Econ Ball Valves & Accessories

Ball Valves & Accessories

2

Proven quality since 1892

Econosto, part of the ERIKS group, has been offering a wide variety of engineered products since 1892.
By focusing on technical superiority along with guaranteed quality, Econosto’s line of Econ® products are
now sold in most of the major markets throughout the world. Given the strength of the North American
markets, the Econ® brand of ball valves, actuators, and accessories are now being inventoried and sold in
the United States and Canada. Primary amongst the targeted market segments are the following:

• Chemical and Petrochemical • Oil and Gas
• Food and Beverage • Original Equipment Manufacturing
• HVAC • Pulp and Paper
• Marine • Semiconductor
• Mining • Water and Wastewater

Econ® Valve Products Econ® Products Featured:
Full Port, Flanged Floating Ball Valve with Spring Return
Econosto offers a variety of valve and valve related products. Actuator and Quarter-Turn, Single Acting Smart Positioner.
Included are ball valves, butterfly valves, double block and
bleed expanding plug valves, control valves, solenoid valves,
pneumatic and electric valve actuators, valve position limit
switches and analog and digital valve positioners under its
own Econ® label and reputable leading brands. Econosto
is constantly looking to enhance and improve its Econ®
valve related offering and new products are being added
constantly.

Up to Date Product Features

The Econ® brand of products are designed around today’s
standards and expectations that come from various agencies
and customer groups. Throughout its extensive product
offering, Econ® products have added features, which make
them suitable for a wide spectrum of applications.

Proven Quality

Quality is the driving force behind the Econosto and it’s
Econ® brand of products. Econosto has its own teams of
Quality Inspectors stationed strategically close to or within
their manufacturing sites in order to guarantee that their
high quality standards are rigidly adhered to.

An increasing number of customers rely upon Econ®
products because there is a low cost to value ratio. This
means that Econ® products are not only cost competitive
but also perform as well as or better than more expensive
products.

3

E10: ASME Class 150

2 Piece, Full Port, Flanged End Ball Valve with Direct Mount Actuation Design

Description

The Econ® E10 Series is a two piece, full port, flanged end
ball valve with ISO 5211 compliant direct mount actuation
pad. The E10 is available in sizes ranging from ½” to 8” with
ASME Class 150 flanges. Valve bodies are made of either
CF8M or WCB with 316SS trim and a variety of seat materials
to choose from.

Features

•  Size Range: ½” – 8”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe to API 607 6th Edition
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  ATEX 94/9/EC (Ex II 2 G-D EX-c II) Anti-static Design
•  TFM 1600 Seat Material (PTFE, RTFE, TFE/SS Options)
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-Luft (VDI 2440, Sec. 3.3.1.3) Certified Live-loaded

Stem Packing
•  Lockable Lever Handle or “T” Handle
•  IEC 61508, SIL 2 capable
•  30° & 60° V-Notch Optional Control Ball

Standards

•  Design: ASME B16.34, API 608
•  Fire Safe: API 607, ISO 10497
•  Face to Face: ASME B16.10
•  Wall Thickness: ASME B16.34
•  End Flange: ASME B16.5
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material Item Component Material

1 Body A351-CF8M A216-WCB 12 Bushing 304SS 304SS

2 End Cap A351-CF8M A216-WCB 13 Gland 316SS 316SS

3 Ball 316SS 316SS 14 Belleville Washer 301SS 301SS

4 Ball Seat TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE 15 Retaining Nuts A194-8 A194-8

5 Body Gasket 316 Spiral Wound + GRAFOIL 316 Spiral Wound + GRAFOIL 16 Stop-Lock-Cap 304SS 304SS

6 Bolt A193-B8 A193-B7 17 Lever/Pipe Sleeve1 Plastic Vinyl Plastic Vinyl
Bolt Nut A194-8 A194-2H
18 Lever 304SS 304SS

7 Stem 316SS 316SS 19 Locking Device 304SS 304SS

8 Anti-Static Device 316SS 304SS 20 Stop Bolt A193-B8 A193-B8

9 Thrust Washer PTFE PTFE 21 T-Handle A53 + Zn Plated A53 + Zn Plated

10 O-Ring FKM (Viton) FKM (Viton) 22 Handle Adapter CF8 CF8

11 Stem Packing GRAFOIL GRAFOIL 1 Color: Blue
Note: 8” supplied without operator. Gear operators are available on request.

4

14 F 15 16 M 4 x Ø O2 20 Ø N1
E Ø N2
13 19 18 17 M
12 5 4 x Ø O1
11 6
10 4
9
B- h T Sizes 22 21 17
8 L 3” - 6”
7
3

2

1

Dimensions

E10: Class 150 - Dimensions in Inches (in)

SIZE Ød L ØA T B Ø h H H1 M F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 0.59 4.25 3.55 0.32 4 0.63 1.89 3.07 5.71 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
3/4" 0.79 4.61 3.94 0.35
1" 0.98 5.00 4.33 0.38 4 0.63 2.09 3.31 5.71 0.35 0.24 0.24 0.35 1.42 (F03) 1.97 (F05)
1-1/4" 1.26 5.51 4.53 0.44
1-1/2" 1.50 6.50 5.12 0.50 4 0.63 2.30 3.55 6.90 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)
2" 1.97 7.01 5.91 0.56
3" 2.99 8.00 7.49 0.69 4 0.63 2.80 4.02 6.90 0.43 0.24 0.35 0.43 1.65 (F04) 2.76 (F07)
4" 3.94 9.02 9.06 0.88
5" 4.92 14.03 10.05 0.88 4 0.63 2.99 4.33 7.49 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)
6" 5.91 15.52 11.03 0.94
8" 7.87 18.01 13.59 1.06 4 0.75 3.23 4.53 7.49 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

4 0.75 4.41 6.94 11.82 0.67 0.35 0.43 0.67 2.76 (F07) 4.02 (F10)

8 0.75 5.51 8.31 15.76 0.87 - 0.43 0.87 - 4.02 (F10)

8 0.88 7.21 10.36 23.64 1.06 0.55 - 1.06 4.93 (F12) -

8 0.88 8.04 11.19 31.52 1.06 0.55 - 1.06 4.93 (F12) -

8 0.88 9.97 13.16 31.52 1.06 0.55 - 1.06 4.93 (F12) -

E10: Class 150 - Dimensions in Millimeters (mm)

SIZE Ød L ØA T B Ø h H H1 M F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

DN15 15 108.0 90.0 8.0 4 16.0 48.0 78.0 145.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)
DN20 20 117.0 100.0 8.9
DN25 25 127.0 110.0 9.6 4 16.0 53.0 84.0 145.0 9.0 6.0 6.0 9.0 36 (F03) 50 (F05)
DN32 32 140.0 115.0 11.2
DN40 38 165.0 130.0 12.7 4 16.0 58.5 90.0 175.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)
DN50 50 178.0 150.0 14.3
DN80 76 203.0 190.0 17.5 4 16.0 71.0 102.0 175.0 11.0 6.0 9.0 11.0 42 (F04) 70 (F07)
DN100 100 229.0 230.0 22.3
DN125 125 356.0 255.0 22.3 4 16.0 76.0 110.0 190.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)
DN150 150 394.0 280.0 23.9
DN200 200 457.0 345.0 27.0 4 19.0 82.0 115.0 190.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

4 19.0 112.0 176.0 300.0 17.0 9.0 11.0 17.0 70 (F07) 102 (F10)

8 19.0 140.0 211.0 400.0 22.0 - 11.0 22.0 - 102 (F10)

8 22.3 183.0 263.0 600.0 27.0 14.0 - 27.0 125 (F12) -

8 22.3 204.0 284.0 800.0 27.0 14.0 - 27.0 125 (F12) -

8 22.3 253.0 334.0 800.0 27.0 14.0 - 27.0 125 (F12) -

5

E10: ASME Class 300

2 Piece, Full Port, Flanged End Ball Valve with Direct Mount Actuation Design

Description

The Econ® E10 Series is a two piece, full port, flanged end ball
valve with ISO 5211 compliant direct mount actuation pad.
The E10 is available in sizes ranging from ½” to 8” with ASME
Class 300 flanges. Valve bodies are made of either CF8M or
WCB with 316SS trim and a variety of seat materials to choose
from.

Features

•  Size Range: ½” – 8”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe to API 607 6th Edition
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  ATEX 94/9/EC (Ex II 2 G-D EX-c II) Anti-static Design
•  TFM 1600 Seat Material (PTFE, RTFE, TFE/SS Options)
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-Luft (VDI 2440, Sec. 3.3.1.3) Certified Live-loaded Stem

Packing
•  Lockable Lever Handle or “T” Handle
•  IEC 61508, SIL 2 capable
•  30° & 60° V-Notch Optional Control Ball

Standards

•  Design: ASME B16.34, API 608
•  Fire Safe: API 607, ISO 10497
•  Face to Face: ASME B16.10
•  Wall Thickness: ASME B16.34
•  End Flange: ASME B16.5
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material Item Component Material

1 Body A351-CF8M A216-WCB 12 Bushing 304SS 304SS

2 End Cap A351-CF8M A216-WCB 13 Gland 316SS 316SS

3 Ball 316SS 316SS 14 Belleville Washer 301SS 301SS

4 Ball Seat TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE 15 Retaining Nuts A194-8 A194-8

5 Body Gasket 316 Spiral Wound + GRAFOIL 316 Spiral Wound + GRAFOIL 16 Stop-Lock-Cap 304SS 304SS

6 Bolt A193-B8 A193-B7 17 Lever/Pipe Sleeve1 Plastic Vinyl Plastic Vinyl
Bolt Nut A194-8 A194-2H
18 Lever 304SS 304SS

7 Stem 316SS 316SS 19 Locking Device 304SS 304SS

8 Anti-Static Device 316SS 304SS 20 Stop Bolt A193-B8 A193-B8

9 Thrust Washer PTFE PTFE 21 T-Handle A53 + Zn Plated A53 + Zn Plated

10 O-Ring FKM (Viton) FKM (Viton) 22 Handle Adapter CF8 CF8

11 Stem Packing GRAFOIL GRAFOIL 1 Color: Blue
Note: 8” supplied without operator. Gear operators are available on request.

