03 -1.209E-02
413 COMB1 0.00 -6.185E-03 -2.459E-03 1.0E+00 -1.331E-02 1.404E-02 -1.209E-02
0.00 2.239E-03 -1.426E-02 -1.237E-02 0.00 -3.093E-03 2.302E-04
0.00 0.00 1.168E-03 429 COMB1 0.00 1.171E-04 -2.280E-03
2.5E-01 2.239E-03 -7.253E-03 -1.237E-02 0.00 3.093E-03 3.536E-04 0.00 -1.827E-02 -1.390E-02 2.343E-04 0.00 5.857E-05 3.194E-04
5.0E-01 2.239E-03 -2.469E-04 -1.237E-02 0.00 0.00 1.168E-03
7.5E-01 2.239E-03 6.759E-03 -1.237E-02 0.00 6.185E-03 -2.212E-03 2.5E-01 -1.827E-02 -6.896E-03 2.343E-04 0.00 -5.857E-05 2.644E-04
5.0E-01 -1.827E-02 1.099E-04 2.343E-04
1.00 2.239E-03 1.376E-02 -1.237E-02 7.5E-01 -1.827E-02 7.116E-03 2.343E-04 0.00 -1.171E-04 -2.390E-03

414 COMB1 0.00 -1.544E-04 -2.401E-03 1.00 -1.827E-02 1.412E-02 2.343E-04
0.00 6.119E-03 -1.414E-02 -3.088E-04 0.00 -7.720E-05 2.591E-04
0.00 0.00 1.168E-03 430 COMB1 0.00 6.184E-03 -2.222E-03
2.5E-01 6.119E-03 -7.137E-03 -3.088E-04 0.00 7.720E-05 3.248E-04 0.00 -1.106E-02 -1.378E-02 1.237E-02 0.00 3.092E-03 3.487E-04
5.0E-01 6.119E-03 -1.314E-04 -3.088E-04 0.00 0.00 1.168E-03
7.5E-01 6.119E-03 6.875E-03 -3.088E-04 0.00 1.544E-04 -2.270E-03 2.5E-01 -1.106E-02 -6.779E-03 1.237E-02 0.00 -3.092E-03 2.351E-04
5.0E-01 -1.106E-02 2.272E-04 1.237E-02
1.00 6.119E-03 1.388E-02 -3.088E-04 7.5E-01 -1.106E-02 7.233E-03 1.237E-02 0.00 -6.184E-03 -2.449E-03

415 COMB1 0.00 5.965E-03 -2.356E-03 1.00 -1.106E-02 1.424E-02 1.237E-02
0.00 1.156E-02 -1.405E-02 1.193E-02 0.00 2.982E-03 2.815E-04
0.00 0.00 1.168E-03 436 COMB1 0.00 -4.988E-05 -2.696E-03
2.5E-01 1.156E-02 -7.047E-03 1.193E-02 0.00 -2.982E-03 3.023E-04 0.00 -2.303E-02 -1.138E-02 -7.226E-05 0.00 0.00 1.290E-03
5.0E-01 1.156E-02 -4.149E-05 1.193E-02
7.5E-01 1.156E-02 6.964E-03 1.193E-02 0.00 -5.965E-03 -2.315E-03 6.9E-01 -3.880E-02 -1.694E-04 -7.226E-05 0.00 4.988E-05 -2.462E-03
1.38 -5.456E-02 1.104E-02 -7.226E-05
1.00 1.156E-02 1.397E-02 1.193E-02

416 COMB1 0.00 -5.965E-03 -2.315E-03 437 COMB1 0.00 1.397E-04 -1.313E-03
0.00 1.156E-02 -1.397E-02 -1.193E-02 0.00 -2.982E-03 3.023E-04 0.00 7.851E-02 -5.936E-03 2.340E-04 0.00 0.00 5.577E-04
0.00 0.00 1.168E-03
2.5E-01 1.156E-02 -6.964E-03 -1.193E-02 0.00 2.982E-03 2.815E-04 6.0E-01 6.274E-02 -3.311E-04 2.340E-04 0.00 -1.397E-04 -9.177E-04
5.0E-01 1.156E-02 4.149E-05 -1.193E-02 0.00 5.965E-03 -2.356E-03 1.19 4.698E-02 5.274E-03 2.340E-04
7.5E-01 1.156E-02 7.047E-03 -1.193E-02
1.0E+00 1.156E-02 1.405E-02 -1.193E-02

438 COMB1 0.00 8.774E-05 -9.138E-04 470 COMB1 -1.43 1.796E-03 2.667E-04 0.00 1.592E-04 3.303E-03
0.00 -1.845E-02 -5.267E-03 1.470E-04 0.00 0.00 5.577E-04 0.00 -1.42 7.400E-03 2.667E-04 0.00 0.00 5.577E-04

6.0E-01 -3.421E-02 3.375E-04 1.470E-04 0.00 -8.774E-05 -1.317E-03 6.0E-01 -1.40 1.301E-02 2.667E-04 0.00 -1.592E-04 -5.533E-03
1.19 -4.998E-02 5.942E-03 1.470E-04 1.19

439 COMB1 0.00 -8.923E-05 -2.435E-03 473 COMB1 -2.30 7.109E-04 1.315E-04 0.00 7.852E-05 2.655E-03
0.00 5.939E-02 -1.100E-02 -1.293E-04 0.00 0.00 1.290E-03 0.00 -2.28 6.316E-03 1.315E-04 0.00 0.00 5.577E-04

6.9E-01 4.363E-02 2.087E-04 -1.293E-04 0.00 8.923E-05 -2.723E-03 6.0E-01 -2.27 1.192E-02 1.315E-04 0.00 -7.852E-05 -4.886E-03
1.38 2.787E-02 1.142E-02 -1.293E-04 1.19

440 COMB1 0.00 1.361E-04 -8.906E-04 474 COMB1 2.13 -5.247E-04 0.00 -2.099E-04 8.587E-01
0.00 3.922E-02 -5.228E-03 2.280E-04 0.00 0.00 5.577E-04 0.00 -3.667E-02 2.14 -5.247E-04 0.00 -1.049E-04 4.316E-01
2.16 -5.247E-04 0.00 0.00 1.829E-03
6.0E-01 5.498E-02 3.765E-04 2.280E-04 0.00 -1.361E-04 -1.340E-03 2.0E-01 -3.667E-02 2.17 -5.247E-04 0.00 1.049E-04 -4.307E-01
1.19 7.075E-02 5.981E-03 2.280E-04 4.0E-01 -3.667E-02 2.18 -5.247E-04 0.00 2.099E-04 -8.660E-01
6.0E-01 -3.667E-02
441 COMB1 0.00 2.173E-05 -2.425E-03 8.0E-01 -3.667E-02
0.00 -4.641E-02 -1.099E-02 3.148E-05 0.00 0.00 1.290E-03
475 COMB1
6.9E-01 -3.064E-02 2.235E-04 3.148E-05 0.00 -2.173E-05 -2.733E-03 0.00 -1.119E-02 -1.927E-02 1.781E-03
1.38 -1.488E-02 1.143E-02 3.148E-05
1.0E-01 -1.119E-02 -1.647E-02 1.781E-03
442 COMB1 0.00 -1.722E-05 -2.716E-03 2.0E-01 -1.119E-02 -1.367E-02 1.781E-03 0.00 3.561E-04 -3.107E-03
0.00 2.258E-02 -1.141E-02 -2.495E-05 0.00 0.00 1.290E-03 3.0E-01 -1.119E-02 -1.086E-02 1.781E-03 0.00 1.781E-04 -1.320E-03
4.0E-01 -1.119E-02 -8.062E-03 1.781E-03 0.00 0.00 1.868E-04
6.9E-01 3.835E-02 -1.981E-04 -2.495E-05 0.00 1.722E-05 -2.442E-03 0.00 -1.781E-04 1.413E-03
1.38 5.411E-02 1.101E-02 -2.495E-05 0.00 -3.561E-04 2.360E-03

443 COMB1 0.00 9.657E-05 -1.312E-03 477 COMB1 0.00 8.806E-04 -3.480E-03
0.00 -7.460E-02 -5.934E-03 1.618E-04 0.00 0.00 5.577E-04 0.00 2.566E-01 -2.113E-02 4.403E-03 0.00 4.403E-04 -1.506E-03
0.00 0.00 1.868E-04
6.0E-01 -5.884E-02 -3.290E-04 1.618E-04 0.00 -9.657E-05 -9.190E-04 1.0E-01 2.566E-01 -1.833E-02 4.403E-03 0.00 -4.403E-04 1.600E-03
1.19 -4.308E-02 5.276E-03 1.618E-04 2.0E-01 2.566E-01 -1.553E-02 4.403E-03 0.00 -8.806E-04 2.732E-03
3.0E-01 2.566E-01 -1.273E-02 4.403E-03
444 COMB1 4.0E-01 2.566E-01 -9.925E-03 4.403E-03
0.00 3.105E-02 -1.159E-02 -9.798E-05
0.00 -3.919E-05 -1.647E-03 479 COMB1 0.00 1.381E-03 -4.120E-03
2.0E-01 3.105E-02 -5.985E-03 -9.798E-05 0.00 -1.960E-05 1.108E-04 0.00 2.472E-02 -2.434E-02 6.906E-03 0.00 6.906E-04 -1.826E-03
4.0E-01 3.105E-02 -3.803E-04 -9.798E-05 0.00 0.00 7.473E-04 0.00 0.00 1.868E-04
6.0E-01 3.105E-02 5.224E-03 -9.798E-05 0.00 1.960E-05 2.629E-04 1.0E-01 2.472E-02 -2.153E-02 6.906E-03 0.00 -6.906E-04 1.920E-03
8.0E-01 3.105E-02 1.083E-02 -9.798E-05 0.00 3.919E-05 -1.342E-03 2.0E-01 2.472E-02 -1.873E-02 6.906E-03 0.00 -1.381E-03 3.373E-03
3.0E-01 2.472E-02 -1.593E-02 6.906E-03
445 COMB1 4.0E-01 2.472E-02 -1.313E-02 6.906E-03
0.00 2.962E-02 -9.922E-03 2.026E-03
0.00 4.052E-04 -1.237E-03 481 COMB1 0.00 1.037E-03 -4.275E-03
1.0E-01 2.962E-02 -7.120E-03 2.026E-03 0.00 2.026E-04 -3.850E-04 0.00 2.564E-01 -2.511E-02 5.184E-03 0.00 5.184E-04 -1.904E-03
2.0E-01 2.962E-02 -4.317E-03 2.026E-03 0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
3.0E-01 2.962E-02 -1.515E-03 2.026E-03 0.00 -2.026E-04 4.784E-04 1.0E-01 2.564E-01 -2.231E-02 5.184E-03 0.00 -5.184E-04 1.997E-03
4.0E-01 2.962E-02 1.287E-03 2.026E-03 0.00 -4.052E-04 4.898E-04 2.0E-01 2.564E-01 -1.951E-02 5.184E-03 0.00 -1.037E-03 3.528E-03
3.0E-01 2.564E-01 -1.671E-02 5.184E-03
446 COMB1 4.0E-01 2.564E-01 -1.390E-02 5.184E-03
0.00 -4.022E-03 -1.163E-02 -1.446E-04
0.00 -5.782E-05 -1.661E-03 482 COMB1 2.13 1.537E-03 0.00 6.149E-04 8.583E-01
2.0E-01 -4.022E-03 -6.022E-03 -1.446E-04 0.00 -2.891E-05 1.034E-04 0.00 -6.142E-04 2.14 1.537E-03 0.00 3.075E-04 4.314E-01
4.0E-01 -4.022E-03 -4.172E-04 -1.446E-04 0.00 0.00 7.473E-04 2.15 1.537E-03 0.00 0.00 1.829E-03
6.0E-01 -4.022E-03 5.188E-03 -1.446E-04 0.00 2.891E-05 2.703E-04 2.0E-01 -6.142E-04 2.17 1.537E-03 0.00 -3.075E-04 -4.305E-01
8.0E-01 -4.022E-03 1.079E-02 -1.446E-04 0.00 5.782E-05 -1.328E-03 4.0E-01 -6.142E-04 2.18 1.537E-03 0.00 -6.149E-04 -8.656E-01
6.0E-01 -6.142E-04
447 COMB1 8.0E-01 -6.142E-04
0.00 -5.737E-03 -1.005E-02 5.219E-03
0.00 1.044E-03 -1.263E-03 483 COMB1 0.00 -1.624E-04 -4.475E-03
1.0E-01 -5.737E-03 -7.247E-03 5.219E-03 0.00 5.219E-04 -3.978E-04 0.00 -1.215E-04 -2.611E-02 -8.119E-04 0.00 -8.119E-05 -2.004E-03
2.0E-01 -5.737E-03 -4.445E-03 5.219E-03 0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
3.0E-01 -5.737E-03 -1.642E-03 5.219E-03 0.00 -5.219E-04 4.912E-04 1.0E-01 -1.215E-04 -2.331E-02 -8.119E-04 0.00 8.119E-05 2.098E-03
4.0E-01 -5.737E-03 1.160E-03 5.219E-03 0.00 -1.044E-03 5.153E-04 2.0E-01 -1.215E-04 -2.051E-02 -8.119E-04 0.00 1.624E-04 3.728E-03
3.0E-01 -1.215E-04 -1.771E-02 -8.119E-04
448 COMB1 4.0E-01 -1.215E-04 -1.490E-02 -8.119E-04
0.00 -1.670E-03 -1.168E-02 -2.336E-04
0.00 -9.342E-05 -1.683E-03 497 COMB1 1.17 -4.368E-03 1.178E-04 0.00 7.033E-05 -3.771E-04
2.0E-01 -1.670E-03 -6.075E-03 -2.336E-04 0.00 -4.671E-05 9.272E-05 0.00 1.15 1.237E-03 1.178E-04 0.00 0.00 5.577E-04
4.0E-01 -1.670E-03 -4.705E-04 -2.336E-04 0.00 0.00 7.473E-04
6.0E-01 -1.670E-03 5.134E-03 -2.336E-04 0.00 4.671E-05 2.809E-04 6.0E-01 1.14 6.841E-03 1.178E-04 0.00 -7.033E-05 -1.854E-03
8.0E-01 -1.670E-03 1.074E-02 -2.336E-04 0.00 9.342E-05 -1.306E-03 1.19

449 COMB1 0.00 1.350E-03 -1.259E-03 498 COMB1 0.00 1.794E-04 4.995E-04
0.00 -5.104E-03 -1.003E-02 6.749E-03 0.00 6.749E-04 -3.957E-04 0.00 -5.999E-01 -2.900E-03 3.005E-04 0.00 0.00 5.577E-04
0.00 0.00 1.868E-04
1.0E-01 -5.104E-03 -7.227E-03 6.749E-03 0.00 -6.749E-04 4.892E-04 6.0E-01 -6.157E-01 2.705E-03 3.005E-04 0.00 -1.794E-04 -2.730E-03
2.0E-01 -5.104E-03 -4.425E-03 6.749E-03 0.00 -1.350E-03 5.113E-04 1.19 -6.314E-01 8.310E-03 3.005E-04
3.0E-01 -5.104E-03 -1.622E-03 6.749E-03
4.0E-01 -5.104E-03 1.180E-03 6.749E-03 500 COMB1
0.00 -8.392E-01 2.319E-03 3.825E-04
450 COMB1 0.00 -5.817E-05 -1.700E-03 0.00 2.284E-04 3.615E-03
0.00 -1.323E-03 -1.172E-02 -1.454E-04 0.00 -2.908E-05 8.406E-05 6.0E-01 -8.234E-01 7.924E-03 3.825E-04 0.00 0.00 5.577E-04
0.00 0.00 7.473E-04 1.19 -8.076E-01 1.353E-02 3.825E-04
2.0E-01 -1.323E-03 -6.119E-03 -1.454E-04 0.00 2.908E-05 2.896E-04 0.00 -2.284E-04 -5.846E-03
4.0E-01 -1.323E-03 -5.138E-04 -1.454E-04 0.00 5.817E-05 -1.289E-03
6.0E-01 -1.323E-03 5.091E-03 -1.454E-04 503 COMB1 -2.61 7.748E-04 7.805E-05 0.00 4.659E-05 2.693E-03
8.0E-01 -1.323E-03 1.070E-02 -1.454E-04 0.00 -2.59 6.380E-03 7.805E-05 0.00 0.00 5.577E-04

6.0E-01 -2.58 1.198E-02 7.805E-05 0.00 -4.659E-05 -4.924E-03
1.19

451 COMB1 0.00 9.392E-04 -1.274E-03 504 COMB1 2.22 -3.555E-04 0.00 -1.422E-04 8.947E-01
0.00 -1.106E-03 -1.011E-02 4.696E-03 0.00 4.696E-04 -4.034E-04 0.00 -4.651E-02 2.23 -3.555E-04 0.00 -7.110E-05 4.496E-01
0.00 0.00 1.868E-04 2.25 -3.555E-04 0.00 0.00 1.829E-03
1.0E-01 -1.106E-03 -7.304E-03 4.696E-03 0.00 -4.696E-04 4.969E-04 2.0E-01 -4.651E-02 2.26 -3.555E-04 0.00 7.110E-05 -4.487E-01
2.0E-01 -1.106E-03 -4.501E-03 4.696E-03 0.00 -9.392E-04 5.266E-04 4.0E-01 -4.651E-02 2.27 -3.555E-04 0.00 1.422E-04 -9.020E-01
3.0E-01 -1.106E-03 -1.699E-03 4.696E-03 6.0E-01 -4.651E-02
4.0E-01 -1.106E-03 1.103E-03 4.696E-03 8.0E-01 -4.651E-02

