Recognitive IP Video Solutions EN-500132-20190926-013

Recognitive IP Video Solutions

Video Surveillance Business

-2 -

-3 -

-4 -

CONTENT 1
7
Command Control & Data Centre 14
IP Camera 17
NVR 30
Mobile Solutions
Intelligent and Recognitive Solutions

-5 -

Command Control & Data Centre

-1 -

Command Control & Data Centre

Overview

Kedacom provides carrier-class video surveillance core devices and supplementary software system, helping users establish Command
Control & Data Centre based on IP video applications with more than 100,000 channels.

Key Advantages VMS LEVEL 1 Tree Structure List
Client First Level VMS
Powerful Networking System Second Level VMS
VMS LEVEL 2 Third Level VMS
• 32 x VMS hardware platform stack
• 8 levels cascade VMS LEVEL 3
• Up to 100,000 surveillance points accessible
• 3G/4G wireless peripheral units accessible

High Reliability Traditional RAID, System crash when 2 HDD broken
KEDACOM RAIDX,still write when only 1 HDD left
• Embedded design
• N+1 backup
• Redundant power supply
• RAID 0,1,5,6,10, RAID X
• Cloud storage
• SMART technology for disk management
• PLR (Packet Loss Recovery)

Abundant Professional Functions

• Overall device management
• Integrated alarm management
• Comprehensive record management
• Bi-directional audio
• E-Map
• Streaming media service
• TV wall composition

Ultra-fine Pitch LED Display

• Low brightness but high grey scale
• Professional image processing
• High working accuracy
• Magnetic and modular
• Fanless & silent
• Pioneering star topology
• Power and link redundancy

Visualization Dashboard

The visualization dashboard presents complex data
through graphical display, providing customers an
intuitive, interactive visualization environment.
It is mainly used in scenes such as command monitoring,
comprehensive data display and presentation reporting.

• Optimize resources and improve efficiency
• Reduce operation complexity
• Provide data support for leadership

-2 -

Products Storage Command Control & Data Centre

Storage Cloud Storage System IPSAN
96 TB per set 32T/48T/64T/96T
Type
Capacity Up to 100PB in one system 500Mbs
Read-write Speed 8Gbps Read-write Speed by Node RAID0,1,5,6,10，RAIDX

RAID Virtual Storage SATA
HDD Data Corruption Recovery 3 x Gigabit
Ethernet Redundant Power Supply
Power SATA
Model VS200G
3 x Gigabit
Redundant Power Supply

KCloudStor 2000

VMS 1,000 Channel Video Management System 10,000 Channel

Camera Access 3,000 Channel by Stack 5,000 Channel 30,000 Channel by Stack
Maximum Camera Access 20,000 Channel by Cascade 15,000 Channel by Stack 100,000 Channel by Cascade
50,000 Channel by Cascade
Decoder Access 300 Channel by Each 600 Channel by Each
Ethernet 1,000 Channel by Stack 600 Channel by Each 1,500 Channel by Stack
Model 1,500 Channel by Stack
2 x Gigabit -
3 x Gigabit
KDM2801H-G2 KDM2901-G2
KDM2802A-G2


-3 -

Command Control & Data Centre

Command Control Centre

Type Model Decoder Module Chassis
Chassis KDM201-SH-F
Feature
Decoder Module KDM201-D01F
Rack mount
Decoder Module KDM201-D02E 8 x Slot

Decoder Module KDM201-D04F 1 x Gigabit RJ45
1 x HDMI, 1 x VGA, 1 x BNC video out
1 x 3.5mm Mic in, 1 x 3.5mm Line in, 1 x 3.5mm Line out

1 x RS232, 1 x RS485
1 × QXGA / 2 × 1080p / 4 × 720p / 9 × D1 / 16 × CIF

2 x HDMI, 1 x VGA
H.265 / H.264

1 x 3.5mm Line in, 1 x 3.5mm Line out
1 x RS485

2 × 4K / 4 × 4MP / 9 × 1080p / 16 × 720p

4 x HDMI
1 x 3.5mm Line in, 1 x 3.5mm Line out

1 x RS232, 1 x RS485
2 x QXGA / 4 x 1080p / 8 x 720p / 16 x D1 / 64 x CIF

Keyboard

Type Network Keyboard Network Keyboard
Feature
Model 1 x RS232, 1 x RS422, 1 x RS485, 1 x 10/100M RJ45 1 x RS232, 1 x RS422, 1 x 10/100/1000M RJ45
Picture Compatible with Platform 1 x USB3.0, 2 x HDMI output
Camera PTZ control 7" colour LCD
Video decoder control Compatible with Platform
Camera PTZ control
KB-20 Video decoder control

KB-30

-4 -

Command Control & Data Centre

LED Display Screen

Model Picture Pixel Pitch Unit Resolution Unit Unit Area Weight per Unit Avg Power Video Receive
JY-P2-X12 Dimensions 0.209m² Consumption Power Input Port
JY-P2-X12S
JY-P2-X15 Port (RJ45)
JY-P2-X15S
JY-P3-X12L 1.27mm 480 × 270 609.92 × 343.08 9kg 255W/m² 1 1
JY-P3-X15L × 82 (mm)

1.27mm 480 × 270 609.92 × 343.08 0.209m² 10kg 255W/m² 2 2
× 82 (mm)

1.588mm 384 × 216 609.92 × 343.08 0.209m² 9kg 255W/m² 1 1
× 82 (mm)

1.588mm 384 × 216 609.92 × 343.08 0.209m² 10kg 255W/m² 2 2
× 82 (mm)

1.250mm 480 × 270 600 × 337.5 0.2025m² 6.6kg 222W/m² 1 1
× 69 (mm)

1.5625mm 384 × 216 600 × 337.5 0.2025m² 6.6kg 173W/m² 1 1
× 69 (mm)

LED Sender

Model Picture Video Input Transmission Max. Load Video Management Port Dimensions Weight
JY-S100 Distance Resolution Output 5.6kg
1 × DVI-D 5.7kg
10m 1920 × 1080p 28, self- 1 × LAN port (100Base-TX), for 443 x 384 x 44 5.7kg
1 × DVI-D @ 60Hz adaptive uniform control (mm) 5.6kg
1 × HDBaseT 5.7kg
JY-S100-T twisted-pair 100m 1920 × 1080p 28, self- 1 × M/S senders data sync port 443 x 384 x 44 5.7kg
@ 60Hz adaptive 1 × RS232 (mm)
1 × DVI-D
JY-S100-F 1 × HDBaseT 10km 1920 × 1080p 28, self- 1 × LAN port (100Base-TX), for 443 x 384 x 44
@ 60Hz adaptive uniform control (mm)
fiber
JY-S100-D12 10m 1920 × 1080p 20, self- 1 × M/S senders data sync port 443 x 384 x 44
1 × DVI-D @ 60Hz adaptive 1 × RS232 (mm)

JY-S100-T-D12 1 × DVI-D 100m 1920 × 1080p 20, self- 1 × LAN port (100Base-TX), for 443 x 384 x 44
1 × HDBaseT @ 60Hz adaptive uniform control (mm)
twisted-pair
JY-S100-F-D12 10km 1920 × 1080p 20, self- 1 × M/S senders data sync port 443 x 384 x 44
1 × DVI-D @ 60Hz adaptive 1 × RS232 (mm)
1 × HDBaseT
1 × LAN port (100Base-TX), for
fiber uniform control

1 × M/S senders data sync port
1 × RS232

1 × LAN port (100Base-TX), for
uniform control

1 × M/S senders data sync port
1 × RS232

1 × LAN port (100Base-TX), for
uniform control

1 × M/S senders data sync port
1 × RS232

-5 -

Command Control & Data Centre

LCD Display Screen

Model Picture Diagonal Backlight Bezel Luminance Contrast Resolution Input Output Control
JL-L1-49L18 Direct Width 500cd/m² rate Interface
JL-L1-49H18 1.8mm 700cd/m² 1920 × 1080 1 × DVI, 1 × 1 × BNC RS232 / IR
JL-L1-55L18 49" 1.8mm 500cd/m² 3000:1 1920 × 1080 VGA, 1 × HDMI, 1 × BNC RS232 / IR
JL-L1-55H18 LED 1.8mm 700cd/m² 4000:1 1920 × 1080 1 × BNC RS232 / IR
JL-L1-46L35 1.8mm 500cd/m² 3000:1 1920 × 1080 1 × BNC 1 × BNC RS232 / IR
JL-L1-46H35 Direct 3.5mm 700cd/m² 4000:1 1920 × 1080 1 × BNC RS232 / IR
JL-L1-49L35 49" 3.5mm 500cd/m² 3000:1 1920 × 1080 1 × DVI, 1 × 1 × BNC RS232 / IR
JL-L1-55L35 3.5mm 500cd/m² 3000:1 1920 × 1080 VGA, 1 × HDMI, 1 × BNC RS232 / IR
JL-L1-55H35 LED 3.5mm 700cd/m² 3000:1 1920 × 1080 1 × BNC RS232 / IR
Direct 3.5mm 3000:1 1920 × 1080 1 × BNC 1 × BNC RS232 / IR
55" 4000:1
1 × DVI, 1 ×
LED VGA, 1 × HDMI,
Direct
55" 1 × BNC

LED 1 × DVI, 1 ×
Direct VGA, 1 × HDMI,
46"
1 × BNC
LED
Direct 1 × DVI, 1 ×
46" VGA, 1 × HDMI,

LED 1 × BNC
Direct
49" 1 × DVI, 1 ×
VGA, 1 × HDMI,
LED
Direct 1 × BNC
55"
1 × DVI, 1 ×
LED VGA, 1 × HDMI,
Direct
55" 1 × BNC

LED 1 × DVI, 1 ×
VGA, 1 × HDMI,

1 × BNC

1 × DVI, 1 ×
VGA, 1 × HDMI,

1 × BNC

Splicing Processor

Model Picture SPEC Dimensions Input Slot Output Slot Max. Input Max. Output Power Module
19-inch, 4U Channel Channel
MSP100-X1-4U 19-inch, 8U 438 × 316 × 178 6 2 1
19-inch, 14U (mm) 16 × 1080p + 4 × 4 × 4K / 8 ×
19-inch, 22U 4K / 1080p Redundant Power
MSP100-X1-8U 438 × 316 × 356 13 4.5 Supply (the
(mm) 24 × 1080p 9 x 4K / 18 ×
MSP100-X1- 1080p second power is
14U 438 × 316 × 623 24 9 36 × 1080p + 8 × optional)
(mm) 32 18 4K / 18 x 4K / 36 ×
MSP100-X1- 1080p Redundant Power
22U 438 × 316 × 979 52 × 1080p Supply
(mm) 36 x 4K / 72 ×
64 × 1080p + 16 1080p Redundant Power
× 4K / Supply

96 × 1080p

56 × 1080p + 36
× 4K /

128 × 1080p

-6 -

IP Camera

-7 -

IP Camera

Overview

KEDACOM is a professional manufacturer of IP cameras. These well-designed IP Cameras can fulfill users' video surveillance requirements
in different scenarios, providing optimal video footage with abundant enhanced features.