6

14 F 15 16 M 4 x Ø O2 20 Ø N1
E Ø N2
13 19 18 17 M
12 5 4 x Ø O1
11 6
10 4
9
B- h T Sizes 22 21 17
8 L 3” - 6”
7
3

2

1

Dimensions

E10: Class 300 - Dimensions in Inches (in)

SIZE Ød L ØA T B Ø h H H1 M F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 0.59 5.52 3.74 0.50 4 0.63 1.93 3.11 5.71 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
3/4" 0.79 5.99 4.53 0.56
1" 0.98 6.50 4.93 0.63 4 0.75 2.30 3.51 5.71 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
1-1/4" 1.26 7.01 5.32 0.69
1-1/2" 1.50 7.49 6.11 0.75 4 0.75 2.50 3.74 6.90 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)
2" 1.97 8.51 6.50 0.82
3" 2.99 11.11 8.27 1.06 4 0.75 2.80 4.02 6.90 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)
4" 3.94 12.02 8.87 1.19
5" 4.93 15.01 11.03 1.32 4 0.88 3.15 4.45 7.49 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)
6" 5.91 15.88 12.61 1.38
8" 7.88 19.78 14.97 1.64 4 0.75 3.35 4.65 7.49 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

4 0.88 4.41 6.93 11.82 0.67 0.35 0.43 0.67 2.76 (F07) 4.02 (F10)

8 0.88 5.52 8.31 15.76 0.87 - 0.43 0.87 - 4.02 (F10)

8 0.88 7.21 10.36 23.64 1.06 0.55 - 1.06 4.92 (F12) -

12 1.00 8.04 11.19 31.52 1.06 0.55 - 1.06 4.92 (F12) -

12 1.00 9.97 13.16 31.52 1.06 0.55 - 1.06 4.92 (F12) -

E10: Class 300 - Dimensions in Millimeters (mm)

SIZE Ø d L Ø A T B Ø h H H1 M F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

DN15 15 140.0 95.0 12.7 4 16.0 49.0 79.0 145.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)
DN20 20 152.0 115.0 14.3
DN25 25 165.0 125.0 15.9 4 19.0 58.5 89.0 145.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)
DN32 32 178.0 135.0 17.5
DN40 38 190.0 155.0 19.1 4 19.0 63.5 95.0 175.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)
DN50 50 216.0 165.0 20.7
DN80 76 282.0 210.0 27.0 4 19.0 71.0 102.0 175.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)
DN100 100 305.0 225.0 30.2
DN125 125 381.0 280.0 33.4 4 22.3 80.0 113.0 190.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)
DN150 150 403.0 320.0 35.0
DN200 200 502.0 380.0 41.7 8 19.0 85.0 118.0 190.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

8 22.3 112.0 176.0 300.0 17.0 9.0 11.0 17.0 70 (F07) 102 (F10)

8 22.3 140.0 211.0 400.0 22.0 - 11.0 22.0 - 102 (F10)

8 22.3 183.0 263.0 600.0 27.0 14.0 - 27.0 125 (F12) -

12 25.4 204.0 284.0 800.0 27.0 14.0 - 27.0 125 (F12) -

12 25.4 253.0 334.0 800.0 27.0 14.0 - 27.0 125 (F12) -

7

E15: ASME Class 150

1 Piece, Reduced Port, Flanged End Ball Valve with Bracket Mount Actuation Design

Description

The Econ® E15 Series is a one piece, reduced port, flanged
end ball valve with bracket mount actuation pad. The E15 is
available in sizes ranging from ½” to 6” with ASME Class 150
flanges. Valve bodies are made of either CF8M or WCB with
316SS trim and a variety of seat materials to choose from.

Features

•  Size Range: ½” - 6”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe Design Approved
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  TFM 1600 Seat Material (PTFE, RTFE Options)
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot

Standards

•  Design: ASME B16.34, API 608
•  Wall Thickness: ASME B16.34
•  End Flange: ASME B16.5
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material Item Component Material

1 Body A351-CF8M A216-WCB 12 Belleville Washer 301SS 301SS
2 End Cap A351-CF8M A216-WCB 13 Retaining Nuts A194-8 A194-8
3 Ball 14 Stop-Lock-Cap 304SS 304SS
4 Ball Seat 316SS 316SS 15 Lever/Pipe Sleeve4 Plastic Vinyl Plastic Vinyl
5 Body Gasket1 16 Lever 304SS 304SS
6 Stem TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE 17 Locking Device 304SS 304SS
7 Anti-Static Device PTFE PTFE 18 Stop Bolt A193-B8 A193-B8
8 Thrust Washer 316SS 316SS 19 T-Handle A53 + Zn Plated A53 + Zn Plated
9 Stem Packing2 20 Handle Adapter
10 Bushing3 316SS 304SS CF8 CF8
11 Gland TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE

PTFE PTFE

50% SS + 50% PTFE 50% SS + 50% PTFE 1 Fire safe: 316 Spiral Wound + GRAFOIL
316SS 316SS 2 Fire safe: GRAFOIL
3 Fire safe: 304SS
4 Color: Blue

8

M 4xØO 18
E
16 F
J

13 14 2 15
11 12
17
10

9 K
85 ØN
7

6

M 15

20

4 19
3
Sizes
1 B- h 3” - 6”
LT

Dimensions Ø N (IS0) K

E15: Class 150 - Dimensions in Inches (in) 1.65 (F04) 3/8-24 UNF
SIZE Ø d Ø d1 L Ø A T H H1 B Ø h M F J E Ø O 1.65 (F04) 3/8-24 UNF
1.97 (F05) 9/16-18 UNF
1/2" 0.49 0.39 4.25 3.51 0.40 0.91 2.92 4 0.63 5.36 0.83 0.37 0.25 0.20 1.97 (F05) 9/16-18 UNF
3/4" 0.75 0.49 4.61 3.88 0.43 0.91 2.92 4 0.63 5.36 0.83 0.37 0.25 0.20 2.76 (F07) 5/8-18 UNF
1" 0.99 0.69 5.00 4.26 0.46 1.32 3.45 4 0.63 6.70 0.85 0.40 0.35 0.24 2.76 (F07) 5/8-18 UNF
1-1/4" 1.26 0.99 5.51 4.61 0.52 1.64 3.76 4 0.63 6.70 0.85 0.40 0.35 0.24 4.02 (F10) 7/8-14 UNF
1-1/2" 1.50 1.26 6.50 5.00 0.58 1.87 4.14 4 0.63 7.88 1.26 0.59 0.38 0.32 4.02 (F10) 1-1/8 -12 UNF
2" 1.97 1.50 7.01 6.01 0.64 2.23 4.49 4 0.75 7.88 1.26 0.59 0.38 0.32 4.02 (F10) 1-3/8 -12 UNF
3" 2.99 2.38 8.00 7.51 0.77 2.97 5.59 4 0.75 11.82 1.67 0.73 0.63 0.39
4" 3.86 2.99 9.02 9.01 0.96 3.78 7.66 8 0.75 15.76 2.17 0.99 0.71 0.39 Ø N (ISO) K
6" 5.91 3.94 10.52 11.03 1.02 5.24 9.50 8 0.87 15.76 2.44 1.18 0.71 0.39
42 (F04) 3/8-24 UNF
E15: Class 150 - Dimensions in Millimeters (mm) 42 (F04) 3/8-24 UNF
SIZE Ø d Ø d1 L Ø A T H H1 B Ø h M F J E Ø O 50 (F05) 9/16-18 UNF
50 (F05) 9/16-18 UNF
DN15 12.5 10.0 108.0 89.0 10.1 23.0 74.0 4 16.0 136.0 21.0 9.5 6.3 5 70 (F07) 5/8-18 UNF
DN20 19.0 12.5 117.0 98.6 10.9 23.0 74.0 4 16.0 136.0 21.0 9.5 6.3 5 70 (F07) 5/8-18 UNF
DN25 25.0 17.5 127.0 108.0 11.6 33.5 87.5 4 16.0 170.0 21.5 10.2 9.0 6 102 (F10) 7/8-14 UNF
DN32 32.0 25.0 140.0 117.0 13.1 41.5 95.5 4 16.0 170.0 21.5 10.2 9.0 6 102 (F10) 1-1/8 -12 UNF
DN40 38.0 32.0 165.0 127.0 14.6 47.5 105.0 4 16.0 200.0 32.0 15.0 9.6 8 102 (F10) 1-3/8 -12 UNF
DN50 50.0 38.0 178.0 152.5 16.3 56.5 114.0 4 19.0 200.0 32.0 15.0 9.6 8
DN80 76.0 60.3 203.0 190.5 19.5 75.5 142.0 4 19.0 300.0 42.5 18.5 16.0 10
DN100 98.0 76.0 229.0 228.6 24.3 96.0 194.5 8 19.0 400.0 55.0 25.0 18.0 10
DN150 150.0 100.0 267.0 280.0 26.0 133.0 241.0 8 22.0 400.0 62.0 30.0 18.0 10

9

E15: ASME Class 300

1 Piece, Reduced Port, Flanged End Ball Valve with Bracket Mount Actuation Design

Description

The Econ® E15 Series is a one piece, reduced port, flanged
end ball valve with bracket mount actuation pad. The E15 is
available in sizes ranging from ½” to 4” with ASME Class 300
flanges. Valve bodies are made of either CF8M or WCB with
316SS trim and a variety of seat materials to choose from.

Features

•  Size Range: ½” - 4”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe Design Approved
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  TFM 1600 Seat Material (PTFE, RTFE Options)
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot

Standards

•  Design: ASME B16.34, API 608
•  Wall Thickness: ASME B16.34
•  End Flange: ASME B16.5
•  Face to Face: ASME B16.10
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material Item Component Material

1 Body A351-CF8M A216-WCB 12 Belleville Washer 301SS 301SS
2 End Cap A351-CF8M A216-WCB 13 Retaining Nuts A194-8 A194-8
3 Ball 14 Stop-Lock-Cap
4 Ball Seat 316SS 316SS 15 Lever/Pipe Sleeve3 304SS 304SS
5 Body Gasket1 16 Lever Plastic Vinyl Plastic Vinyl
6 Stem TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE 17 Locking Device
7 Anti-Static Device PTFE PTFE 18 Stop Bolt 304SS 304SS
8 Thrust Washer 316SS 316SS 19 T-Handle 304SS 304SS
9 Stem Packing1 20 Handle Adapter
10 Bushing2 316SS 304SS A193-B8 A193-B8
11 Gland TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE 1 Fire safe: GRAFOIL A53 + Zn Plated A53 + Zn Plated
2 Fire safe: 304SS
PTFE PTFE 3 Color: Blue CF8 CF8
50% SS + 50% PTFE 50% SS + 50% PTFE

316SS 316SS

10

M 4xØO 18
E
16 F
J

13 14 2 15
11 12
17
10

9 K
85 ØN
7

6

M 15

20

4 19
3
Sizes
1 B- h 3” - 6”
LT

Dimensions Ø N (ISO) K

E15: Class 300 - Dimensions in Inches (in) 1.65 (F04) 3/8-24 UNF
SIZE Ø d Ø d1 L Ø A T H H1 B Ø h M F J E Ø O 1.65 (F04) 3/8-24 UNF
1.97 (F05) 9/16-18 UNF
1/2" 0.49 0.39 5.52 3.74 0.58 0.91 2.92 4 0.63 5.40 0.83 0.37 0.25 0.20 1.97 (F05) 9/16-18 UNF
3/4" 0.75 0.49 5.99 4.53 0.64 0.91 2.92 4 0.75 5.40 0.83 0.37 0.25 0.20 2.76 (F07) 5/8-18 UNF
1" 0.99 0.69 6.50 4.93 0.71 1.32 3.45 4 0.75 6.70 0.85 0.40 0.35 0.24 2.76 (F07) 5/8-18 UNF
1-1/4" 1.26 0.99 7.01 5.32 0.77 1.64 3.76 4 0.75 6.70 0.85 0.40 0.35 0.24 4.02 (F10) 7/8-14 UNF
1-1/2" 1.50 1.26 7.49 6.11 0.83 1.87 4.14 4 0.88 7.88 1.26 0.59 0.38 0.32 4.02 (F10) 1-1/8-12 UNF
2" 1.97 1.50 8.51 6.50 0.89 2.23 4.49 8 0.75 7.88 1.26 0.59 0.38 0.32
3" 2.99 2.38 11.11 8.27 1.14 2.97 5.59 8 0.88 11.82 1.67 0.73 0.63 0.39
4" 3.86 2.99 12.02 8.87 1.27 3.78 7.68 8 0.88 15.76 2.17 0.99 0.71 0.39