452 COMB1 0.00 7.670E-05 -1.703E-03 505 COMB1 0.00 2.064E-04 -4.686E-03
0.00 -2.477E-02 -1.173E-02 1.918E-04 0.00 3.835E-05 8.257E-05 0.00 -1.316E-02 -2.717E-02 1.032E-03 0.00 1.032E-04 -2.110E-03
0.00 0.00 7.473E-04 0.00 0.00 1.868E-04
2.0E-01 -2.477E-02 -6.126E-03 1.918E-04 0.00 -3.835E-05 2.911E-04 1.0E-01 -1.316E-02 -2.437E-02 1.032E-03 0.00 -1.032E-04 2.203E-03
4.0E-01 -2.477E-02 -5.213E-04 1.918E-04 0.00 -7.670E-05 -1.286E-03 2.0E-01 -1.316E-02 -2.156E-02 1.032E-03 0.00 -2.064E-04 3.939E-03
6.0E-01 -2.477E-02 5.083E-03 1.918E-04 3.0E-01 -1.316E-02 -1.876E-02 1.032E-03
8.0E-01 -2.477E-02 1.069E-02 1.918E-04 4.0E-01 -1.316E-02 -1.596E-02 1.032E-03

453 COMB1 0.00 -1.499E-04 -1.227E-03 507 COMB1 0.00 5.300E-04 -5.246E-03
0.00 -2.553E-02 -9.871E-03 -7.495E-04 0.00 -7.495E-05 -3.799E-04 0.00 2.465E-01 -2.997E-02 2.650E-03 0.00 2.650E-04 -2.389E-03
0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
1.0E-01 -2.553E-02 -7.068E-03 -7.495E-04 0.00 7.495E-05 4.733E-04 1.0E-01 2.465E-01 -2.716E-02 2.650E-03 0.00 -2.650E-04 2.483E-03
2.0E-01 -2.553E-02 -4.266E-03 -7.495E-04 0.00 1.499E-04 4.795E-04 2.0E-01 2.465E-01 -2.436E-02 2.650E-03 0.00 -5.300E-04 4.499E-03
3.0E-01 -2.553E-02 -1.463E-03 -7.495E-04 3.0E-01 2.465E-01 -2.156E-02 2.650E-03
4.0E-01 -2.553E-02 1.339E-03 -7.495E-04 4.0E-01 2.465E-01 -1.876E-02 2.650E-03

467 COMB1 0.00 1.165E-04 -5.928E-04 509 COMB1 0.00 8.636E-04 -6.629E-03
0.00 7.791E-01 -4.729E-03 1.952E-04 0.00 0.00 5.577E-04 0.00 7.222E-02 -3.688E-02 4.318E-03 0.00 4.318E-04 -3.081E-03
0.00 0.00 1.868E-04
6.0E-01 7.633E-01 8.753E-04 1.952E-04 0.00 -1.165E-04 -1.638E-03 1.0E-01 7.222E-02 -3.408E-02 4.318E-03 0.00 -4.318E-04 3.174E-03
1.19 7.476E-01 6.480E-03 1.952E-04 2.0E-01 7.222E-02 -3.128E-02 4.318E-03 0.00 -8.636E-04 5.882E-03
3.0E-01 7.222E-02 -2.848E-02 4.318E-03
468 COMB1 0.00 1.037E-04 1.276E-05 4.0E-01 7.222E-02 -2.567E-02 4.318E-03
0.00 -8.473E-02 -3.715E-03 1.737E-04 0.00 0.00 5.577E-04
511 COMB1
6.0E-01 -1.005E-01 1.890E-03 1.737E-04 0.00 -1.037E-04 -2.243E-03
1.19 -1.163E-01 7.494E-03 1.737E-04

0.00 2.462E-01 -4.745E-02 7.950E-03 0.00 1.590E-03 -8.742E-03 564 COMB1 2.22 3.555E-04 0.00 1.422E-04 8.947E-01
1.0E-01 2.462E-01 -4.465E-02 7.950E-03 0.00 7.950E-04 -4.138E-03 0.00 -4.651E-02 2.23 3.555E-04 0.00 7.110E-05 4.496E-01
2.0E-01 2.462E-01 -4.184E-02 7.950E-03 0.00 0.00 1.868E-04 2.25 3.555E-04 0.00 0.00 1.829E-03
3.0E-01 2.462E-01 -3.904E-02 7.950E-03 0.00 -7.950E-04 4.231E-03 2.0E-01 -4.651E-02 2.26 3.555E-04 0.00 -7.110E-05 -4.487E-01
4.0E-01 2.462E-01 -3.624E-02 7.950E-03 0.00 -1.590E-03 7.995E-03 4.0E-01 -4.651E-02 2.27 3.555E-04 0.00 -1.422E-04 -9.020E-01
6.0E-01 -4.651E-02
8.0E-01 -4.651E-02

512 COMB1 2.21 2.809E-03 0.00 1.124E-03 8.924E-01 565 COMB1 0.00 -2.064E-04 -4.686E-03
0.00 6.034E-02 2.23 2.809E-03 0.00 5.618E-04 4.485E-01 0.00 -1.316E-02 -2.717E-02 -1.032E-03 0.00 -1.032E-04 -2.110E-03
2.24 2.809E-03 0.00 0.00 1.829E-03 0.00 0.00 1.868E-04
2.0E-01 6.034E-02 2.25 2.809E-03 0.00 -5.618E-04 -4.476E-01 1.0E-01 -1.316E-02 -2.437E-02 -1.032E-03 0.00 1.032E-04 2.203E-03
4.0E-01 6.034E-02 2.27 2.809E-03 0.00 -1.124E-03 -8.997E-01 2.0E-01 -1.316E-02 -2.156E-02 -1.032E-03 0.00 2.064E-04 3.939E-03
6.0E-01 6.034E-02 3.0E-01 -1.316E-02 -1.876E-02 -1.032E-03
8.0E-01 6.034E-02 4.0E-01 -1.316E-02 -1.596E-02 -1.032E-03

513 COMB1 0.00 -2.906E-04 -7.972E-03 567 COMB1 0.00 -5.300E-04 -5.246E-03
0.00 1.087E-02 -4.360E-02 -1.453E-03 0.00 -1.453E-04 -3.752E-03 0.00 2.465E-01 -2.997E-02 -2.650E-03 0.00 -2.650E-04 -2.389E-03
0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
1.0E-01 1.087E-02 -4.079E-02 -1.453E-03 0.00 1.453E-04 3.846E-03 1.0E-01 2.465E-01 -2.716E-02 -2.650E-03 0.00 2.650E-04 2.483E-03
2.0E-01 1.087E-02 -3.799E-02 -1.453E-03 0.00 2.906E-04 7.225E-03 2.0E-01 2.465E-01 -2.436E-02 -2.650E-03 0.00 5.300E-04 4.499E-03
3.0E-01 1.087E-02 -3.519E-02 -1.453E-03 3.0E-01 2.465E-01 -2.156E-02 -2.650E-03
4.0E-01 1.087E-02 -3.239E-02 -1.453E-03 4.0E-01 2.465E-01 -1.876E-02 -2.650E-03

527 COMB1 0.00 0.00 0.00 -1.292E-03 569 COMB1 0.00 -8.636E-04 -6.629E-03
0.00 8.686E-01 -5.901E-03 0.00 0.00 0.00 5.577E-04 0.00 7.222E-02 -3.688E-02 -4.318E-03 0.00 -4.318E-04 -3.081E-03
0.00 0.00 1.868E-04
6.0E-01 8.528E-01 -2.967E-04 0.00 0.00 0.00 -9.382E-04 1.0E-01 7.222E-02 -3.408E-02 -4.318E-03 0.00 4.318E-04 3.174E-03
1.19 8.371E-01 5.308E-03 2.0E-01 7.222E-02 -3.128E-02 -4.318E-03 0.00 8.636E-04 5.882E-03
3.0E-01 7.222E-02 -2.848E-02 -4.318E-03
528 COMB1 -1.39 -4.111E-03 0.00 0.00 0.00 -2.238E-04 4.0E-01 7.222E-02 -2.567E-02 -4.318E-03
0.00 -1.41 1.493E-03 0.00 0.00 0.00 5.577E-04
571 COMB1
6.0E-01 -1.42 7.098E-03 0.00 0.00 0.00 -2.007E-03 0.00 2.462E-01 -4.745E-02 -7.950E-03
1.19
1.0E-01 2.462E-01 -4.465E-02 -7.950E-03
530 COMB1 1.42 -4.153E-03 0.00 0.00 0.00 -2.487E-04 2.0E-01 2.462E-01 -4.184E-02 -7.950E-03 0.00 -1.590E-03 -8.742E-03
0.00 1.43 1.452E-03 0.00 0.00 0.00 5.577E-04 3.0E-01 2.462E-01 -3.904E-02 -7.950E-03 0.00 -7.950E-04 -4.138E-03
4.0E-01 2.462E-01 -3.624E-02 -7.950E-03 0.00 0.00 1.868E-04
6.0E-01 1.45 7.056E-03 0.00 0.00 0.00 -1.982E-03 0.00 7.950E-04 4.231E-03
1.19 0.00 1.590E-03 7.995E-03

533 COMB1 0.00 0.00 0.00 -1.301E-03 572 COMB1 2.21 -2.809E-03 0.00 -1.124E-03 8.924E-01
0.00 -8.759E-01 -5.916E-03 0.00 0.00 0.00 5.577E-04 0.00 6.034E-02 2.23 -2.809E-03 0.00 -5.618E-04 4.485E-01
2.24 -2.809E-03 0.00 0.00 1.829E-03
6.0E-01 -8.601E-01 -3.116E-04 0.00 0.00 0.00 -9.293E-04 2.0E-01 6.034E-02 2.25 -2.809E-03 0.00 5.618E-04 -4.476E-01
1.19 -8.444E-01 5.293E-03 4.0E-01 6.034E-02 2.27 -2.809E-03 0.00 1.124E-03 -8.997E-01
6.0E-01 6.034E-02
534 COMB1 8.0E-01 6.034E-02
0.00 -7.197E-02
2.62 0.00 0.00 0.00 1.06 573 COMB1 0.00 2.906E-04 -7.972E-03
2.0E-01 -7.197E-02 2.64 0.00 0.00 0.00 5.307E-01 0.00 1.087E-02 -4.360E-02 1.453E-03 0.00 1.453E-04 -3.752E-03
4.0E-01 -7.197E-02 2.65 0.00 0.00 0.00 2.124E-03 0.00 0.00 1.868E-04
6.0E-01 -7.197E-02 2.67 0.00 0.00 0.00 -5.297E-01 1.0E-01 1.087E-02 -4.079E-02 1.453E-03 0.00 -1.453E-04 3.846E-03
8.0E-01 -7.197E-02 2.68 0.00 0.00 0.00 -1.06 2.0E-01 1.087E-02 -3.799E-02 1.453E-03 0.00 -2.906E-04 7.225E-03
3.0E-01 1.087E-02 -3.519E-02 1.453E-03
535 COMB1 4.0E-01 1.087E-02 -3.239E-02 1.453E-03
0.00 -2.329E-02 -3.073E-02
0.00 0.00 0.00 -5.398E-03 587 COMB1 0.00 -1.165E-04 -5.928E-04
1.0E-01 -2.329E-02 -2.792E-02 0.00 0.00 0.00 -2.465E-03 0.00 7.791E-01 -4.729E-03 -1.952E-04 0.00 0.00 5.577E-04
2.0E-01 -2.329E-02 -2.512E-02 0.00 0.00 0.00 1.868E-04
3.0E-01 -2.329E-02 -2.232E-02 0.00 0.00 0.00 2.559E-03 6.0E-01 7.633E-01 8.753E-04 -1.952E-04 0.00 1.165E-04 -1.638E-03
4.0E-01 -2.329E-02 -1.952E-02 0.00 0.00 0.00 4.650E-03 1.19 7.476E-01 6.480E-03 -1.952E-04

537 COMB1 0.00 0.00 0.00 -6.053E-03 588 COMB1 0.00 -1.037E-04 1.276E-05
0.00 2.994E-01 -3.400E-02 0.00 0.00 0.00 -2.793E-03 0.00 -8.473E-02 -3.715E-03 -1.737E-04 0.00 0.00 5.577E-04
0.00 0.00 0.00 1.868E-04
1.0E-01 2.994E-01 -3.120E-02 0.00 0.00 0.00 2.886E-03 6.0E-01 -1.005E-01 1.890E-03 -1.737E-04 0.00 1.037E-04 -2.243E-03
2.0E-01 2.994E-01 -2.840E-02 0.00 0.00 0.00 5.306E-03 1.19 -1.163E-01 7.494E-03 -1.737E-04
3.0E-01 2.994E-01 -2.559E-02
4.0E-01 2.994E-01 -2.279E-02 590 COMB1
0.00
539 COMB1 0.00 0.00 0.00 -7.767E-03 -1.43 1.796E-03 -2.667E-04 0.00 -1.592E-04 3.303E-03
0.00 5.026E-01 -4.257E-02 0.00 0.00 0.00 -3.650E-03 6.0E-01 -1.42 7.400E-03 -2.667E-04 0.00 0.00 5.577E-04
0.00 0.00 0.00 1.868E-04 1.19
1.0E-01 5.026E-01 -3.977E-02 0.00 0.00 0.00 3.743E-03 -1.40 1.301E-02 -2.667E-04 0.00 1.592E-04 -5.533E-03
2.0E-01 5.026E-01 -3.697E-02 0.00 0.00 0.00 7.020E-03
3.0E-01 5.026E-01 -3.416E-02 593 COMB1 -2.30 7.109E-04 -1.315E-04 0.00 -7.852E-05 2.655E-03
4.0E-01 5.026E-01 -3.136E-02 0.00 -2.28 6.316E-03 -1.315E-04 0.00 0.00 5.577E-04

6.0E-01 -2.27 1.192E-02 -1.315E-04 0.00 7.852E-05 -4.886E-03
1.19

541 COMB1 0.00 0.00 0.00 -1.144E-02 594 COMB1 2.13 5.247E-04 0.00 2.099E-04 8.587E-01
0.00 2.997E-01 -6.096E-02 0.00 0.00 0.00 -5.489E-03 0.00 -3.667E-02 2.14 5.247E-04 0.00 1.049E-04 4.316E-01
0.00 0.00 0.00 1.868E-04 2.16 5.247E-04 0.00 0.00 1.829E-03
1.0E-01 2.997E-01 -5.816E-02 0.00 0.00 0.00 5.582E-03 2.0E-01 -3.667E-02 2.17 5.247E-04 0.00 -1.049E-04 -4.307E-01
2.0E-01 2.997E-01 -5.536E-02 0.00 0.00 0.00 1.070E-02 4.0E-01 -3.667E-02 2.18 5.247E-04 0.00 -2.099E-04 -8.660E-01
3.0E-01 2.997E-01 -5.255E-02 6.0E-01 -3.667E-02
4.0E-01 2.997E-01 -4.975E-02 8.0E-01 -3.667E-02

542 COMB1 2.63 0.00 0.00 0.00 1.06 595 COMB1 0.00 -3.561E-04 -3.107E-03
0.00 5.275E-03 2.65 0.00 0.00 0.00 5.333E-01 0.00 -1.119E-02 -1.927E-02 -1.781E-03 0.00 -1.781E-04 -1.320E-03
2.66 0.00 0.00 0.00 2.124E-03 0.00 0.00 1.868E-04
2.0E-01 5.275E-03 2.68 0.00 0.00 0.00 -5.322E-01 1.0E-01 -1.119E-02 -1.647E-02 -1.781E-03 0.00 1.781E-04 1.413E-03
4.0E-01 5.275E-03 2.70 0.00 0.00 0.00 -1.07 2.0E-01 -1.119E-02 -1.367E-02 -1.781E-03 0.00 3.561E-04 2.360E-03
6.0E-01 5.275E-03 3.0E-01 -1.119E-02 -1.086E-02 -1.781E-03
8.0E-01 5.275E-03 4.0E-01 -1.119E-02 -8.062E-03 -1.781E-03

543 COMB1 0.00 0.00 0.00 -2.175E-02 597 COMB1 0.00 -8.806E-04 -3.480E-03
0.00 7.570E-02 -1.125E-01 0.00 0.00 0.00 -1.064E-02 0.00 2.566E-01 -2.113E-02 -4.403E-03 0.00 -4.403E-04 -1.506E-03
0.00 0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
1.0E-01 7.570E-02 -1.097E-01 0.00 0.00 0.00 1.073E-02 1.0E-01 2.566E-01 -1.833E-02 -4.403E-03 0.00 4.403E-04 1.600E-03
2.0E-01 7.570E-02 -1.069E-01 0.00 0.00 0.00 2.100E-02 2.0E-01 2.566E-01 -1.553E-02 -4.403E-03 0.00 8.806E-04 2.732E-03
3.0E-01 7.570E-02 -1.041E-01 3.0E-01 2.566E-01 -1.273E-02 -4.403E-03
4.0E-01 7.570E-02 -1.013E-01 4.0E-01 2.566E-01 -9.925E-03 -4.403E-03