Key Advantages Normal Glass Anti-fog Glass

Innovative Industrial Design Packet loss, Latency Jitter

• Simple appearance video stream NVR
• Hassle-free installation dynamic adjustment VMS
• IP67
• IK10 IP Camera
• Vapour proof
• Anti-fog / Heating glass With KEDACOM
Starlight
High Reliability
Without KEDACOM
• Industrial components adoption Starlight
• TVS 6000V lightning protection
• Surge protection and voltage protection Enterguard Object left Object removal
• -40° C ~ 70° C / -40° F ~ 158° F
• 7x24x365 continuous operation Guard Area Motion Detection Exit Guard Area

Powerful Network Adaptability Audio Surge Tampering Gathering

• Packet loss recovery,
Video stream dynamic adjustment

• ANR
(Automatic Network Replenishment)

Excellent Image

• Starlight 2.0
• Ultra WDR
• Smart IR
• Smart H.265
• High speed AF algorithm
• 3D noise reduction
• Defog

Abundant Professional Functions

• Embedded Orientation sensor (O-sensor)
Gravity sensor (G-sensor)

• Embedded intelligent analytic functions
• Audio mixed recording
• Laser model
• Multiple code streams

-8 -

IP Camera

Products

Box Camera

Model Picture Image Resolution Compression WDR Intelligent Starlight Specialty Interface
IPC113-HN Sensor
IPC123-HN
IPC143-HN 1/3" 1.3MP H.265/H.264 Digital WDR Basic - O/G sensor PoE, Micro SD Card Slot, Audio
IPC123-FN Intelligent Ⅱ
IPC123-Fi9N Built-in Mic Alarm, RS485, Video Out
IPC183-Fi9N
1/3" 2.0MP H.265/H.264 Digital WDR Basic - O/G sensor PoE, Micro SD Card Slot, Audio
Intelligent Ⅱ
Built-in Mic Alarm, RS485, Video Out

1/3" 4.0MP H.265/H.264 Ultra WDR Basic - O/G sensor PoE, Micro SD Card Slot, Audio
Ultra WDR Intelligent Ⅱ
Ultra WDR Built-in Mic Alarm, RS485, Video Out
Ultra WDR
1/1.9" 2.0MP H.265/H.264 Basic 0.001lux 60fps PoE, Micro SD Card Slot, Audio
Intelligent Ⅱ O/G sensor Alarm, RS485, Video Out
1/2" 2.0MP H.265/H.264 Starlight Built-in Mic
Basic 2.0 PoE, Micro SD Card Slot, Audio
1/1.8" 4K H.265/H.264 Intelligent Ⅱ 60fps Alarm, RS485, Video Out
0.005lux O/G sensor
Basic Built-in Mic PoE, Micro SD card Slot, Audio
Intelligent Ⅱ Alarm, RS485, Video Out
60fps
O/G sensor
Built-in Mic

Semi Dome Camera

Model Picture Image Resolution IR Lens Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC2240- 1/3" 2.0MP - 2.1mm H.265/H.264 Digital - Basic Intelligent - Mini size PoE, Micro SD Card
HN-P Fixed Lens WDR Ⅰ IK10 Slot

IPC2240- 1/3" 2.0MP 30m smart IR 2.8/3.6/6mm H.265/H.264 Digital - Basic Intelligent - Built-in Mic PoE, Micro SD Card
HN- Fixed Lens WDR Ⅰ Slot
PIR30 Mini size
1/3" 2.0MP - 2.1mm H.265/H.264 Digital - Basic Intelligent - IK10 PoE, Micro SD Card
IPC2240- Fixed Lens WDR Ⅱ Slot, Audio, Alarm
HN-S Built-in Mic RS485, Video Out
1/3" 2.0MP 30m smart IR 2.8/3.6/6mm H.265/H.264 Digital - Basic Intelligent -
IPC2240- Fixed Lens WDR Ⅱ Mini size PoE, Micro SD Card
HN- IK10 Slot, Audio, Alarm
SIR30 1/3" 4.0MP - 2.1mm H.265/H.264 Digital - Basic Intelligent - RS485, Video Out
Fixed Lens WDR Ⅰ Built-in Mic
IPC2440- PoE, Micro SD Card
HN-P 1/3" 4.0MP 30m smart IR 2.8/3.6/6mm H.265/H.264 Digital - Basic Intelligent - Mini size Slot
Fixed Lens WDR Ⅰ IK10
IPC2440- PoE, Micro SD Card
HN- 1/3" 4.0MP - 2.1mm H.265/H.264 Digital - Basic Intelligent - Built-in Mic Slot
PIR30 Fixed Lens WDR Ⅱ
Mini size PoE, Micro SD Card
IPC2440- 1/3" 4.0MP 30m smart IR 2.8/3.6/6mm H.265/H.264 Digital - Basic Intelligent - IK10 Slot, Audio, Alarm
HN-S Fixed Lens WDR Ⅱ RS485, Video Out
Built-in Mic
IPC2440- PoE, Micro SD Card
HN- Mini size Slot, Audio, Alarm
SIR30 IK10 RS485, Video Out

Built-in Mic

Mini size
IK10

Built-in Mic

Mini size
IK10

Built-in Mic

LC2110- 1/3" 1.3MP 30m smart IR 2.8/3.6/6/8/ H.264 Digital IP66 Motion - - -
BN-D 12mm Fixed Lens WDR Detection

IPC2111- 1/3" 1.3MP 30m smart IR 2.8/3.6/6/8mm H.265/H.264 Digital IP66 Basic Intelligent - Built-in Mic -
HN-DIR Fixed Lens WDR IP66 Ⅰ Anti-fog glass -
IK10 (optional)
IPC2211- 1/2.8" 2.0MP 40m smart IR 2.8/3.6/6/8mm H.265/H.264 Ultra Basic Intelligent 0.002lux
FN-DIR Fixed Lens WDR Ⅰ Built-in Mic
Anti-fog glass
IK10 (optional)

-9 -

IP Camera

Semi Dome Camera

Model Picture Image Resolution IR Lens Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC2211- 1/2.8" 2.0MP 40m smart IR 2.8/3.6/6/8mm H.265/H.264 Ultra IP66 Basic Intelligent 0.002lux Built-in Mic PoE, Micro SD Card
FN-PIR Fixed Lens WDR IP66 Ⅰ Anti-fog glass Slot
IP66 IK10 (optional)
IPC2211- IP66
FN-SIR 1/2.8" 2.0MP 40m smart IR 2.8/3.6/6/8mm H.265/H.264 Ultra IP66 Basic Intelligent 0.002lux Built-in Mic PoE, Micro SD Card
Fixed Lens WDR IP67 Ⅱ Anti-fog glass Slot, Audio, Alarm
IPC2411- IP67 IK10 (optional) RS485, Video Out
HN-DIR IP67
1/3" 4.0MP 30m smart IR 2.8/3.6/6/8mm H.265/H.264 Digital IP67 Basic Intelligent - Built-in Mic -
IPC2411- Fixed Lens WDR IP67 Ⅰ Anti-fog glass
HN-PIR IP67 IK10 (optional)
IP67
IPC2411- 1/3" 4.0MP 30m smart IR 2.8/3.6/6/8mm H.265/H.264 Digital Basic Intelligent - Built-in Mic PoE, Micro SD Card
HN-SIR Fixed Lens WDR Ⅰ Anti-fog glass Slot
IK10 (optional)
IPC2241-
FN-PIR 1/3" 4.0MP 30m smart IR 2.8/3.6/6/8mm H.265/H.264 Digital Basic Intelligent - Built-in Mic PoE, Micro SD Card
Fixed Lens WDR Ⅱ Anti-fog glass Slot, Audio, Alarm
IPC2241- IK10 (optional) RS485, Video Out
FN-SIR
1/2.8" 2.0MP 15m start IR 2.8/3.6/6/8mm H.265/H.264 Ultra Basic Intelligent 0.001lux Mini size PoE, Micro SD Card
IPC2241- Fixed Lens WDR Ⅰ IK10, Built-in Mic Slot
FNW-PIR
EN50155
IPC2241-
FNW-SIR 2.8/3.6/6/8mm Ultra Basic Intelligent Mini size PoE, Micro SD Card
Fixed Lens WDR Ⅱ
IPC2233- 1/2.8" 2.0MP 15m start IR H.265/H.264 0.001lux IK10, Built-in Mic Slot, Audio, Alarm
FN-S
EN50155 RS485, Video Out
IPC2233-
FN- 1/2.8" 2.0MP 15m start IR 2.8/3.6/6/8mm H.265/H.264 Ultra Basic Intelligent 0.001lux Mini size PoE, Micro SD Card
PIR40 Fixed Lens WDR Ⅰ IK10, Built-in Mic Slot

IPC2233- WiFi, EN50155
FN-SIR40
2.8/3.6/6/8mm Ultra Basic Intelligent Mini size PoE, Micro SD Card
Fixed Lens WDR Ⅱ
1/2.8" 2.0MP 15m start IR H.265/H.264 0.001lux IK10, Built-in Mic Slot, Audio, Alarm

WiFi, EN50155 RS485, Video Out

1/2.8" 2.0MP - 2.1mm H.265/H.264 Ultra Basic Intelligent 0.002lux IK10 PoE, Micro SD Card
1/2.8" 2.0MP Fixed Lens WDR Ⅱ Slot, Audio, Alarm
1/2.8" 2.0MP 40m RS485, Video Out
Smart IR
2.7 ~ 12mm H.265/H.264 Ultra Basic Intelligent 0.002lux IK10 PoE, Micro SD Card
40m Motorized WDR Ⅰ Slot
Smart IR Varifocal Lens