E15: Class 300 - Dimensions in Millimeters (mm) Ø N (ISO) K
SIZE Ø d Ø d1 L Ø A T H H1 B Ø h M F J E Ø O
42 (F04) 3/8-24 UNF
DN15 12.5 10.0 140.0 95.0 14.7 23.0 74.0 4 16.0 137.0 21.0 9.5 6.3 5 42 (F04) 3/8-24 UNF
DN20 19.0 12.5 152.0 115.0 16.3 23.0 74.0 4 19.0 137.0 21.0 9.5 6.3 5 50 (F05) 9/16-18 UNF
DN25 25.0 17.5 165.0 125.0 17.9 33.5 87.5 4 19.0 170.0 21.5 10.2 9.0 6 50 (F05) 9/16-18 UNF
DN32 32.0 25.0 178.0 135.0 19.5 41.5 95.5 4 19.0 170.0 21.5 10.2 9.0 6 70 (F07) 5/8-18 UNF
DN40 38.0 32.0 190.0 155.0 21.1 47.5 105.0 4 22.3 200.0 32.0 15.0 9.6 8 70 (F07) 5/8-18 UNF
DN50 50.0 38.0 216.0 165.0 22.7 56.5 114.0 8 19.0 200.0 32.0 15.0 9.6 8 102 (F10) 7/8-14 UNF
DN80 76.0 60.3 282.0 210.0 29.0 75.5 142.0 8 22.3 300.0 42.5 18.5 16.0 10 102 (F10) 1-1/8-12 UNF
DN100 98.0 76.0 305.0 225.0 32.2 96.0 195.0 8 22.3 400.0 55.0 25.0 18.0 10

11

E20: 2000 - 1500 WOG

3 Piece Full Port Ball Valve with NPT, Socket or Butt Weld Ends
with Direct Mount Actuation Design

Description

The Econ® E20 Series is a three piece, full port ball valve with
NPT, socket or butt weld ends and ISO 5211 compliant direct
mount actuation pad. The E20 is rated to 2000 WOG in sizes
ranging from ¼” to 1” and to 1500 WOG in sizes ranging from
1-¼” to 2”. Valve bodies are made of either CF8M or WCB with
316SS trim and a variety of seat materials to choose from.

Features

•  Size Range: ¼” – 2”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe to API 607 5th Edition
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  TFM 4215 Seat Material (TFM 1600 + 15% Carbon Option)
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-Luft Design/Approved Live Loaded Stem Packing
•  30° & 60° V-Notch Optional Control Ball

Standards

•  Design: ASME B16.34, MSS SP-110, API608
•  2000 WOG for ¼” - 1”
•  1500 WOG for 1-¼” - 2”
•  Fire Safe: API 607, ISO 10497
•  Wall Thickness: ASME B16.34 Class 800
•  Pipe Thread: ASME B1.20.1
•  Butt Weld: ASME B16.25 (Ø B2 Sch 80)
•  Socket Weld ASME B16.11
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material Item Component Material

1 Body A351-CF8M A216-WCB 12 O-Ring FKM FKM
A351-CF8M A216-WCB 13 Stem Packing GRAFOIL GRAFOIL
2 Cap (Thread) A351-CF3M A216-WCB 14 Bushing 304SS 304SS
Cap (Welding) 15 Gland 316SS 316SS
316SS 316SS 16 Belleville Washer 301SS 301SS
3 Ball TFM 4215 TFM 4215 17 Retaining Nuts A194-8 A194-8
GRAFOIL GRAFOIL 18 Stop-Lock-Cap 304SS 304SS
4 Ball Seat A193-B8 A193-B8 19 Locking Device 304SS 304SS
A194-8 A194-8 20 Lever 304SS 304SS
5 Body Gasket 21 Lever Sleeve1 Plastic Vinyl Plastic Vinyl
304SS 304SS
6 Bolt 316SS 316SS 1 Color: Blue
316SS 304SS
7 Bolt Nut PTFE PTFE

8 Bolt Washer

9 Stem

10 Anti-Static Device

11 Thrust Washer

12

20 4 x Ø O2
M18 E
17 19 4 x Ø O1

16

15 Ø N1
Ø N2
14 21
13

12 8

11 7

10

9

4 T LB (LE)
3 L

2
5

1 L6

Socket Weld End LB (Butt Weld End)
LE (Extended Butt Weld End)

Dimensions

E20: 2000 - 1500 WOG - Dimensions in Inches (in)
SIZE Ø d L LB LE H H1 F M Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2) T Ø W1 Ø W2 Ø W3

1/4” 0.42 2.96 2.76 6.50 1.69 3.27 0.28 5.32 0.24 0.24 0.35 1.42 (F03) 1.65 (F04) 0.39 0.55 0.30 0.71
3/8” 0.50 2.96 2.76 6.50 1.69 3.27 0.28 5.32 0.24 0.24 0.35 1.42 (F03) 1.65 (F04) 0.39 0.70 0.42 0.71
1/2” 0.59 2.96 2.96 6.50 1.69 3.27 0.28 5.32 0.24 0.24 0.35 1.42 (F03) 1.65 (F04) 0.39 0.86 0.55 0.87
3/4” 0.79 3.15 3.55 7.49 1.97 3.03 0.35 5.32 0.24 0.28 0.35 1.42 (F03) 1.97 (F05) 0.51 1.07 0.74 1.10
1” 0.99 3.55 3.94 8.51 2.29 3.45 0.43 6.70 0.24 0.28 0.43 1.65 (F04) 1.97 (F05) 0.51 1.33 0.96 1.34
1-1/4” 1.28 4.33 4.33 9.02 2.48 4.06 0.43 6.70 0.24 0.35 0.43 1.65 (F04) 2.76 (F07) 0.63 1.68 1.28 1.69
1-1/2” 1.50 4.73 4.93 9.50 2.94 4.18 0.55 7.88 0.28 0.35 0.55 1.97 (F05) 2.76 (F07) 0.63 1.91 1.50 1.97
2” 1.97 5.52 5.91 11.50 3.35 4.61 0.55 7.88 0.28 0.35 0.55 1.97 (F05) 2.76 (F07) 0.67 2.41 1.94 1.22

E20: 2000 - 1500 WOG - Dimensions in Millimeters (mm)

SIZE Ø d L LB LE H H1 F M Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2) T Ø W1 Ø W2 Ø W3

DN8 10.6 75.0 70.0 165.0 43.0 83.0 7.0 135.0 6.0 6.0 9.0 36 (F03) 42 (F04) 10.0 14.0 7.6 18.0

DN10 12.7 75.0 70.0 165.0 43.0 83.0 7.0 135.0 6.0 6.0 9.0 36 (F03) 42 (F04) 10.0 17.8 10.7 18.0

DN15 15.0 75.0 75.0 165.0 43.0 83.0 7.0 135.0 6.0 6.0 9.0 36 (F03) 42 (F04) 10.0 21.8 13.9 22.0

DN20 20.0 80.0 90.0 190.0 50.0 77.0 9.0 135.0 6.0 7.0 9.0 36 (F03) 50 (F05) 13.0 27.1 18.8 28.0

DN25 25.0 90.0 100.0 216.0 58.0 87.5 11.0 170.0 6.0 7.0 11.0 42 (F04) 50 (F05) 13.0 33.8 24.3 34.0

DN32 32.4 110.0 110.0 229.0 63.0 103.0 11.0 170.0 6.0 9.0 11.0 42 (F04) 70 (F07) 16.0 42.6 32.5 43.0

DN40 38.0 120.0 125.0 241.0 74.5 106.0 14.0 200.0 7.0 9.0 14.0 50 (F05) 70 (F07) 16.0 48.6 38.1 50.0

DN50 50.0 140.0 150.0 292.0 85.0 117.0 14.0 200.0 7.0 9.0 14.0 50 (F05) 70 (F07) 17.0 61.2 49.2 31.0

13

E30: 2000 - 1500 WOG

2 Piece, Full Port NPT Ball Valve with Direct Mount Actuation Design

Description

The Econ® E30 Series is a two piece, full port ball valve with
NPT ends and ISO 5211 compliant direct mount actuation pad.
The E30 is rated to 2000 WOG in sizes ranging from ¼” to 1”
and 1500 WOG in sizes ranging from 1-¼” to 2”. Valve bodies
are made of either CF8M or WCB with 316SS trim and TFM
4215 seats.

Features

•  Size Range: ¼” – 2”
•  CF8M and WCB Bodies/316SS Trim
•  Fire Safe Design Approved
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  TFM 4215 Seats
•  Anti-Static Devices for Ball-stem-body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-Luft Design/Approved Live Loaded Stem Packing

Standards

•  Design: ASME B16.34, MSS SP-110
•  2000 WOG for ¼” - 1”
•  1500 WOG for 1¼” - 2”
•  Pipe Thread: ASME B1.20.1
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material

1 Body A351-CF8M A216-WCB
2 End Cap A351-CF8M A216-WCB
3 Ball
4 Ball Seat 316SS 316SS
5 Body Gasket1 TFM4215 / TFM1600 + 15% Carbon TFM4215 / TFM1600 + 15% Carbon
6 Stem
7 Anti-Static Device PTFE PTFE
8 Thrust Washer 316SS 316SS
9 O-Ring 316SS 304SS
10 Stem Packing1 PTFE PTFE
11 Bushing2 FKM FKM
12 Gland PTFE PTFE
13 Belleville Washer 50% SS + 50% PTFE 50% SS + 50% PTFE
14 Retaining Nuts 316SS 316SS
15 Stop-Lock-Cap 301SS 301SS
16 Lever Sleeve3 A194-8 A194-8
17 Lever 304SS 304SS
18 Locking Device Plastic Vinyl Plastic Vinyl
304SS 304SS
304SS 304SS

1 Fire safe: GRAFOIL
2 Fire safe: 304SS
3 Color: Blue

14

F 11 4 x Ø O2 Ø N1
10 E Ø N2
15 9
14 8 4 x Ø O1
13
12 7
6
M

4 5 14 17 16
18
3 L1 2
L1

Dimensions

E30: 2000 - 1500 WOG - Dimensions in Inches (in)

SIZE Ø d L L1 H H1 F M Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/4" 0.42 2.44 1.14 1.70 2.76 0.35 5.71 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
0.35 1.42 (F03) 1.65 (F04)
3/8" 0.47 2.44 1.14 1.70 2.76 0.35 5.71 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
0.35 1.42 (F03) 1.97 (F05)
1/2" 0.59 2.96 1.36 1.70 2.76 0.35 5.71 0.24 0.24 0.43 1.65 (F04) 1.97 (F05)
0.43 1.65 (F04) 2.76 (F07)
3/4" 0.79 3.15 1.46 2.00 3.07 0.35 5.71 0.24 0.28 0.55 1.97 (F05) 2.76 (F07)
0.55 1.97 (F05) 2.76 (F07)
1" 0.99 3.55 1.77 2.29 3.51 0.43 6.90 0.24 0.28
□E Ø N1 (ISO 1) Ø N2 (ISO 2)
1-1/4" 1.26 4.33 2.01 2.48 3.68 0.43 6.90 0.24 0.35
9.0 36 (F03) 42 (F04)
1-1/2" 1.50 4.73 2.36 2.92 4.18 0.55 7.49 0.28 0.35 9.0 36 (F03) 42 (F04)
9.0 36 (F03) 42 (F04)
2" 1.97 5.51 2.76 3.29 4.55 0.55 7.49 0.28 0.35 9.0 36 (F03) 50 (F05)
11.0 42 (F04) 50 (F05)
E30: 2000 - 1500 WOG- Dimensions in Millimeters (mm) 11.0 42 (F04) 70 (F07)
14.0 50 (F05) 70 (F07)
SIZE Ø d L L1 H H1 F M Ø O1 Ø O2 14.0 50 (F05) 70 (F07)

DN8 10.6 62.0 29.0 43.1 70.0 9.0 145.0 6.0 6.0

DN10 12.0 62.0 29.0 43.1 70.0 9.0 145.0 6.0 6.0

DN15 15.0 75.0 34.5 43.1 70.0 9.0 145.0 6.0 6.0

DN20 20.0 80.0 37.0 50.7 78.0 9.0 145.0 6.0 7.0

DN25 25.0 90.0 45.0 58.0 89.0 11.0 175.0 6.0 7.0

DN32 32.0 110.0 51.0 63.0 93.5 11.0 175.0 6.0 9.0

DN40 38.0 120.0 60.0 74.0 106.0 14.0 190.0 7.0 9.0

DN50 50.0 140.0 70.0 83.5 115.5 14.0 190.0 7.0 9.0

15

E52: 1000 WOG

2 Piece, Full Port NPT Ball Valve

Description

The Econ® E52 Series is a two piece, full port ball valve with
NPT ends. The E52 is rated to 1000 WOG and is available in
sizes ranging from ¼” to 2”. Valve bodies are made of either
CF8M or WCB with 316SS trim and PTFE seats.