557 COMB1 1.17 -4.368E-03 -1.178E-04 0.00 -7.033E-05 -3.771E-04 599 COMB1 0.00 -1.381E-03 -4.120E-03
0.00 1.15 1.237E-03 -1.178E-04 0.00 0.00 5.577E-04 0.00 2.472E-02 -2.434E-02 -6.906E-03 0.00 -6.906E-04 -1.826E-03
0.00 0.00 1.868E-04
6.0E-01 1.14 6.841E-03 -1.178E-04 0.00 7.033E-05 -1.854E-03 1.0E-01 2.472E-02 -2.153E-02 -6.906E-03 0.00 6.906E-04 1.920E-03
1.19 2.0E-01 2.472E-02 -1.873E-02 -6.906E-03 0.00 1.381E-03 3.373E-03
3.0E-01 2.472E-02 -1.593E-02 -6.906E-03
558 COMB1 0.00 -1.794E-04 4.995E-04 4.0E-01 2.472E-02 -1.313E-02 -6.906E-03
0.00 -5.999E-01 -2.900E-03 -3.005E-04 0.00 0.00 5.577E-04
601 COMB1
6.0E-01 -6.157E-01 2.705E-03 -3.005E-04 0.00 1.794E-04 -2.730E-03 0.00 2.564E-01 -2.511E-02 -5.184E-03
1.19 -6.314E-01 8.310E-03 -3.005E-04
1.0E-01 2.564E-01 -2.231E-02 -5.184E-03
560 COMB1 0.00 -2.284E-04 3.615E-03 2.0E-01 2.564E-01 -1.951E-02 -5.184E-03 0.00 -1.037E-03 -4.275E-03
0.00 -8.392E-01 2.319E-03 -3.825E-04 0.00 0.00 5.577E-04 3.0E-01 2.564E-01 -1.671E-02 -5.184E-03 0.00 -5.184E-04 -1.904E-03
4.0E-01 2.564E-01 -1.390E-02 -5.184E-03 0.00 0.00 1.868E-04
6.0E-01 -8.234E-01 7.924E-03 -3.825E-04 0.00 2.284E-04 -5.846E-03 0.00 5.184E-04 1.997E-03
1.19 -8.076E-01 1.353E-02 -3.825E-04 0.00 1.037E-03 3.528E-03

563 COMB1 -2.61 7.748E-04 -7.805E-05 0.00 -4.659E-05 2.693E-03 602 COMB1 2.13 -1.537E-03 0.00 -6.149E-04 8.583E-01
0.00 -2.59 6.380E-03 -7.805E-05 0.00 0.00 5.577E-04 0.00 -6.142E-04 2.14 -1.537E-03 0.00 -3.075E-04 4.314E-01
2.15 -1.537E-03 0.00 0.00 1.829E-03
6.0E-01 -2.58 1.198E-02 -7.805E-05 0.00 4.659E-05 -4.924E-03 2.0E-01 -6.142E-04 2.17 -1.537E-03 0.00 3.075E-04 -4.305E-01
1.19 4.0E-01 -6.142E-04
6.0E-01 -6.142E-04

8.0E-01 -6.142E-04 2.18 -1.537E-03 0.00 6.149E-04 -8.656E-01 6.0E-01 -2.477E-02 5.083E-03 -1.918E-04 0.00 3.835E-05 2.911E-04
8.0E-01 -2.477E-02 1.069E-02 -1.918E-04 0.00 7.670E-05 -1.286E-03

603 COMB1 0.00 1.624E-04 -4.475E-03 633 COMB1 0.00 1.499E-04 -1.227E-03
0.00 -1.215E-04 -2.611E-02 8.119E-04 0.00 8.119E-05 -2.004E-03 0.00 -2.553E-02 -9.871E-03 7.495E-04 0.00 7.495E-05 -3.799E-04
0.00 0.00 1.868E-04 0.00 0.00 1.868E-04
1.0E-01 -1.215E-04 -2.331E-02 8.119E-04 0.00 -8.119E-05 2.098E-03 1.0E-01 -2.553E-02 -7.068E-03 7.495E-04 0.00 -7.495E-05 4.733E-04
2.0E-01 -1.215E-04 -2.051E-02 8.119E-04 0.00 -1.624E-04 3.728E-03 2.0E-01 -2.553E-02 -4.266E-03 7.495E-04 0.00 -1.499E-04 4.795E-04
3.0E-01 -1.215E-04 -1.771E-02 8.119E-04 3.0E-01 -2.553E-02 -1.463E-03 7.495E-04
4.0E-01 -1.215E-04 -1.490E-02 8.119E-04 4.0E-01 -2.553E-02 1.339E-03 7.495E-04

616 COMB1 0.00 4.988E-05 -2.696E-03 640 COMB1 0.00 -1.101E-05 -3.769E-03
0.00 -2.303E-02 -1.138E-02 7.226E-05 0.00 0.00 1.290E-03 0.00 -2.280E-03 -1.785E-02 -1.720E-05 0.00 -5.507E-06 5.090E-04
0.00 0.00 1.915E-03
6.9E-01 -3.880E-02 -1.694E-04 7.226E-05 0.00 -4.988E-05 -2.462E-03 3.2E-01 -2.280E-03 -8.877E-03 -1.720E-05 0.00 5.507E-06 4.485E-04
1.38 -5.456E-02 1.104E-02 7.226E-05 6.4E-01 -2.280E-03 9.459E-05 -1.720E-05
9.6E-01 -2.280E-03 9.067E-03 -1.720E-05 0.00 1.101E-05 -3.890E-03
617 COMB1 0.00 -1.397E-04 -1.313E-03
0.00 7.851E-02 -5.936E-03 -2.340E-04 0.00 0.00 5.577E-04 1.28 -2.280E-03 1.804E-02 -1.720E-05

6.0E-01 6.274E-02 -3.311E-04 -2.340E-04 0.00 1.397E-04 -9.177E-04 641 COMB1
1.19 4.698E-02 5.274E-03 -2.340E-04 0.00 7.126E-02 -1.594E-02 6.150E-05

618 COMB1 0.00 -8.774E-05 -9.138E-04 2.7E-01 7.126E-02 -8.390E-03 6.150E-05 0.00 3.312E-05 -3.164E-03
0.00 -1.845E-02 -5.267E-03 -1.470E-04 0.00 0.00 5.577E-04 5.4E-01 7.126E-02 -8.445E-04 6.150E-05 0.00 1.656E-05 1.112E-04
8.1E-01 7.126E-02 6.701E-03 6.150E-05 0.00 0.00 1.354E-03
6.0E-01 -3.421E-02 3.375E-04 -1.470E-04 0.00 8.774E-05 -1.317E-03 0.00 -1.656E-05 5.660E-04
1.19 -4.998E-02 5.942E-03 -1.470E-04 1.08 7.126E-02 1.425E-02 6.150E-05
0.00 -3.312E-05 -2.254E-03

619 COMB1 0.00 8.923E-05 -2.435E-03 642 COMB1 0.00 -1.143E-05 -2.008E-03
0.00 5.939E-02 -1.100E-02 1.293E-04 0.00 0.00 1.290E-03 0.00 3.108E-02 -1.379E-02 -2.123E-05 0.00 -5.717E-06 6.889E-04
0.00 0.00 1.354E-03
6.9E-01 4.363E-02 2.087E-04 1.293E-04 0.00 -8.923E-05 -2.723E-03 2.7E-01 3.108E-02 -6.245E-03 -2.123E-05 0.00 5.717E-06 -1.164E-05
1.38 2.787E-02 1.142E-02 1.293E-04 5.4E-01 3.108E-02 1.301E-03 -2.123E-05
8.1E-01 3.108E-02 8.846E-03 -2.123E-05 0.00 1.143E-05 -3.409E-03
620 COMB1
0.00 3.922E-02 -5.228E-03 -2.280E-04 1.08 3.108E-02 1.639E-02 -2.123E-05

6.0E-01 5.498E-02 3.765E-04 -2.280E-04 0.00 -1.361E-04 -8.906E-04 643 COMB1 0.00 -2.860E-05 -5.947E-02
1.19 7.075E-02 5.981E-03 -2.280E-04 0.00 0.00 5.577E-04 0.00 2.655E-02 -1.048E-01 -4.467E-05 0.00 -1.430E-05 -2.734E-02
0.00 0.00 1.915E-03
0.00 1.361E-04 -1.340E-03 3.2E-01 2.655E-02 -9.587E-02 -4.467E-05 0.00 1.430E-05 2.830E-02
6.4E-01 2.655E-02 -8.690E-02 -4.467E-05
621 COMB1 0.00 -2.173E-05 -2.425E-03 9.6E-01 2.655E-02 -7.793E-02 -4.467E-05 0.00 2.860E-05 5.182E-02
0.00 -4.641E-02 -1.099E-02 -3.148E-05 0.00 0.00 1.290E-03
1.28 2.655E-02 -6.896E-02 -4.467E-05
6.9E-01 -3.064E-02 2.235E-04 -3.148E-05 0.00 2.173E-05 -2.733E-03
1.38 -1.488E-02 1.143E-02 -3.148E-05

622 COMB1 0.00 1.722E-05 -2.716E-03 644 COMB1 0.00 2.635E-05 5.164E-02
0.00 2.258E-02 -1.141E-02 2.495E-05 0.00 0.00 1.290E-03 0.00 3.482E-02 6.869E-02 4.115E-05 0.00 1.317E-05 2.821E-02
0.00 0.00 1.915E-03
6.9E-01 3.835E-02 -1.981E-04 2.495E-05 0.00 -1.722E-05 -2.442E-03 3.2E-01 3.482E-02 7.766E-02 4.115E-05 0.00 -1.317E-05 -2.726E-02
1.38 5.411E-02 1.101E-02 2.495E-05 6.4E-01 3.482E-02 8.663E-02 4.115E-05
9.6E-01 3.482E-02 9.560E-02 4.115E-05 0.00 -2.635E-05 -5.930E-02

1.28 3.482E-02 1.046E-01 4.115E-05

623 COMB1 0.00 -9.657E-05 -1.312E-03 645 COMB1 0.00 -3.449E-05 -3.004E-03
0.00 -7.460E-02 -5.934E-03 -1.618E-04 0.00 0.00 5.577E-04 0.00 -4.561E-02 -1.564E-02 -6.405E-05 0.00 -1.725E-05 1.913E-04
0.00 0.00 1.354E-03
6.0E-01 -5.884E-02 -3.290E-04 -1.618E-04 0.00 9.657E-05 -9.190E-04 2.7E-01 -4.561E-02 -8.093E-03 -6.405E-05 0.00 1.725E-05 4.860E-04
1.19 -4.308E-02 5.276E-03 -1.618E-04 5.4E-01 -4.561E-02 -5.473E-04 -6.405E-05
8.1E-01 -4.561E-02 6.998E-03 -6.405E-05 0.00 3.449E-05 -2.414E-03
624 COMB1 0.00 3.919E-05 -1.647E-03
0.00 3.105E-02 -1.159E-02 9.798E-05 0.00 1.960E-05 1.108E-04 1.08 -4.561E-02 1.454E-02 -6.405E-05
0.00 0.00 7.473E-04
2.0E-01 3.105E-02 -5.985E-03 9.798E-05 0.00 -1.960E-05 2.629E-04 646 COMB1 0.00 1.101E-05 -3.769E-03
4.0E-01 3.105E-02 -3.803E-04 9.798E-05 0.00 -3.919E-05 -1.342E-03 0.00 -2.280E-03 -1.785E-02 1.720E-05 0.00 5.507E-06 5.090E-04
6.0E-01 3.105E-02 5.224E-03 9.798E-05 0.00 0.00 1.915E-03
8.0E-01 3.105E-02 1.083E-02 9.798E-05 3.2E-01 -2.280E-03 -8.877E-03 1.720E-05 0.00 -5.507E-06 4.485E-04
6.4E-01 -2.280E-03 9.459E-05 1.720E-05
625 COMB1 0.00 -4.052E-04 -1.237E-03 9.6E-01 -2.280E-03 9.067E-03 1.720E-05 0.00 -1.101E-05 -3.890E-03
0.00 2.962E-02 -9.922E-03 -2.026E-03 0.00 -2.026E-04 -3.850E-04
0.00 0.00 1.868E-04 1.28 -2.280E-03 1.804E-02 1.720E-05
1.0E-01 2.962E-02 -7.120E-03 -2.026E-03 0.00 2.026E-04 4.784E-04
2.0E-01 2.962E-02 -4.317E-03 -2.026E-03 0.00 4.052E-04 4.898E-04 647 COMB1 0.00 -3.312E-05 -3.164E-03
3.0E-01 2.962E-02 -1.515E-03 -2.026E-03 0.00 7.126E-02 -1.594E-02 -6.150E-05 0.00 -1.656E-05 1.112E-04
4.0E-01 2.962E-02 1.287E-03 -2.026E-03 0.00 0.00 1.354E-03
2.7E-01 7.126E-02 -8.390E-03 -6.150E-05 0.00 1.656E-05 5.660E-04
626 COMB1 0.00 5.782E-05 -1.661E-03 5.4E-01 7.126E-02 -8.445E-04 -6.150E-05
0.00 -4.022E-03 -1.163E-02 1.446E-04 0.00 2.891E-05 1.034E-04 8.1E-01 7.126E-02 6.701E-03 -6.150E-05 0.00 3.312E-05 -2.254E-03
0.00 0.00 7.473E-04
2.0E-01 -4.022E-03 -6.022E-03 1.446E-04 0.00 -2.891E-05 2.703E-04 1.08 7.126E-02 1.425E-02 -6.150E-05
4.0E-01 -4.022E-03 -4.172E-04 1.446E-04 0.00 -5.782E-05 -1.328E-03
6.0E-01 -4.022E-03 5.188E-03 1.446E-04 648 COMB1 0.00 1.143E-05 -2.008E-03
8.0E-01 -4.022E-03 1.079E-02 1.446E-04 0.00 3.108E-02 -1.379E-02 2.123E-05 0.00 5.717E-06 6.889E-04
0.00 0.00 1.354E-03
627 COMB1 0.00 -1.044E-03 -1.263E-03 2.7E-01 3.108E-02 -6.245E-03 2.123E-05 0.00 -5.717E-06 -1.164E-05
0.00 -5.737E-03 -1.005E-02 -5.219E-03 0.00 -5.219E-04 -3.978E-04 5.4E-01 3.108E-02 1.301E-03 2.123E-05
0.00 0.00 1.868E-04 8.1E-01 3.108E-02 8.846E-03 2.123E-05 0.00 -1.143E-05 -3.409E-03
1.0E-01 -5.737E-03 -7.247E-03 -5.219E-03 0.00 5.219E-04 4.912E-04
2.0E-01 -5.737E-03 -4.445E-03 -5.219E-03 0.00 1.044E-03 5.153E-04 1.08 3.108E-02 1.639E-02 2.123E-05
3.0E-01 -5.737E-03 -1.642E-03 -5.219E-03
4.0E-01 -5.737E-03 1.160E-03 -5.219E-03 649 COMB1 0.00 2.860E-05 -5.947E-02
0.00 2.655E-02 -1.048E-01 4.467E-05 0.00 1.430E-05 -2.734E-02
628 COMB1 0.00 9.342E-05 -1.683E-03 0.00 0.00 1.915E-03
0.00 -1.670E-03 -1.168E-02 2.336E-04 0.00 4.671E-05 9.272E-05 3.2E-01 2.655E-02 -9.587E-02 4.467E-05 0.00 -1.430E-05 2.830E-02
0.00 0.00 7.473E-04 6.4E-01 2.655E-02 -8.690E-02 4.467E-05
2.0E-01 -1.670E-03 -6.075E-03 2.336E-04 0.00 -4.671E-05 2.809E-04 9.6E-01 2.655E-02 -7.793E-02 4.467E-05 0.00 -2.860E-05 5.182E-02
4.0E-01 -1.670E-03 -4.705E-04 2.336E-04 0.00 -9.342E-05 -1.306E-03
6.0E-01 -1.670E-03 5.134E-03 2.336E-04 1.28 2.655E-02 -6.896E-02 4.467E-05
8.0E-01 -1.670E-03 1.074E-02 2.336E-04
650 COMB1 0.00 -2.635E-05 5.164E-02
629 COMB1 0.00 -1.350E-03 -1.259E-03 0.00 3.482E-02 6.869E-02 -4.115E-05 0.00 -1.317E-05 2.821E-02
0.00 -5.104E-03 -1.003E-02 -6.749E-03 0.00 -6.749E-04 -3.957E-04 0.00 0.00 1.915E-03
0.00 0.00 1.868E-04 3.2E-01 3.482E-02 7.766E-02 -4.115E-05 0.00 1.317E-05 -2.726E-02
1.0E-01 -5.104E-03 -7.227E-03 -6.749E-03 0.00 6.749E-04 4.892E-04 6.4E-01 3.482E-02 8.663E-02 -4.115E-05
2.0E-01 -5.104E-03 -4.425E-03 -6.749E-03 0.00 1.350E-03 5.113E-04 9.6E-01 3.482E-02 9.560E-02 -4.115E-05 0.00 2.635E-05 -5.930E-02
3.0E-01 -5.104E-03 -1.622E-03 -6.749E-03
4.0E-01 -5.104E-03 1.180E-03 -6.749E-03 1.28 3.482E-02 1.046E-01 -4.115E-05