2.7 ~ 12mm H.265/H.264 Ultra Basic Intelligent 0.002lux IK10 PoE, Micro SD Card
Motorized WDR Ⅱ Slot, Audio, Alarm
Varifocal Lens RS485, Video Out

IPC2433- 1/3" 4.0MP 40m 2.7 ~ 12mm H.265/H.264 Digital IP67 Basic Intelligent - IK10 PoE, Micro SD Card
HN- Smart IR Motorized WDR Ⅰ Slot
PIR40 Varifocal Lens

IPC2433- 1/3" 4.0MP 40m 2.7 ~ 12mm H.265/H.264 Digital IP67 Basic Intelligent - IK10 PoE, Micro SD Card
HN- Smart IR Motorized WDR Ⅱ Slot, Audio, Alarm
SIR40 Varifocal Lens RS485, Video Out

IPC2231- 1/2.8" 2.0MP - 2.0/2.2mm Fixed Ultra IP67 Basic Intelligent 0.002lux IK10, 2 x Audio in PoE, Micro SD Card
FN-S 1/2.8" 2.0MP 2.8 ～ 12mm AF H.265/H.264 WDR IP67 Ⅱ Power output Slot, Audio, Alarm
1/3" 4.0MP IP67 RS485, Video Out
IPC2231- 1/3" 4.0MP Lens IP67
FN-SIR40
40m 2.8 ～ 12mm AF H.265/H.264 Ultra Basic Intelligent 0.002lux IK10, 2 x Audio in PoE, Micro SD Card
IPC2431- Smart IR Lens WDR Ⅱ Power output Slot, Audio, Alarm
HN-S RS485, Video Out

IPC2431- - 2.0/2.2mm Fixed Ultra Basic Intelligent - IK10, 2 x Audio in PoE, Micro SD Card
HN- 2.8 ～ 12mm AF H.265/H.264 WDR Ⅱ Power output Slot, Audio, Alarm
SIR40 RS485, Video Out
Lens

40m 2.8 ～ 12mm AF H.265/H.264 Ultra Basic Intelligent - IK10, 2 x Audio in PoE, Micro SD Card
Smart IR Lens WDR Ⅱ Power output Slot, Audio, Alarm
RS485, Video Out

- 10 -

IP Camera

Speed Dome Camera

Model Picture Image Resolution Lens IR Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection
IPC411-
E020-N0 1/3" 1.3MP 16x - H.264 Digital WDR - Motion - PoE (optional), SD Card
Detection - Slot, Audio, Alarm
IPC411-
E020-N1 RS485, Video Out

IPC421- 1/3" 1.3MP 16x - H.264 Digital WDR IP67 Motion - - SD Card Slot, Audio
E230-N0 Detection Alarm, RS485, Video Out

IPC421- 1/2.8" 2.0MP 30x - H.265/H.264 Ultra WDR - Basic 0.003lux O-sensor PoE (optional), SD Card
F120-N0 Intelligent Slot, Audio, Alarm
RS485, Video Out
IPC421- Ⅱ
F120-N1
1/2.8" 2.0MP 20x - H.265/H.264 Ultra WDR - Basic 0.003lux O-sensor PoE (optional), SD Card
IPC421- Intelligent Slot, Audio, Alarm
F233-N1 RS485, Video Out
Ⅰ
IPC427-
F020-N 1/2.8" 2.0MP 20x - H.265/H.264 Ultra WDR IP67 Basic 0.003lux O-sensor SD Card Slot, Audio
Intelligent 0.003lux Alarm, RS485, Video Out
IPC427- 0.006lux
F120-NP 1/2.8" 2.0MP 33x - H.265/H.264 Ultra WDR IP67 Ⅰ 0.006lux O-sensor SD Card Slot, Audio
0.006lux Alarm, RS485, Video Out
IPC427- Basic
F130-NP 1/2.8" 2.0MP 20x 180m H.265/H.264 Digital WDR IP66 Intelligent O-sensor SD Card Slot
Audio Alarm
IPC425- Ⅱ
G245-N 1/2.8" 2.0MP 20x 180m H.265/H.264 Digital WDR IP66 O-sensor PoE, SD Card Slot
Basic Audio, Alarm
IPC415- Intelligent
E120-N 1/2.8" 2.0MP 30x 180m H.265/H.264 Digital WDR IP66 O-sensor PoE, SD Card Slot
Ⅰ Audio, Alarm
IPC425-
F120-N Basic
Intelligent
IPC425-
F223-N Ⅰ

IPC425- Basic
F233-N Intelligent

IPC425- Ⅰ
F233-NL
1/1.9" 2.0MP 45x 220m H.265/H.264 Digital WDR IP66 Motion 0.002lux GPS Built-in eMMC, Audio
IPC445- Detection Alarm, RS485
H120-N
1/3" 1.3MP 16x 150m H.264 Digital WDR IP66 Motion - - SD Card Slot
IPC485- Detection Audio Alarm
H233-N
1/2.8" 2.0MP 20x 180m H.265/H.264 Ultra WDR IP66 Basic 0.003lux O-sensor SD Card Slot
IPC422- Intelligent 0.001lux Audio Alarm
F105-N 0.003lux
1/1.9" 2.0MP 23x 220m H.265/H.264 Ultra WDR IP66 Ⅰ O-sensor SD Card Slot, Audio
IPC422- Alarm, RS485, Video Out
F105-NP Basic
1/2.8" 2.0MP 33x 220m H.265/H.264 Ultra WDR IP66 Intelligent 60fps SD Card Slot, Audio
IPC422- Wiper Alarm, RS485, Video Out
F112-N Ⅱ O-sensor
60fps SD Card Slot, Audio
IPC422- Basic Laser Alarm, RS485, Video Out
F112-NP Intelligent Wiper
O-sensor SD Card Slot
Ⅱ Audio Alarm
O-sensor
1/2.8" 2.0MP 33x 500m H.265/H.264 Ultra WDR IP66 Basic 0.003lux
Intelligent

Ⅱ

1/3" 4.0MP 20x 180m H.265/H.264 Digital WDR IP66 Basic -
Intelligent -
1/1.7" 4K 33x 220m H.265/H.264 Ultra WDR IP66 0.001lux O-sensor SD Card Slot, Audio
Ⅰ 0.001lux Alarm, RS485, Video Out
0.001lux
1/2.8" 2.0MP 5x 30m H.265/H.264 Ultra WDR IP66 Basic 0.001lux O-sensor SD Card Slot, Audio
Intelligent
IK10 Alarm, RS485, Video Out
Ⅱ
1/2.8" 2.0MP 5x 30m H.265/H.264 Ultra WDR IP66 O-sensor PoE, SD Card Slot
Basic
Intelligent IK10 Alarm, RS485, Video Out

1/2.8" 2.0MP 12x 50m H.265/H.264 Ultra WDR IP66 Ⅱ O-sensor SD Card Slot, Audio

Basic IK10 Alarm, RS485, Video Out
Intelligent
1/2.8" 2.0MP 12x 50m H.265/H.264 Ultra WDR IP66 O-sensor PoE, SD Card Slot
Ⅱ IK10 Audio, Alarm, RS485

Basic Video Out
Intelligent

Ⅱ

Basic
Intelligent

Ⅱ

- 11 -

IP Camera

Model Picture Image Resolution Lens IR Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor 1500m Protection
IPC980- 1000m
T850-NL 1/1.8" x 12 2x Ultra Basic GPS SD Card Slot
WDR Intelligent Ⅱ 360˚ Audio, Alarm
IPC980- & 1/1.8" x 4096×1800 50x H.265/H.264 IP66 0.005lux Panoramic RS485, Video Out
U850-NL 50x IP66 Basic 0.005lux Laser PTZ
1 & 8MP Intelligent Ⅱ SD Card Slot
GPS Audio, Alarm
1/1.8" x 6 1x Ultra 180˚ RS485, Video Out
WDR Panoramic
& 1/1.8" x 4096×1800 H.265/H.264 Laser PTZ

1 & 8MP

Explosion Proof

Model Picture Image Resolution Lens Compression WDR Ingress Intelligent Starlight Specialty Storage
IPC820-FB Sensor Protection
IPC421-FB
1/2.8" 2.0MP 20x H.265/H.264 Ultra WDR IP68 Basic 0.003lux Exd Ⅱ CT6 / DIP A20 SD Card (optional)
Intelligent Ⅰ TA,T6

1/2.8" 2.0MP 20x H.265/H.264 Ultra WDR IP68 Basic 0.003lux Exd Ⅱ CT6 / DIP A20 SD Card (optional)
Intelligent Ⅰ TA,T6

IR Bullet Camera

Model Picture Image Resolution IR Lens Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC2253-FNB- 1/2.8" 2.0MP 40m 3.6/6mm H.265/H.264 Ultra IP67 Basic 0.002lux Mini size PoE, Micro SD Card
PIR40 smart IR Fixed Lens WDR Intelligent Ⅰ Anti-fog glass Slot

IPC2453- 1/3" 4.0MP 30m 3.6/6mm H.265/H.264 Digital IP67 Basic - Mini size PoE, Micro SD Card
HNB-PIR30 smart IR Fixed Lens WDR Intelligent Ⅰ
Anti-fog glass Slot

LC2150-BN-D 1/3" 1.3MP 30~50m 3.6/6/8/12/16mm H.264 Digital IP66 Motion - - -
WDR Detection
smart IR Fixed Lens

IPC2152-HN- 1/3" 1.3MP 30~50m 3.6/6/8/12/16mm H.265/H.264 Digital IP66 Basic - Anti-fog glass -
DIR smart IR Fixed Lens WDR Intelligent Ⅰ

IPC2252-FN- 1/2.8" 2.0MP 60m 3.6/6/8/12/16mm H.265/H.264 Ultra IP66 Basic 0.002lux Anti-fog glass -
DIR smart IR Fixed Lens WDR Intelligent Ⅰ

IPC2252-FN/ 1/2.8" 2.0MP 60m 3.6/6/8/12/16mm H.265/H.264 Ultra IP66/67 Basic 0.002lux Anti-fog glass PoE, Micro SD Card
FNB-PIR smart IR Fixed Lens WDR Intelligent Ⅰ Slot

IPC2252-FN/ 1/2.8" 2.0MP 60m 3.6/6/8/12/16mm H.265/H.264 Ultra IP66/67 Basic 0.002lux Anti-fog glass PoE, Micro SD Card
FNB-SIR smart IR Fixed Lens WDR Intelligent Ⅱ Slot, Audio, Alarm
RS485, Video Out
IPC2452-HN-
DIR 1/3" 4.0MP 30~50m 3.6/6/8/12/16mm H.265/H.264 Digital IP66 Basic - Anti-fog glass -
smart IR Fixed Lens WDR Intelligent Ⅰ