Features

•  Size Range: ¼” – 2”
•  CF8M and WCB Bodies/316SS Trim
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot

Standards

•  Design: ASME B16.34,
•  Pipe Thread: ASME B1.20.1
•  Inspection and Testing: API 598

MM L2L2

1111 1414
1010 1212 1313

99 77
88
66

55 Dimensions

44 SIZE E52: 1000 WOG - Dimensions in Inches (in) G
33 Ø d L H M L2
1/4" 1.12
22 3/8" 0.42 2.29 2.29 3.94 0.50 1.12
1/2" 0.47 2.29 2.29 3.94 0.50 1.12
11 of ConsLtLruction 3/4" 0.59 2.44 2.29 3.94 0.50 1.37
1" 0.79 2.85 2.52 5.08 0.87 1.37
Materials 1-1/4" 0.99 3.35 3.03 6.15 0.87 1.50
1-1/2" 1.26 3.70 3.27 6.15 0.93 1.50
Item Component Material 2" 1.50 4.14 3.78 7.19 0.93 1.50
1.97 4.92 4.02 7.19 0.93
1 Body A351-CF8M A216-WCB
2 Cap A351-CF8M A216-WCB E52: 1000 WOG - Dimensions in Millimeters (mm)
3 Ball
4 Ball Seat 316SS 316SS SIZE Ø d L H M L2 G
5 Stem PTFE PTFE
6 Body Gasket 316SS 316SS DN8 10.6 58.0 58.0 100.0 12.7 28.5
7 Thrust Washer PTFE PTFE 28.5
8 V-Ring Packing PTFE PTFE DN10 12.0 58.0 58.0 100.0 12.7 28.5
9 Gland Nut PTFE PTFE 34.8
10 Stem Washer 304SS 304SS DN15 15.0 62.0 58.0 100.0 12.7 34.8
11 Retaining Nut 304SS 304SS 38.1
12 Locking Device A194-8 A194-8 DN20 20.0 72.4 64.0 129.0 22.0 38.1
13 Lever 304SS 304SS 38.1
14 Lever Sleeve 304SS 304SS DN25 25.0 85.0 77.0 156.0 22.0
Plastic Vinyl Plastic Vinyl
16 DN32 32.0 94.0 83.0 156.0 23.6

DN40 38.0 105.0 96.0 182.5 23.6

DN50 50.0 125.0 102.0 182.5 23.6

E55: 1000 WOG

1 Piece, Reduced Port NPT Ball Valve

Description

The Econ® E55 Series is a one piece, double reduced port ball
valve with NPT ends. The E55 is rated to 1000 WOG and is
available in sizes ranging from ¼” to 2”. Valve bodies are made
of either 316SS or Carbon Steel with 316SS trim and PTFE
seats.

Features

•  Size Range: ¼” – 2”
•  Carbon Steel and 316SS Bodies/316SS Trim
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  Locking Device is Available Upon Request

Standards M

•  Design: ASME B16.34, MSS SP-110
•  Pipe Thread: ASME B1.20.1
•  Inspection and Testing: MSS SP-110

M

9 10 11 12 13
8
9 10 11 12 13
87

76

65

5
4

43 Dimensions
32
21 L E55: 1000 WOG - Dimensions in Inches (in)

SIZE Ød L H M

1L 1/4" 0.20 1.64 1.34 2.76
3/8" 3.15
1/2" 0.28 1.85 1.38 3.62
3/4" 3.62
Materials of Construction 1" 0.36 2.29 1.73 4.53
1-1/4" 4.53
Item Component Material 1-1/2" 0.49 2.40 1.81 5.00
2" 5.00
1 Body 0.59 2.90 2.01
2 Ball
3 End Plug A351-CF8M A216-WCB 0.79 3.07 2.29
4 Ball Seat 316SS 316SS
5 Stem 0.99 3.35 2.60
6 Body Gasket A351-CF8M A216-WCB
7 Thrust Washer PTFE PTFE 1.26 4.02 2.84
8 Stem Packing 316SS 316SS
9 Gland Nut PTFE PTFE E55: 1000 WOG - Dimensions in Millimeters (mm)
10 Stem Washer PTFE PTFE
11 Retaining Nut PTFE PTFE SIZE Ø d L H M
12 Lever 304SS 304SS
13 Lever Sleeve 304SS 304SS DN8 5.0 41.5 34.0 70.0
A194-8 A194-8
304SS 304SS DN10 7.0 47.0 35.0 80.0

Plastic Vinyl Plastic Vinyl DN15 9.1 58.0 44.0 92.0

DN20 12.5 61.0 46.0 92.0

DN25 15.0 73.5 51.0 115.0

DN32 20.0 78.0 58.0 115.0

DN40 25.0 85.0 66.0 127.0

DN50 32.0 102.0 72.0 127.0 17

E60: ASME Class 150

3-Way Full Port, Flanged End Ball Valve with Direct Mount Actuation Design

Description

The Econ® E60 Series is a three-way, flanged end ball valve
with ISO 5211 compliant direct mount actuation pad. The E60
is available in sizes ranging from ¼” to 4” with ASME Class 150
flanges. Valve bodies are made of either CF8M or WCB with
316SS trim and a variety of seat materials to choose from.


Features

•  Size Range: ½” – 4”
•  CF8M and WCB Bodies/316SS Trim
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-LUFT Design/Approved Live Loaded Stem Packing
•  Locking in Every 90° Increments
•  L-Port and T-Port Configurations Available

Standards

•  Design: ASME B16.34, API 608
•  Flanged Ends: ASME B16.5
•  Wall Thickness: ASME B16.34
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material

1 Body A351-CF8M A216-WCB
2 Ball 316SS 316SS

Cap A351-CF8M A216-WCB
3 End Cap A351-CF8M A216-WCB
A351-CF8M A216-WCB
Bottom Cap
4 Body Gasket PTFE PTFE
5 Ball Seat
6 Bolt TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE
7 Stem A193-B8 A193-B7
8 Anti-Static Device 316SS 316SS
9 Thrust Washer
10 O-Ring 316SS 304SS
11 Stem Packing PTFE PTFE
12 Bushing FKM FKM
13 Gland PTFE PTFE
14 Belleville Washer
15 Stop-Lock-Cap 50% SS + 50% PTFE 50% SS + 50% PTFE
16 Retaining Nuts 316SS / 304SS 316SS / 304SS
301SS 301SS

304SS 304SS
A194-8 A194-8

18

4 x Ø O2 Ø N1 M
E Ø N2
Sizes
4 x Ø O1 2” - 4”

M

11 12 13 14 15 16 16

10 6 F
9
3
8

7

5 B- h T L/2
4 L
3

21

Dimensions

E60: Class 150 - Dimensions in Inches (in)

SIZE Ø d L Ø A T H H1 M B Ø h F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 0.59 5.91 3.55 0.32 2.09 3.28 5.69 4 0.63 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)

3/4" 0.79 6.50 3.94 0.35 2.25 3.43 5.69 4 0.63 0.35 0.24 0.28 0.35 1.42 (F03) 1.97 (F05)

1" 0.98 7.13 4.33 0.38 2.68 3.90 6.90 4 0.63 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)

1-1/4" 1.26 7.49 4.53 0.44 2.84 4.06 6.90 4 0.63 0.43 0.24 0.35 0.43 1.65 (F04) 2.76 (F07)

1-1/2" 1.50 8.35 5.12 0.50 3.35 4.69 7.88 4 0.63 0.55 0.28 0.35 0.55 2 (F05) 2.76 (F07)

2" 1.93 9.06 5.91 0.56 3.62 4.96 7.88 4 0.75 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

3" 2.95 12.21 7.49 0.69 4.69 7.29 15.76 4 0.75 0.67 0.35 0.43 0.67 2.76 (F07) 4.02 (F10)

4" 3.90 14.46 9.06 0.88 5.91 8.71 15.76 8 0.75 0.87 - 0.43 0.87 - 4.02 (F10)

E60: Class 150 - Dimensions in Millimeters (mm)

SIZE Ø d L Ø A T H H1 M B Ø h F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

DN15 15 150.0 90.0 8.0 53.0 83.3 144.5 4 16.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)

DN20 20 165.0 100.0 8.9 57.0 87.0 144.5 4 16.0 9.0 6.0 7.0 9.0 36 (F03) 50 (F05)

DN25 25 181.0 110.0 9.6 68.0 99.0 175.0 4 16.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)

DN32 32 190.0 115.0 11.2 72.0 103.0 175.0 4 16.0 11.0 6.0 9.0 11.0 42 (F04) 70 (F07)

DN40 38 212.0 130.0 12.7 85.0 119.0 200.0 4 16.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

DN50 49 230.0 150.0 14.3 92.0 126.0 200.0 4 19.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

DN80 75 310.0 190.0 17.5 119.0 185.0 400.0 4 19.0 17.0 9.0 11.0 17.0 70 (F07) 102 (F10)

DN100 99 367.0 230.0 22.3 150.0 221.0 400.0 8 19.0 22.0 - 11.0 22.0 - 102 (F10)

19

E60: ASME Class 300

3-Way Full Port, Flanged End Ball Valve with Direct Mount Actuation Design

Description

The Econ® E60 Series is a three-way, flanged end ball valve
with ISO 5211 compliant direct mount actuation pad. The E60
is available in sizes ranging from ¼” to 4” with ASME Class 300
flanges. Valve bodies are made of either CF8M or WCB with
316SS trim and a variety of seat materials to choose from.