630 COMB1 0.00 5.817E-05 -1.700E-03 651 COMB1 0.00 3.449E-05 -3.004E-03
0.00 -1.323E-03 -1.172E-02 1.454E-04 0.00 2.908E-05 8.406E-05 0.00 -4.561E-02 -1.564E-02 6.405E-05 0.00 1.725E-05 1.913E-04
0.00 0.00 7.473E-04 0.00 0.00 1.354E-03
2.0E-01 -1.323E-03 -6.119E-03 1.454E-04 0.00 -2.908E-05 2.896E-04 2.7E-01 -4.561E-02 -8.093E-03 6.405E-05 0.00 -1.725E-05 4.860E-04
4.0E-01 -1.323E-03 -5.138E-04 1.454E-04 0.00 -5.817E-05 -1.289E-03 5.4E-01 -4.561E-02 -5.473E-04 6.405E-05
6.0E-01 -1.323E-03 5.091E-03 1.454E-04 8.1E-01 -4.561E-02 6.998E-03 6.405E-05 0.00 -3.449E-05 -2.414E-03
8.0E-01 -1.323E-03 1.070E-02 1.454E-04
1.08 -4.561E-02 1.454E-02 6.405E-05

631 COMB1 0.00 -9.392E-04 -1.274E-03 652 COMB1 0.00 6.244E-05 -3.650E-03
0.00 -1.106E-03 -1.011E-02 -4.696E-03 0.00 -4.696E-04 -4.034E-04 0.00 -6.457E-03 -1.766E-02 9.751E-05 0.00 3.122E-05 5.686E-04
0.00 0.00 1.868E-04 0.00 0.00 1.915E-03
1.0E-01 -1.106E-03 -7.304E-03 -4.696E-03 0.00 4.696E-04 4.969E-04 3.2E-01 -6.457E-03 -8.691E-03 9.751E-05 0.00 -3.122E-05 3.889E-04
2.0E-01 -1.106E-03 -4.501E-03 -4.696E-03 0.00 9.392E-04 5.266E-04 6.4E-01 -6.457E-03 2.806E-04 9.751E-05
3.0E-01 -1.106E-03 -1.699E-03 -4.696E-03 9.6E-01 -6.457E-03 9.253E-03 9.751E-05 0.00 -6.244E-05 -4.010E-03
4.0E-01 -1.106E-03 1.103E-03 -4.696E-03
1.28 -6.457E-03 1.822E-02 9.751E-05

632 COMB1 0.00 -7.670E-05 -1.703E-03 653 COMB1 0.00 5.514E-05 -3.351E-03
0.00 -2.477E-02 -1.173E-02 -1.918E-04 0.00 -3.835E-05 8.257E-05 0.00 -6.844E-02 -1.628E-02 1.024E-04 0.00 2.757E-05 1.761E-05
0.00 0.00 7.473E-04 0.00 0.00 1.354E-03
2.0E-01 -2.477E-02 -6.126E-03 -1.918E-04 2.7E-01 -6.844E-02 -8.738E-03 1.024E-04 0.00 -2.757E-05 6.596E-04
4.0E-01 -2.477E-02 -5.213E-04 -1.918E-04 5.4E-01 -6.844E-02 -1.192E-03 1.024E-04
8.1E-01 -6.844E-02 6.353E-03 1.024E-04 0.00 -5.514E-05 -2.067E-03

1.08 -6.844E-02 1.390E-02 1.024E-04

654 COMB1

0.00 -2.853E-02 -9.364E-03 1.929E-04 0.00 1.039E-04 3.753E-04 142 -441.58 -170.10 851.70 -441.58 -170.10 851.70 0.00 0.00
2.7E-01 -2.853E-02 -1.818E-03 1.929E-04 0.00 5.194E-05 1.881E-03 126 -791.97 -1338.06 1089.58 -791.97 -1338.06 1089.58 0.00 0.00
5.4E-01 -2.853E-02 5.727E-03 1.929E-04 0.00 0.00 1.354E-03 125 323.04 59.29 391.81 323.04 59.29 391.81 0.00 0.00
8.1E-01 -2.853E-02 1.327E-02 1.929E-04 0.00 -5.194E-05 -1.203E-03 143 -27.35 -1108.67 629.69 -27.35 -1108.67 629.69 0.00 0.00

1.08 -2.853E-02 2.082E-02 1.929E-04 0.00 -1.039E-04 -5.793E-03

655 COMB1 0.00 -3.602E-05 -6.069E-02 8 COMB1 228.16 -256.97 574.88 228.16 -256.97 574.88 0.00 0.00
0.00 -4.685E-02 -1.067E-01 -5.626E-05 0.00 -1.801E-05 -2.795E-02 125 92.79 -708.22 549.13 92.79 -708.22 549.13 0.00 0.00
0.00 0.00 1.915E-03 143 145.39 -281.80 397.20 145.39 -281.80 397.20 0.00 0.00
3.2E-01 -4.685E-02 -9.777E-02 -5.626E-05 0.00 1.801E-05 2.891E-02 141 10.02 -733.05 371.45 10.02 -733.05 371.45 0.00 0.00
6.4E-01 -4.685E-02 -8.880E-02 -5.626E-05 115
9.6E-01 -4.685E-02 -7.982E-02 -5.626E-05 0.00 3.602E-05 5.303E-02
9 COMB1
1.28 -4.685E-02 -7.085E-02 -5.626E-05 141
115
656 COMB1 0.00 -8.984E-05 5.130E-02 114 190.14 -132.62 380.46 190.14 -132.62 380.46 0.00 0.00
0.00 -1.242E-02 6.815E-02 -1.403E-04 0.00 -4.492E-05 2.804E-02 132 153.77 -253.85 355.58 153.77 -253.85 355.58 0.00 0.00
0.00 0.00 1.915E-03 110.19 -156.61 332.72 110.19 -156.61 332.72 0.00 0.00
3.2E-01 -1.242E-02 7.712E-02 -1.403E-04 0.00 4.492E-05 -2.708E-02 73.82 -277.84 307.85 73.82 -277.84 307.85 0.00 0.00
6.4E-01 -1.242E-02 8.609E-02 -1.403E-04
9.6E-01 -1.242E-02 9.506E-02 -1.403E-04 0.00 8.984E-05 -5.896E-02 10 COMB1
138 -315.59 369.00 2710.71 -315.59 369.00 2710.71 0.00 0.00
1.28 -1.242E-02 1.040E-01 -1.403E-04 110 -2267.40 -6137.05 3167.66 -2267.40 -6137.05 3167.66 0.00 0.00
126 1153.17 809.63 148.95 1153.17 809.63 148.95 0.00 0.00
657 COMB1 0.00 -3.510E-05 -3.201E-03 130 -798.64 -5696.42 605.90 -798.64 -5696.42 605.90 0.00 0.00
0.00 5.414E-02 -1.601E-02 -6.517E-05 0.00 -1.755E-05 9.237E-05
0.00 0.00 1.354E-03 11 COMB1 0.00 0.00
2.7E-01 5.414E-02 -8.460E-03 -6.517E-05 0.00 1.755E-05 5.849E-04 126 637.52 -909.21 741.09 637.52 -909.21 741.09 0.00 0.00
5.4E-01 5.414E-02 -9.145E-04 -6.517E-05 130 356.44 -1846.14 605.90 356.44 -1846.14 605.90 0.00 0.00
8.1E-01 5.414E-02 6.631E-03 -6.517E-05 0.00 3.510E-05 -2.216E-03 143 202.97 -1039.57 372.18 202.97 -1039.57 372.18 0.00 0.00
116 -78.11 -1976.50 236.98 -78.11 -1976.50 236.98
1.08 5.414E-02 1.418E-02 -6.517E-05

658 COMB1 0.00 -6.244E-05 -3.650E-03 12 COMB1 323.11 -639.12 291.61 0.00 0.00
0.00 -6.457E-03 -1.766E-02 -9.751E-05 0.00 -3.122E-05 5.686E-04 143 323.11 -639.12 291.61 262.58 -840.90 236.98 0.00 0.00
0.00 0.00 1.915E-03 116 262.58 -840.90 236.98 147.52 -691.80 212.16 0.00 0.00
3.2E-01 -6.457E-03 -8.691E-03 -9.751E-05 0.00 3.122E-05 3.889E-04 115 147.52 -691.80 212.16 86.99 -893.57 157.53 0.00 0.00
6.4E-01 -6.457E-03 2.806E-04 -9.751E-05 129 86.99 -893.57 157.53
9.6E-01 -6.457E-03 9.253E-03 -9.751E-05 0.00 6.244E-05 -4.010E-03

1.28 -6.457E-03 1.822E-02 -9.751E-05

659 COMB1 0.00 -5.514E-05 -3.351E-03 13 COMB1
0.00 -6.844E-02 -1.628E-02 -1.024E-04 0.00 -2.757E-05 1.761E-05 115 291.28 -212.60 196.29 291.28 -212.60 196.29 0.00 0.00
0.00 0.00 1.354E-03 129 264.93 -300.41 157.53 264.93 -300.41 157.53 0.00 0.00
2.7E-01 -6.844E-02 -8.738E-03 -1.024E-04 0.00 2.757E-05 6.596E-04 132 166.69 -249.98 161.72 166.69 -249.98 161.72 0.00 0.00
5.4E-01 -6.844E-02 -1.192E-03 -1.024E-04 119 140.35 -337.79 122.96 140.35 -337.79 122.96 0.00 0.00
8.1E-01 -6.844E-02 6.353E-03 -1.024E-04 0.00 5.514E-05 -2.067E-03

1.08 -6.844E-02 1.390E-02 -1.024E-04

660 COMB1 0.00 -1.039E-04 3.753E-04 14 COMB1
0.00 -2.853E-02 -9.364E-03 -1.929E-04 0.00 -5.194E-05 1.881E-03 110 -2267.40 -6137.05 -3167.66 -2267.40 -6137.05 -3167.66 0.00 0.00
0.00 0.00 1.354E-03 137 -315.59 369.00 -2710.71 -315.59 369.00 -2710.71 0.00 0.00
2.7E-01 -2.853E-02 -1.818E-03 -1.929E-04 0.00 5.194E-05 -1.203E-03 130 -798.64 -5696.42 -605.90 -798.64 -5696.42 -605.90 0.00 0.00
5.4E-01 -2.853E-02 5.727E-03 -1.929E-04 117 1153.17 809.63 -148.95 1153.17 809.63 -148.95 0.00 0.00
8.1E-01 -2.853E-02 1.327E-02 -1.929E-04 0.00 1.039E-04 -5.793E-03

1.08 -2.853E-02 2.082E-02 -1.929E-04

661 COMB1 0.00 3.602E-05 -6.069E-02 15 COMB1 0.00 0.00
0.00 -4.685E-02 -1.067E-01 5.626E-05 0.00 1.801E-05 -2.795E-02 130 356.44 -1846.14 -605.90 356.44 -1846.14 -605.90 0.00 0.00
0.00 0.00 1.915E-03 117 637.52 -909.21 -741.09 637.52 -909.21 -741.09 0.00 0.00
3.2E-01 -4.685E-02 -9.777E-02 5.626E-05 0.00 -1.801E-05 2.891E-02 116 -78.11 -1976.50 -236.98 -78.11 -1976.50 -236.98 0.00 0.00
6.4E-01 -4.685E-02 -8.880E-02 5.626E-05 144 202.97 -1039.57 -372.18 202.97 -1039.57 -372.18
9.6E-01 -4.685E-02 -7.982E-02 5.626E-05 0.00 -3.602E-05 5.303E-02
16 COMB1
1.28 -4.685E-02 -7.085E-02 5.626E-05 116 262.58 -840.90 -236.98
144 323.11 -639.12 -291.61
662 COMB1 0.00 8.984E-05 5.130E-02 129 86.99 -893.57 -157.53 262.58 -840.90 -236.98 0.00 0.00
0.00 -1.242E-02 6.815E-02 1.403E-04 0.00 4.492E-05 2.804E-02 120 147.52 -691.80 -212.16 323.11 -639.12 -291.61 0.00 0.00
0.00 0.00 1.915E-03 86.99 -893.57 -157.53 0.00 0.00
3.2E-01 -1.242E-02 7.712E-02 1.403E-04 0.00 -4.492E-05 -2.708E-02 147.52 -691.80 -212.16 0.00 0.00
6.4E-01 -1.242E-02 8.609E-02 1.403E-04
9.6E-01 -1.242E-02 9.506E-02 1.403E-04 0.00 -8.984E-05 -5.896E-02 17 COMB1
129 264.93 -300.41 -157.53 264.93 -300.41 -157.53 0.00 0.00
1.28 -1.242E-02 1.040E-01 1.403E-04 120 291.28 -212.60 -196.29 291.28 -212.60 -196.29 0.00 0.00
119 140.35 -337.79 -122.96 140.35 -337.79 -122.96 0.00 0.00
663 COMB1 0.00 3.510E-05 -3.201E-03 133 166.69 -249.98 -161.72 166.69 -249.98 -161.72 0.00 0.00
0.00 5.414E-02 -1.601E-02 6.517E-05 0.00 1.755E-05 9.237E-05
0.00 0.00 1.354E-03 18 COMB1
2.7E-01 5.414E-02 -8.460E-03 6.517E-05 0.00 -1.755E-05 5.849E-04 137 194.98 522.18 -271.02 194.98 522.18 -271.02 0.00 0.00
5.4E-01 5.414E-02 -9.145E-04 6.517E-05 118 22.47 -52.86 -417.64 22.47 -52.86 -417.64 0.00 0.00
8.1E-01 5.414E-02 6.631E-03 6.517E-05 0.00 -3.510E-05 -2.216E-03 117 -276.31 380.79 -497.44 -276.31 380.79 -497.44 0.00 0.00
146 -448.82 -194.24 -644.06 -448.82 -194.24 -644.06 0.00 0.00
1.08 5.414E-02 1.418E-02 6.517E-05

SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 5 19 COMB1
2/25/14 21:43:00 117 -791.97 -1338.06 -1089.58 -791.97 -1338.06 -1089.58 0.00 0.00
146 -441.58 -170.10 -851.70 -441.58 -170.10 -851.70 0.00 0.00
SHELL ELEMENT STRESSES 144 -27.35 -1108.67 -629.69 -27.35 -1108.67 -629.69 0.00 0.00
121 323.04 59.29 -391.81 323.04 59.29 -391.81 0.00 0.00
SHELL LOAD JOINT S11-BOT S22-BOT S12-BOT S11-TOP S22-TOP S12-TOP S13-
AVG S23-AVG 20 COMB1 92.79 -708.22 -549.13 0.00 0.00
144 92.79 -708.22 -549.13 228.16 -256.97 -574.88 0.00 0.00
2 COMB1 121 228.16 -256.97 -574.88 10.02 -733.05 -371.45
139 54.71 79.85 321.27 54.71 79.85 321.27 0.00 0.00 120 10.02 -733.05 -371.45 145.39 -281.80 -397.20 0.00 0.00
128 14.15 -55.35 278.54 14.15 -55.35 278.54 0.00 0.00 145 145.39 -281.80 -397.20 0.00 0.00
127 -82.65 38.64 268.04 -82.65 38.64 268.04 0.00 0.00
142 -123.21 -96.56 225.30 -123.21 -96.56 225.30 0.00 0.00 21 COMB1 153.77 -253.85 -355.58 0.00 0.00
120 153.77 -253.85 -355.58 190.14 -132.62 -380.46 0.00 0.00
3 COMB1 145 190.14 -132.62 -380.46 73.82 -277.84 -307.85 0.00 0.00
127 -85.18 30.20 411.63 -85.18 30.20 411.63 0.00 0.00 133 73.82 -277.84 -307.85 110.19 -156.61 -332.72 0.00 0.00
142 -115.97 -72.41 432.94 -115.97 -72.41 432.94 0.00 0.00 123 110.19 -156.61 -332.72
140 -16.70 50.75 371.22 -16.70 50.75 371.22 0.00 0.00
125 -47.48 -51.87 392.53 -47.48 -51.87 392.53 0.00 0.00 22 COMB1
118 14.15 -55.35 -278.54 14.15 -55.35 -278.54 0.00 0.00
4 COMB1 136 54.71 79.85 -321.27 54.71 79.85 -321.27 0.00 0.00
140 -25.04 22.93 528.77 -25.04 22.93 528.77 0.00 0.00 146 -123.21 -96.56 -225.30 -123.21 -96.56 -225.30 0.00 0.00
125 -142.36 -368.12 575.60 -142.36 -368.12 575.60 0.00 0.00 122 -82.65 38.64 -268.04 -82.65 38.64 -268.04 0.00 0.00
113 125.49 68.09 374.79 125.49 68.09 374.79 0.00 0.00
141 8.18 -322.96 421.62 8.18 -322.96 421.62 0.00 0.00 23 COMB1
146 -115.97 -72.41 -432.94 -115.97 -72.41 -432.94 0.00 0.00
5 COMB1 122 -85.18 30.20 -411.63 -85.18 30.20 -411.63 0.00 0.00
113 106.44 4.58 426.22 106.44 4.58 426.22 0.00 0.00 121 -47.48 -51.87 -392.53 -47.48 -51.87 -392.53 0.00 0.00
141 52.93 -173.79 404.88 52.93 -173.79 404.88 0.00 0.00 135 -16.70 50.75 -371.22 -16.70 50.75 -371.22 0.00 0.00
131 37.83 -16.01 355.99 37.83 -16.01 355.99 0.00 0.00
114 -15.68 -194.37 334.65 -15.68 -194.37 334.65 0.00 0.00 24 COMB1
121 -142.36 -368.12 -575.60 -142.36 -368.12 -575.60 0.00 0.00
6 COMB1 135 -25.04 22.93 -528.77 -25.04 22.93 -528.77 0.00 0.00
128 22.47 -52.86 417.64 22.47 -52.86 417.64 0.00 0.00 145 8.18 -322.96 -421.62 8.18 -322.96 -421.62 0.00 0.00
138 194.98 522.18 271.02 194.98 522.18 271.02 0.00 0.00 124 125.49 68.09 -374.79 125.49 68.09 -374.79 0.00 0.00
142 -448.82 -194.24 644.06 -448.82 -194.24 644.06 0.00 0.00
126 -276.31 380.79 497.44 -276.31 380.79 497.44 0.00 0.00 25 COMB1
145 52.93 -173.79 -404.88 52.93 -173.79 -404.88 0.00 0.00
7 COMB1