IPC2452-HN/ 1/3" 4.0MP 30~50m 3.6/6/8/12/16mm H.265/H.264 Digital IP66/67 Basic - Anti-fog glass PoE, Micro SD Card
HNB-PIR smart IR Fixed Lens WDR Intelligent Ⅰ Slot

IPC2452-HN/ 1/3" 4.0MP 30~50m 3.6/6/8/12/16mm H.265/H.264 Digital IP66/67 Basic PoE, Micro SD Card
HNB-SIR smart IR Fixed Lens WDR Intelligent Ⅱ - Anti-fog glass Slot, Audio, Alarm

RS485, Video Out

- 12 -

IP Camera

Model Picture Image Resolution IR Lens Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC2252- 1/2.8" 2.0MP 50~70m 2.8 ~ 12mm H.265/H.264 Ultra IP66/67 Basic 0.002lux Heating glass PoE, Micro SD Card
FN/FNB- smart IR Motorized WDR Intelligent Ⅰ Slot
PIR50-Z2812 Varifocal Lens

IPC2252- 1/2.8" 2.0MP 50~70m 2.8 ~ 12mm H.265/H.264 Ultra IP66/67 Basic 0.002lux Heating glass PoE, Micro SD Card
FN/FNB- smart IR Motorized WDR Intelligent Ⅱ Slot, Audio, Alarm
SIR50-Z2812 Varifocal Lens RS485, Video Out

IPC2452- 1/3" 4.0MP 30~50m 2.8 ~ 12mm H.265/H.264 Digital IP66/67 Basic - Heating glass PoE, Micro SD Card
HN/HNB- smart IR Motorized WDR Intelligent Ⅰ Slot
PIR50-Z2812 Varifocal Lens

IPC2452- 1/3" 4.0MP 30~50m 2.8 ~ 12mm H.265/H.264 Digital IP66/67 Basic - PoE, Micro SD Card
HN/HNB- smart IR Motorized WDR Intelligent Ⅱ Heating glass Slot, Audio, Alarm
SIR50-Z2812 Varifocal Lens
RS485, Video Out
IPC2251-
FN/FNB- 1/2.8" 2.0MP 50~80m 2.8 ~ 12mm H.265/H.264 Ultra IP67 Basic 0.001lux O/G sensor PoE, Micro SD Card
SIR50-Z2812 smart IR AF Lens WDR Intelligent Ⅱ Heating glass Slot, Audio, Alarm
RS485, Video Out
IPC2251-
FN/FNB- 1/2.8" 2.0MP 80~120m 6 ～ 48mm H.265/H.264 Ultra IP67 Basic 0.001lux O/G sensor PoE, Micro SD Card
SIR80-Z6048 smart IR AF Lens WDR Intelligent Ⅱ Heating glass Slot, Audio, Alarm
RS485, Video Out

Fish Eye & Pinhole

Model Picture Image Resolution IR Lens Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC2860-HN- 1/1.7" 12MP 30m smart 1.85mm H.265/H.264 Digital IP67 Basic - IK10, Built-in Mic PoE, Micro SD Card
SIR30-L0185 IR Fixed Lens WDR Intelligent Ⅱ Built-in Speaker Slot, Audio, Alarm

RS485

IPC2860-HN- 1/1.7" 8.0MP 15m smart 1.85mm H.265/H.264 Digital IP67 Basic - K10, Built-in Mic PoE, Micro SD Card
PIR15-L0185 IR Fixed Lens WDR Intelligent Ⅰ
Built-in Speaker Slot

IPC2270-FN- 1/2.8" 2.0MP - 3.7mm H.265/H.264 Ultra - Basic - Pinhole Micro SD Card Slot
S-L0370 Fixed Lens WDR Intelligent Ⅰ Audio, Alarm, RS485

Video Out

PTZ Camera

Model Picture Image Resolution Lens IR Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection
IPC523-
F255-NL 1/2.8" 2.0MP 55x 1500m H.265/H.264 Ultra WDR IP66 Basic 0.003lux Laser Micro SD Card
IP66 Intelligent Ⅱ Wiper (optional), Audio
IPC523- IP66 O-sensor Alarm, Video Out
F255-NR025 IP66
1/2.8" & 2.0MP & 55x & - H.265/H.264 Ultra WDR IP66 Basic 0.003lux Laser Micro SD Card
IPC523- Thermal 400×300 25mm - H.265/H.264 Ultra WDR Intelligent Ⅱ Wiper (optional), Audio
F255-NR050 Fixed Lens O-sensor Alarm, Video Out
Thermal
IPC525- 1/2.8" & 2.0MP & 55x & Basic 0.003lux Micro SD Card
F132-NL2 Thermal 400×300 50mm Intelligent Ⅱ Laser (optional), Audio
Fixed Lens Wiper Alarm, Video Out
IPC525- O-sensor
F160-NL3 1/1.9" 2.0MP 32x 2000m H.265/H.264 Ultra WDR Basic 0.001lux Thermal Micro SD Card Slot
Intelligent Ⅱ Audio, Alarm
Laser
1/1.9" 2.0MP 60x H.265/H.264 Ultra WDR Basic 0.001lux Optical Defog Micro SD Card Slot
2x Barlow 3000m Intelligent Ⅱ AR & AF glass Audio, Alarm

lens O-sensor
Laser

Optical Defog
AR & AF glass

O-sensor

- 13 -

IP Camera

Model Picture Image Resolution Lens IR Compression WDR Ingress Intelligent Starlight Specialty Interface
Sensor Protection

IPC525- 1/1.9" 2.0MP 60x H.265/H.264 Ultra WDR IP66 Basic 0.001lux Laser Micro SD Card Slot
F260-NL5 2x Barlow 5000m IP66 Intelligent Ⅱ Optical Defog Audio, Alarm
IP66 AR & AF glass
lens IP66 Micro SD Card Slot
O-sensor Audio, Alarm
IPC525- 1/1.9" & 2.0MP & 32x & 3000m H.265/H.264 Ultra WDR Basic 0.001lux Laser
F132-NL3-R75 Thermal 800×600 75mm Intelligent Ⅱ Micro SD Card Slot
Fixed Lens Thermal Audio, Alarm
Optical Defog
IPC525-F160- 1/1.9" & 2.0MP & 62x & 5000m H.265/H.264 Ultra WDR Basic 0.001lux AR & AF glass Micro SD Card Slot
NL5-R100 Thermal 800×600 100mm Intelligent Ⅱ Audio, Alarm
Fixed Lens O-sensor
Laser
IPC528-F360- 1/1.8" & 2.0MP & 60x & 10x 5000m H.265/H.264 Ultra WDR Basic 0.001lux
NL5-R150Z Thermal 800×600 Intelligent Ⅱ Thermal
Optical Defog
AR & AF glass

O-sensor
Laser

Thermal
Optical Defog
AR & AF glass

O-sensor

Intelligent Products

Model Picture Description Image Resolution Compression WDR Intelligent Starlight Specialty Interface
Sensor -
- PoE, Micro SD Card
IPC123-Fi4N Recognitive Box 1/2" 2.0MP H.265/H.264 Ultra WDR Face Starlight - Slot, Audio, Alarm
Camera RS485, Video Out
Recognition 2.0
PoE, Micro SD Card
IPC183-Fi9N Recognitive Box 1/1.8" 4K H.265/H.264 Ultra WDR Face 0.005lux Slot, Audio, Alarm
Camera Recognition RS485, Video Out

IPC2252-Gi4N Human Recognitive 1/2.8" 2.0MP H.265/H.264 Digital WDR Face and Body 0.002lux Micro SD Card Slot
Camera Recognition Audio, Alarm, RS485

IPC2231-Gi4N Human Recognitive 1/2.8" 2.0MP H.265/H.264 Digital WDR Face and Body 0.002lux - Micro SD Card Slot
Camera 2.0MP Recognition Audio, Alarm, RS485
IPC2241- 2.0MP
Gi4NW-SIR15 Human Recognitive 1/2.8" 2.0MP H.265/H.264 Ultra WDR Face and body 0.002lux IP67, IK10 Micro SD Card Slot
Camera H.265/H.264 Recognition EN50155 Audio, Alarm, RS485
IPC2241- Wi-Fi supported
Gi4NG-SIR15
Human Recognitive 1/2.8" Ultra WDR Face and body 0.002lux IP67, IK10 Micro SD Card Slot
IPC2255-Gi4N Camera Recognition EN50155 Audio, Alarm, RS485
Wi-Fi supported
3G / 4G supported

Human Recognitive 1/1.9" H.265/H.264 Digital WDR Face and Body 0.001lux IP67 Micro SD Card Slot
Camera Recognition Audio, Alarm, RS485

IPC2655-Gi4N Human Recognitive 1/1.8" 6.0MP H.265/H.264 Digital WDR Face and Body 0.001lux IP67 Micro SD Card Slot
Camera Recognition Audio, Alarm, RS485
IPC2255-Gi7N
Recognitive Bullet 1/1.9" 2.0MP H.265/H.264 Digital WDR Body and 0.001lux IP67 Micro SD Card Slot
IPC2655-Gi7N Camera Vehicle Audio, Alarm, RS485

IPC121-Bi5N Recognition

IPC425- Recognitive Bullet 1/1.8" 6.0MP H.265/H.264 Digital WDR Body and - IP67 Micro SD Card Slot
i020-N Camera Vehicle Audio, Alarm, RS485
KSCA120-
AI-FC Recognition
KSCA120-
AIG-FC SD Card Slot, Audio

1/1.9" 2.0MP H.264 Digital WDR Auto Tracking 0.002lux - Alarm, RS485, RS232
1/2.8" 2.0MP
Recognitive Video Out
Tracking System
SD Card Slot, Audio
H.264 Digital WDR Recognition 0.005lux - Alarm, RS485
Auto Tracking Video Out

Facial Recognition 1/2.8"x 2.0MP H.265/H.264 Digital WDR Face 0.001lux Qualcomm SD Card Slot，Built-in
Access Control 2 2.0MP Recognition / Liveness Detection Mic, 5" touchscreen
Terminal RS485, Card Reader
RFID

Facial Recognition 1/2.8"x H.265/H.264 Face Qualcomm SD Card Slot，Built-in
Access Control 2 Digital WDR Recognition / 0.001lux Liveness Mic, 5" touchscreen
Terminal RS485, Card Reader
RFID Detection, 4G

- 14 -

IP Camera

NVR

- 15 -

NVR

Overview

By delivering a comprehensive portfolio of professional NVRs, with different levels of capabilities and capacities, KEDACOM assists
clients to deploy video surveillance systems, encompassing tens to hundreds of peripheral units accessibility. With the powerful
complimentary NVR Station CMS level software, hundreds of KEDACOM NVRs can be managed simultaneously and seamlessly on a
PC client-ware.