Features

•  Size Range: ½” – 4”
•  CF8M and WCB Bodies/316SS Trim
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  Pressure Balance Hole in Ball Slot
•  TA-LUFT Design/Approved Live Loaded Stem Packing
•  Locking in Every 90° Increments
•  L-Port and T-Port Configurations Available

Standards

•  Design: ASME B16.34, API 608
•  Flanged Ends: ASME B16.5
•  Wall Thickness: ASME B16.34
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material

1 Body A351-CF8M A216-WCB
2 Ball 316SS 316SS

Cap A351-CF8M A216-WCB
3 End Cap A351-CF8M A216-WCB
A351-CF8M A216-WCB
Bottom Cap
4 Body Gasket PTFE PTFE
5 Ball Seat
6 Bolt TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE
7 Stem A193-B8 A193-B7
8 Anti-Static Device 316SS 316SS
9 Thrust Washer
10 O-Ring 316SS 304SS
11 Stem Packing PTFE PTFE
12 Bushing FKM FKM
13 Gland PTFE PTFE
14 Belleville Washer
15 Stop-Lock-Cap 50% SS + 50% PTFE 50% SS + 50% PTFE
16 Retaining Nuts 316SS / 304SS 316SS / 304SS
301SS 301SS

304SS 304SS
A194-8 A194-8

20

4 x Ø O2 Ø N1 M
E Ø N2
Sizes
4 x Ø O1 2” - 4”

M

11 12 13 14 15 16 16

10 6 F
9
3
8

7

5 B- h T L/2
4 L
3

21

Dimensions

E60: Class 300 - Dimensions in Inches (in)

SIZE Ø d L Ø A T H H1 M B Ø h F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 0.59 5.91 3.74 0.50 2.09 3.28 5.69 4 0.63 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)

3/4" 0.79 6.50 4.53 0.56 2.25 3.43 5.69 4 0.75 0.35 0.24 0.28 0.35 1.42 (F03) 1.65 (F05)

1" 0.98 7.13 4.93 0.63 2.68 3.90 6.90 4 0.75 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)

1-1/4" 1.26 8.16 5.32 0.69 2.84 4.06 6.90 4 0.75 0.43 0.24 0.35 0.43 1.65 (F04) 2.76 (F07)

1-1/2" 1.50 9.22 6.11 0.75 3.35 4.69 7.88 4 0.88 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

2" 1.93 10.17 6.50 0.82 3.62 4.96 7.88 8 0.75 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

3" 2.95 14.18 8.27 1.06 4.69 7.29 15.76 8 0.88 0.67 0.35 0.43 0.67 2.76 (F07) 4.02 (F10)

4" 3.90 15.68 8.87 1.19 5.91 8.71 15.76 8 0.88 0.87 - 0.43 0.87 - 4.02 (F10)

E60: Class 300 - Dimensions in Millimeters (mm)

SIZE Ø d L Ø A T H H1 M B Ø h F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

DN15 15 150.0 95.0 12.7 53.0 83.3 144.5 4 16.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)

DN20 20 165.0 115.0 14.3 57.0 87.0 144.5 4 19.0 9.0 6.0 7.0 9.0 36 (F03) 42 (F05)

DN25 25 181.0 125.0 15.9 68.0 99.0 175.0 4 19.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)

DN32 32 207.0 135.0 17.5 72.0 103.0 175.0 4 19.0 11.0 6.0 9.0 11.0 42 (F04) 70 (F07)

DN40 38 234.0 155.0 19.1 85.0 119.0 200.0 4 22.3 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

DN50 49 258.0 165.0 20.7 92.0 126.0 200.0 8 19.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

DN80 75 360.0 210.0 27.0 119.0 185.0 400.0 8 22.3 17.0 9.0 11.0 17.0 70 (F07) 102 (F10)

DN100 99 398.0 225.0 30.2 150.0 221.0 400.0 8 22.3 22.0 - 11.0 22.0 - 102 (F10)

21

E70: 1000 WOG

3-Way Full Port NPT Ball Valve with Direct Mount Actuation Design

Description

The Econ® E70 Series is a three-way, full port ball valve with
NPT ends and ISO 5211 compliant direct mount actuation pad.
The E70 is rated to 1000 WOG and is available in sizes ranging
from ¼” to 1-½”. Valve bodies are made of either CF8M or WCB
with 316SS trim and a variety of seat materials to choose from.

Features

•  Size Range: ½” – 1-½”
•  CF8M and WCB Bodies/316SS Trim
•  Built-in ISO 5211 Mounting Pad for Easy Automation
•  Anti-Static Devices for Ball-Stem-Body
•  Blow-out Proof Stem
•  TA-LUFT Design/Approved Live Loaded Stem Packing
•  Positive Position Location at 90° Increments
•  Locking in Every 90° Increments
•  L-Port and T-Port Configurations Available

Standards

•  Design: ASME B16.34, MSS SP-110
•  Wall Thickness: ASME B16.34 Class 400
•  Pipe Thread: ASME B1.20.1
•  Inspection and Testing: API 598

Materials of Construction

Item Component Material

1 Body A351-CF8M A216-WCB
2 End Cap A351-CF8M A216-WCB
3 Ball
4 Ball Seat 316SS 316SS
5 Body Gasket TFM1600 / PTFE / RTFE TFM1600 / PTFE / RTFE
6 Stem
7 Anti-Static Device PTFE PTFE
8 Thrust Washer 316SS 316SS
9 O-Ring 316SS 304SS
10 Stem Packing PTFE PTFE
11 Bushing FKM FKM
12 Gland PTFE PTFE
13 Belleville Washer 50% SS + 50% PTFE 50% SS + 50% PTFE
14 Stop-Lock-Cap 316SS 316SS
15 Retaining Nuts 301SS 301SS
304SS 304SS
A194-8 A194-8

22

13 14 15 M 4 x Ø O2 Ø N1
12 4 x Ø O1 Ø N2
11 F
10 E
9 7
8 6 L
5 L/2
4
3 C

2L
1 L/2

Dimensions

E70: 1000 WOG - Dimensions in Inches (in)

SIZE Ø d L H H1 M F C Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 0.59 3.47 1.93 3.03 5.79 0.35 1.73 0.28 0.24 0.35 1.42 (F03) 1.97 (F05)

3/4" 0.79 4.25 2.34 3.43 6.96 0.43 2.13 0.28 0.24 0.43 1.65 (F04) 1.97 (F05)

1" 0.98 4.88 2.48 3.66 6.96 0.43 2.44 0.35 0.24 0.43 1.65 (F04) 2.76 (F07)

1-1/4" 1.26 5.32 2.90 4.06 8.47 0.55 2.66 0.35 0.28 0.55 1.97 (F05) 2.76 (F07)

1-1/2" 1.57 6.46 3.26 4.45 8.47 0.55 3.23 0.35 0.28 0.55 1.97 (F05) 2.76 (F07)

E70: 1000 WOG - Dimensions in Millimeters (mm)

SIZE Ø d L H H1 M F C Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

DN15 15 88.0 49.0 77.0 147.0 9.0 44.0 7.0 6.0 9.0 36 (F03) 50 (F05)

DN20 20 108.0 59.5 87.0 176.5 11.0 54.0 7.0 6.0 11.0 42 (F04) 50 (F05)

DN25 25 124.0 63.0 93.0 176.5 11.0 62.0 9.0 6.0 11.0 42 (F04) 70 (F07)

DN32 32 135.0 73.5 103.0 215.0 14.0 67.5 9.0 7.0 14.0 50 (F05) 70 (F07)

DN40 40 164.0 82.8 113.0 215.0 14.0 82.0 9.0 7.0 14.0 50 (F05) 70 (F07)

23

Cv of Ball Valve

Standard and V-Notch Balls

Standard Ball

Cv Value of Ball Valve

Size/Series 1/4" 3/8" 1/2” 3/4” 1” 1-1/4” 1-1/2” 2” 3” 4” 5” 6” 8”
DN8 DN10 DN15 DN20 DN25 DN32 DN40 DN50 DN80 DN100 DN125 DN150 DN200
E10
E15 - - 18 36 48 72 120 190 600 1100 1700 2600 4200
E20 - - 15 18 36 48 58 120 450 600 - - -
E30 - - 18 36 48 72 120 190 - - - - -
E52 - - 18 36 48 72 120 190 - - - - -
E55 - - 18 36 48 72 120 190 600 - - - -
E60 - - - - 18 36 48 72 - - - - -
E70 15 15 18 36 45 58 112 224 410 762 - - -
13 13 18 36 45 58 120 - - - - - -

30° V-Notch Ball

Series Size V- 10% Cv Value of Ball Valve with 30° V-Notch 70% 80% 90% 100%
Notch Open Open Open Open Open
E10 & E20 1/2” DN15 20% 30% 40% 50% 60%
E10 & E20 3/4” DN20 30° 0.00 Open Open Open Open Open 1.94 3.03 4.21 5.51
E10 & E20 1” DN25 30° 0.01 3.25 5.10 7.08 9.26
E10 & E20 1-1/2” DN40 30° 0.01 0.00 0.16 0.45 0.79 1.36 5.03 7.88 10.94 14.31
E10 & E20 2” DN50 30° 0.02 0.01 0.27 0.76 1.32 2.28 9.78 13.73 19.13 23.85
3” DN80 30° 0.00 0.01 0.42 1.17 2.04 3.52 23.02 32.12 42.09 42.18
E10 4” DN100 30° 0.02 0.03 0.95 2.30 4.09 6.63 44.97 61.75 84.75 103.82
E10 6” DN150 30° 0.08 0.00 2.76 5.70 9.84 15.25 81.77 113.91 157.89 176.19
E10 30° 0.03 1.88 6.10 12.01 20.45 31.24 160.02 226.81 301.33 387.09
4.41 11.07 21.56 36.32 56.01
4.24 17.35 39.34 70.13 108.15

60° V-Notch Ball

Series Size V- 10% Cv Value of Ball Valve with 60° V-Notch 60% 70% 80% 90% 100%
Notch Open Open Open Open Open Open
E10 & E20 1/2” DN15 20% 30% 40% 50%
E10 & E20 3/4” DN20 60° 0.01 Open Open Open Open 2.30 3.29 5.15 7.15 9.35
E10 & E20 1” DN25 60° 0.01 3.87 5.52 8.66 12.02 15.72
E10 & E20 1-1/2” DN40 60° 0.03 0.01 0.27 0.76 1.33 5.10 7.07 13.01 17.47 24.29
E10 & E20 2” DN50 60° 0.01 0.01 0.46 1.29 2.24 10.18 15.80 23.64 34.77 45.76
3” DN80 60° 0.05 0.17 0.55 1.64 2.76 19.63 31.35 47.42 70.82 81.13
E10 4” DN100 60° 0.03 0.01 1.24 3.39 6.27 47.73 73.19 106.87 157.58 190.40
E10 6” DN150 60° 0.07 0.07 2.59 6.90 12.08 83.04 132.96 212.46 340.90 401.72
E10 60° 0.00 2.24 8.09 17.30 29.89 183.18 289.67 437.26 654.69 782.39
5.64 15.02 29.85 51.10
6.49 26.68 62.56 112.45

Note:
The data is tested in pure water at ambient temperature. The value above will vary in different mediums.
Cv is the flow coefficient in imperial units. It is defined as the flow rate in US gallons per minute [gpm] of water at a temperature of 60ºF with
a pressure drop across the valve of 1 psi.

