ROTOGRAVURE SLEEVES AND RUBBER IMPRESSION (NIP) ROLLERS

ZENPRESS-P - 45-95 ShA Water/Alcohol

Special elastomer for coating rubber impression rollers in rotogravure
printing in presence of water or alcohol based inks. The fiber glass
conductive sleeve and the special compound make the product
antistatic.

45 95 40 140oC Antistatic Food contact
sleeve certified
SHORE A Kg/cm Max temp
140oC
Hardness Max load
range 45-95 40 [Kg/cm]

ZENPRESS-N - 60-95 ShA Water/Alcohol

Special elastomer for coating rubber impression rollers with aliphatic
solvents based inks and high printing pressure (up to 50 [kg/cm]) on
paper, cardboard, laminated substrates and aluminium; highly
resistant to edge cuts.

60 95 50 120oC Antistatic Food contact
sleeve certified
SHORE A Kg/cm Max temp
120oC
Hardness Max load
range 60-95 50 [Kg/cm]

ESA PRINTING

ZENPRESS ESA ORANGE - 75-90 ShA High Temp.

Elastomer designed for printing impression rollers with electrostatic
assist (ESA) for printing on plastic film and paper. ESA Orange
eliminates ionization effect typical of traditional black rubber
compounds with carbon black. The volumetric resistance, dynamic
resistance and insulation values of ESA Orange comply with the
electrostatic assist system installed on the printing press and the type
of application.

ESA 75 90 15 150oC Food contact
certified
E.S.A. SHORE A Max load Max tmp
System 15 [Kg/cm] 150oC
Hardness
range 75-90

ZENPRESS ESA GREEN - 80-90 ShA Water/Alcohol

Technopolymer designed to coat impression rollers for ESA printing on
paper and cardboard with higher printing loads and high resistance to
the abrasion with water, alcohol o acetate max 30% based inks.
Cleaning with gasoline or with a blend of 80% Ethyl alcohol and 20%
ethyl Acetate

ESA 80 90 50 90oC Food contact
certified
E.S.A. SHORE A Max load Max tmp
System 50 [Kg/cm] 90oC
Hardness
range 80-90

SOLVENT LESS LAMINATION ROLLER

We designed SL series specially for Solvent less Lamination Rubber Rollers for Rotogravure
flexible packaging industry. Our solvent less rubber rollers are designed and manufactured
under the supervision and strict quality measures. High-grade raw materials and
advanced manufacturing practices ensure the premier quality of the product.

QUALITY FEATURES

v Extraordinary performance.
v Abrasion resistance
v Highly solvent resistance.
v Excellent bonding with shell.
v Suitable for all machine speeds.
v Heat resistant capability
v Have good strength, stability and uniformity.

We are manufactured our solvent less transfer as well as nip rollers to most of solvent less
machines like Kohali , Bobst , Raulimax , Nordmeccanica ,Pelican and many more.

Product Specification
Hardness- 75°-90° Shore A
Concentricity-≤0.03 to ≤0.05
O D - ±0.03 to ±0.05
Length: - ±0.03±0.05