Key Advantages

Superior Performance Search the moving target by pictures and attributes Facial recognition

• 4K (8MP) accessible and output Packet loss, Latency Jitter
• H.265
• Up to 16 x hard disks video stream NVR
dynamic adjustment
(96TB capacity) /model
• 16 x 1080p simultaneous play back IP Camera
• Output different source with 3 connected local display
• Up to 512Mbps incoming bandwidth

Abundant Professional Functions

• 16-slice playback
• Analytics alarm filter
• TV wall accessible
• Disk management (group and quota)
• IPSAN accessible
• High speed raw data retrieval
• Bi-directional audio recording
• Facial recognition smart search

High Reliability

• Embedded design
• N+1 hot backup (N=36)
• Redundant power supply
• RAID 0/1/5/6/10
• Disk dormancy

Excellent Network Adaptability

• ANR
(Automatic Network Replenishment)

• Auto network organizing
• PLR (Packet Loss Recovery)
• Multiple network access

General Management Software (CMS)

• 128 x NVRs management
with one software

• IP cameras batch upgrade
• E-Map integrated
• 6 x displays accessible with different source output

- 16 -

NVR

Products

Network Video Recorder

Model Picture IP Camera Storage RAID Com Video Out Audio Alarm Control Ethernet USB Decoding Specialty
Input pression Capability

NVR1829- 4/9/16 1 × SATA - H.265/ 1 × HDMI 1 × Audio in - - 1x 2 x USB Up to 1 x PoE, Long Term
01B channel (4K) 10/100M 2.0 4K@30fps / 4 x Recording
H.264 1 × VGA 1 × Audio out 1080p@30fps
NVR1828- or 1 x
01B Gigabit

NVR1828- 9/16 1× SATA - H.265/ 1 × HDMI 1 × Audio in 4 x Inputs 1x 1 x Gigabit 2 x USB Up to 1 x PoE, Long Term
02B channel H.264 (4K) 1 × Audio out 2x RS485 2.0 4K@30fps Recording

NVR1827- 1 × VGA Outputs /4x
04B 1080p@30fps

NVR1821- 4/9/16/32 2× SATA - H.265/ 1 × HDMI 1 × Audio in 4 x Inputs 1x 1 x Gigabit 2 x USB Up to 1 x PoE, Long Term
04A channel H.264 (4K) 1 × Audio out 2x RS485 2.0 4K@30fps / 4 x Recording
1080p@30fps
NVR1821- 1 × VGA Outputs
08A
9/16/32 4× SATA - H.265/ 1 × HDMI 1 × Audio in 4 x Inputs 1x 1 x Gigabit 2 x USB Up to 1 x PoE, Long Term
channel H.264 (4K) 1 × Audio out 2x RS485 2.0 4K@30fps / 4 x Recording
1080p@30fps
9/16/32 1 × VGA Outputs
channel
1 × HDMI 2 x Inputs 2 × USB Up to 4 x N+1 Backup
9/16/32/64 (4K) 2x Mobile Front-end
channel 4 × SATA RAID H.265/ 1 × Audio in 2x 2 x Gigabit 2.0 4K@30fps
1 × eSATA 0/1/5/6/10 H.264 1 × VGA 1 × Audio out Outputs RS485 1 × USB / 16 x Access

8 × SATA RAID H.265/ 2x 3.0 1080p@30fps N+1 Backup
1 × eSATA 0/1/5/6/10 H.264 RS485 Mobile Front-end
1 × HDMI 2 x Inputs 2 × USB Up to 4 x
(4K) 2x Access
1 × Audio in 2 x Gigabit 2.0 4K@30fps
1 × VGA 1 × Audio out Outputs 1 × USB / 16 x

3.0 1080p@30fps

1 × HDMI 1x 2 × USB Up to 4 x Mobile Front-end
(4K) RS485 Access
NVR2821- 9/16/32 4 × SATA RAID H.265/ 1 × Audio in - 3 x Gigabit 2.0 4K@30fps Human
04B/LI channel 0/1/5/6/10 H.264 1 × VGA 1 × Audio out 1x 2× USB / 16 x
RS232 Recognition
3.0 1080p@30fps Camera Access
Face Matching

1 × HDMI 1x 2 × USB Up to 4 x Mobile Front-end
(4K) RS485 Access
NVR2821- 9/16/32 4 × SATA RAID H.265/ 1 × Audio in - 3 x Gigabit 2.0 4K@30fps Human
04B/HI channel 0/1/5/6/10 H.264 1 × VGA 1 × Audio out 1x 2× USB / 16 x
RS232 Recognition
NVR2881- 3.0 1080p@30fps Camera Access
16B/HI Face Matching

NVR2821- 2 × HDMI 2 x Inputs 1x 2 × USB Up to 4 x HDD Hot Swap
03A/V (4K) 2x RS485 Mobile Front-end
16/32/64/128 16 × SATA RAID H.265/ 1 × Audio in 3 x Gigabit 2.0 4K@30fps
NVR2821- channel 0/1/5/6/10 H.264 1 × VGA 1 × Audio out Outputs 1x 2× USB / 16 x Access
06A/V RS232 Human
H.265/ 3.0 1080p@30fps Recognition
NVR2860E- H.264 2x Camera Access
08A RAID 1 × HDMI 2 x Inputs RS485 2 × USB Up to 4 x Face Matching
0/1/5 H.265/ (4K) 2x N+1 Backup
NVR2882- 9/16/32 3× SATA (optional) H.264 1 × Audio in 2x 2 x Gigabit 2.0 4K@30fps Mobile Front-end
16A channel 1 × eSATA 1 × VGA 1 × Audio out Outputs RS485 1 × USB / 16 x Access
Anti-Salt
3.0 1080p@30fps Moisture-Proof
Fungus-Proof
RAID 1 × HDMI 2 x Inputs 2 × USB Up to 4 x HDD Shock-proof
0/1/5/6/10 (4K) 2x N+1 Backup
9/16/32 6× SATA (optional) 1 × Audio in 2 x Gigabit 2.0 4K@30fps Mobile Front-end
channel 1 × eSATA 1 × VGA 1 × Audio out Outputs 1 × USB / 16 x Access
Anti-Salt
3.0 1080p@30fps Moisture-Proof
Fungus-Proof
HDD Shock-proof

1 × HDMI 2 x Inputs 2 × USB Up to 4 x HDD Hot Swap
(4K) 2x N+1 Backup
16/32/48/64 8 × SATA RAID H.265/ 1 × Audio in 2x 2 x Gigabit 2.0 4K@30fps
channel 1 × eSATA 0/1/5/6/10 H.264 1 × VGA 1 × Audio out Outputs RS485 1 × USB / 16 x Mobile Front-end
Access
3.0 1080p@30fps

1 × HDMI 2 x Inputs 2 × USB Up to 4 x HDD Hot Swap
(4K) 2x N+1 Backup
16/32/64 16 × SATA RAID H.265/ 1 × Audio in 2x 2 x Gigabit 2.0 4K@30fps
channel 1 × eSATA 0/1/5/6/10 H.264 1 × VGA 1 × Audio out Outputs RS485 1 × USB / 16 x Mobile Front-end
Access
3.0 1080p@30fps

- 17 -

Mobile Solutions

- 18 -

Mobile Solutions

Overview

Mobile surveillance is increasingly applied within Safe City applications, Crisis Management. KEDACOM offers video surveillance
products and solutions which can be integrated with security vehicles and surveillance equipment carried by law enforcement
personnel. All these products can be seamlessly integrated with KEDACOM VMS thus to obtain wired, wireless, fixed and portable
video footages.

Portable System

KEDACOM Portable Mobile System comprises high-performance video surveillance devices together with abundant accessories
which can all be carried by law enforcement personnel. It encompasses Body Worn Surveillance Phone, Body Worn Camera, External
Camera, DV adaptor, Data Docking Station and other related accessories. KEDACOM Portable Mobile System is being applied within
law enforcement, security patrol, crisis management, covert monitoring and similar scenarios to acquire audio / visual data and
upload it to command center in real-time.
KEDACOM Portable Mobile System is being widely deployed for use with 3G/4G and wireless networks. Real-time audio and video
interaction is possible between related peripheral units and command center. It can also be used with the KEDACOM KWTP wireless
protocol to ensure excellent video stability for streaming and superior image quality.

- 19 -

Mobile Solutions

Body Worn Camera

DSJ-U1 series is an exquisite all-in-one Body Worn Camera from
KEDACOM. This device can be carried easily with continuous video/
audio streaming which can be recorded and uploaded to command
center in real-time through 3G/4G or Wi-Fi network. DSJ-U1 is
embedded with a high-resolution starlight camera, an LED and IR light
for day/night vision. It is designed to use within multiple scenarios and
adhere to the IP67 and drop test standard.

Features 3G/4G, Wi-Fi, Bluetooth, NFC
Qualcomm 8 Core
High-performance Processor 9 hours Continuous Working

GPS+ GLONASS 9 hours continuous using replaceble battery

Shortcut Button + 2.2 inch High Quality Video 20MP LED+IR
Touchscreen Snapshot Auto
1080p triggered
Video by
sensitivity
15 IR
distance

PTT Button

PTT, Bidirectional Audio and
Message

Compact + 3 Proofings

2 Meters drop

Dustproof
Waterproof

- 20 -

Mobile Solutions

Body Worn Surveillance Phone

IPW200 Series Body Worn Surveillance Phone is a specialized and intelligent device
which has powerful video processing and video streaming capabilities. It is equipped
with a 5.5-inch touchscreen and high definition dual cameras.

It enables real-time capture and video uploads to command center using 3G/4G and
Wi-Fi networks through KEDACOM's professional app which is installed in the device
by default. The surveillance phone can be deployed within varying environments
because of its dedicated water-proof, dust-proof and drop tested design.