24

Kv of Ball Valve

Standard and V-Notch Balls

Standard Ball

Kv Value of Ball Valve

Size/Series 1/4" 3/8" 1/2” 3/4” 1” 1-1/4” 1-1/2” 2” 3” 4” 5” 6” 8”
DN8 DN10 DN15 DN20 DN25 DN32 DN40 DN50 DN80 DN100 DN125 DN150 DN200
E10
E15 - - 15 31 41 62 103 163 514 943 1458 2228 3599
E20 - - 13 15 31 41 50 103 386 514 - - -
E30 - - 15 31 41 62 103 163 - - - - -
E52 - - 15 31 41 62 103 163 - - - - -
E55 - - 15 31 41 62 103 163 514 - - - -
E60 - - - - 15 31 41 62 - - - - -
E70 13 13 15 31 39 50 96 192 351 653 - - -
11 11 15 31 39 50 103 - - - - - -

30° V-Notch Ball

Series Size V- 10% Kv Value of Ball Valve with 30° V-Notch 70% 80% 90% 100%
Notch Open Open Open Open Open
E10 & E20 1/2” DN15 20% 30% 40% 50% 60%
E10 & E20 3/4” DN20 30° 0.00 Open Open Open Open Open 1.68 2.62 3.64 4.77
E10 & E20 1” DN25 30° 0.01 2.82 4.41 6.12 8.01
E10 & E20 1-1/2” DN40 30° 0.01 0.00 0.14 0.39 0.68 1.17 4.35 6.82 9.46 12.38
E10 & E20 2” DN50 30° 0.02 0.01 0.24 0.65 1.14 1.97 8.46 11.88 16.55 20.63
3” DN80 30° 0.00 0.01 0.36 1.01 1.76 3.04 19.91 27.78 36.41 36.49
E10 4” DN100 30° 0.02 0.03 0.82 1.99 3.54 5.73 38.90 53.41 73.31 89.80
E10 6” DN150 30° 0.07 0.00 2.39 4.93 8.51 13.19 70.73 98.53 136.57 152.40
E10 30° 0.03 1.63 5.28 10.39 17.69 27.02 138.42 196.19 260.65 334.83
3.81 9.58 18.65 31.42 48.45
3.67 15.01 34.03 60.66 93.55

60° V-Notch Ball

Series Size V- 10% Kv Value of Ball Valve with 60° V-Notch 70% 80% 90% 100%
Notch Open Open Open Open Open
E10 & E20 1/2” DN15 20% 30% 40% 50% 60%
E10 & E20 3/4” DN20 60° 0.01 Open Open Open Open Open 2.84 4.45 6.18 8.09
E10 & E20 1” DN25 60° 0.01 4.78 7.49 10.39 13.60
E10 & E20 1-1/2” DN40 60° 0.03 0.01 0.24 0.66 1.15 1.99 6.12 11.25 15.11 21.01
E10 & E20 2” DN50 60° 0.01 0.01 0.40 1.11 1.94 3.34 13.67 20.45 30.08 39.58
3” DN80 60° 0.04 0.15 0.48 1.42 2.39 4.41 27.12 41.02 61.26 70.18
E10 4” DN100 60° 0.03 0.01 1.07 2.93 5.42 8.81 63.31 92.44 136.31 164.70
E10 6” DN150 60° 0.06 0.06 2.24 5.97 10.45 16.98 115.01 183.78 294.88 347.49
E10 60° 0.00 1.94 7.00 14.96 25.85 41.29 250.56 378.23 566.31 676.77
4.88 12.99 25.82 44.20 71.83
5.61 23.08 54.11 97.27 158.45

Note:
The data is tested in pure water at ambient temperature. The value above will vary in different mediums.
Kv is the flow coefficient in metric units. It is defined as the flow rate in cubic meters per hour [m3/h] of water at a temperature of 16ºC with a
pressure drop across the valve of 1 bar.

25

Torque Figures

Close to Open Torque at Various Differential Pressure (∆P)

E10: Class 150/300 with Standard Seats (TFM1600)
Valve Torque at Differential Pressure (∆P)

75 psig 150 psig 285 psig 740 psig
Size / ∆P 5 bar 10 bar 20 bar 50 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/2" DN15 5 44 5 44 5 44
3/4" DN20 5 44
1" DN25 6 53 6 53 6 53 6 53
1-1/4" DN32 11 97
1-1/2" DN40 10 88 10 88 11 97 17 150
2" DN50 24 212
3" DN80 13 115 13 115 15 133 35 310
4" DN100 90 796
5" DN125 19 168 19 168 22 195 135 1195
6" DN150 285 2522
8" DN200 25 221 29 257 32 283 530 4690
760 6726
65 575 72 637 81 717

100 885 110 973 122 1080

190 1681 210 1858 245 2168

280 2478 306 2708 340 3009

370 3274 430 3805 487 4310

E15: Class 150/300 with Standard Seats (TFM1600)
Valve Torque at Differential Pressure (∆P)

75 psig 150 psig 285 psig 740 psig
Size / ∆P 5 bar 10 bar 20 bar 50 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/2" DN15 5 44 5 44 5 44
3/4" DN20 5 44
1" DN25 6 53 6 53 6 53 6 53
1-1/4" DN32 9 80
1-1/2" DN40 8 72 8 72 8 72 13 116
2" DN50 19 168
3" DN80 12 106 12 106 13 116 28 248
4" DN100 60 531
6" DN150 15 133 15 133 17 152 96 850
164 1450
22 195 23 204 25 220

48 425 51 252 55 487

72 638 80 708 90 795

130 1151 140 1239 156 1380

E20: 2000 - 1500 WOG with Standard Seats (TFM4125)
Valve Torque at Differential Pressure (∆P)

75 psig 150 psig 300 psig 700 psig 1000 psig 1500 psig 2000 psig
Size / ∆P 5 bar 10 bar 20 bar 50 bar 63 bar 100 bar 140 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/4" DN8 7 62 7 62 7 62 7 62
3/8" DN10 7 62 7 62 7 62
1/2" DN15 7 62 7 62 7 62 7 62 7 62 7 62 7 62
3/4" DN20 7 62 7 62 8 71
1" DN25 8 71 7 62 7 62 7 62 7 62 8 71 9 80
1-1/4" DN32 13 115 13 115 16 142
1-1/2" DN40 17 150 8 71 8 71 8 71 8 71 26 230 --
2" DN50 25 221 37 328 --
33 292 13 115 13 115 13 115 13 115 55 487 --

17 150 20 177 22 195 25 221

25 221 29 257 31 274 34 301

33 292 42 372 46 407 49 434

Note:
1. E10, E52, E60 & E70 Series: Torque values increase 30% if selected seat material is Reinforced PTFE, EK+PTFE or TFM4215.
2. E15 Series (Reduced Port): Torque values increase 30% if selected seat material is Reinforced PTFE, EK+PTFE or TFM4215.
3. For E20 & E30 Series: If the working temperature is greater than 356°F (180°C), an additional safety factor minimum of 20% is recommended.
4. For actuator sizing, a safety factor minimum of 30% is recommended.

26

Torque Figures

Close to Open Torque at Various Differential Pressure (∆P)

E30: 2000 - 1500 WOG with Standard Seats (TFM4125)
Valve Torque at Differential Pressure (∆P)

75 psig 150 psig 300 psig 700 psig 1000 psig 1500 psig 2000 psig
Size / ∆P 5 bar 10 bar 20 bar 50 bar 63 bar 100 bar 140 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/4" DN8 7 62 7 62 7 62 7 62
3/8" DN10 7 62 7 62 7 62
1/2" DN15 7 62 7 62 7 62 7 62 7 62 7 62 7 62
3/4" DN20 7 62 7 62 8 71
1" DN25 8 71 7 62 7 62 7 62 7 62 8 71 9 80
1-1/4" DN32 13 115 13 115 16 142
1-1/2" DN40 17 150 8 71 8 71 8 71 8 71 26 230 29 257
2" DN50 25 221 37 328 41 363
33 292 13 115 13 115 13 115 13 115 55 487 59 522

17 150 20 177 22 195 25 221

25 221 29 257 31 274 34 301

33 292 42 372 46 407 49 434

E52: 1000 WOG with Standard Seats (PTFE)
Valve Torque at Differential Pressure (∆P)

Size / ∆P 75 psig 150 psig 300 psig 700 psig 1000 psig
5 bar 10 bar 20 bar 50 bar 63 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/4" DN8 5 44 5 44 Nm in-lb
3/8" DN10 5 44 5 44
1/2" DN15 5 44 5 44 5 44 5 44 5 44
3/4" DN20 5 44 5 44 5 44
1" DN25 6 53 5 44 5 44 6 53 5 44
1-1/4" DN32 10 88 11 97 6 53
1-1/2" DN40 13 115 6 53 6 53 17 150 11 97
2" DN50 19 168 24 212 19 168
25 221 10 88 11 97 35 310 26 230
38 336
13 115 15 133

19 168 22 195

29 257 32 283

E60: Class 150/300 with Standard Seats (TFM1600)
Valve Torque at Differential Pressure (∆P)

Size / ∆P 75 psig 150 psig 285 psig 740 psig
5 bar 10 bar 20 bar 50 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/2" DN15 8 71 8 71 9 80
3/4" DN20 9 80
1" DN25 12 106 12 106 13 115 13 115
1-1/4" DN32 22 195
1-1/2" DN40 18 159 18 159 19 168 33 292
2" DN50 45 398
3" DN80 23 204 23 204 27 239 65 575
4" DN100 160 1416
32 283 32 283 38 336 265 2345

45 398 50 442 56 496

110 973 122 1080 138 1221

190 1681 209 1850 232 2053

E70: 1000 WOG with Standard Seats (TFM1600)
Valve Torque at Differential Pressure (∆P)

Size / ∆P 75 psig 150 psig 300 psig 700 psig 1000 psig
5 bar 10 bar 20 bar 50 bar 63 bar
Nm in-lb Nm in-lb Nm in-lb Nm in-lb
1/2" DN15 9 80 9 80 Nm in-lb
3/4” DN20 9 80 9 80
1” DN25 9 80 9 80 10 88 10 88 9 80
1-1/4” DN32 14 124 15 133 10 88
1-1/2” DN40 18 159 14 124 15 133 20 177 15 133
25 221 28 248 22 195
18 159 18 159 30 265

26 230 26 230

27

Seat Performance Capabilities

Pressure Temperature Data

900 62 90

5 800 55 890090000 565262 80
Floating Ball Valves, Class 150/3008
8087000 555458 Full Bore - Sizes 1-1/4” - 2”176352461845237329586470000000000000000000000054321786(32918765400000000-00000000000000000--0000000022000000000200000000009000000000-02) 0(CC-CCCC1l0lllaaa0laClC8aCasCssslsslsssla)sla0assa1s11s1ss1s15s55s5s55010010110055S5SC5C01S0C(S0S0S1S3S0SSCBSBC0BB8SBS0oSB1oSoo0o)BdodB0BddBdodyyooy0yoydydddyyyy(24CCC4CC00lllal0aalCaa40C4sCssCs0lssssla)l0ssala3as33s3Cs03s0s00ss00ls030a0303030sS0SS0sC00CS0(SS050S32SS5BSBBC00CSB6BoS0oo0SoS05oBd0ddB0CBddoBy0yyo)oSyydod0dBydyyoy(d636y0100660º0)FººF202431470C01225443746122345484811º858141482514814F522137044345267412445881158441812 70
1 7076000 484481 60
4 6065800000 41435145 50
8 40
1 30
4 20
Pressure in bar 5800547000000 Full Bore - Sizes 1/2” - 1”Class 300 CS Body 3545324488 PresPsruerses iuPPrnrreeebissPassnrruuebrrsaeesriiurnnebbiaanrrbar PresPsruerses iuPPrnrreeebissParssnreuusbrrsaeeruiirnne ibbnaarrbar 10
PresPsruerses iuPPrnrreeepissPsssinruueprrsseesiiiurnneppissiin psi4700436000000 ClasCs l3aC0sls0a3sSs0S03B0Co0SdCyBSoBdoydy 2488224811 PresPsruerses iuPPrnrreeepissPsrssineuusprrsseeiuiirnne ippssniipsi Pressure in psi
3600325000000 2411213144
2500214000000 Class 150 CS Body ClaCslsa3ss003C0Sl0SasSBsSo3Bd0oy0dCyS Body 134417248
CClaClsalssas1ss5101505C0SSSCBSBooBddoyydy ClasCsla3s0s03S0S0 BCoSdByody
ClaCslsa1ss5015S0SSBSoBdoydy
Class 300 SS Body

