Riello Brochure

1

Triple sentry to 2
secure your power

Raffaele Librelotto

Danang, 26/09/19

Reliable Power for a sustainable World

Contents

1Product Overview 2 Sales Models & Accessiories
3Feature’s Details 4 Sell Our Value
5 Service Approach

3

1 Product Overview

4

Background MST 60-80-100

Riello Multi Sentry 10-100 kVA facts MST 10-15-20-30-40
MCM 10-15-20
 13 years production (10-20 kVA released Nov 2006) MCT 10-15-20
 Thousands units produced every year
 Product flexibility
 Reliability achievement

5

Market needs MST 10-15-20-30-40

Multi Sentry 10-20 Vs. Market MCM 10-15-20
MCT 10-15-20
 Technological advancement
 High performances
 Output pf 0.9 -> Output pf 1
 IT new technology progress -> Mid-range market growth
 Green approach

6

First of all: Flexibility! Active - ACT Xtend - XTD

Compact - CPT 10-15-20 kVA/kW 10-15-20 kVA/kW
3-3 (S3T) 3-3 (S3T)
10-15-20 kVA/kW 3/1-1 (S3M) 3/1-1 (S3M)
3-3 (S3T)
3/1-1 (S3M)

 280x840x700 (WxDxH)  380x850x1025 (WxDxH)  440x840x1320 (WxDxH) 7
 0.24 sqm footprint  0.33 sqm footprint  0.37 sqm footprint
 One battery string  Two battery strings  Three battery strings

Sentryum: UPS Single line drawings

Single Input Dual Input

8

2 Sales Models & Accessories

9

Compact version – Highlights

Front  Touch screen graphic display
 UPS status led
Rear  Front cover
 Cold start / Connectivity interfaces
 Communication slots
 SWOUT / SWIN / SWBATT (Internal)
 SWMB
 In/Out terminals-cables
 1x 40 battery blocks (Optional)

10

Active version – Highlights

Front  Touch screen graphic display
 UPS status led
Rear  Cold start button
 SWBATT (Internal) / SWIN / SWBYP /SWOUT
 SWMB
 In/Out terminals-cables
 2x 40 battery blocks (Optional)
 Connectivity interfaces
 Communications slots

11

Xtend version – Highlights

Front  Touch screen graphic display
 Cold start button
Rear  UPS status led 12
 SWBATT (Internal)
 SWIN / SWBYP / SWMB /SWOUT
 In/Out terminals-cables
 3x 40 battery blocks (Optional)
 Connectivity interfaces
 Communications slots
 Schuko soket (10A)

Compact - Active – Xtend: Outfit summary table

Feature Compact Active Xtend

Power range 10-15-20 kVA 10-15-20 kVA 10-15-20 kVA 13
Output Voltage 3 ph / 1 ph 3 ph / 1 ph 3 ph / 1 ph
Terminal / cables accessibility
Front door Rear, dedicated terminal cover Bottom front side Bottom front side
Castors No, front cover Yes Yes
Yes
Switches Yes (SWIN, SWOUT, SWMB) Yes (SWIN, SWOUT, SWBYP, SWMB)
No Yes (SWIN, SWOUT, SWMB) Yes standard
DI (Separate bypass input line and switch) SWBYP optional
Battery fuse holder Yes 1x 40 blocks Yes, 1÷3x 40 blocks
Internal batteries Yes horizontal Yes (optional Ex-work/on site) Yes, vertical
Cold Start Yes internal battery
Display 5” Touch Screen (Resistive) No Yes, 1÷2x 40 blocks Yes
UPS status led Yes standard
Embedded communication board Yes horizontal
(R.E.P.O. In/Out contacts/USB/RS232) Yes
Communication slots
Additional Input signals Yes
(External Sync and Temp Battery Box)
Schuko socket (Powered upstream SWOUT) Yes

Yes

No

Sentryum: Connectivity interfaces Same layout for

Communication Compact
board (standard): Active
Xtend
 R.E.P.O.
 5x programmable Other interface
opto insulated inputs ports:
 4x programmable
output contacts  Parallel card
(24VDC/30VAC – 1A) (optional)
 USB port  Slot for
 RS 232 port RJ10 Communication and
contact optional card
 Slot for
Communication
optional card

14

Sentryum: Internal back up time

1÷3 Strings
40/80/120 blocks

1÷2 Strings
40/80 blocks

1x Strings
40 blocks

Model / Battery type 7Ah 9Ah 7Ah 9Ah 7Ah 9Ah

S3T/S3M 10 kVA 11 16 28 45 52 70

S3T/S3M 15 kVA 6 9 17 24 28 45

S3T/S3M 20 kVA N.A. 6 11 16 19 28

15

Sentryum: Battery cabinets

BBOX TYPE BB 1320 (9 Ah) BB 1600 (40 Ah) BB 1900 (112 Ah)