Features 3G/4G, Wi-Fi, Bluetooth, NFC

Qualcomm 8 Core High-
performance Processor

5.5 inch Touchscreen

GPS+ GLONASS

13MP Ultrathin + 3 Proofings
rear camera

High Quality Video Dustproof
Waterproof

2 Meters drop

Dual SIM

PTT Button Dual SIM

PTT, Bidirectional Audio and
Message

Extra Battery, NFC and
Fingerprint Kit

Shortcut Button

Alarm Button

- 21 -

Mobile Solutions

Accessories

Button / Badge camera

USBCAM-130 can be used together with IPW200 and DSJ-U1. It can be
disguised as a button and used for covert surveillance. It is also supports
a resolution of 1080p@30fps. Together with the embedded microphone, it
delivers excellent audio and video continuously.

Ear-hook camera

USBCAM-200 series are an ear-hook camera which can be used together
with IPW200 and DSJ-U1. At first glance, it looks like a Bluetooth headset
from appearance but it enables true covert surveillance.

USBCAM-200 series also has a lens with F2.2 large aperture and
diagonal Field of View (FOV) up to 84 ° . USBCAM-210 acquires videos at
720p@30fps and USBCAM-230 acquires videos at 1080p@30fps. The built-
in microphone and headset can be used for communication with command
center in intercom mode.

DV adaptor

PF10 is a device to convert signal from HDMI to USB, which can work with
IPW200. PF10 can convert and transmit video from micro HDMI interface
from third party DV or video capture device to IPW200 linked to micro
USB. By doing this, third party equipment's video can be acquired and
accessed. The resolution can be as high as 1080p.

Vehicle Holder

DSJ-VB series are vehicle holders of body worn camera. They can be
adjusted to all angles. DSJ-VB01 is a strong dash mount. DSJ-VB02 is dock
for rear view mirror bracket.

Vest Holder

DSJ-SS series are vest holders for body worn camera with a customized
leather case. DSJ-SS01 is a single sided holder with elastic strap and DSJ-
SS02 is double-shouldered design.

- 22 -

Mobile Solutions

Data Docking Station

ZCS-KDCA1 is an associated equipment for DSJ-U1 Body Worn Camera.
Up to 24 units of Body Worn Cameras can be docked in it simultaneously.
Correspondingly, unified management for record downloading and camera
charging can be done using it.

ZCS-KDCA1 supports a 13.3-inch touchscreen to provide a more visible
user interface. 3 slots for 3.5-inch hard disk supports up to 12TB space with
RAID functionality which secures data more reliably.

Functions like Resume Download in addition to Auto Download, Auto File,
Auto Delete are supported to make ZCS-KDCA1 very simple to use. Users
only need to dock the Body Worn Camera into the dock and manage it
offline using the touchscreen. ZKS-KDCA1 is also available for optional
software to manage multiple ZCS-KDCA1 units simultaneously.

Data Docking Station Management Software

The software allows authorized personnel to access and manage the data
docking stations (up to 500) and all correlated body worn cameras (up to
10,000) via PC. It enables a unified management so that you can download
all recordings and snapshots from multiple devices. Graphical statistics
display provides you a clear vision of operating status of all body worn
cameras.

VLine Communication Kit The latest alarm records

VLine provides real-time communication services such as Push-to-Talk
and message chat. It also supports address book and contacts service,
all the body worn camera and body worn surveillance phone can easily
communicate with other devices. Authorized users can set up or join
groups on VLine PC or Mobile-end. Users are able to send video, audio and
picture messages to all participants, and receive warnings from groups.

- 23 -

Mobile Solutions

Vehicle Mobile System

KEDACOM developed the KEDACOM Vehicle Mobile System (KVMS) which possesses powerful video processing capabilities and
robust mobile network adaptability. It incorporates an in-vehicle NVR, PTZ camera, fixed camera, control PAD, vehicle-mounted
bracket with shock absorber and device box. This system can be deployed in any patrol wagon, fire truck, emergency vehicle, bus
and other similar vehicle. In-vehicle surveillance and concurrent live-viewing, seamless, fast and secure upload of audiovisual data to
command center is a technological paradigm shift.

Dual-sleeve Magnetic IP Camera KDM2410M-V21
Vehicle PTZ Vehicle PTZ Vehicle NVR SVR2420

IP Camera

Shock Absorber
Control PAD

Vehicle Bracker Device Box

Vehicle PTZ Camera

Dual-sleeve Vehicle PTZ IR Camera

IPC521 series can operate consistently with its shock-proof design. The
360° rotation function and 20x/33x optical zoom allows the camera to
monitor vast areas closely. Equipped with a super low illumination sensor,
it can acquire images in color mode at only 0.003lux luminance. 120dB
ultra WDR is supported for superb light distribution for consistent, high
quality imaging. With an efficient IR, distances of up to 200 meters can be
monitored during the night time.

Magnetic Vehicle PTZ IR Camera

IPC522 series can be mounted on the top of vehicles conveniently with 18
pieces of powerful magnets at its base. The high capacity built-in battery
delivers 8-hour long operation time with 4G working as it embedded
Wi-Fi/3G/4G module and requires no cables. With embedded 4 IR light
units and a super low illumination sensor, up to 80-meter distances
can be monitored during night time. The powerful chipset on board
IPC522 enhanced and accomplished the capability and function of facial
recognition in real-time mobility surveillance thru 4G, with personnel
control for a more convenient and efficient deployment.

- 24 -

Mobile Solutions

Vehicle NVR / Wireless Mobile Encoder

Hybrid Vehicle NVR

KDM2410M-V21 is a professional vehicle-mounted device which can either
emulate an NVR to view IP-based camera streams or a wireless encoder for
analog camera access. It can connect, manage and record videos from up
to 4 IP-based and analog cameras simultaneously.

Cameras are connected to KDM2410M-V21 either through its combined
aviation plug or embedded Wi-Fi. A stable physical connection is assured
with an aviation plug even when vehicle is being driven on bumpy roads.
The combined aviation plug not only supports Ethernet and analog
cameras’interfaces, but it can also feed power backward to all cameras,
which makes the installation more conveniently.

The embedded GPS, Wi-Fi module and optional global position module
such as Beidou, GLONASS in the KDM2410M-V21 can upload the vehicle’s
accurate location to command center. Optional 3G / 4G module makes it
possible to support almost all kinds of network protocols, including FDD-
LTE, TDD-LTE, HSPA / UMTS, GSM / GPRS / EDGE, TD-SCDMA, EVDO /
CDMA and so on. Video stream can be transmitted to command center
instantly with such diversified network adaptability.

vehicle CD Player KDM2410M-V21 KDM2410M-V21 has a compact design which can be swiftly installed in the
place of a vehicle CD player which is also aesthetic and saves space.

KDM2410M-V21 possesses a 2.5-inch hard disk drawer, which can be
locked and supports 4TB storage. A structure comprising of a spring
capsule with double shock-proof design, protects hard disk while the
vehicle is being driven on bumpy roads. Besides, the drawer design helps
users change hard disk more conveniently. With the help of USB interface
in its rear panel, the audiovisual records can be retrieved quickly.

Comprehensive interactive operations such as System Management, Live
View and Playback can be conducted through the Control Pad. It can
access the in-vehicle NVR by connecting to its Wi-Fi hotspot and, hence,
not needing any extra cables. After a connection has been established,
the user can wirelessly control the PTZ camera. The touchscreen control
makes the PTZ camera more maneuverable and its operations more visual
and simplified. It also supports real-time two-way voice interaction with
command center.

- 25 -

Mobile Solutions

PoE Vehicle NVR

KEDACOM POE Vehicle NVR Series-SVR2420, is a professional vehicle device designed for Public Transportation, Escort Vehicle,
School Bus and other medium to large size vehicles. Respective 4 x channels sub-model, 8 x channels sub-model and 12 x channels
sub-model could be selected accordingly. Reliable recording can be ensured with device's fanless design, excellent shock-proof
capability RAID with dual Hard Disks and durability under harsh environment. Abundant interfaces make it more convenient to
integrate to existing vehicle system, thus to acquire more real-time vehicle data. Furthermore, KEDACOM's proprietary and unique
KWTP (KEDACOM Wireless Transmission Protocol), in cooperation with dual 3G/4G sim cards, help bring a superb user experience for
real-time remote commanding.

• H.265 / H.264 video encoding
• 4K Decoding
• 12 x 4K HD camera
• Drawer-type shock-proof design
• Embedded 3G / 4G / Wi-Fi module

network enhancement with dual sim card combination
• Embedded GPS / GLONASS module
• Aviation interface with PoE
• Fanless design
• VGA / HDMI output

Mini 4G Vehicle NVR System

KDM2412M is a professional and recognitive vehicle data recorder, which is suitable for Taxi, Police Car and similar small size vehicles.
The device's split design leaves two kinds of cameras which can be selected. A Starlight level and Wide Angle Lens is incorporated
with front camera. And both kinds of cameras are incorporated with not only Starlight level, Wide Angle, and IR Lens, but also
microphone for sound pickup. Besides, both cameras can be attached to front window, so there can be situational awareness from
both inside and outside vehicle.

There is no need to alter inside vehicle with KDM2412M's light and compact design. Dual SD cards help make it durable and reliable
for recording under harsh environment. In addition, KEDACOM's particular clear voice and KWTP technology (KEDACOM Wireless
Transmission Protocol), help bring a superb user experience for real-time remote commanding via 3G / 4G.

• Customized Android OS
• Qualcomm 8 core mobile processor
• 1080p real-time recording, extendable with

second camera
• 2 x alarm input
• Dual SD cards, up to 512 GB/card
• Intelligent car plate recognition (Hardware ready)
• Bi-directional audio
• GPS location
• 3G/4G and multiple kinds of network

- 26 -

Mobile Solutions
Unmanned Aerial Vehicle Mobile System
KEDACOM UAV Solution comprises industrial-grade drones, various payload mounts, integrated ground stations, and back-end
management platform.
KEDACOM intelligent drone can be used in a wide range of surveillance roles such as traffic monitoring, firefighting, search and
rescue, and it can be operated steadily even under severe environment. The high environmental adaptability gives KEDACOM drone
the reliability to safely carry out its fight missions. Integrated with abundant mount cameras, emergency situations can be detected
and the distinct images and videos will be transmit back to the ground station and back-end platform in real-time. Truth revealed at
the fingertips.