12143000001(213(00-00000---02200022(00(-0(0000-9-9--2-22222))09009(9(-)-))C1C100((l(l-88a-a-1C0C1ss01))0sls8l8aa811)ss))5s5s0011151(5SC(303S000S1(818SBC(100(B330S3)o0S)o0880dB8d0B0)yo)yo)dTdyyeTTT22((me99e0e02(23320m(0m(m90p99)0)0303300epp)p))reeea((rrr313t1aaa0u(404((31t3t130t1909r0u4u0u404))e0909r09rr)e)eº)eF(º(ºº2F424F(Fº(0000((C24(24(2440(40º00ºº00)0)0C)CC404040)))))) 500 7287021
505(020600) 60(660300º1F000621ºFº)14F0º17C4
200 300
(290320)00 (13403900) 0
(2(6206)0) (3(1361)6ºC7)ºC0 10(0-2(0-92)9(-)1(-81)8) (3(83)8)Tem(9(3p9)3e)ra(t1u(41r94e)9º)F ((2º(C024)0)4) (2(6206)0) (3(1361)6º7C)º0C
0-2(0--2209)0(-108)
500 60(63001ºF060º)FºC (-29) (-18) 100 TeTmem2p0e0preartaut3ru0er0eºFºF(ºC(4º)C00) 500 60(63001ºF006º)FºC
50(2060) 10(038) T2(e903m(09)3p) er(31a04(t109u4)9re) º(F2400((240º0C)4)) 50(2060)
(260) (316)ºC (38) (260) (316)ºC

Temperature ºF (ºC) Temperature ºF (ºC)

5 800 Full Bore - Sizes 3” - 4” 55 800 Full Bore - Sizes 5” - 8” 55 80

8 8087000 Class 300 CS Body 555458 7808000 458555 70
1 7076000 ClCaCslalsas3sss030300C00SSCSBSoBBdooyddyy 484481 60
4 6065800000 ClaCslsa3sCs0l03a0sSs0S3SB0So0BdCoySdBy ody 41435145 50
8 5800547000000 CCllaassss330000SCSSBBooddyy 3545324488 40
1 4700436000000 Class 150 CS Body Class 300 SS Body 2488224811 30
3600325000000 ClaCCsllsaa1ssss501155C00SCSBSSoBBdooyddyy 2411213144 20
Floating Ball Valves, 2000 - 1500 WOG Floating Ball Valves, 1000 WOG4 2500214000000 ClaCslsa1ss5015S0SSBSoBdoydy 134417248 10
Pressure in bar 140013000000 Class 150 CS Body 7287021 PresPsruerses iuPPrnrreeebissPassnrruuebrrsaeesriiurnnebbiaanrrbar 126354573214648172653000000000000000721634512378654(0000000(0(000000000-----0000000-20000000022222(00000000(000000000-90-9-9-2222)))090CCC9(CC(C(--)l-llll)laaa1aa10aC100C(CssCs(sss8-l8s8sls-lssasla1a0a1)10)s11)11s1ss8s5s558s555s010)000101)155C5CCS5SS000S(SS0SSS111(3(CSCB3BBBBS3B000S8SSoS1ooooo(8180(00)B3dBdddddB30B)0)ooyyyy8yoo800dddd)T)yTyyyeeTTm(2m22e(9(e909003m2mp(2303p0(0)909)0)e3ep03p0)r)reeaarrt((t(a31313a1uu040(40t4(t3r13r01u90909ue04e04)))r09r09eººe)F)FººC((F(F(24(l4º4ºa22CCCC000sC(0(0(04ls(l4Cº40al2C0a)0º2aC)C434C0sClsl0)0salas00sCl)a)s0Csas0)043)s34lss3slas0a0)Ss03)s30s30Ss3000s0S00SB3(0(C(35055S20S20o2C0SC0S00d0B6(S6B06SS(5BS250oyS0o2C000C0BoB0Bd60dSB6)oSd)o)oy0yo00Bdy0dBddo)yyoy)yd(d((663y363y001(101(6360306606010º1º))º)FFF0º62740312ºº0622134407C071225344CCº)41814º)F1481481481854ºFº71320244C205213744C8148141841854 PresPsruerses iuPPrnrreeebissParssnreuusbrrsaeeruiirnne ibbnaarrbar
PresPsruerses iuPPrnrreeepissPsssinruueprrsseesiiiurnneppissiin psi21300021(0(0000----002222(0((000--0--9-9-222222))009909(C(C-))-)ll1a10a0(((Css--88-ss1l1001a0))1188s855s))0)015CS(0(SS1133SBB00(881(1S(oo130303))0d0dB0888yyo000))d)TyeTTTm((2e2ee9900m(3m322m(2(p90099))00033e3p0p0p0)))reeearrrt((aa3a131u0t(40(t4t(3311r3u10u90u90e04404))rrr009909eeºe))F) ºººFF(((F2424ºC(00(00((((244º24º240º40)CC00C0000))400)40)4)))) 500 60(6630001ºF006021ºº)41FFº017C4 PresPsruerses iuPPrnrreeepissPsrssineuusprrsseeiuiirnne ippssniipsi Pressure in psi
50(5200600)
(2(6206)0) (3(1361)6º7C)º0C
500 60(63001ºF006º)FºC
50(2060)
(260) (316)ºC
Full BoreTe-mSipzeersat1/u₄r”e-ºF1”(ºC(2) 000 WOG) FullTBemorpee-raStiuzreesºF1/(4ºC” )- 4”
Full Bore - Sizes 1-1/₄”- 2” (1500 WOG)
T9625841841CEFaKMrb1o62n080STtiFesMetShle4S(SBeSa2Ceeoets1SaaadtM11115)tatty0173658429101129378564-nM11aMM111111120000000000000000000000ARt01519342867d01421569837684200482(000000000000(a000000000000ea-aSa--00000000000-a00000000000200000000t2r2t2ttM((000000000000rei(000000000000--e000000000ei0--9-ad9-22nr222rrE2)l)i00iigs99s0a9aa((A:e-))ls-)ll1Ss110ssa:20((i5(:z--::8sP8t-10e1100t100)s)Tm6a88sP8PsB1MFtPn))Wt-T)aToaEaaT/dFtxFPndPPnC”Fei(a(E1P1EsTd33-TyTEdBrrS002F(i(8itadF8FI11i(saR133”0sh30oE)rE)E00rl088atsde8rtd00hfe0)t)h)oossieasneTTrettteahsgeaREesTmaTtnT(e(2tst12Tmam9t9eReaderR0Rm00Faon((3322m(nT2ma99bmT0t,TEm09dfp)p)00Faed0rE33FoF3aSad00tEre01peaE))pEdpt)etiraer5sadrryreedeler,iaiaanismrE(ar(rafst3t13le1aloa6taTelueu0a((4a04(fr0t33Fm11tat3s1ot0tf9T0r9ruTMu00Ees4tu4oT04&reF)mea)F200r99Fmrr0Sr9Mr1EtiM0EMe))aaeetEºe)º62FaeF71ltr21&00s1etºie0º(6º(0a6Fe0F(24F6(24ral&E0lº0Siºr((000r0a0(C(aC30i(22f44(e0eS(24Ea40on400lº0º0º000)rSC0)03Cl)Cf)rrCd.i4400oe)4ef00lE)ao))))rf-Es).s5eEr.s3EA2rT1SK8S1E50(rE(3i00i05EF5z2+ze25&2E001S0Ke5eS1M0KS0((6d062iP0s(K55siB0z22+51&S2zE0e2+000Me00oMT004/e+i0/66t0&0-P5szr60dP)s)0FoaC”0E0a2e”i00P0M5yT0M/e0xsT-xE/-E51F))TAFa4)1”MP4sFPa”S5558”x/-F”(S.E(Sx-SEa46e3653I4IPME4SP”ixM”0r((S10s1”(S-66SeP33iI63,0I60e16tES00re11C0”1hºIs)ºi)PFF00r66eºB166223757044º0.1402234776566aeCCiEººTs))e25981464181ºP1152968844r)FFPººFE312246605747.º11110948256bF372541427660CCs6PECTEK8264459181.M13734258914818156942o.EEFE3T159nKEM1K4FK6MS10t61e006Tei0F0slTTM0(itFCsTFhM4iMFSSBtse2hM)eo4t4s1e-ahd2t425tAaes1y21tMn112521111151s111121aR86194305271d1t62802480465na4228066804aa11121100000000000a61121110000000000t0000000000tdn(244606802800000000000(re(-i4884066022--00000000000---00000000000-nadW220000000000d2r2200000000002(rig(-00000000000000-9a9-s00000000000d9-C222s2er)l))01SsB:1S9d0s9a(((i5:i5ez--)z-t)0S1o0e1s1eS1010a0(0i50s(smei5Bzr-8s8P8zt-01Me110M0eta1o)00)o-Ts)-m0asa8aat8/1dM/Ft1tMPnxx)-hm)”ae-”EyaPTPad/-/-terxSSx2F”iR(2e(aia(”1I1IP1sr3a3”P3-”Er-traS00S02lb8(8tied82I1(tIa13”0h0f30”))iro)0oln08sie8da0fer0)g)olsyaEsTtTrfTt1aomeoREeem0Tn(r(T2(2f12Tm99ma9m,edE0e0S0Fa03E(t332(2a190m0tteE,09mp1))p)0pear00E3r35d0irie01,e)pena)ip,aE5srllErresele1ea,a6as(a(Er5(afrt303113t1stoat6Tr,au0u04(u404e(&SrEF0m31t31t00990r9trM6rEu04ru04&Eee))a)eee20090r97e1trf0E)eeºe)&0lº6eºF7FFr(r&0iSS0(rº(E(ºa0(F2424e2(4FeS(E7lºSº0(0º00d00)rC(3C0fC24C(eC2i44(040o40-e0ºl00tl)ºra00)SaC))))rACCos.isC40s4e0el.ssElaS))a)AT)sr88s5sMEi.s00FsSe21S0TK80M8((EMi(s0055F5zB2+02B2&2S0S2.0eo000oM4A0i06(6i00T6PEsz(5zdBd250BE02S0022e0e002SM3F0Toy0/y40io0sB60s5i0z16)d)Mz5)Fa0d”102Me10M001e5y500x-y/s1E/0s1a4)a4464)1PMS1M”ix”5x”C/(S(2.s(/-6a43e6-3P36IP3a4F11”ix1tSS0”rx041(10s1”(h-”8I65iIP3-6P3006e6016tS1Me01S0”1ºhºsiI))º”)PIFFsF0º6º607715426234º.0610121945168C,eC10124568911CETº)1925418468tºC)F95233114781281935473ºFEhºF11658120491C19186541210Ca915951KMe35324811971589432713r519b1591o6n00STtiFesMethl4(e2Cs1St5)a-n111121Ad2468680402Sa0000000000
Pressure in bar PresPsruerses iuPPrnrreeebissPassnrruuebrrsaeesriiurnnebbiaanrrbar PresPsruerses iuPPrnrreeebiPssrassnreuusbrrsaeeruiirnne ibbnaarrbar
PresPsruerses iuPPrnrreeepisssPssinruueprrsseesiiiurnneppissiin psi PresPsruerses iuPPrnrreeepiPsssrssineuusprrsseeiuiirnne ippssniipsi Pressure in psi

Accessories

Stem Extension for Direct Mount Actuation Design

Description Features

Stem extensions can be mounted on any Econ® valve with •  4” Extension
direct mount actuation design. These extensions are made •  Square Stem
of stainless steel and have PTFE bushings for smooth •  Suited for Manual or Automated Valves
and clearance free operation. A guide ring at the bottom •  316SS
ensures a solid connection between the extension and the •  Live Loaded Packing Arrangement
ball valve. •  Bolts Directly to ISO 5211 Mounting Pad
•  Optional Leak Sensing Port
•  Allows Direct Actuator Mounting

H1 4 x Ø O2
H2 E

HF 4 x Ø O1
H1
H2 RR

HF
H
Ø N1
Ø N2

Sizes Sizes
1/2” - 2” 3” - 4”