124 106.44 4.58 -426.22 106.44 4.58 -426.22 0.00 0.00 181 2.78 26.42 97.81 2.78 26.42 97.81 0.00 0.00
123 -15.68 -194.37 -334.65 -15.68 -194.37 -334.65 0.00 0.00 158 9.22 47.91 116.21 9.22 47.91 116.21 0.00 0.00
134 37.83 -16.01 -355.99 37.83 -16.01 -355.99 0.00 0.00

27 COMB1 45 COMB1
176 38.21 49.79 -204.56 38.21 49.79 -204.56 0.00 0.00 181 -5.31-5.297E-01 97.85 -5.31-5.297E-01 97.85 0.00 0.00
165 41.08 59.36 -224.72 41.08 59.36 -224.72 0.00 0.00 158-4.624E-01 15.63 106.36-4.624E-01 15.63 106.36 0.00 0.00
164 -26.57 30.35 -200.79 -26.57 30.35 -200.79 0.00 0.00 157 22.05 7.68 104.21 22.05 7.68 104.21 0.00 0.00
179 -23.70 39.92 -220.95 -23.70 39.92 -220.95 0.00 0.00 182 26.90 23.84 112.72 26.90 23.84 112.72 0.00 0.00

28 COMB1 46 COMB1 4.55 118.03 21.11 4.55 118.03 0.00 0.00
164 -18.12 58.52 -196.27 -18.12 58.52 -196.27 0.00 0.00 157 21.11 16.40 134.33 24.66 16.40 134.33 0.00 0.00
179 -24.32 37.85 -188.53 -24.32 37.85 -188.53 0.00 0.00 182 24.66 20.27 122.69 73.51 20.27 122.69 0.00 0.00
177 6.74 65.98 -204.41 6.74 65.98 -204.41 0.00 0.00 170 73.51 32.11 138.99 77.06 32.11 138.99 0.00 0.00
162 5.370E-01 45.31 -196.67 5.370E-01 45.31 -196.67 0.00 0.00 160 77.06

29 COMB1 26.77 -193.76 -5.02 26.77 -193.76 0.00 0.00 47 COMB1
177 -5.02 13.02 -186.83 -9.15 13.02 -186.83 0.00 0.00 155 41.08 59.36 224.72 41.08 59.36 224.72 0.00 0.00
162 -9.15 33.46 -199.18 17.26 33.46 -199.18 0.00 0.00 173 38.21 49.79 204.56 38.21 49.79 204.56 0.00 0.00
150 17.26 19.71 -192.24 13.14 19.71 -192.24 0.00 0.00 183 -23.70 39.92 220.95 -23.70 39.92 220.95 0.00 0.00
178 13.14 159 -26.57 30.35 200.79 -26.57 30.35 200.79 0.00 0.00

30 COMB1 3.40 -12.76 -215.89 0.00 0.00 48 COMB1
150 3.40 -12.76 -215.89 10.91 12.27 -213.85 0.00 0.00 183 -24.32 37.85 188.53 -24.32 37.85 188.53 0.00 0.00
178 10.91 12.27 -213.85 9.98 -10.78 -206.04 0.00 0.00 159 -18.12 58.52 196.27 -18.12 58.52 196.27 0.00 0.00
168 9.98 -10.78 -206.04 17.48 14.24 -203.99 0.00 0.00 158 5.370E-01 45.31 196.67 5.370E-01 45.31 196.67 0.00 0.00
151 17.48 14.24 -203.99 172 6.74 65.98 204.41 6.74 65.98 204.41 0.00 0.00

31 COMB1 49 COMB1 13.02 186.83 -9.15 13.02 186.83 0.00 0.00
165 -26.87 38.97 -142.82 -26.87 38.97 -142.82 0.00 0.00 158 -9.15 26.77 193.76 -5.02 26.77 193.76 0.00 0.00
175 -24.84 45.73 -149.80 -24.84 45.73 -149.80 0.00 0.00 172 -5.02 19.71 192.24 13.14 19.71 192.24 0.00 0.00
179 -49.29 32.24 -140.16 -49.29 32.24 -140.16 0.00 0.00 182 13.14 33.46 199.18 17.26 33.46 199.18 0.00 0.00
163 -47.26 39.01 -147.13 -47.26 39.01 -147.13 0.00 0.00 161 17.26

32 COMB1 30.17 -107.74 -49.91 30.17 -107.74 0.00 0.00 50 COMB1 10.91 12.27 213.85 0.00 0.00
179 -49.91 8.68 -89.35 -56.36 8.68 -89.35 0.00 0.00 182 10.91 12.27 213.85 3.40 -12.76 215.89 0.00 0.00
163 -56.36 47.91 -116.21 9.22 47.91 -116.21 0.00 0.00 161 3.40 -12.76 215.89 17.48 14.24 203.99 0.00 0.00
162 9.22 26.42 -97.81 2.78 26.42 -97.81 0.00 0.00 160 17.48 14.24 203.99 9.98 -10.78 206.04 0.00 0.00
180 2.78 171 9.98 -10.78 206.04

33 COMB1 52 COMB1
162-4.624E-01 15.63 -106.36-4.624E-01 15.63 -106.36 0.00 0.00 8 -68.92 36.66 81.50 -68.92 36.66 81.50 0.00 0.00
180 -5.31-5.297E-01 -97.85 -5.31-5.297E-01 -97.85 0.00 0.00
178 26.90 23.84 -112.72 26.90 23.84 -112.72 0.00 0.00 139 -66.91 43.36 102.19 -66.91 43.36 102.19 0.00 0.00
152 22.05 7.68 -104.21 22.05 7.68 -104.21 0.00 0.00 21 14.21 61.60 84.80 14.21 61.60 84.80 0.00 0.00
127 16.22 68.30 105.49 16.22 68.30 105.49 0.00 0.00

34 COMB1 16.40 -134.33 24.66 16.40 -134.33 0.00 0.00 53 COMB1
178 24.66 4.55 -118.03 21.11 4.55 -118.03 0.00 0.00 21 2.00 20.91 90.34 2.00 20.91 90.34 0.00 0.00
152 21.11 32.11 -138.99 77.06 32.11 -138.99 0.00 127 13.69 59.87 90.03 13.69 59.87 90.03 0.00 0.00
151 77.06 20.27 -122.69 73.51 20.27 -122.69 0.00 0.00 19 7.711E-01 20.54 109.51 7.711E-01 20.54 109.51 0.00 0.00
169 73.51 0.00 140 12.46 59.50 109.21 12.46 59.50 109.21 0.00 0.00

35 COMB1 -24.65 -79.87 -259.45 -24.65 -79.87 0.00 0.00 54 COMB1 -16.29 87.84 -10.28 -16.29 87.84 0.00 0.00
175 -259.45 -47.24 -8.39 -266.22 -47.24 -8.39 0.00 0.00 19 -10.28 31.68 85.77 4.11 31.68 85.77 0.00 0.00
147 -266.22 44.29 -88.77 -29.66 44.29 -88.77 0.00 0.00 140 4.11 -18.79 111.45 -18.61 -18.79 111.45 0.00 0.00
163 -29.66 21.69 -17.28 -36.44 21.69 -17.28 0.00 0.00 17 -18.61 29.18 109.38 -4.22 29.18 109.38 0.00 0.00
167 -36.44 113 -4.22

36 COMB1 55 COMB1
163 -38.76 13.96 -30.98 -38.76 13.96 -30.98 0.00 0.00 17 -33.23 -67.51 67.27 -33.23 -67.51 67.27 0.00 0.00
167 -44.92 -6.57 -17.28 -44.92 -6.57 -17.28 0.00 0.00 113 -23.28 -34.34 98.22 -23.28 -34.34 98.22 0.00 0.00
180 5.27 27.17 -39.07 5.27 27.17 -39.07 0.00 0.00 5 91.13 -30.20 83.60 91.13 -30.20 83.60 0.00 0.00
153-8.877E-01 6.64 -25.37-8.877E-01 6.64 -25.37 0.00 0.00 131 101.08 2.97 114.55 101.08 2.97 114.55 0.00 0.00

37 COMB1 56 COMB1 42.55 -158.82 -69.62 42.55 -158.82 0.00 0.00
180 -2.81 2.191E-01 -39.11 -2.81 2.191E-01 -39.11 0.00 0.00 139 -69.62 14.95 -148.04 -77.90 14.95 -148.04 0.00 0.00
153 -5.25 -7.90 -25.37 -5.25 -7.90 -25.37 0.00 0.00 176 -77.90 68.53 -185.98 16.99 68.53 -185.98 0.00 0.00
152 41.35 13.47 -42.30 41.35 13.47 -42.30 0.00 0.00 127 16.99 40.94 -175.21 8.71 40.94 -175.21 0.00 0.00
166 38.92 5.35 -28.56 38.92 5.35 -28.56 0.00 0.00 164 8.71

38 COMB1 0.00 0.00 57 COMB1
152 40.42 10.35 -56.12 40.42 10.35 -56.12 0.00 0.00 127 14.46 60.10 -201.45 14.46 60.10 -201.45 0.00 0.00
166 30.89 -21.42 -28.56 30.89 -21.42 -28.56 0.00 0.00 164 17.16 69.11 -203.21 17.16 69.11 -203.21 0.00 0.00
169 128.99 36.92 -68.63 128.99 36.92 -68.63 0.00 0.00 140 2.843E-01 55.84 -192.57 2.843E-01 55.84 -192.57 0.00 0.00
156 119.46 5.15 -41.07 119.46 5.15 -41.07 177 2.99 64.86 -194.34 2.99 64.86 -194.34 0.00 0.00

39 COMB1 -47.24 8.39 -266.22 -47.24 8.39 0.00 0.00 58 COMB1 28.03 -216.01 -8.06 28.03 -216.01 0.00 0.00
147 -266.22 -24.65 79.87 -259.45 -24.65 79.87 0.00 0.00 140 -8.06 25.65 -216.29 -8.77 25.65 -216.29 0.00 0.00
174 -259.45 21.69 17.28 -36.44 21.69 17.28 0.00 0.00 177 -8.77 27.35 -218.35 -10.31 27.35 -218.35
167 -36.44 44.29 88.77 -29.66 44.29 88.77 0.00 0.00 113 -10.31 24.98 -218.63 -11.02 24.98 -218.63 0.00 0.00
154 -29.66 150 -11.02 0.00 0.00

40 COMB1 59 COMB1
167 -44.92 -6.57 17.28 -44.92 -6.57 17.28 0.00 0.00 113 -29.36 -36.16 -229.50 -29.36 -36.16 -229.50 0.00 0.00
154 -38.76 13.96 30.98 -38.76 13.96 30.98 0.00 0.00 150 -24.88 -21.24 -213.90 -24.88 -21.24 -213.90 0.00 0.00
153-8.877E-01 6.64 25.37-8.877E-01 6.64 25.37 0.00 0.00 131 96.00 1.44 -214.82 96.00 1.44 -214.82 0.00 0.00
181 5.27 27.17 39.07 5.27 27.17 39.07 0.00 0.00 168 100.47 16.37 -199.22 100.47 16.37 -199.22 0.00 0.00

41 COMB1 61 COMB1
153 -5.25 -7.90 25.37 -5.25 -7.90 25.37 0.00 0.00 7 -68.92 36.66 81.50 -68.92 36.66 81.50 0.00 0.00
181 -2.81 2.191E-01 39.11 -2.81 2.191E-01 39.11 0.00 0.00
166 38.92 5.35 28.56 38.92 5.35 28.56 0.00 0.00 136 -66.91 43.36 102.19 -66.91 43.36 102.19 0.00 0.00
157 41.35 13.47 42.30 41.35 13.47 42.30 0.00 0.00 22 14.21 61.60 84.80 14.21 61.60 84.80 0.00 0.00
122 16.22 68.30 105.49 16.22 68.30 105.49 0.00 0.00

42 COMB1 28.56 30.89 -21.42 28.56 0.00 0.00 62 COMB1
166 30.89 -21.42 56.12 40.42 10.35 56.12 0.00 0.00 22 2.00 20.91 90.34 2.00 20.91 90.34 0.00 0.00
157 40.42 10.35 41.07 119.46 5.15 41.07 0.00 0.00 122 13.69 59.87 90.03 13.69 59.87 90.03 0.00 0.00
156 119.46 5.15 68.63 128.99 36.92 68.63 0.00 0.00 20 7.711E-01 20.54 109.51 7.711E-01 20.54 109.51 0.00 0.00
170 128.99 36.92 135 12.46 59.50 109.21 12.46 59.50 109.21 0.00 0.00

43 COMB1 63 COMB1 -16.29 87.84 -10.28 -16.29 87.84 0.00 0.00
174 -24.84 45.73 149.80 -24.84 45.73 149.80 0.00 0.00 20 -10.28 31.68 85.77 4.11 31.68 85.77 0.00 0.00
155 -26.87 38.97 142.82 -26.87 38.97 142.82 0.00 0.00 135 4.11 -18.79 111.45 -18.61 -18.79 111.45 0.00 0.00
154 -47.26 39.01 147.13 -47.26 39.01 147.13 0.00 0.00 18 -18.61 29.18 109.38 -4.22 29.18 109.38 0.00 0.00
183 -49.29 32.24 140.16 -49.29 32.24 140.16 0.00 0.00 124 -4.22

44 COMB1 64 COMB1
154 -56.36 8.68 89.35 -56.36 8.68 89.35 0.00 0.00 18 -33.23 -67.51 67.27 -33.23 -67.51 67.27 0.00 0.00
183 -49.91 30.17 107.74 -49.91 30.17 107.74 0.00 0.00 124 -23.28 -34.34 98.22 -23.28 -34.34 98.22 0.00 0.00
6 91.13 -30.20 83.60 91.13 -30.20 83.60 0.00 0.00

134 101.08 2.97 114.55 101.08 2.97 114.55 0.00 0.00

65 COMB1 42.55 -158.82 -69.62 42.55 -158.82 0.00 0.00 85 COMB1 -48.96 -38.75 -160.51 -48.96 -38.75 0.00 0.00
136 -69.62 14.95 -148.04 -77.90 14.95 -148.04 0.00 0.00 10 -160.51 39.35 49.78 -134.01 39.35 49.78 0.00 0.00
173 -77.90 68.53 -185.98 16.99 68.53 -185.98 0.00 0.00 12 -134.01 11.75 -14.02 41.85 11.75 -14.02 0.00 0.00
122 16.99 40.94 -175.21 8.71 40.94 -175.21 0.00 0.00 128 41.85 100.06 74.51 68.34 100.06 74.51 0.00 0.00
159 8.71 138 68.34

66 COMB1 86 COMB1 12.20 -214.65 41.99 12.20 -214.65 0.00 0.00
122 14.46 60.10 -201.45 14.46 60.10 -201.45 0.00 0.00 128 41.99 51.19 -288.58 53.69 51.19 -288.58 0.00 0.00
159 17.16 69.11 -203.21 17.16 69.11 -203.21 0.00 0.00 138 53.69 -13.14 -209.19 -42.51 -13.14 -209.19 0.00 0.00
135 2.843E-01 55.84 -192.57 2.843E-01 55.84 -192.57 0.00 0.00 165 -42.51 25.85 -283.12 -30.81 25.85 -283.12 0.00 0.00
172 2.99 64.86 -194.34 2.99 64.86 -194.34 0.00 0.00 175 -30.81

67 COMB1 28.03 -216.01 -8.06 28.03 -216.01 0.00 0.00 87 COMB1
135 -8.06 25.65 -216.29 -8.77 25.65 -216.29 0.00 0.00 12 4.76 80.98 83.90 4.76 80.98 83.90 0.00 0.00
172 -8.77 27.35 -218.35 -10.31 27.35 -218.35 0.00 0.00 2 -19.49 1.413E-01 -111.65 -19.49 1.413E-01 -111.65 0.00 0.00
124 -10.31 24.98 -218.63 -11.02 24.98 -218.63 0.00 0.00 138 -442.22 -53.11 61.27 -442.22 -53.11 61.27 0.00 0.00
161 -11.02 110 -466.48 -133.95 -134.29 -466.48 -133.95 -134.29 0.00 0.00

68 COMB1 88 COMB1 0.00 0.00
124 -29.36 -36.16 -229.50 -29.36 -36.16 -229.50 0.00 0.00 138 -456.88 -101.98 -301.82 -456.88 -101.98 -301.82 0.00 0.00
161 -24.88 -21.24 -213.90 -24.88 -21.24 -213.90 0.00 0.00 110 -387.92 127.89 -134.29 -387.92 127.89 -134.29 0.00 0.00
134 96.00 1.44 -214.82 96.00 1.44 -214.82 0.00 0.00 175 -265.41 -44.54 -269.64 -265.41 -44.54 -269.64 0.00 0.00
171 100.47 16.37 -199.22 100.47 16.37 -199.22 0.00 0.00 147 -196.45 185.33 -102.10 -196.45 185.33 -102.10