• Max. Speed: 72km/h
• 45min flight duration
• Operation in Strong breeze (6th wind scale) and

moderate rain
• H.265/H.264, 1080p@60fps
• Ultra WDR, Starlight
• 30x optical zoom
• Built-in triaxial vision stable PT system
• Ground station with remote control and 3G/4G

transmission functions

- 27 -

Mobile Solutions

Products

Mobile Solutions

Model Picture Image Resolution Lens IR Compression WDR Ingress Intelligent Starlight Storage Specialty
IPC521-H120-N Sensor protection
1/2.8"
1/2.8" 2.0MP 20x 200m H.265/H.264 Digital WDR IP66 Motion Built-in Wiper
1/2.8" Detection 0.003lux SD card

1/2.8" (optional)

IPC521-F233-N 1/2.8" 2.0MP 33x 200m H.265/H.264 Ultra WDR IP66 Motion Built-in Wiper
Detection 0.003lux SD card
1/2.8"
(optional)
1/2.8"
IPC521-H120-W 2.0MP 20x 60m H.265/H.264 Digital WDR IP66 Motion Built-in Built-in super
Detection 0.003lux SD card magnet

(optional) Wi-Fi supported
Built-in battery

IPC521-F120-G 2.0MP 20x 80m H.265/H.264 Digital WDR IP66 Motion 0.003lux Built-in Built-in super
Detection SD card magnet
(standard
128G) Wi-Fi supported
3G / 4G supported

Built-in battery

IPC522-F230-W 2.0MP 30x 80m H.265/H.264 Digital WDR IP66 Motion 0.003lux Built-in Built-in super
Detection SD card magnet
(standard
128G) Wi-Fi supported
Built-in battery

IPC522-F230-G 2.0MP 30x 80m H.265/H.264 Digital WDR IP66 Motion 0.003lux Built-in Built-in super
Detection SD card magnet
(standard
128G) Wi-Fi supported
3G / 4G supported

Built-in battery

IPC522-G230-G 2.0MP 30x 80m H.265/H.264 Digital WDR IP66 Motion 0.003lux Built-in Built-in super
Detection SD card magnet
(standard
Facial 128G) Wi-Fi supported
Recognition 3G / 4G supported

Built-in battery

Model Picture Features

KDM2410M-V21 Vehicle NVR / Wireless Mobile Encoder
4 Channel IP Camera + 4 Channel Analog Camera access

H.265 / H.264
Built-in Wi-Fi AP module, can access Wi-Fi IP camera and PAD

All mobile networks supported
Built-in GPS module

Supports dual SIM card bundle

SVR2420-0204A/4P Mobile NVR
8 x PoE Port (IEEE802.3af)
8 Channel IP camera access

H.265 / H.264
8MP, 1080P, 720P, D1, CIF, QCIF
Built-in Wi-Fi / GPS, Built-in 3G/4G Module (optional)
Supports dual SIM card bundle

2 x 2.5” HDD Bay

SVR2420-0208A/8P Mobile NVR
4 x PoE Port (IEEE802.3af)
4 Channel IP camera access

H.265 / H.264
8MP, 1080P, 720P, D1, CIF, QCIF
Built-in Wi-Fi / GPS, Built-in 3G/4G Module (optional)
Supports dual SIM card bundle

2 x 2.5” HDD Bay

SVR2420-0212A/8P Mobile NVR
IPW200-P1HD 8 x PoE Port (IEEE802.3af)
12 Channel IP camera access

H.265 / H.264
8MP, 1080P, 720P, D1, CIF, QCIF
Built-in Wi-Fi / GPS, Built-in 3G/4G Module (optional)
Supports dual SIM card bundle

2 x 2.5” HDD Bay

Body Worn Surveillance Phone
Android 5.0 OS

5.5” 1080p HD IPS screen display
Supports location function by GPS, GLONASS, Beidou

Supports dual SIM dual standby
IP67, adaptive to various environments

1.5 meters drop shock protection

DSJ-U1 Body Worn Camera
Deep customized Android OS
- 28 - Qualcomm 8 core mobile processor

2mp starlight camera
2.2” touchscreen display
IR night vision, 15M Infrared Distance
Wi-Fi, 3G / 4G, GPS location
IP67, adaptive to various environments
2 meters drop shock protection

Model Picture Mobile Solutions

ZCS-KDCA1 Features

USBCAM-130 Data Docking Station
Supports up to 24 units of Body Worn Cameras
USBCAM-230
Supports extended module
DSJ-VB01 13.3" touchscreen
DSJ-VB02
DSJ-SS01 Record downloading and camera charging
3 slots for 3.5" hard disk supports up to 12TB storage
DSJ-SS02
Button Camera
MA-B1 1080p

MA-B2 Mini Size
Hidden wear
Model Built-in Mic
Low power consumption
ZFS-KDCA1 Data
Docking Station Ear-hook Camera
1080p
Management
Software Mini Size
Built-in Mic
VLine Built-in earphone
Communication Low power consumption

Kit Vehicle Holder
Strong dash mount

Adjustable angle

Vehicle Holder
Dock for rear view mirror bracket

Adjustable angle

Vest Holder
Single Sided Strap Holder
Customized leather case

Adjustable elastic

Vest Holder
Double Shoulder Strap Holder

Customized leather case
Adjustable elastic

1 x Charger Slot
Constant current fast charge

Trickle charge
Overcurrent protection
Short circuit protection
5V DC, 6W (Power Adapter Not Included)

6 x Charger Slot
Constant current fast charge

Trickle charge
Overcurrent protection
Short circuit protection

AC100-240V, 50W

Features

Device management for Body Worn Camera and Data Docking Station
ZFS-KDCA1 can help you manage the data docking station by PC

You can easily access the data docking station and all the body worn cameras
and download the recordings and snapshots

ZFS-KDCA1 supports multiple device management. The software can manage up to
10,000 body worn cameras and 500 data docking stations
It supports graphical statistics, so you can get and view

the operating statistics of all the body worn camera. B/S user interface

VLine is a communication Kit for Kedacom portable mobile devices
such as body worn camera and body worn surveillance phone

It can provide real-time communication service, such as Push-to-Talk and message chat
VLine supports address book and contacts service, so the body worn camera
and body worn surveillance phone can easily communicate with other devices
Supports up to 500 client in a group, supports up to 50,000 users
supports low Message and PTT delay (< 500 ms) on 3G/4G networks

- 29 -

Mobile Solutions

Model Picture Features

KUV-A6120E Wheelbase 1200mm; Arm umbrella folding design for easy carrying and rapid deployment
Flying time 60min (no load); Image transmission standard distance 10km (signal without interference, no occlusion)
KUV-A6120
Maximum mission load of 11kg; 6 rotorcraft x 1 set, battery x 1 set (30000mAh x 2 pieces)
KUV-A4080 charger x 1 set, positive and negative paddles x 1 pair

KPL-Z230 Wheelbase 1200mm; Arm umbrella folding design for easy carrying and rapid deployment
Flying time 45min (no load); Image transmission standard distance 10km (signal without interference, no occlusion)
KPL-R125
Maximum mission load of 7kg; 6 rotorcraft x 1 set, battery x 1 set (22000mAh x 2 pieces)
KPL-F2 charger x 1 set, positive and negative paddles x 1 pair

KPL-F808 Wheelbase 800mm; Arm umbrella folding design for easy carrying and rapid deployment
KPL-V1 Flying time 60min (no load); Image transmission standard distance 10km (signal without interference, no occlusion)
KPL-P1
KGS-A Maximum mission load of 1kg; 4 rotorcraft x 1 set, battery x 1 set (22000mAh x 1 pieces)
charger x 1 set, positive and negative paddles x 1 pair
KGS-C
Model 30x optical zoom camera mount
Starlight, 120dB Ultra WDR

2.0M, 1/2.8", H.265 / H.264, 1920×1080@60fps
High-precision Tri-axial stabilization

1.1kg, Suitable for KUV-A6120E, KUV-A6120, KUV-A4080 aircraft

Thermal camera mount
25mm lens, 800×600@30fps

H.265 / H.264
High-precision Tri-axial stabilization
700g, Suitable for KUV-A6120E, KUV-A6120, KUV-A4080 aircraft

Dual-Spectral camera mount
Visible: 30x optical zoom, 120dB Ultra WDR, Starlight

2.0M, 1/2.8", H.265 / H.264, 1920×1080@60fps
Thermal: 25mm lens, 800×600@30fps, H.265 / H.264

High-precision Tri-axial stabilization
1.1kg, Suitable for KUV-A6120E, KUV-A6120 aircraft

4K Fixed camera mount
8mm lens, 8.0M, 1/1.7", 4096×2160@30fps

H.265 / H.264
High-precision Tri-axial stabilization
350g, Suitable for KUV-A6120E, KUV-A6120, KUV-A4080 aircraft

Megaphone mount
Broadcast distance up to 500 meters
Audio data transmission distance up to 10km

Built-in 2 MP mini camera
600g, Suitable for KUV-A6120E, KUV-A6120 aircraft

Throwing device mount
Supports up to three dropping points, a single load exceeds 5kg (requires aircraft load capacity)

Built-in 2 MP mini camera
498g, Suitable for KUV-A6120E, KUV-A6120 aircraft

Integrated Ground Station
KEDACOM Professional GCS Ground Station Software
Ground image retransmission + remote control + 4G transmission + dual screen computer
10km image transmission (environment without signal interference)

8 hours working time
Suitable for KUV-A6120E, KUV-A6120 aircraft

Handheld Ground Station
KEDACOM Professional GCS Ground Station Software
Ground image retransmission + remote control + 4G transmission + tablet
7km image transmission (environment without signal interference)

2 hours working time
Suitable for KUV-A6120E, KUV-A6120, KUV-A4080 aircraft

Features

KVA-B30 30000mAh lithium battery, 22.2V Output, can be used for KUV-A6120E aircraft, contains two pieces of battery, packed in a explosion-proof box

KVA-B22 22000mAh lithium battery, 22.2V Output, can be used for KUV-A6120 aircraft, contains two pieces of battery, packed in a explosion-proof box

KVA-B22-4 22000mAh lithium battery, 22.2V Output, can be used for KUV-A4080 aircraft, contains one battery

- 30 -

Intelligent and Recognitive Solutions

- 31 -

Intelligent and Recognitive Solutions

What is Recognitive Technology?