Dimensions

Direct Mount Stem Extension - Dimensions in Inches (in)

SIZE H H1 H2 F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2)

1/2" 3.94 0.47 0.91 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
3/4"
1" 3.94 0.47 0.91 0.35 0.24 0.24 0.35 1.42 (F03) 1.65 (F04)
1-1/4"
1-1/2" 3.94 0.59 1.06 0.43 0.24 0.28 0.43 1.65 (F04) 1.97 (F05)
2" 3.94 0.59 1.06 0.43 0.24 0.28 0.43 1.65 (F04)
3" 1.97 (F05)E
4"
3.94 0.51 1.18 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

3.94 0.51 1.18 0.55 0.28 0.35 0.55 1.97 (F05) 2.76 (F07)

3.94 0.95 1.81 0.67 0.35 0.43 0.67 2.76 (F07) 4.02 (F10)

3.94 1.77 2.05 0.87 - 0.43 0.87 - 4.02 (F10)

Direct Mount Stem Extension - Dimensions in Millimeters (mm) Ø O2

SIZE H H1 H2 F Ø O1 Ø O2 □E Ø N1 (ISO 1) Ø N2 (ISO 2) Ø N1
Ø N2
DN15 100 12.0 23.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)

DN20 100 12.0 23.0 9.0 6.0 6.0 9.0 36 (F03) 42 (F04)

DN25 100 15.0 27.0 11.0 6.0 7.0 11.0 42 (F04) 50 (F05)

DN32 100 15.0 27.0 11.0 6.0 7.0 11.0 42 (F04) 50 ((ØFF0075))O1
DN40 100 13.0 30.0 14.0 7.0 9.0 14.0 50 (F05) 70

DN50 100 13.0 30.0 14.0 7.0 9.0 14.0 50 (F05) 70 (F07)

DN80 100 24.0 46.0 17.0 9.0 11.0 17.0 70 (F07) 102 (F10)

DN100 100 45.0 52.0 22.0 - 11.0 22.0 - 102 (F10)

4xØO 29

F F

Accessories E

Stem Extension for Bracket Mount Actuation Design RR

Ø O2

Description Ø N1
Ø N2
Econ® stem extensions can be mounted on Econ® ball Features
valves with bracket mount actuation design (E15 Series).
These extensions are made of stainless steel and have PTFE •  4” Extension
bushings for smooth and clearance free operation. A guide •  Double D Stem, Gland Packing and Test Connection
ring at the bottom ensures a solid connection between the
extension and the ball valve. •  SuØiteOd1for Manual or Automated Valves

•  316SS
•  Live Loaded Packing Arrangement
•  Bolts Directly to ISO 5211 Mounting Pad
•  Optional Leak Sensing Port
•  Allows Direct Actuator Mounting
•  Lever Can Be Used

H1 4xØO
H2 E
K
HF
H1
H2

HF
H

ØN

Sizes Sizes
1/2” - 2” 3” - 4”

Dimensions

Bracket Mount Stem Extension - Dimensions in Inches (in)

SIZE H H1 H2 F Ø O E Ø N (ISO) K

1/2" 3.94 0.47 0.91 0.35 0.20 0.25 1.65 (F04) 3/8-24 UNF
3/4"
1" 3.94 0.47 0.91 0.35 0.20 0.25 1.65 (F04) 3/8-24 UNF
1-1/4"
1-1/2" 3.94 0.59 1.06 0.43 0.24 0.35 1.97 (F05) 9/16-18 UNF
2"
3" 3.94 0.59 1.06 0.43 0.24 0.35 1.97 (F05) 9/16-18 UNF
4"
3.94 0.51 1.18 0.55 0.32 0.38 2.76 (F07) 5/8-18 UNF

3.94 0.51 1.18 0.55 0.32 0.38 2.76 (F07) 5/8-18 UNF

3.94 0.94 1.81 0.67 0.39 0.63 4.02 (F10) 7/8-14 UNF

3.94 1.77 2.05 0.87 0.39 0.71 4.02 (F10) 1-1/8 -12 UNF

Bracket Mount Stem Extension - Dimensions in Millimeters (mm)

SIZE H H1 H2 F Ø O E Ø N (ISO) K

DN15 100 11.9 23.1 8.9 5.0 6.3 42 (F04) 3/8-24 UNF

DN20 100 11.9 23.1 8.9 5.0 6.3 42 (F04) 3/8-24 UNF

DN25 100 15.0 26.9 10.9 6.0 9.0 50 (F05) 9/16-18 UNF

DN32 100 15.0 26.9 10.9 6.0 9.0 50 (F05) 9/16-18 UNF

DN40 100 13.0 30.0 14.0 8.0 9.6 70 (F07) 5/8-18 UNF

DN50 100 13.0 30.0 14.0 8.0 9.6 70 (F07) 5/8-18 UNF

DN80 100 23.9 46.0 17.0 10.0 16.0 102 (F10) 7/8-14 UNF

DN100 100 45.0 52.1 22.1 10.0 18.0 102 (F10) 1-1/8 -12 UNF

30

Rack & Pinion Actuators Accessories

•  Compact Pneumatic Double Acting or Spring Return Quarter Turn Actuators
Actuators with Aluminum Housing
31
•  14 Different Sizes and Variety of Spring Combinations
•  Bidirectional Travel Stops
•  Output Torques up to 56,831 in-lb (6,421 Nm)
•  ATEX, SIL 3, CE Certifications
•  Mounting Arrangement and Design Comply to NAMUR

VDI/VDE 3845 and ISO 5211 Standards
•  Anti-corrosive Coatings According to EN-15714

Scotch Yoke Actuators

•  Modularly Designed Double Acting and Spring Return
Scotch Yoke Actuators in 10 Different Sizes

•  Symmetric Yoke for Constant Output Torque up to 2.2
million in-lb (250,000 Nm)

•  Fully Protected Against Ingress Water
•  Bidirectional Travel Stops
•  Designed in Accordance with Pressure Equipment

Directive (PED) 97/23/EC
•  ATEX, SIL 3, CE Certifications

Electric Actuator

•  Torque Range from 690 to 25,900 in-lb (78 to 2,926 Nm)
•  Standard Weatherproof Enclosure (IP67, NEMA 4, 4X & 6)
•  Optional Explosion Proof Enclosure (Exd II BT4Gb or II2G)
•  Standardized ISO 5211 Mounting Flange
•  Open/Close Limit and Torque Switches
•  Manual Override
•  Self Locking Gear Train
•  Mechanical Stops (Adjustable)
•  Optional Proportional Control Card
•  110VAC/24VAC/24VDC Power

Accessories

Heavy Duty Lever, Smart Positioner and Limit Switches
Heavy Duty Lever

•  Option for Econ® Ball Valves with Direct Mount Top Flange
•  For Ball Valves Sizes 1/4” to 3”
•  Molded Lever for Severe Operating Conditions
•  Compatible with Econ® E10, E20, E30, E60 and E70 Series of

Ball Valves
•  Figure 6001B

Smart Positioners

•  Linear or Rotary Action
•  Single or Double Acting
•  Push Button Calibration
•  4 - 20 mA Input Control Signal
•  -22°F to 185°F (-30°C to 85°C) Ambient Temperature
•  LCD Display
•  HART Capable
•  Linear, Quick Opening, =%, & User Defined Characteristics
•  70 LPM Air Capacity
•  IP66 Enclosure
•  Figure 3301 through 3304

Limit Switches

•  For General Purpose or Explosion Proof Applications
•  Micro mechanical Switches or Inductive Switches
•  Red and Yellow Visual Position Indicators
•  ATEX Certified
•  Econ® Brand or Customer Preference
•  Compatible with 3-Way Valves Using a Special Visual

Position Indicator
•  Figures 79651, 79652 and 79653

32

Ball Valve Ordering Matrix

How to Order

Example: A 2”, Two Piece ASME Class 150, Full Port Ball Valve with Flanged Ends, Carbon Steel Body, Stainless Steel Trim,
TFM1600 Seats, Graphite Packing, NACE Compliant, Fire Safe, Locking Lever Operated is written: 10E10-AR-CSFG-NFC-0200

A—B C—D E F G—H I J —K

10E10 AR CSFG NFC 0200

A Construction Type F Seats

10E10 2-PC. ASME-150, Full Port, Flanged E EK+PTFE**
30E10 2-PC. ASME-300, Full Port, Flanged F TFM1600
10E15 1-PC. ASME-150, Reduced Port, Flanged G TFM4215
30E15 1-PC. ASME-300, Reduced Port, Flanged H TFM1600 + 15% Carbon**
2WE20 3-PC. 2000WOG, Full Port, NPT/SW/BW/BWE (≤1") P PEEK***
5WE20 3-PC. 1500WOG, Full Port, NPT/SW/BW/BWE (>1") R RTFE**
2WE30 2-PC. 2000WOG, Full Port, NPT (≤1") T PTFE
5WE30 2-PC. 1500WOG, Full Port, NPT (>1") Z METAL**
1WE52 2-PC. 1000WOG, Full Port, NPT* V 50%PTFE +50%SS**
1WE55 1-PC. 1000WOG, Double Red. Port, NPT*
10E60 3-Way ASME-150, Full Port, L/T Port, Flanged G Body Gasket
30E60 3-Way ASME-300, Full Port, L/T Port, Flanged
1WE70 3-Way 1000WOG, Full Port, L/T Port, NPT G Graphite
T PTFE
B —
Port Configuration —
A
T As Defined (Standard Configuration) H NACE
L T-Port
3 L-Port N NACE
6 30° V-Notch** O NON-NACE
60° V-Notch**
C I Fire Safe
End Connection
B F Fire Safe
X BW x BW** O NON-Fire Safe
R BWE x BWE
O RF Flange J Operator
W FNPT x FNPT
U SW x SW C Locking Lever
J FNPT x SW
RTJ Flange** L T-Handle
D
— G Gear
C Body Material
A —
S Carbon Steel (A216-WCB)
Alloy 20** K Port Size
E Stainless Steel (A351-CF8M) NPS DN

C Trim 0025 1/4" 8
A
S Carbon Steel 0038 3/8" 10
Alloy 20**
Stainless Steel 0050 1/2" 15

0075 3/4" 20

0100 1" 25

0125 1-1/4" 32

0150 1-1/2" 40

0200 2" 50

0250 2-1/2" 65

0300 3" 80

0400 4" 100

Note: 0500 5" 125
* Manual operation only (A)
** Full factory lead time may be required for valves with these components. 0600 6" 150
*** PEEK Seats only available for valves sizes 4” and below.
0800 8" 200 33

NOTES

34

NOTES

35

UNITED STATES CANADA local distributor/agent

The Newdell Company Quantum Supply Limited (HQ) The contents of this publication are presented for
13750 Hollister Rd Unit 201 - 2400 Dollarton Highway informational purposes only, and while effort has
Houston, TX 77086 North Vancouver, BC V7H 0B3 been made to ensure their accuracy, they are not to
T (713) 590-1312 T (604) 985-9186 be construed as warranties or guarantees, expressed
Toll Free (877) 510-7853 Toll Free (866) 723-4279 or implied, regarding the products or services
www.newdellco.com Quantum Supply Limited (VAC) described herein or their use or applicability.
6442 Roper Road
Edmonton, AB T6B 3P9
T (780) 462-9166
Quantum Supply Limited
300-840 6th Ave SW
Calgary, AB TZP 3E5
T (403) 930-1930
www.quantumltd.com

© 2016 ERIKS nv
Econonsto and ® Econ® are registered trademarks of ERIKS nv.
SPECNA_ECONBV_April 22 2016