S3M/S3T 10 kVA 70 (153 c/w UPS battery) 116 N.A.
S3M/S3T 15 kVA 45 (98 c/w UPS battery) 70 200
S3M/S3T 20 kVA 28 (70 c/w UPS battery) 50 150

Same MST Battery Cabinet: 16

 Same approach
 Same batteries
 Reduced stock

Sentryum: Options and accessories OT Version Air filter

OPTIONS & ACCESSORY IP X1 IP X1
(Opt 1) (Opt 1)
 Parallel card On site On site
 Battery kit (battery fitting inside UPS)
 Double Input
 Synchro kit
 Temperature sensor
 Extended Recharge battery current (ER version)
 Output isolation transformer
 Front door air filter
 IP X1 / 3X Protection

IP 2X IP 3X 17
(Standard) (Opt 2)
Ex-work
IP 21 Version
IP 31 Version

Compact - Active – Xtend: Options & Accessories summary table

Feature Compact Active Xtend

Parallel Optional, Parallel card S3M/S3T
Kit Internal battery installation
Battery connection set for Battery connection set for Battery connection set for
DI (separate bypass input line and switch) COMPACT S3T/S3M ( 40 batt) ACTIVE S3T/S3M (2x 40 batt) XTEND S3T/S3M (3x 40 batt)
External Synchro includes support shelves + cables includes support shelves + cables includes support shelves + cables
Battery temperature sensor On site installation kit S3T/S3M
Extended recharge (ER) Not Applicable Standard
Or
IP X1 Protection Ex-work fitting

Front door air filter Optional, On site installation kit S3T/S3M

Internal Output transformer Optional, On site installation kit

Optional Ex-work fitting to move from:

6 to 12 A S3M/S3T 10kVA

6 to 20 A S3M/S3T 15 kVA

6 to 20 A S3M/S3T 20 kVA

Optional, On site installation kit on

Not Applicable Not Applicable IP20 (standard frame)
Not Applicable
Not Applicable IP30 (special frame)

Optional, On site replacing door

Not Applicable Or

Ex-work fitting

S3M 10-15-20 OT version (Ex-work)

Not Applicable Or 18

S3T 10-15-20 OT version (Ex-work)

Sentryum: Demo version for show room

Demo units

 Compact / Active / Xtend
 User interfaces included (switches /communication interfaces/display)
 Display running in demo mode
 NO power components/cards/batteries
 Single phase power supply (IEC+ schuko plug)

DS3TK10CESPORUA DS3TK10BESPORUB DS3TK10JESPORUB 19

3 Feature’s Details

20

Sentryum Technologies

Technologies

 State of the art components
 Latest generation of DSP Dual core microprocessor
 Advanced digital control
 Last generation IGBT
 Graphic display / Status led

21

Sentryum: Technical specification

Technical Specification

 Range: 10-15-20 kVA/ KW (up to 40°C NO downgrading)
 Parallel: up to 8 units
 Input voltage: 400V +/-20% (-40% @ 50% load)
 THDi <3% / PF 0.99 / THDv <1.5% Non-linear load
 Battery charger: 6 Amps (12 / 20 ER version)
 Inverter overload: 103% Infinite / 110% 60 min / 125% 10 min / 150% 60 sec (@40°C)
 Inverter short circuit: 2.7 In x 200ms + 1.5 In x 300ms
 Bypass overload: 110% infinite 125% 60 min 150% 10 min 200% 1 min
 Overall efficiency: up to 96.5% from 25 to 75% of load rate

270%

More power to clear the fault

150%

30%

0 500 ms 22
200 ms + 300 ms

Sentryum: Remarkable features

Remarkable features

 Three models, extensive range of solutions
 Compactness to minimize
 Exceptional efficiency for the range
 High power availability (kVA=KW / overload / inverter short circuit)
 Smart Battery Management (battery controls / ER version)
 Maximum reliability (advanced control/ smart ventilation/ redundant power supply)
 Installation Flexibility (Dual Input / isolation transformer / higher IP rating / air filter)
 Embedded communication board to interface the environment
 Colored graphic display / led status bar to ease the monitoring

23

Sentryum at a glance 24

TECHNICAL SPECIFICATION

 Range: 10-15-20 kVA/ KW (up to 40°C NO downgrading)
 Parallel: up to 8 units
 Input voltage: 400V +/-20% (-40% @ 50% load)
 THDi <3% / PF 0.99 / THDv <1.5% Non-linear load
 Battery charger: 6 Amps (12 / 20 ER version)
 Inverter overload: 103% Infinite / 110% 60 min / 125% 10 min / 150% 60 sec (@40°C)
 Inverter short circuit: 2.7 In x 200ms + 1.5 In x 300ms
 Bypass overload: 110% Infinite 125% 60 min 150% 10 min 200% 1 min
 Overall efficiency: up to 96.5% from 25 to 75% of load rate