Since releasing the industry's first truly innovative recognitive camera in 2014, Kedacom continues to accelerate the development of big data
applications by challenging traditional video surveillance technology. Kedacom will unveil further improved recognitive cameras which will
enhance customers' intelligent front-end system implementation in different scenarios. In the meantime, Kedacom stands ready to push a more
comprehensive solution over the cloud storage infrastructure together with big data applications to help customers deploy end-to-end and fully
intelligent video-to-data-to-video surveillance systems.

We are now focusing on these technologies and products, through standardization of products using a convenient and collaborative
development model that allows global partners to achieve rapid integration of intelligent technology for end customers' innovative projects.
Some such projects include Safe City, intelligent transportation, Smart Safety and Security, smart retail shops and more solutions.

In a traditional video surveillance system, a camera can capture video streams or snapshots which are transmitted to a backend storage device.
The current standard of security surveillance includes the retrieval and analysis of these videos and pictures from back-end storage devices.

The evolution of 'smart' video surveillance systems from traditional surveillance systems encompasses image recognition technology that allows
features such as tripwire drawing and warning area masking and can be set easily using the camera' s image settings. By discerning the target's
movement and its breach of virtual line on entering & exiting the warning area it generates an alarm and collates these event-triggered images
in the background. The security manager / operator is alerted of the triggered alarm so he / she can further assess the intrusion to determine its
nature and take appropriate action.

However, there are some technical limitations to such smart technology. Using this method only partial image pixel changes are recognized
by the camera. And If, for instance, parameters like light intensity, image color or the target size changes, multiple targets appear on-screen
simultaneously and this can raise multiple fault alarms unnecessarily.

In such a case Recognitive Technology, compared with Smart Technology, is more advanced in terms of functions and capability. Recognitive
technology uses a more sophisticated image recognition algorithm, integrating high-performance processing chipset, capable of identifying
and classifying an image. Recognitive technology can not only identify the moving object and the intrusion event, its core capacity is also to
accurately identify multiple moving targets, the ability to trace target movement and determine its speed, direction and characteristics like size,
color and type.

Framework Conventional Smart Technology Recognitive Technology

Image capture + Video Image capture + Video Image capture + Video Encoding +
Encoding Encoding + Smart simple Higher Recognitive Technology

Technology

Processor Codec Codec + Lower CPU Codec + Higher CPU

Capture Content Video, Images Video, Images, Alarms Video, Images, Alarms, Target Track,
Speed, Direction, Size, Colors, Type

Application Conventional Security Enhanced Alarmed Security Intelligent Security & Smart
Application Management

- 32 -

Intelligent and Recognitive Solutions

Kedacom Recognitive Technology Products

The Recognitive Camera

The Recognitive Camera consists of an embedded high-end chipset and analytic algorithm on-board its system. Multiple moving targets can be
locked simultaneously and analyzed. The system differentiates people from objects, determines one’s speed, color, direction of movement etc.
Recognitive Camera can deliver 3 types of streams to the backend storage device - live video, snapshot photos, and label text data which are
generated by the camera. The information is categorized and its features are indexed together with live video data across backend storage
infrastructure which makes cross-reference research possible and also allows authorized users to quickly pinpoint the target within raw footage.

Features
• Object Recognition Algorithm Integrated Within Camera
• Auto Snapshot on Every Moving Object
• Grab the Characteristics of Every Moving Object (Type, Colour, Size, Direction, and Speed)
• SDK Supported (For Application Development Partner)
• Additional Version: Vendor Development Version (Hardware and basic SDK provided.

Vendors can integrate their own analytics algorithms inside camera.)

- 33 -

Intelligent and Recognitive Solutions

Human Recognitive Camera

Human Recognitive Camera is equipped with an embedded high-end chipset, advanced professional recognitive algorithm and
preloaded software. The camera can identify and classify various types of people entering the surveilled region. This Human
Recognitive Camera can capture and recognise not only the facial images, but also simultaneously captures and recognises people by
their facial image and body profile. Going beyond facial image capture, this recognitive camera also captures a person's rear profile
accurately including head and body contours. The camera can also determine a human subject's moving direction, speed and other
characteristics.

Features
• Human Recognition Algorithm Integrated into Camera
• Auto Snapshot Acquired on Every Moving Human
• Auto Selection of the Best Facial Position
• Grabs Characteristics of Moving Person (Direction, Speed)
• Bidirectional People Counting
• SDK Supported (For Application Development Partner)

- 34 -

Intelligent and Recognitive Solutions

Border Collie iNVR

KEDACOM Border Collie iNVR is powered by advanced AI technology and it redefines the application of NVR to a whole new level.
With a reasonable cost, users can enjoy a similar experience to a VMS system. It will be your all-in-one solution in a single device.

Embedded with KEDACOM advanced algorithm, this outstanding iNVR assure 99.9% accuracy for human capture and 98% accuracy
for face recognition. It also works well for multiple angles identification including profile, frontal, 45 degree and more, to ensure the
most accurate matching results. In addition, the system also supports vehicle number plate recognition, which is great for vehicle
access control and parking lot management.

To deliver an exceptional customer experience, Border Collie iNVR provides a highly customizable dashboard that contains more than
18 graph and chart widgets to visualize the data, including face and vehicle detection alarm, access control, alarm linkage, E-map etc.
Users are able to select the modules that they need, and organize the dashboard items into functional views that suit their business
needs in just 3 steps.

It can be applied to various scenarios including:

... ...

Casino Hotel Community Retail Office Building Bank More

Features:
• People Counting & Heat Map For Customer Flow Analysis
• Restricted Area Control
• VIP Customer Identification
• Early Warning Unwelcome Guest
• Access Control Integrated With Iiveness Detection Technology
• ANPR For Entrance & Exit
• Human Silhouette Detection And Facial Recognition
• Embedded Time-attendance Management

- 35 -

Intelligent and Recognitive Solutions

Falcon Human Recognition System

EPAS8000 KEDACOM FALCON Human Recognition System is a software capable to seize human live images of head-shoulder,
entire body separately, and build up an object related database. The system recognizes human faces at real-time, tells sex gender,
age range and even ethnic groups, and distinguishes colors and textures of people' s wearing. It also provides historical search
about certain people and faces. The system can be applied to human flow control mainly on major roads, public crowded area in
air and sea ports, transport interchanges where human-filtering request is strictly imposed by public security.

Functions
• Live Snapshot Analysis
• Static Enter-Bank-Pictures Comparison
• Dynamic Search
• Dynamic Arming
• Follow Tagged People

Live Snapshot Analysis
The camera captures human head-shoulder and whole-body picturesat front-end while the FALCON server stores the live pictures at back-end.
Saving bandwidth and resources, the back-end server analyzes attributes of human in pictures sent by front-end cameras, including sex, age
group, nationality, with or without glasses and gauze mask, colors of tops and bottoms, texture of tops, front or back side of human and etc.

- 36 -

Intelligent and Recognitive Solutions
Static Enter-Bank-Pictures Comparison
The system supports 3 kinds of searching picture by picture, front human face snapshot, ID card picture and front selfie by cellphone;
supports adding, deleting, editing and viewing human face and human banks; supports single and batch pictures entering bank;
supports adding info to single and batch enter-bank-pictures and supports viewing, editing and removing info of registered pictures.

Dynamic Search
The system supports searching pictures by durations or camera positions, by personal attributes, by human pictures of head-shoulder
or whole-body, and by any combination of the above-mentioned methods. The searched pictures can be linked to the snapshot
site and personal attributes, to multiple snapshots or panoramic pictures of the site, and to video records at the site. Moreover, the
searched pictures can be set to arm, to tag or to search pictures instantly.

- 37 -

Intelligent and Recognitive Solutions
Dynamic Arming
Dynamic arming supports blacklist or whitelist alarming, independent arming of multiple lists simultaneously, authorization
assignment on the lists, live or preset arming, one-click arming on mobile client and batch disarming over live alarm notifications.
The system supports searching alarms by durations and camera sites, by alarm levels and types, by alarm treatment and checking
status, and by any combination of the above-mentioned methods. The search result can be viewed according to similarity level and
be linked to the snapshot site, to top 10 suspects and the arming info, and to the details on the arming list.

Follow Tagged People
The system supports tagging people with Key, Suspect and Follow according to your concern extent so as to facilitate filtering
followed targets; supports viewing and searching tagged personnel by groups; and supports authorization assignment of tagging
to different accounts.

- 38 -

Intelligent and Recognitive Solutions

Small and medium-sized Recognitive Solutions

Recognitive Tracking System, Recognitive Camera and Human Recognitive Camera can be directly connected to Kedacom professional
NVR. The professional NVR can gain and record the video, snapshot and target characteristics from the recognitive camera. By the
recognitive smart search functions of NVR station software, you can easily search any targets by snapshots or characteristics.

Recognitive Smart Search function in NVR Station.

Searching the recording by snapshot, filtered by color, direction and type.

Integration into Third party System
Recognitive Camera

Recognitive Tracking System, Recognitive Camera and Human Recognitive can support ONVIF and provide SDK. All the recognitive
cameras can easily access to third party NVR and VMS system.

Recognitive Tracking System Recognitive Camera Human Recognitive Camera Third party NVR/VMS

Recognitive NVR

Standard ONVIF-compliant camera can be directly accessed by the Recognitive NVR, the latter's SDK is also available to third party
CMS / VMS system integrators.

Onvif SDK

Recognitive NVR Third party CMS/VMS

- 39 -

Scan the QR Code to
Find Video Demos

- 40 -

- 41 -

Website Facebook China (Headquarters) Shenzhen Korea EN-500132-20190926-013

www.kedacom.com 131, Jinshan Road, New District, Room 1709 Building 3. Tianxia. #1802 Daeryung Techno 15th, 401 Simindaero,
- 42 - Suzhou 215011, P.R.China feicuimingzhu, Jinji Road, Nanshan Dongan-Gu, Gyunggi-Do, Korea 431062.
Tel: (86) 512 6841 8188 district,Shenzhen, China. 518000 Tel: (82) 31 386 3140
Email: [email protected] Tel: (86) 138 2886 0464 Email: [email protected]
Email: [email protected]
Singapore Turkey
Netherlands
(International Headquarters) Merkez: Beşyol Mah. Cami Sok.
Groenhof 344, Amstelveen, 1186GK, No:14 K.Çekmece / İstanbul
627A Aljunied Road, BizTech Centre, #09- The Netherlands. Tel: 0(212) 220 55 50 (Dahili:103)
07, Singapore 389842. Tel: (31) 020 640 1114 Email: [email protected]
Tel: (65) 6842 5700 Email: [email protected]
Email: [email protected]