70 COMB1 89 COMB1
5 64.21 119.45 -11.42 64.21 119.45 -11.42 0.00 0.00 2 -19.49 1.413E-01 111.65 -19.49 1.413E-01 111.65 0.00 0.00
9 15.24 -43.78 -4.57 15.24 -43.78 -4.57 0.00 0.00 14 4.76 80.98 -83.90 4.76 80.98 -83.90 0.00 0.00
131 79.87 124.15 -57.12 79.87 124.15 -57.12 0.00 0.00
114 30.91 -39.08 -50.27 30.91 -39.08 -50.27 0.00 0.00 110 -466.48 -133.95 134.29 -466.48 -133.95 134.29 0.00 0.00
137 -442.22 -53.11 -61.27 -442.22 -53.11 -61.27 0.00 0.00

71 COMB1 78.35 119.07 219.85 0.00 0.00 90 COMB1 0.00 0.00
131 78.35 119.07 219.85 34.94 -25.63 191.57 0.00 0.00 110 -387.92 127.89 134.29 -387.92 127.89 134.29 0.00 0.00
114 34.94 -25.63 191.57 46.02 109.37 199.60 0.00 0.00 137 -456.88 -101.98 301.82 -456.88 -101.98 301.82 0.00 0.00
168 46.02 109.37 199.60 2.61 -35.33 171.31 0.00 0.00 147 -196.45 185.33 102.10 -196.45 185.33 102.10 0.00 0.00
151 2.61 -35.33 171.31 174 -265.41 -44.54 269.64 -265.41 -44.54 269.64

72 COMB1 91 COMB1 39.35 -49.78 -134.01 39.35 -49.78 0.00 0.00
9 129.85 -9.40 -39.69 129.85 -9.40 -39.69 0.00 0.00 14 -134.01 -48.96 38.75 -160.51 -48.96 38.75 0.00 0.00
11 125.57 -23.65 -27.91 125.57 -23.65 -27.91 0.00 0.00 16 -160.51 100.06 -74.51 68.34 100.06 -74.51 0.00 0.00
114 156.78 -1.32 -43.68 156.78 -1.32 -43.68 0.00 0.00 137 68.34 11.75 14.02 41.85 11.75 14.02 0.00 0.00
132 152.50 -15.57 -31.90 152.50 -15.57 -31.90 0.00 0.00 118 41.85

73 COMB1 0.00 0.00 92 COMB1 51.19 288.58 53.69 51.19 288.58 0.00 0.00
114 160.81 12.13 198.16 160.81 12.13 198.16 0.00 0.00 137 53.69 12.20 214.65 41.99 12.20 214.65 0.00 0.00
132 158.72 5.17 111.86 158.72 5.17 111.86 0.00 0.00 118 41.99 25.85 283.12 -30.81 25.85 283.12 0.00 0.00
151 62.19 -17.46 197.19 62.19 -17.46 197.19 0.00 0.00 174 -30.81 -13.14 209.19 -42.51 -13.14 209.19 0.00 0.00
169 60.10 -24.42 110.89 60.10 -24.42 110.89 155 -42.51

74 COMB1 93 COMB1 8.84 -17.03 -5.92 8.84 0.00 0.00
11 188.80 -4.68 -23.50 188.80 -4.68 -23.50 0.00 0.00 16 -17.03 -5.92 30.96 -43.11 -92.85 30.96 0.00 0.00
1 182.08 -27.08 1.25 182.08 -27.08 1.25 0.00 0.00 7 -43.11 -92.85 -15.50 33.53 9.25 -15.50 0.00 0.00
132 245.37 12.29 -29.78 245.37 12.29 -29.78 0.00 0.00 118 33.53 9.25 6.62 7.45 -77.68 6.62 0.00 0.00
119 238.65 -10.11 -5.03 238.65 -10.11 -5.03 0.00 0.00 136 7.45 -77.68

75 COMB1 33.03 113.98 251.59 33.03 113.98 0.00 0.00 94 COMB1 33.67 9.71 185.13 0.00 0.00
132 251.59 -2.92 -5.03 240.81 -2.92 -5.03 0.00 0.00 118 33.67 9.71 185.13 6.63 -80.40 177.94 0.00 0.00
119 240.81 -7.78 108.95 115.58 -7.78 108.95 0.00 0.00 136 6.63 -80.40 177.94 25.45 7.24 172.52 0.00 0.00
169 115.58 -43.72 -10.06 104.80 -43.72 -10.06 0.00 0.00 155 25.45 7.24 172.52 -1.58 -82.86 165.33 0.00 0.00
156 104.80 173 -1.58 -82.86 165.33

76 COMB1 SAP2000 v7.40 File: BILLBOARD 4.5 X 6 2345OKE COBA FINAL KN-m Units PAGE 6
1 182.08 -27.08 -1.25 182.08 -27.08 -1.25 0.00 0.00 2/25/14 21:43:00
13 188.80 -4.68 23.50 188.80 -4.68 23.50 0.00 0.00
119 238.65 -10.11 5.03 238.65 -10.11 5.03 0.00 0.00 SHELL ELEMENT PRINCIPAL STRESSES
133 245.37 12.29 29.78 245.37 12.29 29.78 0.00 0.00

77 COMB1 SHELL LOAD JOINT SMAX-BOT SMIN-BOT SVM-BOT SMAX-TOP SMIN-TOP SVM-
119 240.81 TOP SVMAX-AVG
133 251.59
156 104.80 -2.92 5.03 240.81 -2.92 5.03 0.00 0.00 2 COMB1 388.80 -254.24 560.94 388.80 -254.24 560.94 0.00
170 115.58 33.03 -113.98 251.59 33.03 -113.98 0.00 0.00 139 260.09 -301.30 486.62 260.09 -301.30 486.62 0.00
-43.72 10.06 104.80 -43.72 10.06 0.00 0.00 128 252.81 -296.82 476.50 252.81 -296.82 476.50 0.00
-7.78 -108.95 115.58 -7.78 -108.95 0.00 0.00 127 115.81 -335.58 406.07 115.81 -335.58 406.07 0.00
142
78 COMB1
13 125.57 -23.65 27.91 125.57 -23.65 27.91 0.00 0.00 3 COMB1 388.16 -443.14 720.46 388.16 -443.14 720.46 0.00
15 129.85 -9.40 39.69 129.85 -9.40 39.69 0.00 0.00 127 339.29 -527.67 756.70 339.29 -527.67 756.70 0.00
133 152.50 -15.57 31.90 152.50 -15.57 31.90 0.00 0.00 142 389.78 -355.73 645.85 389.78 -355.73 645.85 0.00
123 156.78 -1.32 43.68 156.78 -1.32 43.68 0.00 0.00 140 342.86 -442.21 681.71 342.86 -442.21 681.71 0.00
125
79 COMB1
133 158.72 5.17 -111.86 158.72 5.17 -111.86 0.00 0.00 4 COMB1 528.25 -530.37 916.79 528.25 -530.37 916.79 0.00
123 160.81 12.13 -198.16 160.81 12.13 -198.16 0.00 0.00 140 331.32 -841.80 1047.53 331.32 -841.80 1047.53 0.00
170 60.10 -24.42 -110.89 60.10 -24.42 -110.89 0.00 0.00 125 472.68 -279.09 658.21 472.68 -279.09 658.21 0.00
160 62.19 -17.46 -197.19 62.19 -17.46 -197.19 0.00 0.00 113 295.57 -610.36 800.19 295.57 -610.36 800.19 0.00
141
80 COMB1
15 15.24 -43.78 4.57 15.24 -43.78 4.57 0.00 0.00 5 COMB1 484.76 -373.75 745.56 484.76 -373.75 745.56 0.00
6 64.21 119.45 11.42 64.21 119.45 11.42 0.00 0.00 113 360.02 -480.88 730.74 360.02 -480.88 730.74 0.00
123 30.91 -39.08 50.27 30.91 -39.08 50.27 0.00 0.00 141 367.92 -346.10 618.45 367.92 -346.10 618.45 0.00
134 79.87 124.15 57.12 79.87 124.15 57.12 0.00 0.00 131 241.34 -451.39 609.05 241.34 -451.39 609.05 0.00
114
81 COMB1
123 34.94 -25.63 -191.57 34.94 -25.63 -191.57 0.00 0.00 6 COMB1
134 78.35 119.07 -219.85 78.35 119.07 -219.85 0.00 0.00 128 404.14 -434.53 726.47 404.14 -434.53 726.47 0.00
160 2.61 -35.33 -171.31 2.61 -35.33 -171.31 0.00 0.00 138 675.15 42.01 655.15 675.15 42.01 655.15 0.00
171 46.02 109.37 -199.60 46.02 109.37 -199.60 0.00 0.00 142 334.99 -978.05 1181.71 334.99 -978.05 1181.71 0.00
126 648.38 -543.91 1033.87 648.38 -543.91 1033.87 0.00
83 COMB1
8 -43.11 -92.85 -30.96 -43.11 -92.85 -30.96 0.00 0.00 7 COMB1 556.61 -1168.28 1524.79 556.61 -1168.28 1524.79 0.00
10 -17.03 -5.92 -8.84 -17.03 -5.92 -8.84 0.00 0.00 142 58.26 -2188.28 2217.98 58.26 -2188.28 2217.98 0.00
139 7.45 -77.68 -6.62 -6.62 0.00 0.00 126 604.57 -222.25 741.12 604.57 -222.25 741.12 0.00
128 33.53 9.25 15.50 7.45 -77.68 15.50 0.00 0.00 125 261.95 -1397.97 1545.68 261.95 -1397.97 1545.68 0.00
33.53 9.25 143

84 COMB1 6.63 -80.40 -177.94 0.00 0.00 8 COMB1 0.00
139 6.63 -80.40 -177.94 33.67 9.71 -185.13 0.00 0.00 125 609.56 -638.36 1080.82 609.56 -638.36 1080.82 0.00
128 33.67 9.71 -185.13 -1.58 -82.86 -165.33 0.00 0.00 143 371.95 -987.38 1216.77 371.95 -987.38 1216.77
176 -1.58 -82.86 -165.33 25.45 7.24 -172.52 0.00 0.00
165 25.45 7.24 -172.52

141 382.78 -519.19 784.11 382.78 -519.19 784.11 0.00 179 231.34 -215.11 386.72 231.34 -215.11 386.72 0.00
115 163.85 -886.88 979.14 163.85 -886.88 979.14 0.00

9 COMB1 716.38 442.03 -384.51 716.38 0.00 28 COMB1 346.95 220.17 -179.77 346.95 0.00
141 442.03 -384.51 711.64 359.81 -459.89 711.64 0.00 164 220.17 -179.77 331.03 197.84 -184.31 331.03 0.00
115 359.81 -459.89 621.32 335.26 -381.68 621.32 0.00 179 197.84 -184.31 359.58 242.90 -170.18 359.58 0.00
114 335.26 -381.68 622.47 252.51 -456.53 622.47 0.00 177 242.90 -170.18 343.61 220.86 -175.02 343.61 0.00
132 252.51 -456.53 162 220.86 -175.02

10 COMB1 29 COMB1 336.91 205.29 -183.54 336.91 0.00
138 2758.94 -2705.53 4732.45 2758.94 -2705.53 4732.45 0.00 177 205.29 -183.54 324.17 189.09 -185.22 324.17 0.00
110 -490.41 -7914.05 7680.59 -490.41 -7914.05 7680.59 0.00 162 189.09 -185.22 346.20 224.70 -173.98 346.20 0.00
126 1208.76 754.05 1057.46 1208.76 754.05 1057.46 0.00 150 224.70 -173.98 333.43 208.69 -175.85 333.43 0.00
130 -724.80 -5770.26 5444.17 -724.80 -5770.26 5444.17 0.00 178 208.69 -175.85

11 COMB1 935.28 -1206.97 1860.21 0.00 30 COMB1 374.23 211.36 -220.72 374.23 0.00
126 935.28 -1206.97 1860.21 512.11 -2001.81 2301.01 0.00 150 211.36 -220.72 370.57 225.43 -202.26 370.57 0.00
130 512.11 -2001.81 2301.01 305.92 -1142.52 1322.29 0.00 178 225.43 -202.26 357.32 205.90 -206.70 357.32 0.00
143 305.92 -1142.52 1322.29 -48.97 -2005.64 1981.61 0.00 168 205.90 -206.70 353.69 219.86 -188.13 353.69 0.00
116 -48.97 -2005.64 1981.61 151 219.86 -188.13

12 COMB1 0.00 31 COMB1 253.93 152.62 -140.52 253.93 0.00
143 404.59 -720.60 987.16 404.59 -720.60 987.16 0.00 165 152.62 -140.52 266.76 164.34 -143.45 266.76 0.00
116 311.32 -889.64 1079.51 311.32 -889.64 1079.51 0.00 175 164.34 -143.45 252.97 137.44 -154.49 252.97 0.00
115 198.10 -742.38 858.74 198.10 -742.38 858.74 0.00 179 137.44 -154.49 265.60 149.20 -157.46 265.60 0.00
129 111.67 -918.26 978.89 111.67 -918.26 978.89 163 149.20 -157.46

13 COMB1 554.58 358.72 -280.05 554.58 0.00 32 COMB1 0.00
115 358.72 -280.05 560.78 305.87 -341.35 560.78 0.00 179 105.07 -124.82 199.33 105.07 -124.82 199.33 0.00
129 305.87 -341.35 458.70 222.09 -305.38 458.70 0.00 163 71.24 -118.92 166.40 71.24 -118.92 166.40 0.00
132 222.09 -305.38 475.99 170.11 -367.56 475.99 0.00 162 146.37 -89.24 206.04 146.37 -89.24 206.04 0.00
119 170.11 -367.56 180 113.12 -83.92 171.27 113.12 -83.92 171.27

14 COMB1 33 COMB1 184.91 114.25 -99.08 184.91 0.00
110 -490.41 -7914.05 7680.59 -490.41 -7914.05 7680.59 0.00 162 114.25 -99.08 169.56 94.96 -100.80 169.56 0.00
137 2758.94 -2705.53 4732.45 2758.94 -2705.53 4732.45 0.00 180 94.96 -100.80 196.90 138.10 -87.37 196.90 0.00
130 -724.80 -5770.26 5444.17 -724.80 -5770.26 5444.17 0.00 178 138.10 -87.37 181.54 119.32 -89.60 181.54 0.00
117 1208.76 754.05 1057.46 1208.76 754.05 1057.46 0.00 152 119.32 -89.60

15 COMB1 512.11 -2001.81 2301.01 0.00 34 COMB1 0.00
130 512.11 -2001.81 2301.01 935.28 -1206.97 1860.21 0.00 178 154.92 -113.86 233.68 154.92 -113.86 233.68 0.00
117 935.28 -1206.97 1860.21 -48.97 -2005.64 1981.61 0.00 152 131.15 -105.48 205.33 131.15 -105.48 205.33 0.00
116 -48.97 -2005.64 1981.61 305.92 -1142.52 1322.29 0.00 151 195.38 -86.21 249.90 195.38 -86.21 249.90 0.00
144 305.92 -1142.52 1322.29 169 172.43 -78.65 222.45 172.43 -78.65 222.45

16 COMB1 0.00 35 COMB1
116 311.32 -889.64 1079.51 311.32 -889.64 1079.51 0.00 175-5.134E-02 -284.04 284.02-5.134E-02 -284.04 284.02 0.00
144 404.59 -720.60 987.16 404.59 -720.60 987.16 0.00 147 -46.92 -266.54 246.46 -46.92 -266.54 246.46 0.00
129 111.67 -918.26 978.89 111.67 -918.26 978.89 0.00 163 103.48 -88.85 166.72 103.48 -88.85 166.72 0.00
120 198.10 -742.38 858.74 198.10 -742.38 858.74 167 26.44 -41.19 59.04 26.44 -41.19 59.04 0.00

17 COMB1 560.78 305.87 -341.35 560.78 0.00 36 COMB1
129 305.87 -341.35 554.58 358.72 -280.05 554.58 0.00 163 28.28 -53.08 71.54 28.28 -53.08 71.54 0.00
120 358.72 -280.05 475.99 170.11 -367.56 475.99 0.00 167 6.985E-02 -51.56 51.60 6.985E-02 -51.56 51.60 0.00
119 170.11 -367.56 458.70 222.09 -305.38 458.70 0.00 180 56.79 -24.35 72.12 56.79 -24.35 72.12 0.00
133 222.09 -305.38 153 28.52 -22.77 44.51 28.52 -22.77 44.51 0.00

18 COMB1 37 COMB1 -40.44 67.80 37.84 -40.44 67.80 0.00
137 675.15 42.01 655.15 675.15 42.01 655.15 0.00 180 37.84 -31.97 44.49 18.83 -31.97 44.49 0.00
118 404.14 -434.53 726.47 404.14 -434.53 726.47 0.00 153 18.83 -17.13 81.87 71.95 -17.13 81.87 0.00
117 648.38 -543.91 1033.87 648.38 -543.91 1033.87 0.00 152 71.95 -10.99 61.50 55.26 -10.99 61.50 0.00
146 334.99 -978.05 1181.71 334.99 -978.05 1181.71 0.00 166 55.26

19 COMB1 38 COMB1
117 58.26 -2188.28 2217.98 58.26 -2188.28 2217.98 0.00 152 83.48 -32.72 103.78 83.48 -32.72 103.78 0.00
146 556.61 -1168.28 1524.79 556.61 -1168.28 1524.79 0.00 166 43.46 -34.00 67.24 43.46 -34.00 67.24 0.00
144 261.95 -1397.97 1545.68 261.95 -1397.97 1545.68 0.00 169 165.59 3.159E-01 165.43 165.59 3.159E-01 165.43 0.00
121 604.57 -222.25 741.12 604.57 -222.25 741.12 0.00 156 132.68 -8.08 136.90 132.68 -8.08 136.90 0.00