REMARKABLE FEATURES

 Three models, extensive range of solutions
 Compactness to minimize
 Exceptional efficiency for the range
 High power availability (kVA=KW / overload / inverter short circuit)
 Smart Battery Management (battery controls / ER version)
 Maximum reliability (advanced control/ smart ventilation/ redundant power supply)
 Installation Flexibility (Dual Input / isolation transformer / higher IP rating / air filter)
 Embedded communication board to interface the environment
 Colored graphic display / led status bar to ease the monitoring

Sentryum Documentation

Further more 25

 Accessory’s manuals (on TEC area)
 Photo package (on TEC area)
 Video Riello (on Riello UPS YouTube channel)

Sentryum Certificates

26

4 Sell Our Value

27

Multy Sentry Vs Sentryum

Technologies Performances
MST 10-20 S3T 10-20

Flexible Choice Easy operations

28

Multy Sentry Vs Sentryum: TECHNOLOGIES

Technologies

 DSP+micro processor MST 10-20 Control S3T 10-20  Dual Core DSP+ Advanced PLD
 Discrete components Power components  IGBT modules
Part interconnection
 Separated components Inverter topology  Integrated components

 Two level Inverter  Three level Inverter

04 29
Benefits: High efficiency, Fast dynamic response, High power availability, High MTBF

Multy Sentry Vs Sentryum: PERFORMANCES

Performances

 0.9 / < 3 with no linear load PF / THDV  1 / <1.5 with no linear load
Efficiency  96.5% (~500€/y for 20 kVA)
 94% MST 10-20 Overload S3T 10-20
Short circuit
 125% 1min./ 150% 5 sec Volume  125% 10min./ 150% 1 min.

 150% for 500ms  270% 200ms + 150% 300ms

 MCT (0.25) dm3 / MST (0.494) dm3  CPT (0.165) / ACT (0.33) dm3

0 5 XTD (0.488) dm3

Benefits: Zero impact source, High power quality, Energy bill reduction, Easy handling 30

Multy Sentry Vs Sentryum: FLEXIBLE CHOICE

Flexible Choice

 Two cabinets MST 10-20 Solutions S3T 10-20  Three cabinets
 1÷2 x 40 batteries Back up time levels  1÷3 x 40 batteries

 ER version 6 to 10 A ER Version  ER version 6 to 12/20 A
Operation flexibility
 IP XX special / On door display /  IP X1 kit / On frame display /
Program. contact (5In+4Out)
DB 15 contact (3In+4Out)
4
0

Benefits: High installation flexibility, Long inbuilt backup time, Easy on site operations 31

Multy Sentry Vs Sentryum: EASY TO USE

Easy operations

 BW LCD display + 6 led MST 10-20 Local monitoring S3T 10-20  Graphic touch s. + Led status
 Different port layout Communication interface  Same port layout

 17 PCB/NO terminal cover / Serviceability  14 PCB / gland plate / 2nd PS
Power component replacement
 Capacitors embedded Know-how/product experience  Separate capacitor card

 Consolidated / well known  New one / learning

1 4

Benefits: Easy and intuitive display monitoring, Coherent offer, Minimize maintenance impact 32

Triple sentry to secure your power 33

5 Service approach

34

Display

35

Level of access

 3 Level of access for different levels of protection

 Default Setting: Only Expert Password

 User: Monitoring + System Information
 PowerUser: Commands and Display Configuration
 Expert: System Configuration

36

‘Basic’ Configuration from the Display:

37

‘Advanced‘ Complete Configuration with the Service Software (UComS3)

 Simply clean layout
 Useful settings descriptions
 Extra Features

38

Service Software: UComS3

 Configure (Configurator)

 Data Download (Downloader)

 Analyze (Event Analyzer)
 Analyze (History Analyzer)

 Monitor (Status Analyzer)
 Monitor (Oscilloscope)

 Service (Debug)
 Service (Calibrate)

39

Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World
Reliable Power for a sustainable World
Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World Reliable Power for a sustainable World

Reliable Power for a sustainable World

40

The content of this presentation (including texts, graphics, photos, tables, logos, etc.)
and the presentation itself are protected by copyright.

They were created by RPS SpA (Riello UPS) independently.

Any dissemination of the presentation and/or content or parts
thereof is only permitted with written permission from RPS SpA. Without written
permission of RPS SpA. this document and/or parts thereof may not be passed on,
modified, published, translated or reproduced, either by photocopies, or by others –
in particular by electronic procedures. This reservation also extends to inclusion in or

evaluation by databases. Infringements will be prosecuted.

41