20 COMB1 0.00 39 COMB1
144 371.95 -987.38 1216.77 371.95 -987.38 1216.77 0.00 147 -46.92 -266.54 246.46 -46.92 -266.54 246.46 0.00
121 609.56 -638.36 1080.82 609.56 -638.36 1080.82 0.00 174-5.134E-02 -284.04 284.02-5.134E-02 -284.04 284.02 0.00
120 163.85 -886.88 979.14 163.85 -886.88 979.14 0.00 167 26.44 -41.19 59.04 26.44 -41.19 59.04 0.00
145 382.78 -519.19 784.11 382.78 -519.19 784.11 154 103.48 -88.85 166.72 103.48 -88.85 166.72 0.00

21 COMB1 711.64 359.81 -459.89 711.64 0.00 40 COMB1
120 359.81 -459.89 716.38 442.03 -384.51 716.38 0.00 167 6.985E-02 -51.56 51.60 6.985E-02 -51.56 51.60 0.00
145 442.03 -384.51 622.47 252.51 -456.53 622.47 0.00 154 28.28 -53.08 71.54 28.28 -53.08 71.54 0.00
133 252.51 -456.53 621.32 335.26 -381.68 621.32 0.00 153 28.52 -22.77 44.51 28.52 -22.77 44.51 0.00
123 335.26 -381.68 181 56.79 -24.35 72.12 56.79 -24.35 72.12 0.00

22 COMB1 486.62 260.09 -301.30 486.62 0.00 41 COMB1 -31.97 44.49 18.83 -31.97 44.49 0.00
118 260.09 -301.30 560.94 388.80 -254.24 560.94 0.00 153 18.83 -40.44 67.80 37.84 -40.44 67.80 0.00
136 388.80 -254.24 406.07 115.81 -335.58 406.07 0.00 181 37.84 -10.99 61.50 55.26 -10.99 61.50 0.00
146 115.81 -335.58 476.50 252.81 -296.82 476.50 0.00 166 55.26 -17.13 81.87 71.95 -17.13 81.87 0.00
122 252.81 -296.82 157 71.95

23 COMB1 756.70 339.29 -527.67 756.70 0.00 42 COMB1
146 339.29 -527.67 720.46 388.16 -443.14 720.46 0.00 166 43.46 -34.00 67.24 43.46 -34.00 67.24 0.00
122 388.16 -443.14 681.71 342.86 -442.21 681.71 0.00 157 83.48 -32.72 103.78 83.48 -32.72 103.78 0.00
121 342.86 -442.21 645.85 389.78 -355.73 645.85 0.00 156 132.68 -8.08 136.90 132.68 -8.08 136.90 0.00
135 389.78 -355.73 170 165.59 3.159E-01 165.43 165.59 3.159E-01 165.43 0.00

24 COMB1 0.00 43 COMB1 266.76 164.34 -143.45 266.76 0.00
121 331.32 -841.80 1047.53 331.32 -841.80 1047.53 0.00 174 164.34 -143.45 253.93 152.62 -140.52 253.93 0.00
135 528.25 -530.37 916.79 528.25 -530.37 916.79 0.00 155 152.62 -140.52 265.60 149.20 -157.46 265.60 0.00
145 295.57 -610.36 800.19 295.57 -610.36 800.19 0.00 154 149.20 -157.46 252.97 137.44 -154.49 252.97 0.00
124 472.68 -279.09 658.21 472.68 -279.09 658.21 183 137.44 -154.49

25 COMB1 730.74 360.02 -480.88 730.74 0.00 44 COMB1 0.00
145 360.02 -480.88 745.56 484.76 -373.75 745.56 0.00 154 71.24 -118.92 166.40 71.24 -118.92 166.40 0.00
124 484.76 -373.75 609.05 241.34 -451.39 609.05 0.00 183 105.07 -124.82 199.33 105.07 -124.82 199.33 0.00
123 241.34 -451.39 618.45 367.92 -346.10 618.45 0.00 181 113.12 -83.92 171.27 113.12 -83.92 171.27 0.00
134 367.92 -346.10 158 146.37 -89.24 206.04 146.37 -89.24 206.04

27 COMB1 357.17 248.64 -160.64 357.17 0.00 45 COMB1 169.56 94.96 -100.80 169.56 0.00
176 248.64 -160.64 392.76 275.12 -174.68 392.76 0.00 181 94.96 -100.80 184.91 114.25 -99.08 184.91 0.00
165 275.12 -174.68 351.26 204.69 -200.91 351.26 0.00 158 114.25 -99.08 181.54 119.32 -89.60 181.54 0.00
164 204.69 -200.91 157 119.32 -89.60 196.90 138.10 -87.37 196.90 0.00
182 138.10 -87.37

46 COMB1 0.00 66 COMB1 353.12 240.01 -165.46 353.12 0.00
157 131.15 -105.48 205.33 131.15 -105.48 205.33 0.00 122 240.01 -165.46 357.44 248.00 -161.73 357.44 0.00
182 154.92 -113.86 233.68 154.92 -113.86 233.68 0.00 159 248.00 -161.73 338.17 222.63 -166.50 338.17 0.00
170 172.43 -78.65 222.45 172.43 -78.65 222.45 0.00 135 222.63 -166.50 342.53 230.71 -162.86 342.53 0.00
160 195.38 -86.21 249.90 195.38 -86.21 249.90 172 230.71 -162.86

47 COMB1 392.76 275.12 -174.68 392.76 0.00 67 COMB1 375.58 226.74 -206.78 375.58 0.00
155 275.12 -174.68 357.17 248.64 -160.64 357.17 0.00 135 226.74 -206.78 375.90 225.41 -208.54 375.90 0.00
173 248.64 -160.64 386.72 231.34 -215.11 386.72 0.00 172 225.41 -208.54 379.69 227.68 -210.64 379.69 0.00
183 231.34 -215.11 351.26 204.69 -200.91 351.26 0.00 124 227.68 -210.64 380.02 226.35 -212.39 380.02 0.00
159 204.69 -200.91 161 226.35 -212.39

48 COMB1 331.03 197.84 -184.31 331.03 0.00 68 COMB1 398.90 196.77 -262.29 398.90 0.00
183 197.84 -184.31 346.95 220.17 -179.77 346.95 0.00 124 196.77 -262.29 371.22 190.85 -236.97 371.22 0.00
159 220.17 -179.77 343.61 220.86 -175.02 343.61 0.00 161 190.85 -236.97 384.08 268.68 -171.24 384.08 0.00
158 220.86 -175.02 359.58 242.90 -170.18 359.58 0.00 134 268.68 -171.24 357.46 262.02 -145.19 357.46 0.00
172 242.90 -170.18 171 262.02 -145.19

49 COMB1 324.17 189.09 -185.22 324.17 0.00 70 COMB1
158 189.09 -185.22 336.91 205.29 -183.54 336.91 0.00 5 121.72 61.94 105.42 121.72 61.94 105.42 0.00
172 205.29 -183.54 333.43 208.69 -175.85 333.43 0.00 9 15.59 -44.13 53.65 15.59 -44.13 53.65 0.00
182 208.69 -175.85 346.20 224.70 -173.98 346.20 0.00
161 224.70 -173.98 131 163.27 40.75 147.19 163.27 40.75 147.19 0.00
114 57.16 -65.34 106.17 57.16 -65.34 106.17 0.00

50 COMB1 370.57 225.43 -202.26 370.57 0.00 71 COMB1 394.96 319.50 -122.09 394.96 0.00
182 225.43 -202.26 374.23 211.36 -220.72 374.23 0.00 131 319.50 -122.09 335.96 198.60 -189.29 335.96 0.00
161 211.36 -220.72 353.69 219.86 -188.13 353.69 0.00 114 198.60 -189.29 358.56 279.79 -124.40 358.56 0.00
160 219.86 -188.13 357.32 205.90 -206.70 357.32 0.00 168 279.79 -124.40 298.98 156.00 -188.72 298.98 0.00
171 205.90 -206.70 151 156.00 -188.72

52 COMB1 72 COMB1 0.00
8 80.97 -113.23 168.96 80.97 -113.23 168.96 0.00 9 140.37 -19.91 151.31 140.37 -19.91 151.31 0.00
139 104.35 -127.89 201.46 104.35 -127.89 201.46 0.00 11 130.62 -28.70 147.09 130.62 -28.70 147.09 0.00
21 125.95 -50.15 157.15 125.95 -50.15 157.15 0.00 0.00
127 150.92 -66.40 192.89 150.92 -66.40 192.89 0.00 114 168.04 -12.58 174.67 168.04 -12.58 174.67
132 158.35 -21.42 170.08 158.35 -21.42 170.08

53 COMB1 0.00 73 COMB1 0.00
21 102.29 -79.38 157.74 102.29 -79.38 157.74 0.00 114 298.12 -125.18 376.64 298.12 -125.18 376.64 0.00
127 129.72 -56.17 165.13 129.72 -56.17 165.13 0.00 132 217.62 -53.73 248.88 217.62 -53.73 248.88 0.00
19 120.61 -99.30 190.75 120.61 -99.30 190.75 0.00 151 223.53 -178.80 349.15 223.53 -178.80 349.15 0.00
140 147.69 -75.73 196.80 147.69 -75.73 196.80 169 136.50 -100.83 206.31 136.50 -100.83 206.31

54 COMB1 74.61 -101.18 152.82 0.00 74 COMB1
19 74.61 -101.18 152.82 104.77 -68.97 151.52 0.00 11 191.61 -7.50 195.47 191.61 -7.50 195.47 0.00
140 104.77 -68.97 151.52 92.75 -130.15 193.95 0.00 1 182.09 -27.09 197.03 182.09 -27.09 197.03 0.00
17 92.75 -130.15 193.95 123.12 -98.17 192.05 0.00 132 249.11 8.55 244.95 249.11 8.55 244.95 0.00
113 123.12 -98.17 192.05 119 238.75 -10.21 244.02 238.75 -10.21 244.02 0.00

55 COMB1 0.00 75 COMB1 -15.60 308.31 300.22 -15.60 308.31 0.00
17 19.05 -119.79 130.37 19.05 -119.79 130.37 0.00 132 300.22 -3.02 242.44 240.91 -3.02 242.44 0.00
113 69.57 -127.19 172.81 69.57 -127.19 172.81 0.00 119 240.91 -71.30 223.45 179.10 -71.30 223.45
5 133.75 -72.83 181.48 133.75 -72.83 181.48 0.00 169 179.10 -44.40 133.34 105.47 -44.40 133.34 0.00
131 176.64 -72.59 222.02 176.64 -72.59 222.02 156 105.47 0.00

56 COMB1 292.04 154.89 -181.97 292.04 0.00 76 COMB1
139 154.89 -181.97 270.56 123.67 -186.62 270.56 0.00 1 182.09 -27.09 197.03 182.09 -27.09 197.03 0.00
176 123.67 -186.62 328.01 230.52 -145.00 328.01 0.00 13 191.61 -7.50 195.47 191.61 -7.50 195.47 0.00
127 230.52 -145.00 305.75 200.77 -151.12 305.75 0.00
164 200.77 -151.12 119 238.75 -10.21 244.02 238.75 -10.21 244.02 0.00
133 249.11 8.55 244.95 249.11 8.55 244.95 0.00

57 COMB1 353.12 240.01 -165.46 353.12 0.00 77 COMB1 -3.02 242.44 240.91 -3.02 242.44 0.00
127 240.01 -165.46 357.44 248.00 -161.73 357.44 0.00 119 240.91 -15.60 308.31 300.22 -15.60 308.31 0.00
164 248.00 -161.73 338.17 222.63 -166.50 338.17 0.00 133 300.22 -44.40 133.34 105.47 -44.40 133.34 0.00
140 222.63 -166.50 342.53 230.71 -162.86 342.53 0.00 156 105.47 -71.30 223.45 179.10 -71.30 223.45 0.00
177 230.71 -162.86 170 179.10

58 COMB1 375.58 226.74 -206.78 375.58 0.00 78 COMB1 0.00
140 226.74 -206.78 375.90 225.41 -208.54 375.90 0.00 13 130.62 -28.70 147.09 130.62 -28.70 147.09 0.00
177 225.41 -208.54 379.69 227.68 -210.64 379.69 0.00 15 140.37 -19.91 151.31 140.37 -19.91 151.31 0.00
113 227.68 -210.64 380.02 226.35 -212.39 380.02 0.00 133 158.35 -21.42 170.08 158.35 -21.42 170.08 0.00
150 226.35 -212.39 123 168.04 -12.58 174.67 168.04 -12.58 174.67

59 COMB1 398.90 196.77 -262.29 398.90 0.00 79 COMB1 0.00
113 196.77 -262.29 371.22 190.85 -236.97 371.22 0.00 133 217.62 -53.73 248.88 217.62 -53.73 248.88 0.00
150 190.85 -236.97 384.08 268.68 -171.24 384.08 0.00 123 298.12 -125.18 376.64 298.12 -125.18 376.64 0.00
131 268.68 -171.24 357.46 262.02 -145.19 357.46 0.00 170 136.50 -100.83 206.31 136.50 -100.83 206.31 0.00
168 262.02 -145.19 160 223.53 -178.80 349.15 223.53 -178.80 349.15

61 COMB1 80 COMB1
7 80.97 -113.23 168.96 80.97 -113.23 168.96 0.00 15 15.59 -44.13 53.65 15.59 -44.13 53.65 0.00
136 104.35 -127.89 201.46 104.35 -127.89 201.46 0.00 6 121.72 61.94 105.42 121.72 61.94 105.42 0.00
22 125.95 -50.15 157.15 125.95 -50.15 157.15 0.00 123 57.16 -65.34 106.17 57.16 -65.34 106.17 0.00
122 150.92 -66.40 192.89 150.92 -66.40 192.89 0.00 134 163.27 40.75 147.19 163.27 40.75 147.19 0.00

62 COMB1 0.00 81 COMB1 335.96 198.60 -189.29 335.96 0.00
22 102.29 -79.38 157.74 102.29 -79.38 157.74 0.00 123 198.60 -189.29 394.96 319.50 -122.09 394.96 0.00
122 129.72 -56.17 165.13 129.72 -56.17 165.13 0.00 134 319.50 -122.09 298.98 156.00 -188.72 298.98 0.00
20 120.61 -99.30 190.75 120.61 -99.30 190.75 0.00 160 156.00 -188.72 358.56 279.79 -124.40 358.56 0.00
135 147.69 -75.73 196.80 147.69 -75.73 196.80 171 279.79 -124.40

63 COMB1 74.61 -101.18 152.82 0.00 83 COMB1 96.71 -28.26 -107.69 96.71 0.00
20 74.61 -101.18 152.82 104.77 -68.97 151.52 0.00 8 -28.26 -107.69 21.42 -1.03 -21.92 21.42 0.00
135 104.77 -68.97 151.52 92.75 -130.15 193.95 0.00 10 -1.03 -21.92 82.46 7.96 -78.19 82.46 0.00
18 92.75 -130.15 193.95 123.12 -98.17 192.05 0.00 40.25 41.07 1.70 40.25 0.00
124 123.12 -98.17 192.05 139 7.96 -78.19
128 41.07 1.70

64 COMB1 0.00 84 COMB1 319.42 146.30 -220.07 319.42 0.00
18 19.05 -119.79 130.37 19.05 -119.79 130.37 0.00 139 146.30 -220.07 322.06 207.20 -163.83 322.06 0.00
124 69.57 -127.19 172.81 69.57 -127.19 172.81 0.00 128 207.20 -163.83 297.89 128.02 -212.47 297.89 0.00
6 133.75 -72.83 181.48 133.75 -72.83 181.48 0.00 176 128.02 -212.47 299.67 189.10 -156.41 299.67 0.00
134 176.64 -72.59 222.02 176.64 -72.59 222.02 165 189.10 -156.41

65 COMB1 292.04 154.89 -181.97 292.04 0.00 85 COMB1
136 154.89 -181.97 270.56 123.67 -186.62 270.56 0.00 10 -36.82 -172.64 157.50 -36.82 -172.64 157.50 0.00
173 123.67 -186.62 328.01 230.52 -145.00 328.01 0.00 12 52.63 -147.29 179.49 52.63 -147.29 179.49 0.00
122 230.52 -145.00 305.75 200.77 -151.12 305.75 0.00 128 47.37 6.23 44.58 47.37 6.23 44.58 0.00
159 200.77 -151.12 138 160.38 8.02 156.52 160.38 8.02 156.52 0.00

86 COMB1

128 242.26 -188.07 373.66 242.26 -188.07 373.66 0.00
138 341.02 -236.14 502.59 341.02 -236.14 502.59 0.00
165 181.88 -237.53 364.28 181.88 -237.53 364.28 0.00
175 282.05 -287.02 492.84 282.05 -287.02 492.84 0.00

87 COMB1 0.00
12 135.02 -49.28 165.27 135.02 -49.28 165.27 0.00
2 102.41 -121.76 194.37 102.41 -121.76 194.37 0.00
138 -43.69 -451.64 431.46 -43.69 -451.64 431.46 0.00
110 -86.50 -513.93 476.61 -86.50 -513.93 476.61

88 COMB1 70.69 -629.55 667.71 0.00
138 70.69 -629.55 667.71 160.75 -420.79 520.14 0.00
110 160.75 -420.79 520.14 136.41 -446.35 527.95 0.00
175 136.41 -446.35 527.95 210.92 -222.04 375.00 0.00
147 210.92 -222.04 375.00

89 COMB1 0.00
2 102.41 -121.76 194.37 102.41 -121.76 194.37 0.00
14 135.02 -49.28 165.27 135.02 -49.28 165.27 0.00
110 -86.50 -513.93 476.61 -86.50 -513.93 476.61 0.00
137 -43.69 -451.64 431.46 -43.69 -451.64 431.46

90 COMB1 160.75 -420.79 520.14 0.00
110 160.75 -420.79 520.14 70.69 -629.55 667.71 0.00
137 70.69 -629.55 667.71 210.92 -222.04 375.00
147 210.92 -222.04 375.00 136.41 -446.35 527.95 0.00
174 136.41 -446.35 527.95 0.00

91 COMB1 179.49 52.63 -147.29 179.49 0.00
14 52.63 -147.29 157.50 -36.82 -172.64 157.50 0.00
16 -36.82 -172.64 156.52 160.38 8.02 156.52 0.00
137 160.38 8.02 44.58 47.37 6.23 44.58 0.00
118 47.37 6.23

92 COMB1 502.59 341.02 -236.14 502.59 0.00
137 341.02 -236.14 373.66 242.26 -188.07 373.66 0.00
118 242.26 -188.07 492.84 282.05 -287.02 492.84 0.00
174 282.05 -287.02 364.28 181.88 -237.53 364.28 0.00
155 181.88 -237.53

93 COMB1 21.42 -1.03 -21.92 21.42 0.00
16 -1.03 -21.92 96.71 -28.26 -107.69 96.71 0.00
7 -28.26 -107.69 40.25 41.07 1.70 40.25 0.00
118 41.07 1.70 82.46 7.96 -78.19 82.46 0.00
136 7.96 -78.19

94 COMB1 322.06 207.20 -163.83 322.06 0.00
118 207.20 -163.83 319.42 146.30 -220.07 319.42 0.00
136 146.30 -220.07 299.67 189.10 -156.41 299.67 0.00
155 189.10 -156.41 297.89 128.02 -212.47 297.89 0.00
173 128.02 -212.47

ANALISIS STRUKTUR BILLBOARD 4.5m x 6.00m

ANALISIS STRUKTUR
KOLOM PEDESTAL

Frame Kolom yang Dianalisis:

Nomor : 264
Dimensi : 1.5mx1.5m
Tinggi : 3.5 m

Diagram BMD :

Diagram SFD :

Diagram NFD :

Rekapitulasi: : 0 KNm
Momen : 0 KN
Gaya Geser : 724.44 KN
Gaya Aksial

Analisis dan Desain Struktur Kolom

Dimensi kolom harus disesuaikan dengan tinggi kolom, sehingga memenuhi
syarat kelangsingan.

Diketahui : : 3m 3m
Tinggi kolom : 1500 mm
Pnmpng sb.2 : (jepit-jepit)
(h) : 1.5 m
Pnmpng sb.3 : 1500 mm (1%.Ag) 1500 mm
(b) : (0,50.Asst) (sb.2)
K : 1.5 m
f'c : 0.5 1500 mm
fy : 22.5 MPa Penampang
d' : 300 MPa
d : 46 mm
Y : 1454 mm
Ag : 750 mm
Asst : 2250000 mm2
As = As' 22500 mm2
11250 mm2

Cek Kelangsingan kolom :

Iy (sb.2) = 1/12 . b3 . h

= 0.08 x 1.50 x 3.375

= 0.42 m4

A = b.h

= 1.5 x 1.5

= 2.25 m2

r = Iy

A
= 0.43 m

k.l / r = 3.46

< 22 (Dimensi OK!!)

a. Kondisi beban sentris 2227500 ) + ( 300 x 22500 )
Pn = (0,85.fc’.(Ag – Asst) + fy..Asst))
= ( 0.85 x 22.5 x
= 49350.94 kN
Mn = 0 kNm

b. Kondisi Balance 600 x 1454
xb =
600 + 300
=
ab = 969.3333

= 0.85 x 969.3
fs' = (
823.9333
=
> 969.3333 - 46 ) x 600
fs' =
969.33

571.53 MPa

300 MPa (dipakai fs'!!)

300 MPa

Cc = 0,85 . fc’ . ab . b . 10-3
= 0.85 x 22.5 x 823.933 x 1500 x 0.001
= 23636.59 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.281
= 3159.844

Ts = As . fy . 10-3
= 3375 kN

Pnb' = Cc + Cs - Ts
= 23421.43 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 12590.48 kNm

c. Kondisi Patah Desak 170% x 969.3
x=
= 1647.867 mm
ab =
= 0.85 x 1648
fs' = (
1400.687 mm
=
> 1647.867 - 46 ) x 600
fs' =
1647.9

583.25 MPa

300 MPa (dipakai fs'!!)

300 MPa

fs = ( 1454 - 1648 ) x 600
fs pakai 1647.9

= -70.59 MPa
< 300.00 MPa
= -70.59 MPa

Cc = 0,85 . fc’ . ab . b . 10-3 0.001
= 0.85 x 22.5 x 1400.69 x 1500 x
= 40182.2 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.281
= 3159.844

Ts = As . fs . 10-3
= -794.1176 kN

Pnb' = Cc + Cs - Ts
= 44136.16 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 3660.785 kNm

d. Kondisi Patah Desak 140% x 969.3
x=
= 1357.067 mm
ab =
= 0.85 x 1357
fs' = (
1153.507 mm
=
> 1357.067 - 46 ) x 600
fs' =
1357.1

579.66 MPa

300 MPa (dipakai fs'!!)

300 MPa

fs = ( 1454 - 1357 ) x 600
fs pakai 1357.1

= 42.86 MPa
< 300.00 MPa
= 42.86 MPa

Cc = 0,85 . fc’ . ab . b . 10-3 0.001
= 0.85 x 22.5 x 1153.51 x 1500 x 0.001
= 33091.22 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.281
= 3159.844

Ts = As . fs . 10-3
= 482.1429 kN

Pnb' = Cc + Cs - Ts
= 35768.92 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 8296.903 kNm

e. Kondisi Patah Tarik 60% x 969.3
x=
= 581.6 mm
ab =
= 0.85 x 581.6
fs' = (
494.36 mm
=
> 581.6 - 46 ) x 600
fs' =
581.6

552.54 MPa

300 MPa (dipakai fs'!!)

300 MPa

fs = ( 1454 - 581.6 ) x 600
fs pakai 581.6

= 900.00 MPa
< 300.00 MPa
= 300.00 MPa

Cc = 0,85 . fc’ . ab . b . 10-3
= 0.85 x 22.5 x 494.36 x 1500 x
= 14181.95 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.281
= 3159.844

Ts = As . fs . 10-3
= 3375 kN

Pnb' = Cc + Cs - Ts
= 13966.8 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 11731.5 kNm

f. Kondisi Patah Tarik 30% x 969.3
x=
= 290.8 mm
ab =
= 0.85 x 290.8
fs' = (
247.18 mm
=
> 290.8 - 46 ) x 600
fs' =
290.8

505.09 MPa

300 MPa (dipakai fs'!!)

300 MPa

fs = ( 1454 - 290.8 ) x 600
fs pakai 290.8

= 2400.00 MPa
< 300.00 MPa
= 300.00 MPa

Cc = 0,85 . fc’ . ab . b . 10-3 0.001
= 0.85 x 22.5 x 247.18 x 1500 x
= 7090.976 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.281
= 3159.844

Ts = As . fs . 10-3
= 3375 kN

Pnb' = Cc + Cs - Ts
= 6875.82 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 9042.388 kNm

g. Kondisi momen murni 11250 x 300 1500
a= 0.85 x 22.5 x

= 117.65 mm

Mn = As . fy . (d - a/2) . 10-6
= 4708.721 kNm

Pn = 0 kN

Penulangan Kolom Biaxial

• Diketahui :

data output SAP2000

Pu : 724.44 kN
0 kNm
Mu.x : 0 kNm

Mu.y : Diagram Interaksi Kolom
5,000 10,000 15,000 20,000 25,000 30,000
Data Kolom : : 22.5 MPa Pn (kN) 80,000 1%
f'c : 300 MPa 70,000 2%
fy : 1500 mm 60,000 3%
h : 1500 mm 50,000 4%
b : 2250000 mm2 40,000 Kolom
Ag 30,000
20,000
• Penyelesaian : 10,000

Mn.x = 0 0
0.65 0
= 0.00 kNm

Mn.y = 0.00
= 0.65
0.00 kNm Mn (kNm)

Pn = 724.44
0.65

= 1114.52 kNm

Momen uniaksial ekuivalen yang diperlukan berdasarkan momen terhadap sumbu x (Mo.x) karena momen yang
terbesar adalah Mn.x sehingga digunakan Mo.x sehingga digunakan Mo.x untuk perencanaan.

Mo.x = Mn.x + Mn.y (b/h) . ((1-β)/β)
= 0.00 kNm

Data Mo.x dan Pn selanjutnya dimasukkan ke dalam grafik dan diperhatikan posisinya
Karena posisinya dibawah 1%, maka digunakan As total = 1% . Ag

As.tot. = ρ x Ag - A pipa - A angkur As tiang monopole
= 5,857.16 mm2
Diameter = 18 inci
25 mm 45.72 cm
= 457.2 mm
12 bh.
Diameter tul. = = 9.35 mm
5887.5 457.2 mm
2250000 Tebal = 447.85 mm
164,089.99 mm2
Jumlah (n) = 0.00 Diam. Luar = 157,447.15 mm2
6,642.84 mm2
Diam. Dlm. =

Cek ρ ada = Luas Luar =

Luas Dalam =

= Luas real =

Angkur = 10,000.00 mm2
L 50 (4bh.)

• Penyelesaian : 600 x 1454
xb =

600 + 300

= 969.33333
ab =
0.85 x 969.3333
=
fs' = ( 823.93333

969.33333 - 46 ) x 600

969

= 571.53 MPa
>
= 300 MPa (dipakai fs'!!)

fs' dipakai 300 MPa

Cc = 0,85 . fc’ . ab . b . 10-3

= 0.85 x 22.5 x 823.93 x 1500 x 0.001

= 23636.588 kN

Cs = As' . (f's - 0,85 . f'c) . 10-3
= 11250 x 0.280875
= 3159.8438

Ts = As . fy . 10-3
= 3375 kN

Pnb' = Cc + Cs - Ts
= 23421.431 kN

Mnb = Cc . (Y - a/2) + Cs . (Y - d') + Ts . (d - Y)
= 12590.484 kNm

Cek : Pn < Pnb (Keruntuhan Tarik!!)

1114.52 23421.43

• Penulangan Geser • Gambar Penulangan :

Nu = 1238.36 kN φ 12 - 125
Vu = 0.00 kN
Vu / φ = 0.00 kN

Vc = 1792.02 kN

1/2 Vc = 896.01 kN

> 0.00 kN (Perlu tul.Geser!!)

Diamtr.sgkg. = 12 mm 12 D 25

Av = 226.08 mm2

S1 = 135 mm (dicari yang terkecil.)
S2 = 727 mm

S dipakai = 125 mm

*****

ANALISIS STRUKTUR BILLBOARD 4.5m x 6.00m

ANALISIS STRUKTUR
PONDASI FOOTPLATE

PONDASI FOOTPLATE BUJUR SANGKAR

TIPE : FOOTPLATE

1. STANDARD dan REFERENSI

- Peraturan Pembebanan Indonesia untuk Gedung, 1987;
- Peraturan Perencanaan Tahan Gempa Indonesia untuk Gedung, 2002;
- Tata Cara Perhitungan Struktur Beton Bertulang, 2002;
- Peraturan Perencanaan Bangunan Baja Indonesia, 2000;
- American Concrete Institute (ACI) 318-83;
- AISC - LRFD, 1993;
- Konstruksi Beton I, Delta Teknik Group, 2007;
- Code / Standard Nasional dan Internasional lain yang relevan.

2. KRITERIA ANALISIS

2.1 DATA PONDASI

Beban vertikal ( P ) = 73.87 ton
3.47 tonmeter
Momen ( M ) = 4.64 kg / cm2

Daya dukung tanah ( σ ijin ) = = 46.40 ton / m2

( Footplate memakai tegangan ijin tanah… lihat tabel )

2.2 MATERIAL

Spesifikasi material yang digunakan dalam analisis adalah :

Beton Bertulang (K) = K - 225 = 2,250.00 ton / m2
Compressive strength ( f'c) = 2,250.00 ton / m2
at service ( Ec ) = 2,000,000.00 ton / m2
Modulus of elasticity

Baja Tulangan ( fy ) = BJTP 24 / 30 dan BJTD 30 / 40
Mutu baja ( Es ) = 24,000.00 ton / m2
Tegangan leleh = 20,000,000.00 ton / m2
Modulus of elasticity

Berat Jenis = 7.85 [ton/m3]
Berat jenis baja = 2.40 [ton/m3]
Berat jenis beton

3. PERHITUNGAN DIMENSI STRUKTUR

3.1 LEBAR PONDASI FOOTPLATE 73.87 ton
Detail ukuran terlampir
P=

M = 3.47 tm Asumsi awal lebar pondasi
e = M / P = 0.0469 m
B
B agar pada pelat pondasi bekerja
tekanan (tegangan) sejenis (tekan) maka :

e < 1/6B
0.047 < 1 / 6 B

B > 0.28 m

Coba B = 2.00 m ( trial and error )

1.50 m W= berat pondasi = 7.39 ton
A= m2
q= luas pelat = 4.00
46.40
q2 = P+ W (1+ 6e ) 46.40
q1 = A B

23.17 t/m2 ( < σ tanah = t/m2)
t/m2)
17.46 t/m2 ( < σ tanah =

Cek q1 dan q2 terhadap σ :
q2 Dimensi OK!
q1 Dimensi OK!

3.2 TEBAL PELAT PONDASI FOOTPLATE (BAGIAN UJUNG PELAT) Coba h = 0.30 m ( trial and error )
Detail ukuran terlampir ht = 0.35 m

1.50 m

q3' = 11.83 ton / m2
q3'' = 15.26 ton / m2

21 q netto = 13.54 ton / m2 (harga rata2)

h ht

0.10 1.80 0.10 a = 44.99
q1 q3 q4 q2 b =
τ bpu = 2.16
= 20.8 ton / m2
2.08 kg / cm2

τ * bpu = 15.00 kg / cm2

τ bpu < τ * bpu (persyaratan SNI)

Cek ketebalan :
Ketebalan OK!

Jadi ketebalan yang dipakai untuk ujung pelat adalah :
= 0.35 m

2.00 m
1.80

3.3 PENULANGAN PELAT DAN CEK KETEBALAN PANGKAL PELAT

q1 = 17.46 ton / m2
q2 = 23.17 ton / m2
q3 = 13.54 ton / m2
q4 = 14.97 ton / m2

Untuk 1 meter lebar pelat : Mx = 0.64 tonm

2

Cu = 14.54

q4 q2 q = 0.025 (tabel Prof. Wiratman)

δ = 0.20

(δ : biasanya Tul. Tekan Pondasi sebesar 0.2 Tul. Tarik)

0.25 m A= 6.07 cm2 (jika A terlalu besar maka tambah tebal pelat)
Ø 16 = 4.00 bh.
2 s= 28.00 cm > 5.00 cm
Tulangan OK!
=

Jika dirasakan tulangan masih terlalu rapat maka tebal pangkal pelat bisa ditambah :
h ujung = 0.30 m
h pgkl = 0.30 m

Cu = 14.54 q = 0.025 (tabel Prof. Wiratman)
δ = 0.20

(δ : biasanya Tul. Tekan Pondasi sebesar 0.2 Tul. Tarik)

A= 6.07 cm2 5.00 cm
Ø 16 = 4.00 bh.
s= 28.00 cm >
Tulangan OK!
=

Jadi digunakan Ø 16 - 28.00

A' = 1.21 cm2 5.00 cm
Ø 10 = 2.00 bh.
s= 85.00 cm >
Tulangan OK!
=

Jadi digunakan Ø 10 - 85.00

3.4 CEK GESER PADA POTONGAN 2 - 2

D 2-2 = 9.54 ton ( untuk selebar B )

τ bu = 2.65 kg / cm2 < τ *bu
= 2.65 kg / cm2 < 9.50 ( untuk beban tetap )

Catatan :

1. Jika τ bu > τ * bu, maka tebal pelat harus diperbesar

2. Dari hasil perhitungan, maka tebal pelat :

pada permukaan kolom = 35.00 cm ( ditambah selimut beton )

pada ujung pelat = 35.00 cm ( ditambah selimut beton )

3.5 CEK BERAT SENDIRI PONDASI

B = 2.00 m

Berat sendiri = 3.36 ton < 7.39 ton ( taksiran )

Perhitungan OK!

( Jika berat sendiri setelah dihitung ternyata lebih besar dari taksiran semula,

maka perhitungan diulang lagi, atau dilakukan pengecekan nilai q )

Cek terhadap q =

q max. = 28.96 ton /m2 < 46.40 ton/m2
Perhitungan selesai!

4. GAMBAR PENULANGAN STRUKTUR

1.50 m

∅ 10 - 250

0.35 0.35
280
∅ 16 -

∅ 10 - 250 2.00 m

∅ 16 - 280
